Truen TR-B222R Manuel utilisateur

User Manual ver.1.0

2 Megapixel IP Bullet Camera

1080P @30fps

TR-B222R user manual

2 Megapixel IP Camera Manual

2/70

Safety Precaution

Make sure to turn off the power before installing TR-B222R

Do not install under the direct sunlight or in dusty areas.

Make sure to use the product within the temperature and humidity specified in the specification.

Do not operate the product in presence of vibrations or strong magnetic fields.

Do not put electrically conducting materials in the ventilation hole.

Do not open the top cover of the product. It may cause a failure or electric shock on the

components.

To prevent from overheating, make sure to keep the distance at least 10cm from the ventilation

hole.

Make sure proper voltage (220V/100V) before connecting the power.

We appreciate your purchasing TR series.

Before installing the product, please read the following with care.

TR-B222R user manual

2 Megapixel IP Camera Manual

3/70

1. Introduction

About this manual

This User Manual provides information on operating and managing the megapixel IP box camera. The

Manual includes instructions of installation, operation and configuration of megapixel IP box camera as well

as how to make troubleshooting.

Features

This product is a megapixel Box network-based camera with remote live monitoring, audio monitoring and

control via an IP network such as LAN, ADSL/VDSL, and Wireless LAN.

Video

Highly efficient compression algorithm, H.264 & MJPEG support

Wide range of transmission rates: 32kbps ~ 16mbps

Various transmission modes: CBR, VBR, Hybrid

Motion detection

Audio (Option)

Multi-transmission mode: Simplex (IP Box camera Client PC or Decoder, Client PC or Decoder 

IP Box camera), Full Duplex

Network

Fixed IP & Dynamic IP (DHCP) support

1:1, 1:N support

Multicasting

Various types of Protocol support : TCP/IP, UDP, Multicast, DHCP, SMTP, HTTP, SNMP, RTP, RTSP

OnVIF, PSIA compliant

Sensor and Alarm (Option)

Support direct connections of external sensor and alarm devices

Event Alarm notification.

If an external sensor is activated, camera can be set to move to the corresponding Preset position.

User Interface

Diagnose and upgrade through dedicated program called True Manager

System configuration using Internet Explorer

High Reliability

Reliable embedded system

TR-B222R user manual

2 Megapixel IP Camera Manual

4/70

Product and Accessories

TR-B222R

Quick Manual

TR-B222R user manual

2 Megapixel IP Camera Manual

5/70

Part Names and Functions

Part names and Functions

Connector

Function

1. Ethernet/802.3af

Ethernet port/802.3af

2. Power IN

DC 12V

○

TR-B222R user manual

2 Megapixel IP Camera Manual

6/70

System Connections

TR-B222R .IP Cameras can be connected in either 1 to 1 connection where one TR-B222R is connected to

one PC client or a decoder system or 1 to many connections where one TR-B222R can be connected to

several PCs and decoder systems. (TCS-2000 video server can work as a video decoder which takes the

data from a video server or IP camera, decodes and outputs analog video.)

Topology

Generally, TR-B222R .and PC or a decoder is connected in 1-to-1 mode or 1-to many configuration.

1:1 Connection .

One TR-B222R.is installed at a site where video images are transmitted. A PC or a decoder is installed at a

central location to receive and view the video images on an analog monitor. Audio and serial data are

transferred in either direction.

Site

Remote Center (Decoder)

Remote Center

Site

Remote Center (PC SW)

TR-B222R user manual

2 Megapixel IP Camera Manual

7/70

1:N Connection .

In this configuration, a site can be monitored from many remote central locations. Although up to 64 PCs or

decoders can be connected to one TR-B222R in the real network environment, network bandwidth can limit

the maximum connections. Functionally, the video monitoring system (VMS) software provided can replace

the decoder.

Multicast Mode

If the network supports multicasting, a large number of decoders can be used to receive video effectively

from a TR-B222R .using a single streaming of video and audio. However, multicast mode is possible only

when network environment supports multicast.

Relay

Video and audio data can be retransmitted from a center to another center. The arrangement is useful when

the network bandwidth to the site is limited while there are more than one center want to monitor the site.

Site

Remote Center

Site

Center 1(Decoder)

Center 2 (Decoder)

TR-B222R user manual

2 Megapixel IP Camera Manual

8/70

VMS (Video Monitoring System)

VMS (Video Monitoring System) is a Window-based remote monitoring program in order to monitor or control

video, audio, and events in real time from several IP cameras or video servers. Please refer to the VMS User

Manual for more in detail.

Site

Remote Center

Site

Remote Center (Decoder)

VMS

TR-B222R user manual

2 Megapixel IP Camera Manual

9/70

2. Installation

Connection

Connecting Power

1. Carefully check the voltage and current capacity of the rated power. The rated power is indicated in the

back of main unit.

2. After confirming the power source, connect power adaptor and connect the 12V DC connector to the

system

Connecting Network

1. Plug network cable to Ethernet port (RJ-45 network port).

Connecting Audio (option)

Audio is full-duplex. It is possible to set the mode as Tx-only, Rx-only or Tx-Rx.

1. Connect audio input and output ports to audio devices accordingly.

2. The Audio signal required is line level, so an audio equipment with an amp, mixer or other amplifier

should be used.

Connecting Sensor and Alarm (option)

Connect sensor and alarm devices to corresponding terminals accordingly

Check if it works

Once the power is supplied to the camera, it will start booting. The system will boot up to an operating mode

after approximately 40-60 seconds. The green LED on the Ethernet port will flash indicating the system is

ready.

The software provided in the CD called True Manager allows you to check the IP address and other network

details of the camera. Please refer to the True Manager manual for instructions on how to find the IP address

of the camera and change it if required.

TR-B222R user manual

2 Megapixel IP Camera Manual

10/70

3. System Operation

Remote Video Monitoring

There are two ways to monitor video when the center system and IP camera are connected. In order for

a proper operation, an IP address must be set accordingly. Please refer to True Manager Manual

enclosed with product for further details.

Default ID : admin

Default Password :1234

Video Monitoring using Internet Explorer

Open Internet Explorer and enter camera’s IP address. The system will ask for confirmation to install

Active-X control. Once authorized, the Internet Explorer will start to display video images from camera

as shown below.

Defalut IP Address : http://192.168.10.100
