TRIVIEW THR15X Manuel utilisateur
OPERATING INSTRUCTIONS
THR15X / THR17X / THR19X
2
TABLE OF CONTENTS
zFCC information ------------------------------------------------------------------ 3
zCE information -------------------------------------------------------------------- 3
zSafety Precautions --------------------------------------------------------------- 3
1. Scope ----------------------------------------------------------------------------------- 5
2. Functional specification ---------------------------------------------------------- 5
3. Controls and indication ----------------------------------------------------------- 8
4. OSD Menu ----------------------------------------------------------------------------- 9
5. Regulatory Agency ---------------------------------------------------------------- 27
6. Mechanical --------------------------------------------------------------------------- 27
7. Reliability ----------------------------------------------------------------------------- 27
8. Appendix ----------------------------------------------------------------------------- 28
9. LCD CCTV Monitor Specification -------------------------------------------- 31
3
FCC INFORMATION
This equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Shielded interface cables and A.C. power cord, if any, must be used in order to comply
with emission limits.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
CE INFORMATION
The product must be installed according to the currently valid installation regulations
for EMC to guarantee the designed use and to prevent EMC problems.
The device supplied with this manual is according to the EC, EMC Directive,
89/336/EEC & LVD 73/23/EEC
Standard used for showing compliance with the essential requirements of the device:
EN 55022
EN 61000-3-2
EN 61000-3-3
EN 50130-4
EN 55024
LVD: EN60950-1
SAFETY PRECAUTIONS
1. Do not modify the three-prong grounding type monitor power plug in any way.
2. Operate this unit only from the type of power source indicated on the label.
3. Do not block or cover ventilation openings on the back or bottom of the monitor
cabinet.
4. Do not place this monitor near a radiator or heating vent.
4
5. Do not push objects of any kind through cabinet openings. This may result in fire
or electrical shock.
6. Before adding attachments always ask a service technician to perform routine
safety tests to determine that equipment is in safe operating condition. Ground
potential tests should be part of the routine safety check made by the service
technician.
7. Do not place monitor on an unstable cart, stand, or shelf where it may fall and
injure personnel or damage equipment.
8. Route power cords so that they cannot be walked upon or tripped over. Do not
allow anything to rest on the power cord.
9. Do not install monitor in wet areas, or where it may be exposed to rain or water.
Do not spill liquid of any kind on the unit.
10. Unplug the power cord from the unit before cleaning the display. Use only a damp
cloth. Do not use alcohol, spirits, or ammonia to clean the display. DO NOT
ATTEMPT TO CLEAN THE INTERIOR OF THIS UNIT- THIS ACTION MUST BE
PERFORMED BY THE SERVICE TECHNICIAN AS REQUIRED DURING
NORMAL MAINTENANCE.
11. Refer all servicing to qualified service personnel. REMOVAL OF BACK COVER
BY UNAUTHORIZED PERSONNEL MAY EXPOSE THE USER TO
DANGEROUS VOLTAGES OR OTHER HAZARDS.
12. Unplug the unit immediately and notify the service technician.
A. If liquid has been spilled into the display or the display has been exposed to
rain or water.
B. If the unit has been dropped or the cabinet damaged.
C. If fuses continue to blow.
D. If the power cord is damaged or frayed.
E. If a distinct change from normal operation is apparent.
When replacement parts are required, be sure that the service technician uses
components specified by the manufacturer which have the same characteristics as the
original parts. UNAUTHORIZED SUBSTITUTIONS MAY RESULT IN FIRE,
ELECTRICAL SHOCK OR OTHER HAZARDS.
Upon completion of any service or repairs, ask the technician to perform safety checks
to determine that the equipment is in safe operating condition.
WARNING: SERIOUS SHOCK HAZARDS EXIST
WITHIN THE COVERS OF THIS MONITOR. DO NOT
OPEN THE COVERS UNDER ANY CIRCUMSTANCES,
THERE ARE NO USER SERVICEABLE COMPONENTS
INSIDE
5
1. Scope
This specification is used to define the performance of THR15X/ THR17X/
THR19X color TFT LCD monitor. This system also supports both video input and PC
VGA/DVI input. In video input mode, the system can automatically detect the NTSC
signal and PAL signal. In PC mode, this system can support up to 1024x768 VESA
standard for THR15X and 1280x1024 VESA standard for THR17X/ THR19X.
This system provides frame buffer style de-interlace mechanism and 3D comb
filter to implement the high quality video pictures. The user friendly OSD menu is also
provided to make this system easy to operate.
