TW Audio SYSRACK-TGX Manuel utilisateur

SYSRACK-TGX

Operation manual

Operation manual SYSRACK-TGX

Introduction

The SYSRACK-TGX, developed by TWAUDiO, includes a Dynacord TGX10 power ampliﬁer

as well as the new LED illuminated APL7 TGX connection panel, all combined in the new

Rack4TGX.

TGX 4-channel live sound ampliﬁers from Dynacord are one of the most powerful on the

market and represent the pinnacle of pro audio electronics engineering. Along with unprece-

dented power density, they offer Dynacord’s signature audio quality, advanced reliability and

power efﬁciency.

The APL7 connector panel provides all of the ampliﬁer‘s connections at the front of the

SYSRACK-TGX. The integrated and switchable LED strip ensures a clear overview of the

panel even in difﬁcult lighting conditions.

The panel layout follows the logical signal ﬂow through the ampliﬁer with a power, network,

audio input and output section. The two network ports provide the ability to use the ampliﬁer

in a fully redundant network conﬁguration supporting the latest standards in audio-over-IP

protocols with the OMNEO IP interface for Dante® and AES70.

The panel features the TGX series‘ ability to buffer digital audio signals when multiple ampli-

ﬁers are connected in parallel. The AES/EBU input signal is latency-free processed via an

active circuit in the ampliﬁer.

Instructions in this user manual

WARNING

Thank you for choosing a high-quality product “MADE IN GERMANY” from the brand

TW AUDiO.

If you lend your product to another party, inform that party of the safety-related operating pro-

cedures and hand over this assembly guide. If you require additional copies of this manual,

you can obtain them free of charge from TWAUDiO or download them from www.twaudio.de

Strictly adhere to the instructions contained in this operating manual that are marked as

follows:

This symbol in combination with the signal word “Warning” identiﬁes a potentially hazardous

situation. Failure to comply with this safety instruction can lead to serious injury or even death.

This symbol in combination with the signal word “Warning” identiﬁes a potentially hazardous

situation for persons with a pacemaker. Failure to comply with this safety instruction can lead

to serious injury or even death.

Operation manual SYSRACK-TGX

TIP

Read manual

before use!

Operation manual: OM-SYSRACK-TGX

Version 2.0 en, 10/2023

CAUTION

NOTE

This symbol in combination with the signal word “Caution” identiﬁes a potentially hazardous

situation. Failure to comply with this safety instruction can lead to light or moderate injury.

This symbol in combination with the signal word “Note” identiﬁes a potentially hazardous

situation. Failure to comply with this safety instruction can lead to product damage.

This symbol in combination with the signal word “Tip” identiﬁes additional information or

notes that will simplify working with TWAUDiO products on the basis of practical experience.

Notes on the products

Before using the device, carefully read the operating manual and keep it with the

SYSRACK-TGX.

General information

All information contained in this operating manual was correct to the best of our knowledge

at the time of printing.

Quality warranties or assurance of suitability for a certain type of use based on the technical

speciﬁcations, dimensions and weights are not granted by TWAMBO.

TWAMBO also shall not assume liability for any secondary damage (property damage and/or

personal injury) nor for the failure to comply with this operating manual!

TWAMBO reserves the right to update this document based on recent developments.

TWAMBO GmbH

Karl-Hofer-Str. 42

14163 Berlin

Germany

Phone : + 49 (0) 71 41-48 89 89 0

Fax: + 49 (0) 71 41-48 89 89 99

E-Mail: [email protected]

WWW: www.twaudio.de

Operation manual SYSRACK-TGX

Content

1. Safety | Intended use...................................................................................................... 5

2. Overview ........................................................................................................................ 7

2.1 Components ........................................................................................................... 7

3. Technical specifications .................................................................................................. 8

3.1 SYSRACK-TGX ....................................................................................................... 8

3.2 Dynacord TGX power amplifier ................................................................................ 8

3.3 APL7 connection panel............................................................................................ 9

4. Commissioning............................................................................................................. 10

4.1 Setup .................................................................................................................... 10

4.2 Handling................................................................................................................ 10

4.3 Installation ............................................................................................................. 12

4.4 Transport............................................................................................................... 13

4.5 Service and maintenance ...................................................................................... 14

4.6 Internal wiring ........................................................................................................ 14

4.7 Mains voltage ........................................................................................................ 15

4.8 Network ................................................................................................................ 16

4.9 Audio inputs .......................................................................................................... 19

4.10 Power outputs..................................................................................................... 22

4.11 LED-lighting......................................................................................................... 22

5. Transport and Storage.................................................................................................. 23

6. CE Conformity Declaration............................................................................................ 24

7. Disposal ....................................................................................................................... 25

Operation manual SYSRACK-TGX

1. Safety | Intended use

The SYSRACK-TGX is developed for use in professional sound systems. The SYSRACK-TGX

may only be used by trained and qualiﬁed personnel.

This operating manual describes the intended use of the SYSRACK-TGX. Any other use is

not as intended and may result in damage or even injury.

