SAFETY RAIL SYSTEM INSTRUCTIONS
Important
-
Read and UnderstandThis Document Before Installationor Useof Svstem!
Warning
Manufacturer's instructions must be followed regarding proper system use, maintenanceand installation.
Alternations or misuse of product or failureto follow instructionsmay result in serious injury ordeath.
All safetv rail systems and components are to be used under the safetv standards in place in the iurisdiction in which
you are working. These instructions are not meant to supersede anv local or federal safetv standards.
Any Safety Trolley, which has seen fall arresting service, should not beused after such service and returned
tothe manufacture for immediate inspection. Aswell the whole svstem: trolley, rail and all accessories will
need to be inspected and replaced at once. Until a full replacement ofthe system
is
implemented you should
not ascend ordescend
on
a
system that has incurred usage of
a
fall.
Use
-
Trylon's Safety Trolley
&
Rail system is intended to arrest personnel (not material) should they (the individual) slip or
fall while climbing.
Ensure the anchorage system can support a minimum load of
2500
pounds. Certification is applicable to the device
only. Neither the manufacturer nor CSA has investigated the anchorage system. The Safety Rail Trolley is designed to
work onTrylon's Safety Rail Systems only.
Climbers should always tie off to a structure by means of a lanyard while working or resting. When detaching from the
trolley to work elsewhere on the structure, as a best practice, climbers should also tie off their trolley to avoid the
unlikely event ofthe trolley 'slipping' down the rail during extreme vibrations.
Trylon Fall Protection systemsare not intended to be used asa life line or work position device while working.
Body harnesses supplied with the Fall Protection system may require the use of D-Rings or carabiners to provide a safe
and comfortable fit for the attachment on climber's harness. Length of attachment and clothing should not impede the
locking mechanism on the slider.
Do not exceed
6
inches of distance between slider and attachment point.
Training
Climbers should fully familiarize themselves with the operation of the system before ascendingthe structure or tower.
As well they should insure that the body harness is properly equipped sb
it
does not interfere with arresting features of
the fall protection system. Make certain all applicable hazards are addressed properly to provide climber safety.
Hazardous power lines, antenna radiation, physical obstructions, icing, frost, in addition to climber's knowledge,
ability and health. The Safety Trolley and Rail System is designed for use by one climber at a time.
Inspection
The Safety Rail Trolley system is designed to function as an integrated system and the use of non-compatible materials
is not recommended and may impair performance.
