Zentina Installation Manual

INSTALLATION PREPARATION

Before installation begins, please confirm that you have the materials

indicated below:

Included

RecommendedTools

Precautions Before Installation

Please give enough allowance for the installation. Ensure that there is

room enough for the opening and closing of the bathroom door. Please

see diagram below for product placement measurements.

Please confirm the location of the sewage outlet and the wax ring as

indicated below before installation.

Installation Requirements

Minimum static water pressure: 20 psi

Maximum static water pressure: 80psi

Minimum water flow: 1 Gallon every 10 seconds

115 V power GFCI receptacle within 4’

#1 INSTALLING THE WATER VALVE

Option #1: Copper Stubbed Out of Wall (easiest method)

1. Shut off water to the house and drain water supply line by

opening a nearby faucet.

2. Once the water pressure has reduced and has stopped flowing,

unscrew the nut from the angle valve and remove the valve

from the copper pipe (stub out).

3. Push the nut as far from the brass crimp ring(ferrule) as possible

and using a wheel cutter or a hacksaw, cut the pipe between

ferrule and the wall (as close to the ferrule as possible)

4. Adapt plumbing to ½” FIP(Female Iron Pipe) with a gasketed

John Guest female adapter (Not included).

https://www.johnguest.com/us/en/cts-fittings/speedfit-twist-

and-lock/elbows/speedfit-female-swivel-elbow-nps-thread

5. Thread Valve onto John Guest fitting and tighten in place (Do

not use Teflon tape)

6. Make sure valve is shut off and turn the water back on to check

for leaks before setting the toilet in place

Option #2: Using PEX water line (new construction, remodels, and

plumber installation. Not recommended without a professional)

1. Shut off water to the house and drain water supply line by

opening a nearby faucet.

2. Once the water pressure has reduced and has stopped flowing,

cut off the valve or fitting using a pipe cutter.

3. Insert a ½” Female gasketed swivel adapter (Not Included) into

the PEX water supply and crimp in place (Crimp ring goes on

first)

https://www.plumbersstock.com/pxfes12-12in-brass-pex-

female-swivel-adapter.html

4. Thread Valve onto fitting and tighten in place (Do not use Teflon

tape)

5. Make sure valve is shut off and turn the water back on to check

for leaks before setting the toilet in place

Option #3: Use existing valve (This method will reduce the water

pressure and volume to the toilet and is not recommended unless one

of the first two options cannot be achieved.)

1. Turn the water off at the toilet valve

2. Flush the toilet two or three times to reduce the amount of

water in the toilet tank

3. Remove (Un-Thread) the supply line from existing toilet.(use a

bowl and towel to catch any access water)

4. Remove the supply line from the existing shut off valve and

replace it with a 3/8” to ½” FIP supply line. (Not Included)

https://www.plumbersstock.com/supb1f09-38inx12x9-flex-

faucet-supply-ss.html

5. Thread new supply line onto the shut-off valve included in the

box and tighten in place. (Do not use Teflon tape)

6. Make sure valve is shut off and turn the water back on to check

for leaks before setting the toilet in place

#2 TOILET INSTALLATION

1. Make a cross mark on the floor drain (see below).

2. Lift the toilet seat, remove the white caps, and remove the

screws. Lift the entire top (lid and seat) from the base of the

toilet.

3. Gently flip the toilet on its side, placing it on the pre-prepared

foam board.

4. Make two marks on the side and front of the toilet

perpendicular to the sewage outlet.

5. Install the wax ring under the toilet.

6. Using two people, lift the toilet and align the marks on the toilet

bowl with the cross marks on the ground. Also confirm the

holes in the bottom of the bowl alighn with the closet bolts.

7. Place the washers over the closet bolts.

8. Use a wrench to lock nuts to the closet bolts.

oWarning! DO NOT OVER TIGHTEN! Over tightening may

crack the porcelain base.

9. Reinstall the top of the toilet back onto the base by tightening

the screws and replacing the white caps.

#3 INSTALLING THE BATTERY

1. Open the battery box and insert battery.

2. Close the battery box and attach the sticker onto one side of the

battery box.

3. Connect the wire.

4. Peel the other side of the sticker and fix it to the side of the

toilet.

#4 CONNECT BRAIDED HOSE

1. Connect the braided hose to the angle valve installed on step 1.

2. After tightening by hand, turn the nut ¼ turn with a wrench.

3. Open the supply stop and check for leaks.
