Tuscany 54-3561 Guide de configuration

READ AND SAVE THESE INSTRUCTIONS

(this photo for reference only)

OWNERS INSTRUCTION MANUAL

FOR DUAL MOUNT FAN’S

 INSTALLATION

 OPERATION

 MAINTENANCE

These instructions are suitable for

UL/cUL Listed Ceiling fans

CAUTION

READ INSTRUCTIONS CAREFULLY FOR SAFE

INSTALLATION AND FAN OPERATION. IF UNSURE CONSULT

A QUALIFIED ELECTRICIAN

Safety Tips -----------------------------------------------------------------------------------2

Unpacking Your Fan ----------------------------------------------------------------------3

Material Required ---------------------------------------------------------------------------4

Electrical Outlet box------------------------------------------------------------------------4

Install Mounting Bracket------------------------------------------------------------------5

Installing the Fan-----------------------------------------------------------------------------6

Electrical connections----------------------------------------------------------------------9

Blade Attachment---------------------------------------------------------------------------10

Installing Light kit---------------------------------------------------------------------------11-14

Operation--------------------------------------------------------------------------------------15

Maintenance----------------------------------------------------------------------------------16

Trouble Shooting---------------------------------------------------------------------------17

Part List----------------------------------------------------------------------------------------18

TABLE OF CONTENTS

Page 1

TABLE OF CONTENTS

1. To avoid possible electric shock, turn off the electricity at the main fuse box or

circuit panel before you begin the fan installation or before servicing the fan or

installing accessories.

2. CAUTION: READ ALL INSTRUCTIONS AND SAFETY INFORMATION

CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE

INSTRUCTIONS.

3. Make sure all electrical connections comply with local codes or ordinances and

the national electrical code. If you are unfamiliar with electrical wiring, please use

a qualified and licensed electrician.

4. Make sure you have a location selected for your fan that allows clear space for

the blades to rotate, and at least seven (7) feet of clearance between the floor

and the fan blade tips. The fan should be mounted at least thirty (30) inches from

walls or other upright structures.

5. WARNING: The outlet box and ceiling support joist used must be securely

mounted, and capable of supporting a minimum of 50 pounds.

6. WARNING: To reduce the risk of fire, electrical shock, or personal injury mount to

outlet box marked” Acceptable For Fan Support” and use mounting screws (and

locked washers) provided with the outlet box.

7. Electrical diagrams are for reference only. Light kits that are not packed with the

fan must be UL listed and marked suitable for use with the model fan you are

installing.

8. After installation is complete, check that all connections are absolutely secured.

9. After making electrical connections, spliced conductors should be turned upward

and pushed carefully up into outlet box. The wires should be turned spread apart

with the grounded conductor and the equipment-grounding conductor on one side

of the outlet box.

10. WARNING: To reduce the risk of fire, electrical shock. Do not use this fan with

any solid-state fan speed control device, or rheostat.

11. Do not insert anything into the fan blades while they are rotating.

12. WARNING: To reduce the risk of personal injury, do not bend the blade brackets

when installing the brackets, balancing the blades, or cleaning the fan. Do not

insert foreign objects in between rotating fan blades.

13. To avoid personal injury or damage to the fan and other items, be cautious when

working around or cleaning the fan.

14. Do not use water or detergents when cleaning the fan or fan blades. A dry dust

cloth or lightly dampened cloth will be suitable for most cleaning.

15. Instructions for supply connections: conductor of a fan identified as grounded

conductor to be connected to a grounded conductor of power supply, conductor of

fan identified as ungrounded conductor to be connected to an ungrounded

conductor of power supply, conductor of fan identified for equipment grounding to

be connected to an equipment-grounding conductor.

NOTE: The important safety precautions and instructions appearing in this manual are

not meant to cover all possible conditions and situations that may occur. It must be

understood that common sense and caution are necessary factors in the installation

and operation of this fan.

CAUTION: To reduce the risk of injury to person, install fan so that the blade is at least

2.1 Meters (7 Feet) above the floor.

SAFETY TIPS

Page 2

SAFETY TIPS

1. Unpack your fan and check the contents. Do not discard the carton. If

warranty replacement or repair is ever necessary the fan should be returned in

original packaging. Remove all parts and hardware. Do not lay motor housing

on its side: the decorative casting may shift.

2. Examine all parts. You should have the following:

1. Mounting Bracket

2. Downrod/Ball assembly

3. Ceiling canopy

4. Fan Housing Motor, and switch housing. Remove rubber shipping spacers from

motor. Keep them in case you need to return fan.

5. Set of Blades

6. Blade Arms

7. Light Kit (or different light)

8. Parts Pack Containing:

A/ Mounting bracket hardwares (wire nuts)

B/ Blade attachment hardwares (screws with washers for each blade).

