Turboair J series Manuel utilisateur

J Series

Undercounter Refrigerators

Service Manual

JUR-36-N6

JUR-48-N6

JUR-60-N6

JUR-72-N6

www.turboairinc.com

TABLE OF CONTENTS

EXPLODED VIEW

JUR-36-N6 EXPLODED VIEW

JUR-48-N6 EXPLODED VIEW

JUR-60-N6 EXPLODED VIEW

JUR-72-N6 EXPLODED VIEW

WIRING DIAGRAMS

MAIN COMPONENTS

PARTS LIST

TEMPERATURE CONTROL INSTRUCTION

REPLACEMENT OF MAIN COMPONENTS

REPLACING DOOR

REFRIGERATION COMPARTMENT PARTS

COMPRESSOR COMPARTMENT PARTS

7-8

10-11

JUR-36-N6 EXPLODED VIEW

PART NAME

MAIN PCB COVER

FRONT PCB

ASSY UNIT FRONT COVER

BOTTOM HINGE (R)

DOOR (R)-900

TOP HINGE (R)

EVAP DRAIN GUIDE

AIR GUIDE (L/R)

EVAP DUCT

EVAP FAN MOTOR

EVAP ASSY

COUNTERTOP

EVAP FAN AIR GUIDE

CABINET ASSY

UNIT BRACKET

UNIT SIDE COVER

CONDENSER ASSY

SUCTION PIPE

COMPRESSOR

DRYER

DRAIN PAN

CONDENSER FAN MOTOR

UNIT BRACKET (A)

CASTER

20 21 22

JUR-48-N6 EXPLODED VIEW

PART NAME

MAIN PCB COVER

FRONT PCB

ASSY UNIT FRONT COVER

BOTTOM HINGE (L)

TOP HINGE (L)

DOOR (L)-1200

BOTTOM HINGE (R)

DOOR (R)-1200

TOP HINGE (R)

EVAP DRAIN GUIDE

AIR GUIDE (L/R)

EVAP DUCT

EVAP FAN MOTOR

EVAP ASSY

COUNTERTOP

EVAP FAN AIR GUIDE

CABINET ASSY

UNIT BRACKET

UNIT SIDE COVER

CONDENSER ASSY

SUCTION PIPE

COMPRESSOR

DRYER

DRAIN PAN

CONDENSER FAN MOTOR

UNIT BRACKET (A)

CASTER

23 24 25

JUR-60-N6 EXPLODED VIEW

PART NAME

MAIN PCB COVER

FRONT PCB

ASSY UNIT FRONT COVER

BOTTOM HINGE (L)

TOP HINGE (L)

DOOR (L)-1200

BOTTOM HINGE (R)

DOOR (R)-1200

TOP HINGE (R)

EVAP DRAIN GUIDE

AIR GUIDE (L/R)

EVAP DUCT

EVAP FAN MOTOR

EVAP ASSY

COUNTERTOP

EVAP FAN AIR GUIDE

CABINET ASSY

UNIT BRACKET

UNIT SIDE COVER

CONDENSER ASSY

SUCTION PIPE

COMPRESSOR

DRYER

DRAIN PAN

CONDENSER FAN MOTOR

UNIT BRACKET (A)

CASTER

23 24 25

JUR-72-N6 EXPLODED VIEW

PART NAME

MAIN PCB COVER

FRONT PCB

ASSY UNIT FRONT COVER

BOTTOM HINGE (L)

TOP HINGE (L)

DOOR (L)-1800

BOTTOM HINGE (R)

DOOR (M)-1800

DOOR (R)-1800

TOP HINGE (R)

EVAP DRAIN GUIDE

AIR GUIDE (L/R)

EVAP DUCT

EVAP FAN MOTOR

EVAP ASSY

COUNTERTOP

EVAP FAN AIR GUIDE

CABINET ASSY

UNIT BRACKET

UNIT SIDE COVER

CONDENSER ASSY

SUCTION PIPE

COMPRESSOR

DRYER

DRAIN PAN

CONDENSER FAN MOTOR

UNIT BRACKET (A)