Modiﬁcations on the SYSRACK-TGX are not permitted! There is danger to life! Also observe

the manufacturer‘s instructions and safety notes when operating the products, especially the

power ampliﬁer used.

Before using the SYSRACK-TGX, verify the shipment for completeness and ensure that all

parts are in a proper condition.

The SYSRACK-TGX is designed both for indoor and outdoor use. Keep the device away from

water!

The SYSRACK-TGX may only be used by trained and qualiﬁed personnel. Before each use,

the SYSRACK-TGX must be checked for its full functionality and the proper condition of all

items.

The SYSRACK-TGX has to be taken out of operation immediately, as soon as visible damage

to the rack, the devices or its cabling are visible.

The rack is fully pre-wired and contains a Dynacord TGX system ampliﬁer and a dedicated

connection panel for network and audio as well as power supply.

WARNING

CAUTION

Please adhere to the following safety instructions to avoid risks when using ampliﬁers.

Note the operating modes described in this assembly instructions. Other uses are not per-

missible.

Damage caused by improper use is not covered by TWAMBO.

When moving (assembling, dismantling, maintaining) the SYSRACK-TGX, ensure sufﬁcient

space to prevent collisions with other objects.

WARNING

Operation manual SYSRACK-TGX

Do not squeeze or twist the electrical cables of the SYSRACK-TGX. The respective national

electrotechnical rules and regulations are applicable.

Please note that there is a risk of electric shock or ﬁre if the mains cable or power connector

is damaged!

The SYSRACK-TGX must only be operated via a mains power supply with a safety ground

connector. Do not disconnect or cover the safety ground connection of the power cable.

Replace the mains cable immediately if the cable or connector is damaged!

Ensure that the power connector is only plugged and unplugged if the device is free of vol-

tage.

Make sure that the speciﬁed supply voltages are provided by the power grid. There is a label

with safety instructions on the backside of the rack.

WARNING

CAUTION

NOTE

Operation manual SYSRACK-TGX

2. Overview

2.1 Components

1. Rack4TGX

2. Slide-in front lid

3. Dynacord TGX10 power ampliﬁer

4. APL7 connection panel

5. Ventilation grille

6. Nameplate

7. Mains cable (must be ordered separately)

Figure 2.1 - Overview

Operation manual SYSRACK-TGX

3.1 SYSRACK-TGX

Components 1× Dynacord TGX-power ampliﬁer |

1× APL7 connection panel

Size 19“ rack | 4 U

Dimensions (H × W × D) 253 × 600 ×600 mm [9.96 × 23.62 × 23.62 in]

Weight 34 kg [74.96lbs]

Surface polyurea-coated

OUTPUT POWER

Load impedance 2,7 Ω 4 Ω 8 Ω

Maximum output power

All channels controlled 3000W 2500 W 1250 W

Number of ampliﬁer channels 4

Maximum output voltage 150 V peak

Maximum output current 53 A peak

Frequency response

ref. 1 kHz, analog in to speaker out 20 Hz bis 20 kHz (± 0,5 dB)

3. Technical speciﬁcations

3.2 Dynacord TGX power ampliﬁer

Operation manual SYSRACK-TGX

DIGITAL SIGNAL PROCESSING

Filter structures 17 ﬁlter per channel, can be implemented in

several ﬁlter types

Further signal processing

parameters Gain and Delay (0 to 2500 ms) per channel

Other functions

Source selection and mix, level, mute, polarity,

sine and noise generator, level meters, impedan-

ce measurement, and load monitoring

Source monitoring fallback AES3 lock and OMNEO-/Dante®-Network moni-

toring, switching to alternative source selection

Control software Sonicue

Further technical data for the Dynacord TGX10 power ampliﬁer can be found on the Dynacord

website: www.dynacord.com/de

Mains in 1× Neutrik powerCON®-HC frontseitig

Network PRIMARY / SECONDARY

etherCON®/RJ45 for Dante® audio network and

controlling via direct connection to

the power ampliﬁer

Audio IN / LINK 2× AES3 in combination and alternative use with

4× analog IN & LINK via XLR

Analog

Maximum input level: +24 dBu

Input impedance, active balanced: 20 kΩ

Reference level equal to digital input:

+21 dBu for 0 dBFS

Digital

Format: AES3 (AES/EBU)

Input sample rates: 32 bis 192kHz,

Internal sample rate converter and

signal processing

Audio OUT 6× speakON® NL4 | 1× speakON® NL8

3.3 APL7 connection panel

Operation manual SYSRACK-TGX

4. Commissioning

4.1 Setup

The SYSRACK-TGX should be used in horizontal orientation.

Please note that due to the weight of the SYSRACK-TGX, two people are required to set up

the system.

4.2 Handling

The SYSRACK-TGX has a sliding lid on the front that allows easy access to the devices.

To open the lid, follow these steps:

1. Open the latch on the bottom of the lid.

Figure 4.2.1 - Unlock the lid

WARNING
