FLOOR MACHINE

HIGH SPEED

OWNERS MANUAL &

PARTS LIST

This equipment is intended for commercial use only

CleanFreak.com □ 3900 N. Providence Ave □ Appleton, WI 54913 □ (888)722-5508 □ Local (920)882-8453

SS-20-1500HS-TC

WHEN THE MACHINE IS DELIVERED

Check the carton carefully for signs of rough handling. Remove the machine from the carton. If the

machine is damaged, notify the carrier IMMEDIATELY and request an inspection. Be sure to keep the

carton, packing inserts, packing lists and carrier’s receipt until the inspector has verified your claim.

CleanFreak’s liability ceases when the carrier picks up the shipment but our customer service staff will be

glad to furnish any information needed in connection with the claim and will expedite repair of the

machine.

BEFORE OPERATING THE MACHINE

Read the manual carefully and completely before attempting to operate the unit. This manual has

important information for the use and safe operation of the machine. Keep this manual handy at all times.

This machine will assure years of satisfactory service if operated and maintained according to

recommendations in this manual. If additional information is needed, please contact your local distributor

or write to:

CleanFreak

P.O. Box 569

Wausau, WI 54402

All information and specifications printed in the manual and parts list are current at the time of printing;

however, because of CleanFreak’s policy of continual product development, we reserve the right to make

changes at any time without notice.

WARRANTY

To protect your investment, promptly fill in the required information on the warranty card that comes with

the unit and mail it back.

WARNING

To reduce the risk of fire, electric shock, or injury:

•Do not operate the machine unless trained and authorized.

•Do not leave the machine when plugged in. Unplug from the outlet when not in use, before servicing,

and when changing the brushes or pads.

•Use indoors only.

•Do not allow to be used as a toy. Close attention is necessary when used by or near children.

•Do not bypass or defeat the safety “lock-out lever.”

•The machine was designed for use as per instruction and recommendations written in this manual. Any

deviation from its proper use or purpose and the consequential damage that may occur is the sole

responsibility of the end user.

•Do not use with damaged cord or plug. If the machine is not working as it should, or it has been

dropped, damaged, left outdoors or dropped into water, return it to an authorized service center.

•Do not pull or carry by cord, use cord as handle, close a door on the cord or pull cord around sharp

edges or corners. Do not run machine over cord. Keep cord away from heated surfaces.

WARNING (Continued)

•Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.

•Do not handle plug or appliance with wet hands.

•Make sure the machine is plugged into an electrical outlet with the same voltage and frequency rating

as shown on the nameplate of the machine. Do not attempt to plug a 115- volt machine into a 230- volt

outlet.

•Do not immerse or use this machine in standing water. Such use can cause electric shock.

•Keep the electrical supply cord from contacting the rotating brush or drive block.

•Do not expose machine to freezing temperatures.

•To avoid electric shock, do not expose the unit to rain. Store indoors only.

•Connect to a properly grounded outlet only. See “Grounding Instructions.”

•Turn off all controls before unplugging.

•When using an extension cord, use a 3 conductor grounding cord, 12 gauge wire or heavier.

•Do not put any object into openings. Do not use with any opening blocked. Keep free of dust, lint, hair

and anything that may reduce air flow.

•Do not operate machine in flammable or explosive areas.

•All servicing of CleanFreak’s equipment should be performed by an CleanFreak authorized service

center.

•Keep hair, loose clothing, fingers and all parts of body away from openings and moving parts.

•Use extra care when cleaning on stairs. When servicing machine, use manufacturer’s supplied or

approved replacement parts.

FAILURE TO COMPLY WITH THE WARNING INSTRUCTIONS WILL VOID THE

WARRANTY.

GROUNDING INSTRUCTIONS

Machine must be grounded. If it should malfunction or breakdown, grounding provides a path of least

resistance for electrical current to reduce the risk of electric shock. This machine is equipped with a cord

having an equipment-grounding plug. (Fig 1.) The plug must be plugged into an appropriate outlet that is

properly installed in accordance with all local codes and ordinances. Do not remove ground pin; if

missing, replace plug before use.