CASTER

WIRING DIAGRAMS

MAIN

PCB

CONDENSER

FAN

MOTOR

CONDENSER

FAN

MOTOR

LED

LAMP

GRY

BLU

12V

D-SENSOR

R-SENSOR WHT

BLU

BLK

GRN

WHT

BRN

YEL

BLK

RED

WHT

RED

GRY

BLK

WHT

BLU

BLK BLKBLK

BLK

WHT

BLK BLK

YEL YEL

GRY

LAMP SWITCH

COOLING FAN

YEL

BLK

MOTOR

PROTECTOR

PTC

STARTER

RUNNING

CAPACITOR

BLK

EARTH

POWER

CORD

FRONT

-PCB

EVAP

FAN

MOTOR

DRAIN

PAN

HEATER

SMPS

MAIN

PCB

CONDENSER

FAN

MOTOR

CONDENSER

FAN

MOTOR

LED

LAMP

GRY

BLU

12V

D-SENSOR

R-SENSOR WHT

BLU

BLK

GRN

WHT

BRN

YEL

BLK

RED

WHT

RED

GRY

BLK

WHT

BLU

BLK BLKBLK

BLK

WHT

BLK BLK

YEL YEL

GRY

LAMP SWITCH

COOLING FAN

YEL

BLK

MOTOR

PROTECTOR

PTC

STARTER

RUNNING

CAPACITOR

BLK

EARTH

POWER

CORD

FRONT

-PCB

EVAP

FAN

MOTOR

DRAIN

PAN

HEATER

SMPS

JUR-36-N6

JUR-48/60-N6

WIRING DIAGRAMS

MAIN

PCB

CONDENSER

FAN

MOTOR

CONDENSER

FAN

MOTOR

LED

LAMP

GRY

BLU

12V

D-SENSOR

R-SENSOR WHT

BLU

BLK

GRN

WHT

BRN

YEL

BLK

RED

WHT

RED

GRY

BLK

WHT

BLU

BLK BLKBLK

BLK

WHT

BLK BLK

YEL YEL

GRY

LAMP SWITCH

COOLING FAN

YEL

BLK

MOTOR

PROTECTOR

PTC

STARTER

RUNNING

CAPACITOR

BLK

EARTH

POWER

CORD

FRONT

-PCB

EVAP

FAN

MOTOR

DRAIN

PAN

HEATER

SMPS

JUR-72-N6

MAIN COMPONENTS

COMPRESSOR

COMPRESSOR CAPACITOR

CONDENSER FAN MOTOR

EVAPORATOR FAN MOTOR

MODEL

JUR-36-N6

JUR-48-N6

JUR-60-N6

JUR-72-N6

MODEL

JUR-36-N6

JUR-48-N6

JUR-60-N6

JUR-72-N6

MODEL

JUR-36-N6

JUR-48-N6

JUR-60-N6

JUR-72-N6

MODEL

JUR-36-N6

JUR-48-N6

JUR-60-N6

JUR-72-N6

PART NAME

STARTING

PART NAME

PART NO.

1/6

1/5

CAPACITY

RUNNING

250V/10㎌

POLE

TYPE OF

RSCR

PART NO.

INPUT

115V/60Hz

INPUT

115V/60Hz

INPUT

115V/60HZ

MAKER

TYPE

SHADED POLE

INDUCTION

TYPE

SHADED POLE

INDUCTION

MAKER

NOTE

BLADE

AL5

BLADE

AL5

MAKER

SUNGSHIN

MAKER

SUNGSHIN

HYE90MGU72a

HYE105MGU72a

4511003050

PARTS LIST

PART NAME PART CODE DESCRIPTION

COUNTERTOP ASSY

DOOR ASSY (L)-1200

DOOR ASSY (R)-1200

DOOR ASSY (L)-1500

DOOR ASSY (R)-1500

DOOR ASSY (L)-1800

DOOR ASSY (M)-1800

DOOR ASSY (R)-1800

DOOR GASKET

DOOR BUSHING

SPRING BAR

BOTTOM HINGE (U)(L)

BOTTOM HINGE (U)(R)

TOP HINGE (L)

TOP HINGE (R)

EVA ASSY

KR60090101

KR20000101

KR18120101

KR90000101

JUR4805104

JUR4805202

JUR6005104

JUR6005202

JUR7205402

JUR7205503

JUR7205602

KR23300107

KR53300107

KR83300107

T8F0500701

M720700108

BR98400105

K5R1107102

K5R1107202

KR89910304

KR89910404

JUR200106

JUR201106

PVC

ABS

SUS

MODEL

JUR-36-N6 JUR-48-N6 JUR-60-N6 JUR-72-N6
