TTS Interactive Wall Chart Manuel utilisateur
Warranty & Support
This product is provided with a one year warranty for problems found during
normal usage. Mistreating the Interactive Wall Chart or opening the unit will
invalidate this warranty.
All out of warranty repairs will be subject to a replacement fee.
Technical Support
Please visit www.tts-group.co.uk for the latest product information.
TTS Group Ltd.
Park Lane Business Park
Kirkby-in-Ashfield
Nottinghamshire,
NG17 9GU, UK.
Freephone: 0800 318686 Freefax: 0800 137525
TTS Product Code:
PS00407
WARNING: Do not dispose of this product in
household waste. Hand it over to a collection point
for recycling electronic appliances.
WARNING! Not suitable for children under 36 months
due to small parts – choking hazard. Made in China,
on behalf of the TTS Group Ltd.
Interactive WallTM Chart
Nxxxxx
N448
TTS is proud to be part of plc
Interactive WallTM Chart
30 Recording pockets
Ten seconds each
www.tts-shopping.com
USER GUIDE
Useful Information
Please read all instructions carefully before use.
nPlease retain these instructions for future reference, as they contain
important information.
nAll cleaning should be carried out by an adult.
nEnsure the product is switched off before cleaning begins.
nTo clean the Interactive Wall Chart wipe with a damp cloth.
Safety Warnings
nBatteries should be fitted by an adult.
nUse batteries of the same type.
nDo not mix new and old batteries; replace all batteries at the same time.
nDo not mix rechargeable and non-rechargeable batteries.
nDo not allow batteries to come into contact with liquids at any time.
nAll batteries should be removed from the product for long periods of
storage.
Fitting & Replacing Batteries
1. Your Interactive Wall Chart uses 3 x 1.5V AAA batteries which are user
replaceable.
2. Batteries must be inserted with the correct polarity as indicated in the
battery compartment.
3. Remove the battery cover with a screwdriver.
4. Remove the exhausted batteries, and dispose of responsibly.
5. Replace the battery cover, and tighten screws.
Know your Interactive Wall Chart
Wall Hanging Eyelet
Playback/
Record button
Pocket
battery hatch
Rec/Off/Play
Speaker
Interactive WallTM Chart
Recording and Playback on your Interactive
WallTM Chart
Recording
1. Slide the Rec/Off/Play switch
on the speaker module to Rec.
2. Choose a ‘tile’ to record a
message into.
3. Press and hold the green Rec/
Play button for the tile you want
a message to be recorded into.
4. Speak clearly into the
microphone.
5. Release the green Rec/Play
button. Each Tile can record up
to 10 seconds.
6. Each subsequent message
will record over the message
before it.
Playback
1. Slide the Rec/Off/Play switch
on the speaker module of the
wall chart to play.
2. Press a play button once to
hear the recorded message.
Move the switch to the “Off”
position when not in use to
conserve the batteries.
Rec O Play
Interactive Wall Chart Additional Features
The Interactive Wall Chart has 30 recordable tiles; each tile has a hardwearing
pocket H75 x W75mm to allow content to be inserted.
The Interactive Wall Chart has keyholes and eyelets to allow the item to be wall
mounted.
Technical Specification
Troubleshooting
Interactive WallTM Chart
Feature Specification
Interactive Wall Chart will not
record sounds.
Interactive Wall Chart will not
playback recordings.
Ensure the slide switch is in record
mode.
Ensure that the batteries are fresh,
and are inserted correctly.
Ensure the slide switch is in play
mode.
Ensure that the batteries are fresh,
and are inserted correctly.
Battery Type
Battery Life (Playback mode)
Battery Life (Recording mode)
Recording time
3 x 1.5V AAA batteries
500 plays approx(depending on length)
1000 recordings approx (depending on
length)
10 seconds (per pocket)
Problem Solution