Fig. 1

PREPARING THE MACHINE FOR OPERATION

Your floor machine will operate in a wide variety of hard floors and carpet cleaning applications. Consult

with your local dealer or CleanFreak’s Customer Service to select the correct accessories for the job you

are going to perform.

PAD INSTALLATION

To install pad, tilt the machine back on wheels until machine is resting on handle. Remove center

lock by twisting it counterclockwise. Center the pad on the pad holder and re-insert pad center lock

by twisting clockwise. Make sure the center lock is tight.

To remove: Twist the center lock counterclockwise.

MACHINE OPERATION

1. Install the pad.

2. Plug in machine.

3. Lower the handle to the desired operating position.

*when you start the machine with the pad lifted off the floor. Once it starts spinning then you may lower

to the floor and start working.

TO MANEUVER YOUR HIGH SPEED FLOOR MACHINE: 1500RPM OR 2000RPM

ONLY

1. With the pad installed, turn on the floor machine and move forward then backwards until the

maximum gloss is reached.

2. Keep the machine moving and do not stay in one spot.

3. Practice until you gain experience in operating the unit.

TO RE-ADJUST THE HANDLE-LOCK MECHANISM

Unlock the handle and place it in the upright position. Tighten the adjusting nuts

until there is a slight drag when the handle is raised or lowered. (Fig. 7)

Fig. 7

TO ADJUST THE DRIVE BELT:

(High-speed models only)

1. Loosen, but do not remove the 4 bolts, that hold the motor to the frame.

(Fig. 8)

2. Tighten the 2 screws at the back of the frame until the belt is tight. . Test and

re-adjust the belt until the belt does not slip. Re-tighten the four motor bolts.

WARNING: Do not over-tighten the belt.

Fig. 8

CLEAN UP & STORAGE

1. Unplug and wrap it under the cord hook and around the left side handle grip. Clean the cord and

inspect it for cuts, gashes and loose prongs.

