U-Line Nugget Manuel utilisateur

QUICK START GUIDE

Nugget Ice Machine • ADA, 1 & 3 Class

30635 Rev_A

QUICK START GUIDE u-line.com

WELCOME TO U-LINE



ice making, refrigeration, and wine preservation experience. U-Line continues to be the American leader, delivering versatility



product collection includes Wine Captain®Models, Beverage Centers, Clear Ice Machines, Nugget Ice Machines, Crescent Ice

Makers, Glass & Solid Door Refrigerators, Drawer Models, Freezers, Combo®Models, and more.



and attention to even the smallest details. We are known and respected for our unwavering dedication to product design,



two decades and is proud to have the opportunity to ship to you.

PRODUCT INFORMATION

Looking for additional information on your product? User Guides, Spec Sheets, CAD Drawings, Compliance Documentation,

and Product Warranty information are all available for reference and download at u-line.com.

PROPERTY DAMAGE / INJURY CONCERNS

In the unlikely event property damage or personal injury is suspected related to a U-Line product, please take the following

steps:

1. U-Line Customer Care must be contacted immediately at +1.800.779.2547.

2. Service or repairs performed on the unit without prior written approval from U-Line is not permitted. If the unit has been



GENERAL INQUIRIES

U-Line Corporation

8900 N. 55th Street

Milwaukee, Wisconsin 53223 USA

Monday - Friday 8:00 am to 4:30 pm CST

T: +1.414.354.0300

F: +1.414.354.7905

Email: sales@u-line.com

u-line.com

SERVICE & PARTS ASSISTANCE

Monday - Friday 8:00 am to 4:30 pm CST

T: +1.800.779.2547

F: +1.414.354.5696

Service Email: onlineservice@u-line.com

Parts Email: onlineparts@u-line.com

CONNECT WITH US

Designed, engineered and assembled in WI, USA

QUICK START GUIDE u-line.com

This Quick Start Guide covers the basics of installation and general use of your product.

For more details, see the complete User Guide & Service Manual on u-line.com.

This product is eligible for an additional one-year warranty at no charge when you register your product on u-line.com.

See complete warranty for details.

CONTENTS

Safety and Warning 4

Environmental Requirements 5

Electrical 5

Water Hookup 6

Drain 8

Door Swing 9

Door Adjustments 10

General Installation 13

Integrated Panel Installation 14

Control Operation 15

First Use 17

     

Cleaning 17

Warranty 19

1 year + 1 with registration*

QUICK START GUIDE u-line.com

Safety and Warning

NOTICE

Please read all instructions before installing,

operating, or servicing the appliance.

Use this appliance for its intended purpose only and follow

these general precautions with those listed throughout this

guide:

SAFETY ALERT DEFINITIONS

Throughout this guide are safety items labeled with a

Danger, Warning, or Caution based on the risk type:

Danger means that failure to follow this safety

statement will result in severe personal injury or

death.

Warning means that failure to follow this safety

statement could result in serious personal injury

or death.

Caution means that failure to follow this safety

statement may result in minor or moderate

personal injury, property, or equipment damage.

This unit contains R600a (Isobutane) which is a

ammable hydrocarbon. It is safe for regular

use. Do not use sharp objects to expedite

defrosting. Do not service without consulting the

“R600a specications” section included in the

User Guide. Do not damage the refrigerant

circuit.

Service must be done by factory authorized

service personnel. Any parts shall be replaced

with like components. Failure to comply could

increase the risk of possible ignition due to

incorrect parts or improper service.

CALIFORNIA PROPOSITION 65

This product contains chemicals known to the

state of California to cause cancer and birth

defects or other reproductive harm.

www.P65warnings.CA.gov

DANGER

WARNING

CAUTION

WARNING

QUICK START GUIDE u-line.com

Environmental Requirements

This model is intended for indoor/interior applications only

and is not to be used in installations that are open/

exposed to natural elements.

This unit is designed to operate between 50°F (10°C) and

100°F (38°C). Higher ambient temperatures may reduce



ice production on applicable models.

For best performance, keep the unit out of direct sunlight

and away from heat generating equipment.

In climates where high humidity and dew points are

present, condensation may appear on outside surfaces.

This is considered normal. The condensation will

evaporate when the humidity drops.

Damages caused by ambient temperatures of

40°F (4°C) or below are not covered by the

warranty.

Electrical

SHOCK HAZARD — Electrical Grounding

Required. Never attempt to repair or perform

maintenance on the unit until the electricity has

been disconnected.

Never remove the round grounding prong from

the plug and never use a two-prong grounding

adapter.

Altering, cutting or removing power cord,

removing power plug, or direct wiring can cause

serious injury, re, loss of property and/or life,

and will void the warranty.

Never use an extension cord to connect power to

the unit.

Always keep your working area dry.

NOTICE

Electrical installation must observe all state and

local codes. This unit requires connection to a

grounded (three-prong), polarized receptacle

that has been placed by a qualied electrician.

The unit requires a grounded and polarized 115 VAC,

60 Hz, 15A power supply (normal household current). An

individual, properly grounded branch circuit or circuit

breaker is recommended. A GFCI (ground fault circuit



appliances and is not recommended for your unit because

it could be prone to nuisance tripping. However, be sure

to consult your local codes.

