Turtle Beach Spectre Manuel utilisateur

User GUide

Limited edition PremiUm AmPLified

GAminG HeAdset

Wired

For: Xbox 360® I PS3™ I PC

Mac® I Mobile

Congratulations on your purchase of the Call of Duty® Ghosts Ear Force® Spectre Headset from Turtle Beach.

Compatible with PS3™, Xbox 360®, PC and Mac® computers, tablets, PS Vita™, and mobile devices. The Spectre,

delivers superior, clear sound over PlayStation Network (PSN), Xbox LIVE or online PC/Mac gaming.

For our Knowledgebase and Technical Support Contact info please visit: http://www.turtlebeach.com/support

Table of Contents

Package Contents P4

Features P5

Ampliﬁer Features P6

Basic Hardware Setup P7

PS3 Setup HDMI P8

PS3 Setup RCA P9

PS3 System Settings Conﬁguration P10

Xbox 360 Setup - All Models P11

Xbox 360 Setup (HDMI) P12

Xbox 360 Setup (RCA) P13

Xbox 360 E Setup (HDMI) P14

Xbox 360 System Settings Conﬁguration P15

PC/Mac Setup P16

PC System Settings Conﬁguration P17

Mac System Settings Conﬁguration P18

Mobile Device Setup with the Inline Ampliﬁer P19

Mobile Device Setup without the Inline Ampliﬁer P21

Speaker plates / Troubleshooting P22

Speciﬁcations P23

Compliance / Conformity P24

Warranty P27

Package Contents

Detachable Boom Mic

Xbox 360

Talkback Cable

RCA Splitter Cable

Ear Force® Spectre

Headset

Inline Ampliﬁer

3.5mm, 4-Pole

Auxiliary Cable

Mobile Adapter Cable Turtle Beach StickersSPECTRE Quick

Start Guide

Headset Breakaway

Cable

For: Xbox 360® I PS3™ I PC

Mac® I Mobile

WIRED

Quick Start Guide

For the full user guide or set up video please go to: turtlebeach.com/spectre

Pour consulter le guide d’utilisation complet et les

vidéos de configuration, veuillez visiter le site: turtlebeach.com/spectre

-LOW- HIGH -BASS + -TREBLE +

Product support and warranty information:

Support du produit et des informations de garantie:

www.turtlebeach.com/support

For full console compatibility information

please go to:

Pour les informations de compatibilité avec

les consoles, veuillez visiter le site

www.turtlebeach.com/connect

A B C

FED

Features

· Independent Game and Chat: Separate volume controls for your Game and Chat audio.

· Powerful Inline Amp: Mix in Game, Chat, Mic, Music and answer a phone call all through the Inline Amp.

· Bass and Treble Levels: Tune bass and treble levels to add depth and realism

· Superb Sound: Get better sound from online music, video and communications services.

· Dynamic Chat Boost™: Automatically raises the volume of chat during intense, explosive game situations.

· Variable Mic Monitor: Hear your own voice in the headset to avoid shouting.

· Removable Boom Mic: Use the Mobile Adapter Cable with inline mic as an alternative when on the go.

· Mobile Phone Integration: Connect to the Inline Amp to mix music or take phone calls while playing.

· USB Powered: No AC adapters or batteries required.

Ampliﬁer Features

Mic Switch:

Mic On (High) Mic On (Low)

Phone Call Mode Mic Mute

Mic Mute Indicator LED:

bright blue = Mic On (High)

dark blue = Mic On (Low)

purple = Phone Call Mode

red = Mic Mute

MODE SWITCH

Headset Output

Aux Input for

Phone & Music

Xbox 360 Talkback

Cable Input

Bottom View Top View

Chat Volume Control

Variable Mic Monitor

Bass Control

Treble Control

Chat Boost Indicator LED

Game Volume Control

· Game Volume Control: Adjusts the incoming sound level from the 3.5mm connection.

· Treble/Bass Controls: Adjusts treble and bass levels of incoming sound from the 3.5mm connection.

· Chat Control: Adjusts volume of incoming chat through USB or Xbox 360 chat input

· Variable Mic Monitor: Adjusts the sound level of your voice in the headset

· Mic Switch & Mic Mute Indicator LED:

· Mic on (High) (Bright Blue): Your voice is louder to other people.

· Mic on (Low) (Dim Blue): Your voice is lower to other people.

· Phone Mode (Purple): Routes mic to phone*.

· Mute (Red): Mutes your voice to all parties

· Chat Boost Indicator: When game volume increases; chat volume increases automatically. The Blue LED indicates the Chat

Boost activating. (Brighter when louder, dimmer when softer)

· Aux Input for Phone & Music: Connect your mobile device while gaming using the Auxiliary Cable.

· Xbox Chat Input: Connect your Xbox 360 Controller for chat using the Xbox 360 Talkback Cable

· Headset Jack: Connect your Spectre headset using the Headset Breakaway Cable or the Mobile Adapter Cable.

*Note: Phone mode must be switched on in order to talk on the phone while gaming.

Basic Hardware Setup

Note: When connecting the boom mic, please line up to connect correctly and securely so it is oriented

properly for use. Do not force input when not in line with the keying.

PS3 Setup HDMI

HDMI

USB

PS3 AV Cable

The PS3 AV Cable is included with your console.

PS3 Setup RCA

white

red

yellow

USB

The PS3 AV Cable is included with your console.

PS3 System Settings Conﬁguration

PS3 Audio Output Setup

PS3 Chat Setup

In the PS3 menu, select Settings > Sound Settings

> Audio Multi-output.

1. In the PS3 menu, select Settings > Accessory

Settings > Audio Device Settings > Input Device

> Turtle Beach SPECTRE.

2. In the PS3 menu, select Settings > Accessory

Settings > Audio Device Settings > Output

Device > Turtle Beach SPECTRE.

Audio Device Settings

Microphone Level 3

Input Device TURTLE BEACH SPECTRE

Output Device TURTLE BEACH SPECTRE

Back

X Enter

Audio Output Settings

12/14 12:15 PM

Sets to output audio through multiple connectors

simultaneously. Audio output to connectors that are

not selected in [Audio Output Settings] is downscaled

to 2 Ch.

Audio Device Settings

Microphone Level 3

Input Device TURTLE BEACH SPECTRE

Output Device TURTLE BEACH SPECTRE

Back

X Enter

Audio Output Settings

12/14 12:15 PM

Sets to output audio through multiple connectors

simultaneously. Audio output to connectors that are

not selected in [Audio Output Settings] is downscaled

to 2 Ch.
