Triton RT2000 (X2) Manuel utilisateur

TDN 07100-00098

THIS AREA FOR SERVICE PROVIDER

CONTACT INFORMATION:

Oct 31 2008

Model RT2000 (X2)

Quick RefeRence Guide

MANAGEMENT FUNCTIONS

- Access instRuctions -

1. AtAtM WelcoMe scReen, pRess And hold doWn the <ctRl>

key (loWeR-RiGht coRneR of keypAd), pRess <1> key, then ReleAse

both keys. the pAssWoRd Access pRoMpt is displAyed.

2. enteR pAssWoRd And select <enteR>. the MAnAGeMent functions MAIN MENU is displAyed.

TERMINAL CONFIGURATION REPORT

folloW Access instRuctions to enteR MAnAGeMent functions. select

DIAGNOSTICS > TERMINAL STATUS.

CONFIGURATION SUMMARY: this suMMARy is AcoMpRehensive

RepoRt of cuRRent teRMinAl confiGuRAtion And hARdWARe stAtus

infoRMAtion.

note: itis hiGhly RecoMMended thAt this RepoRt be pRinted And sAved AfteR initiAl setup And WheneveR

chAnGes ARe MAde to the teRMinAls confiGuRAtion.

RESTART / SHUTDOWN TERMINAL

RESTART TERMINAL: this function Reboots the teRMinAl.

folloW Access instRuctions to enteR MAnAGeMent functions. select

SYSTEM PARAMETERS.

SHUTDOWN TERMINAL: this function poWeRs-doWn the teRMinAls

opeRAtinG systeM. When pRoMpted thAt shutdoWn is coMplete, tuRn

on/off sWitch on poWeR supply to <off> position.

DIAGNOSTICS

PURGE: this instRucts the dispenseR to ReMove Any notes (jAMs) in

feed pAth.

folloW Access instRuctions to enteR MAnAGeMent functions. select

DIAGNOSTICS > DISPENSER.

TEST DISPENSE: this instRucts the dispenseR to dispense minimum

one note fRoM eAch instAlled cAssette into the Reject cAssette/AReA.

RESET / TEST PRINTER: this

instRucts the pRinteR to Re-

initiAlize And peRfoRM Atest

pRintout.

select DIAGNOSTICS > PRINTER.

pRint lAst X: tovieW/pRint pReviously Audited oR unAudited

RecoRds, use the pRint lAst X option.

JOURNAL FUNCTIONS

folloW Access instRuctions to enteR MAnAGeMent functions. se-

lect JOURNAL.

eXAMple: enteRinG the nuMbeR ‘50’ Will let you vieW the lAst 50 tRAnsActions/events thAt hAve oc-

cuRRed. you MAy pRint to the Receipt pRinteR.

dAy close: this option is used to coMplete dAily bAlAncinG of

the AtM With the pRocessoR. totAls ARe cleARed And sWitched to

the neXt business dAy.

folloW Access instRuctions to enteR MAnAGeMent functions. select

TERMINAL CLOSE FUNCTIONS.

tRiAl close: this option functions like AdAy close eXcept the totAls ARe not cleARed.

CLOSE FUNCTIONS

CASSETTE CLOSE FUNCTIONS

(fRoM the fRont displAy)

folloW Access instRuctions to enteR MAnAGeMent functions. select TERMINAL CLOSE functions.

select CASSETTE CLOSE.

select cAssette(s) to close. A check MARk ( √)

identifies Which cAssette(s) ARe selected. pRess <en-

teR>.

AfteR cAssette(s) hAve been ReinseRted in the dis-

penseR, pRess <enteR>.

A close RepoRt is displAyed to be pRinted oR sAved.

this opeRAtion Will Reset the nuMbeR of bills in the

cAssette(s) to zeRo (0). pRess <enteR>.

ReMove And Replenish the selected cAssette(s).

folloW cAssette ReplenishMent pRoceduRes.

plAce selected cAssette(s) IN SERVICE. pRess

<enteR>. note: For tDm-200/250 Dispensers.

enteR cAssette QuAntity (nuMbeR of notes, not

vAlue) foR the selected cAssette(s). pRess <enteR> to

Accept entRy. RepeAt foR eAch selected cAssette.