CAUTION

QUICK START GUIDE u-line.com

QUICK START GUIDE

u-line.com

Water Hookup

PREPARE PLUMBING

The water valve uses a standard 1/4" (6.35

mm)

compression fitting. U-Line recommends using accessory

water hook up kit – part # 80-54674-00. The kit includes a

10' (3 m) braided flexible water supply line and a brass

hose fitting.

CAUTION

Plumbing installation must observe all state and

local codes. All water and drain connections

MUST BE made by a licensed/qualified plumbing

contractor. Failure to follow recommendations

and instructions may result in damage and/or

harm.

Water Supply Connection

When connecting the water supply, please note the

following:

•

Before installing the unit and connecting to the cold

water supply, review the local plumbing codes.

•

The water pressure should be between 20 and 120 psi

(138 and 827 kPa).

•

The water line MUST have a shut-off valve in the

supply line.

•

The water line should be looped into 2 coils. This will

allow the unit to be removed for cleaning and servicing.

Make certain that the tubing is not pinched or damaged

during installation.

WARNING

Connect to potable water supply only.

CAUTION

Do not use any plastic water supply line. The line

is under pressure at all times. Plastic may crack

or rupture with age and cause damage to your

home.

Do not use tape or joint compound when

attaching a braided flexible water supply line

that includes a rubber gasket. The gasket

provides an adequate seal – other materials

could cause blockage of the valve.

Failure to follow recommendations and

instructions may result in damage and/or harm,

flooding or void the product warranty.

Use new hose set. Do not reuse old hose set.

CAUTION

Turn off water supply and disconnect electrical

supply to unit prior to installation.

Use caution when handling back panel. The

edges could be sharp..

1. Remove the back panel.Turn off water supply and

disconnect electrical supply to product prior to

attempting installation.

2. Remove the back panel.

QUICK START GUIDE u-line.com

QUICK START GUIDE

u-line.com

3. Thread water line through back panel hole (with

bushing).

4. Locate water valve inlet and connect to valve.

5. Turn on water supply and check for leaks.

6. Reinstall back panel.

QUICK START GUIDE u-line.com

QUICK START GUIDE

u-line.com

Drain

Model numbers including “CL” or “NB” do not include a

factory installed drain pump.

Model numbers including “CP” or “NP” include a factory

installed drain pump.

DRAIN CONNECTION

CAUTION

If your U-Line unit did not come with a factory

installed drain pump you must use a gravity

style drain connection. For assistance in

determining if your unit has a pump please

contact U-Line. The floor drain must be large

enough to accommodate drainage from all

attached drains. Follow these guidelines when

installing drain lines to prevent water from

flowing back into the ice maker storage bin and/

or potentially flowing onto the floor, which may

result in personal injury or property damage.

Drain can NOT be located directly below the unit.

Unit has a solid base that will not allow the unit

to drain below itself.

There is a possibility that hose connections may

have loosened during shipment.

Verify all connections and fittings are free from

leaks.

GRAVITY DRAIN

A gravity drain may be used if:

Drain line has at least a 1" drop per 48" (approximately

2cm drop per 100 cm) of run.

Drain line does not create traps and is vented per local

code.

1. Cut the pre-installed drain tube to length.

2. Connect to your local plumbing per the local code.

3. If necessary, insulate drain line to prevent

condensation.

CAUTION

Failure to connect water supply or drain line

connections properly can result in personal

injury and property damage. Gravity drain

connections must be routed downward from the

rest of the unit at the rate of 1/4" per foot (1 cm

per 50 cm).

Normal

Proper Drain

With Trap

Poor Drainage, Water Will Back Up

With Trap and Vent

Proper Drain

QUICK START GUIDE u-line.com

QUICK START GUIDE

u-line.com

FACTORY INSTALLED DRAIN PUMP

If your drain line will run up to a stand pipe, disposal or

spigot assembly, or does not otherwise meet the

requirements for a gravity drain, you may have ordered a

pre-installed U-Line P60 drain pump.

If you need to install a P60 drain pump into your unit, see

DRAIN PUMP section in the User Manual.

See below for typical installations requiring a drain pump.

The maximum lift for the P60 drain pump is

10 feet. This must be done as close to the rear of

the unit as possible.

Door Swing

1/2" (13 mm) clearance is recommended from wall on

hinge side to allow the door to open 90°. Allow for

additional space for any knobs or pulls installed on the

integrated panel/frame.

Stainless Steel models that are installed adjacent to a wall

require 2-1/4" (57 mm) door clearance on hinge side to

allow for door handle.

Units have a zero clearance when installed adjacent to

cabinets.

