SEE2USB 2.0 EXTERNALVIDEOADAPTER

NTRODUCTION

Thank you for purchasing the SEE2.The flexibility and universality of USB 2.0

technology makes it un-necessary to open your computer.The SEE2 enables you to

connect one or more display devices (CRT/LCD monitor,projector) to your desktop or

notebook PC. The connected display can act as mirrored or extended desktop of the

main display on your computer. Turn your monitor sideways, and enable portrait mode

for easier web and print viewing.

EATURES

wPC Resolution support up VGA1600 x 1200

wPrimary, Extended, Mirror and Rotated modes

wSupports multiple display devices on one PC

wUSB 2.0 compliant

wPlug-and-Play compliant

wWindows OS 2000 SP4 / Windows XPSP2 / Windows Vista

Please note that you can install up to six SEE2 on one PC at the same time.

YSTEM

EQUIREMENTS

wPC USB 2.0 Port

wSingle SEE2: 256MB RAM or Higher; Pentium 4 /

Celeron family or AMD K6/Athlon/Duron family with 1.5GHz

wMultiple SEE2 Units: 512MB RAM or Highe

OPERATING SYSTEMS SUPPORTED

wWindows OS 2000 SP4 /Windows XP SP2 / Windows Vista

ACKAGE

ONTENTS

wSEE2

wCD with User Guide and Installation Driver

wQuick Start Guide

EGULATORY

OMPLIANCE

wFCC / CE / C-tick / VCCI

SEE2USB 2.0 EXTERNALVIDEOADAPTER

UPPORTED

ISPLAY

ESOLUTIONS

VGA

PC Resolutions Supported 16 Bits 32 Bits

1600 x1200 Vn/a

1680 x1050 Vn/a

1400 x1050 VV

1440 x900 VV

1280 x1024 VV

1280 x960 VV

1280 x800 VV

1280 x768 VV

1152 x864 VV

1024 x768 VV

800 x600 VV

SEE2USB 2.0 EXTERNALVIDEOADAPTER

EVICE

NSTALLATION

INDOWS

2000/XP

OFTWARE

NSTALLATION

Installing the device driver enables your computer’soperating system to recognize the

SEE2. Please check what operating system you are using, and ensure you are

referring to the appropriate installation procedure before you begin. Please make sure

the SEE2 is unplugged from your PC or Notebook before executing the setup

program.

Step 1.

Insert the Driver CD into the CD-ROM

drive; the setup program should

launch automatically. If the setup

program does not begin

automatically, click Start, Run and

type D:\Setup.exe”(where D: is the

path of your CD-ROM drive). Youcan

also access it from My Computer

Driver Installation Wizard, click Next”

to continue.

Step 2.

License Agreement; please review

and select I accept the terms of

the license agreement.”Click

Next”to accept the License

Agreement.

Step 3.

The Microsoft Software Installation

Certificate warning dialogue box

will be displayed under Windows

XP OS up to 6 times. Please

select Continue Anyway”to

continue with the device driver

installation. This will not affect the

device driver installation or usage.

The Microsoft Certificate warning

dialogue boxes will not appear once

the driver receives the WHQL

certification.

SEE2USB 2.0 EXTERNALVIDEOADAPTER

Step 4.

Click Finish”to exit the Driver

Wizard.

Step 5

Reboot your computer

SEE2USB 2.0 EXTERNALVIDEOADAPTER

INDOWS

2000/XP

ARDWARE

NSTALLATION

Step 1

Connect the external display device (monitor/projector) to the VGA connector of the

SEE2 and ensure the display device is on

Step 2

Plug the SEE2 into an available USB 2.0 port

of your PC or Notebook. Then your computer

will show the Hardware Installation Wizard,

please select No, not this time”for

checking windows update, and click Next”

Step. 3

Select Install the software automatically

(Recommended)”. Click Next”to continue

Step 4

Please select Continue Anyway”to

continue with the installation. It will not

affect the device installation and the device

usage

The Microsoft Certificate warning dialogue

boxes will not appear when the driver

receives the WHQL certification.

SEE2USB 2.0 EXTERNALVIDEOADAPTER

Step 5

Click Finish”to close the wizard

Step 6

Please select Continue Anyway”to

continue with the device driver installation.

It will not affect the device driver installation

and the device usage

The Microsoft Certificate warning dialogue

boxes will not appear when the driver

receives the WHQL certification.

Step 7

Please select Continue Anyway”to

continue with the device driver installation.

It will not affect the device driver installation

and the device usage

The Microsoft Certificate warning dialogue boxes

will not appear when the driver receives the WHQL

certification.

SEE2USB 2.0 EXTERNALVIDEOADAPTER

Step 8A

FOR MULTIPLE SEE2 UNITS

Please select No, I will restart my

computer later.”and click Finish”to

continue the installation of next SEE2.

Repeat the Hardware Installation Procedure Step 1

- 7 and 8 A for all additional SEE2

units, then after all units are installed, move on to 8 B. Ensure that all units are connected

to monitors that are powered on.

Step 8B

For SINGLE SEE2

Please select Yes, I want to restart my

computer now.”and click Finish”to

complete the driver installation.

SEE2USB 2.0 EXTERNALVIDEOADAPTER

ERIFYING

EVICE

RIVER

NSTALLATION IN

INDOWS

2000/XP

The following procedure allows you to verify the device driver installation. It is

optional, but a useful troubleshooting tool.

Right click My Computer”→Properties”→Hardware”→Device Manager”.

Double click Displayadapters”, and Universal Serial Bus controllers”.
