Tripp Lite PowerVerter PV1250FC Manuel utilisateur

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model Number: PV1250FC

PowerVerter® Plus 1250W Industrial-Strength Inverter with 2 Outlets

Highlights

12V DC input; 120V AC output; 2 outlet

1250 watts continuous output

Peak surge output: OverPower (up to 1 hour) - 1875 watts, Double-Boost (up

to 10 seconds) - 2500 watts

High efficiency power conversion

Automatic overload protection

Description

Utilize you vehicle's battery to efficiently power work site power tools, pumps, as well as your laptop computer. Continuously supplies 1250 watts of

120VAC power to (2) AC outlets from any 12VDC battery source. Frequency control locks AC output at 60Hz for operating stability of motor loads

and other inductive loads with high current startup requirements.

NOTE: To protect against high current draw that may occur during inverter failure, a fuse link rated at 200a should be positioned no more than 18"

from the PV1250FC's battery in the positive line.

Applications

Ideal for power tools, pumps, fans, desktop computer systems, laptops, portable electronics, battery chargers for cell phones and games,

full size TV/DVD & stereo systems, camcorders, lighting and other AC applications under 1250 watts continuous/2500 watts peak.

Package Includes

PV1250FC inverter

Instruction manual

Features

Allows users to run large, motorized AC appliances from any 12V battery or automotive DC system

Converts 12V DC battery power to 120V AC power

1,250 watts continuous output power

Peak output power: OverPower (up to 1 hour) - 1875 watts, Double-Boost (up to 10 seconds) - 2500 watts

2 outlets; DC input terminals for 12V battery connection

Frequency control for operating stability

High-efficiency operation conserves batteries to prolong run time

Diagnostic LEDs indicate load level (high, medium, and low) and battery charge (high, medium, and low)

DC fusing protects inverter against overload

RJ45 port allows connection of APS/PowerVerter Remote Switch (APSRM4)

Automatic overload shutdown

Ignition interlock jack

Specifications

OUTPUT

Frequency

compatibility

60 Hz

Output watts 1250

Continuous output

capacity (watts)

1250

Peak output capacity

(watts)

2500

Output nominal

voltage

120V

Output voltage

regulation

Maintains PWM sine wave output voltage of 120 V AC (+/-5%)

Output frequency

regulation

60 Hz (+/- 0.3 Hz)

Overload protection Circuit breaker

Outlet quantity / type 2 NEMA 5-15R

INPUT

Recommended

Electrical Service

Requires 12V DC input source capable of delivering 127A for the required duration (when used at full capacity). For

automotive applications, professional hardwire installation with 200A battery system fusing is recommended.

Maximum input amps

/ watts

Full continuous load - 127A at 12V DC, No load - 2.2A at 12V DC

Input connection type Set of 2 DC input terminals

Input cord length

details

User supplies cabling. 4 gauge or larger recommended.

Voltage compatibility

(VDC)

BATTERY

DC system voltage

(VDC)

LEDS ALARMS & SWITCHES

Switches 3 position on/off/remote switch enables simple on/off power control plus "remote" setting that enables distant on/off

control of the inverter system when used in conjunction with optional APRM4 remote

Front panel LEDs Set of 6 LEDs offer continuous status information on load percentage (6 levels reported) and battery charge level (7

levels reported). See manual for sequences.

PHYSICAL

Shipping Dimensions

(HWD/in)

12.5 x 11 x 10.75

Shipping Dimensions

(HWD/cm)

31.75 x 27.94 x 27.31

Shipping weight (lbs) 24.8

Shipping weight (kg) 11.2

Unit Dimensions

(HWD/in)

7 x 8.75 x 9

Unit Dimensions

(HWD/cm)

17.78 x 22.23 x 22.86

Unit weight (lbs) 23.2

Unit weight (kg) 10.5

Cooling method Fan

Material of

construction

Polycarbonate

Style Heavy-duty

Form factors

supported

Mounting slots enable permanent placement of inverter on any horizontal surface (see manual for additional

mounting information)

ENVIRONMENTAL

Relative Humidity 0-95% non-condensing

SPECIAL FEATURES

Appearance Black color

Remote control

capability

Yes

WARRANTY

Product Warranty

Period (Worldwide)

1-year limited warranty

Related Items

Optional Products

Related Model Description Qty.

APSRM4 Remote Control Module - for Tripp Lite Inverters and Inverter/Chargers 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

http://www.tripplite.com/sku/PV1250FC.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