2. Wipe down the machine and store in clean dry place.

SS-1500-TC BASE

ITEM # SS-1500-TC DESCRIPTION QTY

1B02196-1 Light, Motor Carbon Brush Wear 1

2C11916 Screw, 10-32 X .375 Phillips 6

3H11830 Label, Drip Cover 1

4D11490C Drip Cover, Chrome w/ Hole for Green Light 1

5C00297 Screw, #8 X .25 in, Pan Head 2

6D11545 Motor Screen 1

7C00293 #8 x .5 in Pan, Black SMS, Phillips 1

8B00187 Cable Clamp, Nylon, .43 in. 1

9G11557 Motor, High Speed 1

10 B00177 Terminal Lug, Female, QD, .25 X .032, 16-14 AWG, Fully Insulated 2

11 D11543 Handle Brace, Left 1

12 H03545 Cover, Serial # Label 1

13 H10976-1 Label, UL STD 561-507 1

14 H00565-5 Label, Serial #, Standard 1

15 C11568 Hex Bolt, .31 - 18 X 2.5 in. 4

16 D11526 Frame, Motor, Black 1

17 D11563 Axle, Handle 1

18 K00674 Bushing, .50 in, Nylon 4

19 C00261 Nut, .25-20, Hex 6

20 D11542 Tension Adjustment Bracket 2

21 C00233 Washer, Flat, .25 in 2

22 C00319 Hex Tap Bolt, 1-4 X 20 X 3.5 in 2

23 D11544 Handle Brace, Right 1

24 C00252 Washer, .375 in, Flat 6

25 C11569 Hex Tap Bolt, 3-8 X 1.25 in 4

26 K11561 Spacer, .25 lg, Nylon, Natural 14

27 C11559 Washer, .515 X .875 X .032 12

28 G11943 Wheel, 5 in 4

29 C02305 Cap Nut, .5 in, Push-on 4

30 C11558 Locknut, .375-16 2

31 D11562 Axle, Wheel 1

32 C11555 Key, Motor, .187 in 2

33 D11532 Pulley 1

34 C11567 Set Screw, .312 in 3

35 K00662-50 Spacer, .5 in 2

36 C00250 Lockwasher, .375, Split 5

37 C11571 Hex Tap Bolt, 3-8 X .75 in 3

38 D11535 Washer, 1.75 in, Steel 1

39 E11478-BLUE Bumper, 20 in Floor Machine 1

40 F11988 Pad, High Speed, 20 in 1

41 2004BR Pad Holder, 20 in, High Speed 1

42 C00262 Nut, .31-18, Hex 4

43 C00251 Lockwasher, .31, Split 4

44 D11565 Bearing Plate, Lower 1

45 D11486-SS Brush Cover, 20 in, Stainless 1

46 K11521 Spacer, Base, Floor Machine 4

47 G11531 Bearing 2

48 D11547 Pulley, 3 7/8 in, w/ Grooves 1

49 L11530 Belt 1

50 C11556 Wave Washer 2

51 D11534 Shaft, 4.11 in 1

52 D11566 Bearing Plate, Upper 1

53 C11574 Retaining Ring 1

54 D11490C Drip Cover, Chrome 1

SS-1500-TC HANDLE

ITEM # SS-1500-TC DESCRIPTION QTY

1H05248-2 Label, Important, Card 1

2B11900-BLUE Power Cord, 12-3, 75 FT, SJTW, BLUE 1

3K11498-BLUE Grip, BLUE 2

4C11528 Screw, 10-32 X .25 in 1

5H12069 Label, 1500 RPM, Saturn 1

6H11908 Label, TRUSTED CLEAN 1

7D11496C Switch Box Cover, Black 1

8H11493 Label, Safety, Floor Machine 1

9C11529 Screw, 10-32 X .375 in 2

10 K11519 Lever Grip, Lockout, Black 1

11 C00278 Locknut, 10-32, Nylon, SS 1

12 D11494 Lockout Bracket 1

13 D11524 Spring, Lockout 1

14 C90007 Screw, 10-32 X .625 Phillips, Truss Head, SS 1

15 C11491 Screw, 10-32 X 1 in, SS 1

16 C00306 Roll Pin, .125 X 1.75 2

17 D11523 Spring, Trigger 2

18 D11479 Handle, Chrome, Floormachine 1

19 D11495 Trigger, Zinc Plated 1

20 K11520 Lever Grip, Trigger, Black 2

21 11507A Assembled Locking Handle, Cord Hook 1

22 C11619 Allen Wrench, .31 in 1

23 D11497 Handle, Locking Clamp 1

24 C11538 Cap Nut, .31 in, Push-on 1

25 C00259 Washer, Slotted, Zinc 1

26 C11536 Spade Bolt, .375-16 X 4 in 1

27 D11507 Cord Hook Clamp 1

28 D11507-2 Cord Hook Body 1

29 C11558 Locknut, Black Oxide, Thin 2

30 C11502 Socket Cap Screw, .375-16 X 2.5 in 1

31 C11537 Dowel Pin, .31 X 1.5 in 1

32 B10734 Strain Relief, Handle 1

33 B11513 Cord, Handle, 14-3 SJTW 1

34 B11762 Terminal Lug, Nylon, Female 2

35 B11465 Swtich, DPST, Pushbutton 1

36 B00177 Terminal Lug, Female, QD, .25 X .032 2

37 C00252 Washer, .375 in, Flat 1

38 C11541 Washer, .375 in, Star 1

39 B11518 Switch Insulation 1

40 C00284 Screw, 10-32 X .375 Ground 1

41 B00187 Cable Clamp, Nylon, .43 in 1

42 B00180-10-3 Ring Terminal, #10 Center 2

43 B11505 Strain Relief Nut, Metal 1

44 C11560 Washer, .93 ID X 1.5 OD 1

45 B11504 Strain Relief, Metal 1

Last Update: 05-22-12
