TYAN GT24

B5501

Service Engineer’s Manual

http://www.tyan.com

PREFACE

This publication, including all photographs, illustrations, and software, is

Neither this manual, nor any material contained herein, may be reproduced

without written consent of manufacturer.

TYAN®is a registered trademark of MiTAC International Corporation.

Version 1.00

Disclaimer

Information contained in this document is furnished by MiTAC International

Corporation and has been reviewed for accuracy and reliability prior to

printing. MiTAC assumes no liability whatsoever, and disclaims any

express or implied warranty, relating to sale and/or use of TYAN®products

including liability or warranties relating to fitness for a particular purpose or

merchantability. MiTAC retains the right to make changes to produce

descriptions and/or specifications at any time, without notice. In no event

will MiTAC be held liable for any direct or indirect, incidental or

consequential damage, loss of use, loss of data or other malady resulting

from errors or inaccuracies of information contained in this document.

Trademark Recognition

All registered and unregistered trademarks and company names

contained in this manual are property of their respective owners including,

but not limited to the following.

TYAN®is a trademark of MiTAC International Corporation.

Intel®is a trademark of Intel®Corporation.

AMI®, AMIBIOS® and combinations thereof are trademarks of AMI

Technologies.

Microsoft®, Windows®are trademarks of Microsoft Corporation.

IBM®, PC®, AT®and PS/2®are trademarks of IBM Corporation.

Winbond®is a trademark of Winbond Electronics Corporation.

http://www.tyan.com

Federal Communication Commission (FCC)

Notice for the USA

Compliance Information Statement (Declaration of

Conformity Procedure) DoC FCC Part 15: This

device complies with part 15 of the FCC Rules

Operation is subject to the following conditions:

1) This device may not cause harmful interference;

2) This device must accept any interference received including

interference that may cause undesired operation. If this equipment

does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the

user is encouraged to try one or more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and the receiver.

– Plug the equipment into an outlet on a circuit different from that of

the receiver.

Consult the dealer on an experienced radio/television technician for

help.

Notice for Canada

This apparatus complies with the Class A limits for radio interference as

specified in the Canadian Department of Communications Radio

Interference Regulations. (Cet appareil est conforme aux norms de

Classe A d’interference radio tel que specifie par le Ministere Canadien

des Communications dans les reglements d’ineteference radio.)

Notice for Europe (CE Mark)

This product is in conformity with the Council

Directive 89/336/EEC, 92/31/EEC (EMC).

CAUTION: Lithium battery included with this board. Do not puncture,

mutilate, or dispose of battery in fire. There will be danger of explosion if

battery is incorrectly replaced. Replace only with the same or equivalent

type recommended by manufacturer. Dispose of used battery according

to manufacturer instructions and in accordance with your local regulatio-

-ns.

http://www.tyan.com

About this Manual

This manual provides you with instructions on installing your TYAN

GT24-B5501. This Manual is intended for experienced users and

integrators with hardware knowledge of personal computers.

This manual consists of the following parts:

Chapter1: Provides an introduction to the TYAN GT24-B5501

barebones, standard parts list, describes the external

components, gives a table of key components, and

provides block diagram of the system.

Chapter2: Covers procedures on installing the CPU, memory

modules and hard drives.

Chapter3: Covers removal and replacement procedures for

pre-installed components.

Appendix: List the cable connection and FRU part tables for

reference of system setup, and technical support in

case a problem arises with your system.

For information on the motherboard, please refer to the

attached motherboard user’s manual. You can find the detailed

description about jumper and BIOS settings from the

motherboard manual.

http://www.tyan.com

SAFETY INFORMATION

Before installing and using TYAN GT24-B5501, take note of the following

precautions:

·Read all instructions carefully.

·Do not place the unit on an unstable surface, cart, or stand.

·Do not block the slots and opening on the unit, which are provided for

ventilation.

·Only use the power source indicated on the marking label. If you are not

sure, contact the power company.