A tRiAl cAssette close RepoRt AutoMAticAlly is

displAyed to be pRinted oR sAved. pRint And RetAin Acopy

foR stARtinG point RefeRence. pRess <enteR> to RetuRn

to close functions.

**IMPORTANT**

ensuRe the MultipleAMount pARAMeteR MAtches

the denoMinAtion of cuRRency in eAch note cAssette!

CASSETTE CLOSE FUNCTIONS

(fRoM the ReAR opeRAtoR seRvice pAnel (touchscReen)







pRess to stARt.





enteR pAssWoRd.

select “cAssette close”.

close cAssette(s) - touch cAs-

sette options on touchpAd until

“AsteRick” AppeARs. select “con-

tinue”.



cAssette close RepoRt AppeARs.

pRint RepoRt. pRess “eXit” When

coMpleted.

*** Cassette Close ***

Cassette A

Last Close Date/Time:

6/4/2007 7:49:39 AM

Start Quantity:

Qty: 200

Amount: $2000.00

Dispensed:

Qty: 50

Amount: $500.00

Remaining:

Qty: 150

Amount: $1500.00



ReMove /Replenish cAssette(s).

pRess “enteR”.

plAce cAssettes “in-seRvice”.

touch cAssette options on touch-

pAd until “AsteRick” AppeARs.

select “continue”.



tRiAl cAssette close RepoRt Ap-

peARs. pRint RepoRt. pRess “eXit”

When coMpleted.



enteR cAssette Qty (eAch).

pRess “ok”.

sele ct “teRMinAl cl ose

functions”.

Select the cassettes to close.

WARNING: Cassette totals will be

reset for the selected cassettes

* Cassette A: $10.00

* Cassette B: $20.00

Continue Exit

Select the cassettes to place in

service.

* Cassette A: $10.00

* Cassette B: $20.00

Continue Exit

Cassette Quantity - Cassette A:

Please enter the number of bills that

are in the cassette (not the value).

1 2 3

456

789

< >

CANCEL

CHANGE

200

You may now remove and replenish

the cassettes. Press ENTER when

done.

Enter

*** Trial Cassette Close ***

Cassette A

Last Close Date/Time:

6/4/2007 7:55:39 AM

Start Quantity:

Qty: 200

Amount: $2000.00

Dispensed:

Qty: 0

Amount: $00.00

Remaining:

Qty: 200

Amount: $2000.00

REPLENISH CASSETTE(S)

unlock / open vAult

cAbinet dooR. the

dispenseR is Mount-

e d t o AslidinG

tRAy. note: the

t r ay Does not

neeD to be extenDeD

For currency re -

plenishment.

ReMove Reject cAssette by GRAspinG the

boX And pullinG fRoM the dispenseR.

note: the Rt2000 utilizes tdM dispenseRs. cuR-

Rency ReplenishMent foR AcAssette is the sAMe

WhetheR its AsinGle oR duAl-cAssette dispenseR

MechAnisM.

count the nuMbeR of bills thAt ReMAin in

the cAssette, if Any.

count the nuMbeR of bills thAt ARe beinG

Added to the ReMAininG notes.

the totAl of these AMounts Will be en-

teRed in the “enteR cAssette QuAntity”

pRoMpt foR cAssette close pRoceduRe.

plAce cuRRency in the cAssette And sloWly

ReleAse the lAtch AlloWinG the pAckeR

plAte to Move foRWARd AGAinst the notes.

unlock note cAs-

sette With supplied

key. o pen lid.

Move pusheR plAte

t o WA R d s ReAR o f

cAssette And secuRe

in plAce With key

lAtch MechAnisM.

STEP ACTION

close lid, lock

cAssette And Rein-

seRt bAck into the

dispenseR. ensuRe

cAssette is fully in-

seRted.

ReMove the note

cAssette(s) b y

GRAspinG the GReen

hAndle And pull

fRoM the dispenseR.

plAce cAssette(s) on AflAt suRfAce.

close, lock, And ReinseRt the Reject cAs-

sette bAck into the dispenseR.

do not Recycle Rejected notes!

unlock And ReMove Any Rejected notes.

