OPERATION MANUAL

EDIC-mini

Tiny xD B68

Digital Voice Recorder

Short Operating Instruction for Digital

Recorder EDIC-mini Tiny xD B68

Specications:

• VAS(VoiceActivatingSystem);

• Circularrecordingmode;

• Timerstostartrecordingatthepresettime;

• Informationprotectionsystem;

• Remotemicrophoneconnection;

• LEDindication;

• Reading  data from the card by a special

readerviaUSB(upto5,5Mb/sec)

• Reading data directly from the Recorder

viaUSBatthespeedof0,7Mb/sec.

Supplied Software makes it possible to:

• Save the recordings on the PC as standard

soundles;

• Restorecompressedpauseswhenuploading

lesontothedrive;

• Settherecorder’sparameters;

• Apply password protection of the access

totherecorder’ssettingsandinformation;

• Updatesoftware.

Appearance

Rec-StopSwitch

Memorycard

compartment

xDMmemory

card

Battery

compartment Microphone

LED

micro-USB

plug

Technical Characteristics:

• Dimensions:56х30х8mm;

• Weight:9g;

• Case:Plastic;

• Memorytype:ReplaceableFlashxDMcard;

• xDMcardvolume:From150to600hours;p

• Audiocodec:10-bits

 Frequency band when recording:

100-10000Hz;

 Sensitivityofbuilt-inmicrophone:upto9m;

 Signal-to-noiseratio:-80dB;

 Samplerate:upto22kHz;

 Powersupply:CR2450;

 Battery life in record mode: 100 hours

(8KHz,withoutcompression);

 Instand-bymode:11months,(250mAh);

 Compression method: uLaw, ADPCM

(2or4bits).

PC system requirements:

operating systems Windows XP, Windows Vista,

Windows7.

Installing the Battery and Memory Card

Install memory card into the compartment as

shown in the scheme. The Recorder operates

under CR 2450 batteries. Open the Lid of

the battery compartment, insert the battery

observingthepolarity(thepositivebatterycontact

is to be upward) and install the Lid up to the

stop. Carefully observe the polarity! Otherwise

the Recorder may malfunction. After the battery

has been installed the Recorder carries

out automatic self-testing signifying it by three

ashes of LED.After that the Recorder is ready

tostartoperating.

Starting the Recording

To start recording switch “Rec-Stop” switch

to “Rec” position. When the recorder starts

recording, the LED ashes ve times.

Afterthattherewillbeonemoreashitsduration

depending on free memory size (for more

details see Instructions in the internal memory

of the Recorder). To stop recording switch

“Rec-Stop”to“Stop”position.

Playing back the Recording

Connect USB cable to the Recorder, then

totheUSBportofthePC.Thesystemrecognizes

a new storage device. Launch «RecManager.

exe» from it. The content of the Recorder

is on the left side of the window. Select

the recording, right-click and select

“Copy to PC”. The recording will be converted

toWAVandappearsattherightsideofthewindow.

To play back the recording left-click it twice.

To disconnect the Recorder connect USB cable

offthePC,afterthatconnectitofftheRecorder.

Instructions

Operating instructions for the Recorder and

“RecManager”arelocatedintheinternalmemory

oftheRecorderrecognizedasastorage device.

These are located in “Instructions EM Tiny

xx.pdf” and “Operation Manual for RecManager

for Tiny хх.pdf», xx specifying the document’s

version. It is recommended to copy the contents

of the storage device onto the hard drive

of the PC to solve all the possible problems

withtheRecorder.

Optional accessories:

1.RemoteMicrophonewithcompressor;

2 Programmableremotemicrophone.

In Box

1.Recorder;

2.xDMmemorycard;

3.USBcabletoconnecttothePC;

4.2CR2450batteries;

5.Instructions.

6.XDReader