·The unit uses a three-wire ground cable, which is equipped with a third

pin to ground the unit and prevent electric shock. Do not defeat the

purpose of this pin. If you outlet does not support this kind of plug,

contact your electrician to replace your obsolete outlet.

·Do not place anything on the power cord. Place the power cord where it

will not be in the way of foot traffic.

·Follow all warnings and cautions in this manual and on the unit case.

·Do not push objects in the ventilation slots as they may touch high

voltage components and result in shock and damage to the

components.

·When replacing parts, ensure that you use parts specified by the

manufacturer.

·When service or repairs have been done, perform routine safety checks

to verify that the system is operating correctly.

·Avoid using the system near water, in direct sunlight, or near a heating

device.

·Cover the unit when not in use.

http://www.tyan.com

Table of Contents

Chapter 1: Overview.........................................................................9

1.1 About the TYAN GT24-B5501 .................................................. 9

1.2 Product Models......................................................................... 9

1.3 Features.................................................................................. 10

1.4 Standard Parts List ................................................................. 14

1.4.1 Box Contents ................................................................... 14

1.4.2 Accessories ..................................................................... 15

1.5 About the Product................................................................... 16

1.5.1 System Front View........................................................... 16

1.5.2 System Rear View ........................................................... 16

1.5.3 LED Definitions ................................................................ 17

1.5.4 Motherboard (S5501) Layout........................................... 19

1.5.5 Jumpers & Connectors .................................................... 20

1.5.6 System Block Diagram .................................................... 21

1.5.7 Internal View .................................................................... 22

Chapter 2: Setting Up..................................................................... 23

2.0.1 Before you Begin ............................................................. 23

2.0.2 Work Area........................................................................ 23

2.0.3 Tools ................................................................................ 23

2.0.4 Precautions...................................................................... 24

2.1 Installing Motherboard Components....................................... 25

2.1.1 Removing the Chassis Cover .......................................... 25

2.1.2 Installing the CPU and Heatsink...................................... 26

2.1.3 Installing the Memory....................................................... 29

2.1.4 Installing Hard Drives....................................................... 32

2.1.5 Installing the PCI-E Cards ............................................... 34

2.2 Rack Mounting........................................................................ 36

2.2.1 Installing the Server in a Rack......................................... 36

http://www.tyan.com

2.2.2 Installing the inner Rails to the Chassis........................... 37

2.2.3 Installing the Outer Rails to the Rack .............................. 38

2.2.4 Rack mounting the Server ............................................... 40

Chapter 3: Replacing Pre-Installed Components ........................ 43

3.1 Introduction ............................................................................. 43

3.2 Disassembly Flowchart........................................................... 43

3.3 Removing the Cover ............................................................... 45

3.4 Replacing Motherboard Components..................................... 45

3.4.1 Replacing Expansion Card .............................................. 45

3.4.2 Disconnecting All Motherboard Cables ........................... 47

3.4.3 Removing the Motherboard ............................................. 49

3.5 Replacing the LED Control Board .......................................... 50

3.5.1 M1008 LED Control Board Features ............................... 52

3.5.2 M1008 LED Control Board Connector Pin Definition ...... 52

3.6 Replacing the System Fan ..................................................... 53

3.7 Replacing the M1232 HDD Backplane ................................... 56

3.7.1 M1232 HDD Backplane Features.................................... 58

3.7.2 M1232 HDD Backplane Connector Pin Definitions ......... 60

Appendix I: Cable Connection Tables ..........................................65

Appendix II: FRU Parts Table ........................................................ 67

Appendix III: Technical Support....................................................69

http://www.tyan.com

Chapter 1: Overview

1.1 About the TYAN GT24-B5501

Congratulations on your purchase of the TYAN®GT24-B5501, a highly

optimized rack-mountable barebone system. GT24-B5501 is designed to

support one Intel® Xeon processor 3400 Series and up to 32GB RDIMM or

16GB UDIMM DDR3-800/1066/1333 memory, providing a rich feature set

and incredible performance. Leveraging advanced technology from Intel®,

GT24-B5501 server system is capable of offering scalable 32 and 64-bit

computing, high bandwidth memory design, and lightning-fast PCI-E bus

implementtation.GT24-B5501 not only empowers your company in

nowadays IT demand but also offers a smooth path for future application

usage.