C/ Blade arm attachment hardware (motor screws and lock washers may already

be in fan motor)

D/ Pull chain/Ball

UNPACKING YOUR FAN

Page 3

1. If there is an existing outlet box, ensure it is clearly marked” Suitable For Fan

Support”. If not, it must be replaced with an approved one.

2. Secure the outlet box (or make sure the existing box is secured) directly to the

building structure. Use appropriate fasteners and building materials. Wood joist

and outlet box must be able to support a minimum of 50 pounds.

3. Figure 1,2 and 3 are examples of different ways to mount the outlet box in different

ways to mount the outlet box in different situations. A longer down rod may be

required in sloped ceiling situations to maintain proper blade clearance.

4. To hang the fan in locations where no ceiling joists is available. A hanger support

bar may be required (Fig. 4)

TOOLS AND MATERIALS REQUIRED

ELECTRICAL OUTLET BOX

Page 4

1. To avoid possible electrical shock, be sure electricity is turned off at the main

power panel before wiring.

All wiring must be in accordance with National and Local Electrical Codes, and the

ceiling fan must be grounded as a precaution against possible electrical shock.

2. Attach hanger bracket to outlet, box using screws provided with the outlet box

(Fig. 5)

INSTALL MOUNTING BRACKET

Page 5

1 Slide the canopy on the downrod(Fig.6) Thread the power leads from the fan

through the canopy and downrod. Take extra care not to pull on power wires. Damage

and loose connections could result from any abnormal pressure on these wires. Set

downrod into downrod collar yoke. Route until the holes match. Being careful not to

damage wiring, insert connector pin through the holes (See Fig. 6A. 6B). Secure the

pin by inserting the stop pin through the connector pin.

WARNING: Do not force connector pin through downrod. Use of force could cause

damage to wires inside. Make sure the stop pin is properly engaged to prevent it from

falling out.

2 Tighten downrod setscrew. Some models have a locknut for the setscrew. To insure

the setscrew fully seats against the downrod. It is necessary to back off the locknut

until it contact the setscrew head prior to tightened the setscrew. When setscrew is

tightened against downrod.locknut should then be tightened against connector yoke.

Some models have 2 downrod setscrews. Repeat for both (Fig.7)

INSTALLING THE FAN

SELECT TYPE OF INSTALLATION

HANG DOWN STYLE

Page 6

3. Tighten motor set screw. Check the strength of this connection (pre-tightened at

factory) by holding the motor housing in position and turning the downrod counter

clockwise. If this connection slips, retighten motor setscrew and locknut. Follow the

same procedures as mentioned above for downrod setscrew.

4. Install ball into hanger bracket opening. The tab opposite of the hanger bracket

opening should fit in slot on ball (Fig 8) .

5. Make wire connections (refer to section titled” Electrical Connections”) For

cUL-listed fan, please secure the safety cable to the junction box.

6. Slide canopy up, and fasten to hanger bracket with the 4 screws provided.

WARNING: To avoid damaging the blade arms and blades, do not install either until

fan is fastened to ceiling. To avoid motor shift, handle fan by downrod or switch

housing only.

Page 7

1. Put 2 screws in the hanger bracket. Leaving them partially out. (Fig. 9.1).

2. Remove three of the six screws and lock washers (every other one) from the top

housing (Fig. 9.2)

3. Place the ceiling canopy over the collar on the top of the motor housing. Align the

mounting holes with the holes in the motor and fasten, using the three screws and

lock washers which are removed in Step 2 (Fig. 9.3)

4. Move the fan assembly up and connect the wires from fan to the wires from ceiling.

(Fig. 9.4)

5. Make wire connections (refer to section titled” ELECTRICAL CONNECTIONS”) For

cUL-listed fan, please secure the safety cable to the junction box.

6. Place the canopy up on the hanger bracket by inserting the slotted opening of the

canopy on the screws. (Fig.9.5)

7. Insert the remaining screws through the remaining canopy holes and tighten all 4

screws.

HUGGER STYLE

Page 8

fig.9.3

1. Four wires are connected to the top of the fan.

Black: ” Hot” Power/Live for the fan

Blue: “ Hot” Power/ Live for the light kit

White: “Common”/Neutral for the fan and the light kit

Green/Green & Yellow: “Ground” /Earth wire

2. If the fan and light are connected to the same circuit, the black and blue wires

should be connected together to the black wire in the ceiling using a wire nut to

make the connection.

3. The white wire from the fan should be connected to the white wire in the ceiling,

using a wire nut to make the connection.

4. The green wire from the fan should be connected to the ground wire in the ceiling,

using a wire nut to make the connection.

ELECTRICAL CONNECTIONS

Page 9

Fig.10A Fig.10B

Fig.10C
