Test Report No.: 14013483 001 Appendix 4 page 15 of 35
1.6 User Manual
(Cover)
Jawbone Bluetooth Headset
User Guide
Version 1
20-Jun-2006
Project No. : C51-A05085-XX
www.tuv.com
Test Report No.: 14013483 001 Appendix 4 page 16 of 35
[Inside Cover]
Jawbone Bluetooth Headset gives you more freedom when moving around. With your Bluetooth-enabled mobile
phone, the headset makes it easy for you to carry on with your tasks while making a call.
Jawbone Bluetooth Headset is compliant with Bluetooth Version 1.2 Class 2 specifications, and is compatible
with mobile phone supporting Bluetooth Headset or Handsfree Profiles. The Noise Cancellation technology
comes with the headset which makes you answer your call in any environments.
www.tuv.com
Test Report No.: 14013483 001 Appendix 4 page 17 of 35
(Page 0)
Contents
Title Page
Jawbone Bluetooth Headset Overview 2
Getting Started 2
Charging Your Headset
Normal Charging Time
Talk and Standby Time
Battery Low Indication
3-4
4
4
4
Turning Your Headset On and Off 5
Pairing Your Headset 6-7
Using Your Headset
Answering a Call
Rejecting a Call
Ending a Call
Muting a Built-in Microphone
Dialling from Your Mobile Phone
Voice Dialling from Your Headset
Last Number Redialling from Your Headset
Rejecting a Call (Handsfree Profile ONLY)
Transferring a Call (Handsfree Profile ONLY)
8-9
8
8
8
8
9
9
9
9
9
Adjusting the Volume 10
Resetting or Removing Pairing 10
Care and Maintenance
Headset
Built-in Battery
Charger
11-12
11
12
12
Safety Information 13
Troubleshooting 14
Declaration of Conformity (DoC) 15
Product Specifications 16
www.tuv.com
Test Report No.: 14013483 001 Appendix 4 page 18 of 35
(Page 1)
Jawbone Bluetooth Headset Overview
-
Figure 1
1 Reset Button
2 Charging Port
3 Ear Hook Insert Hole
4 Earphone
5 Noise Cancellation Technology
6 Built-in Rechargeable Battery
7 Built-in Microphone
8 Status Indicator
9 Multi-Function Button (MFB)
1
2
3
4
5
6
7
8
9
www.tuv.com
Test Report No.: 14013483 001 Appendix 4 page 19 of 35
Getting Started (Page 2)
To use your Jawbone Bluetooth Headset (“the headset”), please start with the following steps below:
1. Charge your headset, and
2. Pair your headset with a Bluetooth-enabled mobile phone.
Figure 2
www.tuv.com
Test Report No.: 14013483 001 Appendix 4 page 20 of 35
(Page 3)
Charging Your Headset
Figure 3
The headset comes with a built-in rechargeable battery. Prior to using the headset for the first time, it is
recommended to fully charge the battery first.
Contact port
www.tuv.com
Test Report No.: 14013483 001 Appendix 4 page 21 of 35
(Page 4)
Insert the charger plug into the headset’s charging socket (refer to Figure 3) and plug the charger to an AC wall
outlet. The status indicator will stay red during charging.
IMPORTANT: Charging indication will be delayed for a few seconds if the headset has not been used for
a long time or the battery is drained.
Normal Charging Time
It takes about three hours to fully charge the battery. When the battery is fully charged, the status indicator will
turn blue and remain on. Unplug the charger from the AC wall outlet and the charger plug from the headset.
Press and hold the MFB (refer to Figure 1) for two seconds to turn on the headset. Please refer to “Turning Your
Headset On and Off” on the next page for details.
Talk and Standby Time
The fully charged battery can offer up to 10 hours of talk time and up to 200 hours of standby time. When there
are no calls the headset should remain turned on in standby mode.
Battery Low Indication
When the battery has become low when the headset is on, the status indicator will flash red and the headset will
emit a beep* every minute. Please follow the instructions describe above to recharge the battery.
*If you are setting up the headset and your mobile phone in a noisy environment, we advise you to put on the
earphone first so that the beep will be more audible.
www.tuv.com
Test Report No.: 14013483 001 Appendix 4 page 22 of 35
(Page 5)
Turning Your Headset On and Off
Turning On the Headset
Press and hold the MFB for two seconds until you hear a short beep. The status indicator will then flash blue.
IMPORTANT: Press the MFB again each time when you want to turn on the headset to re-activate pairing
so as to resume the connection between the headset and the mobile phone. For pairing, please refer to
“Pairing Your Headset” section.
Turning Off the Headset
Press and hold the MFB for three seconds until you hear a long beep. The status indicator will stop flashing.
IMPORTANT: To disconnect the Bluetooth connection, press the MFB firmly to turn off your headset. If
you will not be using the headset for a while, you should consider turning off the Bluetooth function on
your mobile phone as well.
www.tuv.com
Test Report No.: 14013483 001 Appendix 4 page 23 of 35
(Page 6)
Pairing Your Headset
Figure 4
The headset works with Bluetooth-enabled mobile phones only. Prior to using and pairing your headset for the
first time, please check if your mobile phone is Bluetooth-enabled.
The pairing instructions for a typical Bluetooth-enabled mobile phone is explained on the next page. The headset
pairing procedure may vary depending on the model of your mobile phone. Please contact the manufacturer of
your mobile phone or its agent for further information.
www.tuv.com
Test Report No.: 14013483 001 Appendix 4 page 24 of 35
(Page 7)
Pairing Your Headset
1. Place the headset and the mobile phone where they are no more than one metre apart.
2. Ensure the headset is off. (The status indicator does not flash.)
3. Press and hold the MFB until the headset’s status indicator flashes blue and red alternately.
4. Activate your mobile phone’s Bluetooth function. Please refer to your mobile phone user guide for details.
5. Set the mobile phone to search for Bluetooth devices within the one metre range, as instructed in the mobile
phone user guide, and select “Jawbone Bluetooth Headset” from the list.
6. Enter the pre-programmed passkey “0000” and press “OK” to pair your headset and mobile phone. When
the pairing is completed, the headset’s status indicator will flash blue rapidly for five times followed by a long
beep.
7. Go back to your mobile phone’s main menu. For certain mobile phone models, once the headset is activated,
a headset icon will be shown on the screen. You should now be able to make and receive calls using your
headset.
IMPORTANT: If the pairing cannot be completed within two minutes after the pairing mode has been
activated, the headset’s LED indicator will flash purple-red with three beeps, the headset will then turn
off automatically. Please repeat step 2 to 7 above to pair the headset and the mobile phone again.