Cold

Water

Hot

Water

Waste

6KXW2ɞ

Valve

Stand Pipe

P60 Pump Required

Air Gap

(Optional Hook-Up)

Cold

Water

Hot

Water

Waste

6KXW2ɞ

Valve

Disposal Assembly

P60 Pump Required

Waste

Cold

Water

6KXW2ɞ

Valve

Hot

Water

Air Gap

(Optional Hook-Up)

Y-Branch Tailpiece

P60 Pump Required

Wall Wall

90°

Door Swing

90°

Door Swing

Space Required

For any Knobs or Pulls

2-1/4" MIN

(57 mm MIN)

Integrated Stainless

1/2" (13 mm)

QUICK START GUIDE u-line.com

QUICK START GUIDE

u-line.com

Door Adjustments

1 CLASS AND 3 CLASS

DOOR ALIGNMENT AND ADJUSTMENT

Align and adjust the door if it is not level or is not sealing

properly. If the door is not sealed, the unit may not cool

properly, or excessive frost or condensation may form in

the interior.

Properly aligned, the door’s gasket should be

firmly in contact with the cabinet all the way

around the door (no gaps). Carefully examine

the door’s gasket to ensure that it is firmly in

contact with the cabinet. Also make sure the

door gasket is not pinched on the hinge side of

the door.

CAUTION

Do not attempt to use the door to raise or pivot

your unit. This would put excessive stress on the

hinge system.

Alignment and Adjustment Procedure

Open door and remove gasket near the hinges.

Using a T-25 Torx Bit, loosen each pair of Torx head

screws on both the upper and lower hinge plates.

Square and align

door as necessary.

Tighten Torx head

screws on hinge.

Reinstall gasket into

the channel starting

at the corner.

REVERSING THE DOOR

1. Open door.

Using T-25 Torx bit loosen screw #1 and remove screw

#2 on top and bottom hinge. Slide and remove the

door from unit. Completely remove screw #1 on top

and bottom.

Remove caps from screw heads on opposite side (2 on

top and 2 on bottom). Using #2 Phillips bit remove the

4 underlying screws. Reinstall the screws and caps on

the opposite side.

Note: One hinge includes a metal spacer. Spacer

must be used with that hinge when reversing the

door.

Partially install screw #1 in the outer most holes on top

and bottom. Rotate door 180°, align hinge over screw

#1 and slide/seat into position. Reinstall screw #2 on

top and bottom. Tighten both screws and install hinge

cover.

Align and adjust the door:

Align and adjust the door (see DOOR ALIGNMENT AND

ADJUSTMENT).

T-25 Torx Screw

Table des matières

Autres manuels U-Line Machine à glaçons

U-Line

U-Line UACR014-BS01A Manuel d'installation

U-Line

U-Line ADA UACR014 Manuel d'installation

U-Line

U-Line UMCR114-SC01A Manuel d'installation

U-Line

U-Line 3000 SERIES Manuel d'installation

U-Line

U-Line ULN-SS98NF-03A Manuel d'installation

U-Line

U-Line 3000 SERIES Manuel d'installation

U-Line

U-Line Outdoor Series Manuel utilisateur

U-Line

U-Line ADA151M Guide de configuration

U-Line

U-Line UACR015-S01A Manuel d'installation

U-Line

U-Line BCM-95 Manuel utilisateur

U-Line

U-Line Origins BI-95 Manuel utilisateur

U-Line

U-Line WH95TP Manuel utilisateur

U-Line

U-Line CLRCO2075 Manuel utilisateur

U-Line

U-Line CLR1215 Manuel d'installation

U-Line

U-Line Echelon BI-2115 Manuel utilisateur

U-Line

U-Line Echelon BI 2015 Manuel utilisateur

U-Line

U-Line UACR014-BS01A Manuel d'installation

U-Line

U-Line Marine Series WH95FC Manuel utilisateur

U-Line

U-Line CLR1215 Manuel utilisateur

U-Line

U-Line Origins CO1175AS Manuel utilisateur

U-Line

U-Line ULN-CO29B-20A2 Manuel utilisateur

U-Line

U-Line UMCR015-SS01A Manuel d'installation

U-Line

U-Line SP Manuel utilisateur

U-Line

U-Line 95 Icemaker Instructions de construction

Manuels Machine à glaçons populaires d'autres marques

Hoshizaki

Hoshizaki KMD-460MWJ Manuel utilisateur

Sub-Zero

Sub-Zero 315I Instructions d'utilisation

Unold

Unold 48945 Manuel utilisateur

Kenmore

Kenmore 2217402A Manuel utilisateur

Cornelius

Cornelius WM600 Mode d'emploi

GE XPIO43SCSS Manuel utilisateur

Hoshizaki

Hoshizaki KMD-901MAH Manuel utilisateur

Whynter

Whynter FIM-450HA Manuel utilisateur

Andrew James

Andrew James AJ000522 Manuel utilisateur

Scotsman

Scotsman CME1356 Manuel utilisateur

Scotsman

Scotsman ACM 25 Manuel utilisateur

Kärcher

Kärcher IP 120 Manuel utilisateur

Maytag

Maytag MIM1554WRS - Ice Maker Manuel utilisateur

Hoshizaki

Hoshizaki KM-630MAH Manuel utilisateur

Princess

Princess Yonanas Manuel utilisateur

Unold

Unold 48946 Manuel utilisateur

Electrolux

Electrolux E15IM60GP Manuel utilisateur

Cornelius

Cornelius UC150 ICE ONLY Manuel utilisateur