2. Functional Specifications
Power Supply:
The power supply spec is listed below,
AC INPUT
*AC power input range: 100 – 240 VAC, 60/50Hz, 1.5Arms max.
* Power consumption: 45W max.
* Power efficiency: ≥80%
DC INTPUT
* DC JACK power input: 12V +/-10% 3A Min.
Video Characteristics:
Composite Video (CVBS): 1.0 Vp-p (0.5 – 1.5Vpp), Automatic switching from 75 Ω
unbalanced termination to Hi-Z with loop-through
operation.
Y/C (S-video): 1.0 Vp-p (0.5 – 1.5Vpp), Automatic switching from 75 Ωunbalanced
termination to Hi-Z with loop-through operation.
VGA Input:
Analog RGB: 0.707 Vrms.
VGA Timing Modes:
640 x 350 85Hz
640 x 400 85Hz
640 x 480 60/72/75Hz
720 x 400 85Hz
800 x 600 56/60/72/75HZ
1024 x 768 60/70/75Hz
1280 x 1024 60/75Hz (17”/19” only)
6
DVI Input:
DVI 1.0 Compatible Interface
Definition display resolutions:
15” XGA (1024 x 768 at 75 Hz).
17”/19” SXGA (1280 x 1024 at 75 Hz).
Audio Input:
Signal Level: 1.0 Vp-p
Controls: Front Panel: Push buttons
i : Channel select CVBS1, CVBS2, S-VIDEO, VGA/DVI (auto detect)
- / +: Scrolling the cursor or Adjust value
M : Selects On-Screen Display (OSD)
: Switch power On/Off
Indicators:
LED: Power-on (Green), Power Off (Orange), Suspend Mode (VGA mode only,
Orange flash), Freeze (Green flash)
Environmental:
Temperature:
Operating: 00C to +400C
Storage: -200C to +600C
Humidity:
Operating: 10% to 85% (non-condensing)
Storage: 10% to + 95% (non-condensing)
EDID:
This series of displays support EDID, but does not support DDC2B function.
7
Connectors:
A B C D E F G H I
VIDEO:
A AUDIO 1: Stereo phone jack input.
B CVBS 1: BNC loop-through output.
C CVBS 1: BNC input.
D CVBS 2: BNC loop-through output.
E CVBS 2: BNC input.
F S-VIDEO (Y/C): Mini-DIN 4-pin, input only.
PC:
GAUDIO 2: Stereo phone jack input.
HVGA + DVI: One (1) 24+5 pin DVI-I connector.
POWER:
IDC JACK: DC12V in, 3.5Ø
Set up sequence:
1. Make sure the power of PC and/or Video source were turned off.
2. Plug the power adapter, video signal and DVI (or VGA) cable to monitor.
3. Turns the PC and/or Video source power on.
4. Plug the AC power cord onto power adapter.
[Use reverse sequence to teardown the monitor]
8
3. Controls and indication
A- Channel button
zPress the button to select input signal.
B- - / +buttons
zPress the buttons to scrolling the cursor to desired function.
zPress the buttons to adjust the value of selected function in sub OSD menu.
C- Menu button
zPress the button to show the main OSD menu.
zAs a confirmation key during the OSD operation.
D- LED indication
zGreen: Power ON
zOrange: Power OFF (Stand by)
zFlash Orange: Sleep mode (PC mode only)
zFlash Green: Freeze status
E- Power button
zPress the button to turn ON or turn OFF the monitor.
9
4. OSD Menu
Hot Key：
Volume：Press – button to pop up the volume function，and then press – or +
button to adjust the volume value；press MENU button to exit OSD menu.
FREEZE：Press + button to start up the freeze function；press MENU or CH or +
or - button to exit OSD menu.
MUTE：When mute function on，press - button to pop up mute OSD；OSD menu
will go off in 2 sec.
Lock Key：Press and hold MENU buttons for 10 sec. to lock all key.
Unlock Key：Press and hold MENU buttons for 10 sec to unlock all key.
10
Prompt：
No Available Signal：Under VGA or DVI mode，the “NO SIGNAL” prompt will
shows in 2 sec. once cable unplug or signal loss such as PC get into standby
mode
，then shows “GOING TO SLEEP” in 2 sec.
Input signal can't support：Under VGA or DVI mode，the “NON SUPPORT
TIMING” prompt will shows on screen in 1 sec. during the input signal out of
monitor's display capability.