TYAN®is also proud to deliver GT24-B5501 in flavor while supporting up to

four hot-swap hard drives. GT24-B5501 uses TYAN®’s latest chassis

featuring a robust structure and a solid mechanical enclosure. All of this

provides GT24-B5501 the power and flexibility to meet the needs of

nowadays server application.

1.2 Product Models

Model HDD Bays Power supply

B5501G24V4H Hot-swap, 4 HDDs 400 Watts single

http://www.tyan.com

1.3 Features

TYAN GT24B5501 (B5501G24V4H)

Form Factor 1U Rackmount

Chassis Model GT24

Dimension (D x W x

25.4" x 17.2" x 1.72" (645 x 436 x 43.6mm)

Motherboard S5501GM3NR

Board Dimension EATX, 12"x13" (305x330mm)

System

Gross Weight 16 kg

Buttons (1) RST / (1) NMI / (1) ID / (1) PWR w/ LED

LEDs (1) ID / (1) Warning / (3) LAN / (1) Reserved

Front Panel

I/O Ports (2) USB ports

Type / Q'ty 3.5" Hot-Swap / (4)

External Drive

Bay Supported HDD

Interface

SATA-II 3.0Gb/s

System Cooling

Configuration

FAN (4) 4cm fans

Type EPS1U

Input Range Full-range AC(100-240V)

Frequency 47 - 63 Hertz

Output Watts 400 Watts

Power Supply

Efficiency PFC

Supported CPU

Series

Intel Xeon Processors 3400 Series

Processor

Socket Type / Q'ty LGA 1156/ (1)

Table des matières

Autres manuels TYAN Serveur

TYAN

TYAN B8236G70W8HR-HE-IL Manuel utilisateur

TYAN

TYAN Transport GX28 B2882 Manuel utilisateur

TYAN

TYAN TN70A-B8026 Guide de démarrage rapide

TYAN

TYAN B8028Y190X2 Guide de démarrage rapide

TYAN

TYAN GC68-B7126 Guide de démarrage rapide

TYAN

TYAN Transport GT20 B3970-U Guide de démarrage rapide

TYAN

TYAN FT77CB7079 Guide de démarrage rapide

TYAN

TYAN TA77-B7061 Guide de démarrage rapide

TYAN

TYAN GT24 B8212 Manuel utilisateur

TYAN

TYAN Transport TA26 B2882 Manuel utilisateur

TYAN

TYAN FT83A-B7129 Guide de démarrage rapide

TYAN

TYAN MicroServer Series Manuel utilisateur

TYAN

TYAN Tank GT25 (B5381) Guide de démarrage rapide

TYAN

TYAN Tank FT48 B5382 Manuel utilisateur

TYAN

TYAN GT24-B7066 Guide de démarrage rapide

TYAN

TYAN Tank GT14 B5180 Manuel utilisateur

TYAN

TYAN YR188-B537M Manuel utilisateur

TYAN

TYAN GT75B-B7102 Guide de démarrage rapide

TYAN

TYAN FT48A-B7070 Guide de démarrage rapide

TYAN

TYAN Tank GT24 B5383 Manuel utilisateur

TYAN

TYAN Transport GT20 B3870 Manuel utilisateur

TYAN

TYAN Transport GT20 Manuel utilisateur

TYAN

TYAN Tank GT20 B5372 Manuel utilisateur

TYAN

TYAN FT48B-B7100 Guide de démarrage rapide

Manuels Serveur populaires d'autres marques

HP AlphaServer ES47 Manuel utilisateur

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

HP ProLiant Gen9 Manuel utilisateur

Compaq

Compaq ProLiant 3000 Manuel

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

HP Integrity rx2600 Guide d'installation

Milestone

Milestone Husky IVO 350T Manuel utilisateur