STEP ACTION

REPLENISH RECEIPT PAPER

STEP ACTION

pull ReleAse pin,

GRAsp hAndle, And

RotAte pRinteR As-

seMbly up to the

seRvice position.

instAll neW pApeR

Roll/ spindle in

bRAcket.

pApeR feeds fRoM

bottom of Roll!

feed end of pApeR

oveR bAR And into

pRinteR tA k e -u p

slot. pRinteR Will

A u t o M At i c A l l y

GRip And pull pApeR

into feed pAth.

note: this pRoceduRe ReQuiRes teRMinAl is poWeRed up.

ReMove spent pA-

peR Roll And spin-

dle fRoM pApeR

bRAcket.

open the ReAR cAb-

inet sleeve dooR.

ifpApeR ReMAins on

Roll, cut oR teAR

pApeR betWeen

Roll And pRinteR.

ReleAse (Open) the blue tension leveR

shoWn. ReMove Any pApeR fRoM the pRinteR/

cutteR AsseMbly.

Move the ten-

sion leveR bAck

to the CLOSED

position. Ro-

tAte doWn the

pRinteR AsseM-

bly.

Open

Closed

note: this position

also allows receipt

access For printing

reports iF using the

rear service panel

COMBINATION LOCKS

intRoduction

the secuRity cAbinet cAn be secuRed usinG eitheR AMechAnicAl oR electRonic coMbinAtion lock. this pAGe coveRs

hoW to opeRAte the coMbinAtion of eitheR lock.

opeRAtinG the MechAnicAl lock

unlockinG the lock

theRe ARe tWo MARks on the diAl RinG. the indeX At the top is used foR openinG the lock, the indeX 30 deGRees to

the left is used only When chAnGinG the coMbinAtion.

the diAl should AlWAys be tuRned sloWly And evenly. A Revolution is counted eAch tiMe the selected nuMbeR is

AliGned With the openinG indeX. Donot turn the Dial back to compensate For over-Dialing anumber.if, When diAlinG

the coMbinAtion, Any nuMbeR is tuRned beyond the indeX, the entiRe seQuence Must be RepeAted.

unlockinG 3-nuMbeR coMbinAtions (foR eXAMple, “50-25-50”)

1. tuRn the diAl to the leFt At leAst fouR (4) coMplete tuRns to cleAR the coMbinAtion lock to Accept the

coMbinAtion.

2. usinG the ‘openinG indeX’, tuRn the diAl to the leFt, stoppinG When ‘50’ is AliGned With the openinG indeX,

the Fourth tiMe.

3. tuRn the diAl to the right, stoppinG When ‘25’ is AliGned With the openinG indeX, the thirD tiMe.

4. tuRn the diAl to the leFt, stoppinG When ‘50’ is AliGned With the openinG indeX, the seconD tiMe.

5. tuRn the diAl sloWly to the right until the bolt RetRActs.

opeRAtinG the electRonic lock

the electRonic lock coMbinAtion consists of siX diGits. upon ARRivAl, the coMbinAtion of the lock should AlReAdy

be pReset to 1-2-3-4-5-6.

enteRinG the coMbinAtion

1. enteR the pReset coMbinAtion And check foR pRopeR opeRAtion. AfteR eAch keypRess, the lock Will beep. AfteR

the finAl diGit hAs been enteRed, the lock Will beep twice, And the open peRiod Will beGin.

2. When AvAlid coMbinAtion hAs been enteRed, the opeRAtoR Will hAve AppRoXiMAtely 4 seconDs to open the lock.

3. toopen the lock, tuRn the Dial clockWise.

4. AfteR the lock is opened, the cAbinet dooR MAy be opened.

lockout feAtuRe

the lock includes A‘wrong try penalty’ lockout feAtuRe thAt pRevents entRy fRoM unAuthoRized peRsonnel. this

feAtuRe peRfoRMs As folloWs:

• Entryoffour(4)consEcutivEinvalidcombinationsstartsa5-minutEdElaypEriod.

- led flAshes Red At ten (10) second inteRvAls.

• atthEEndofthEdElaypEriod, two(2)morEconsEcutivEinvalidcombinationswillrEstartanadditional

5-Minute delAy.
