Tripp Lite APSX1012SW Manuel utilisateur
230V, 1000W PowerVerter APS INT Inverter/Charger
with Pure Sine Wave Output
MODEL NUMBER: APSX1012SW
Description
Provide clean, reliable pure sine wave power for all your alternative energy needs with the Tripp Lite
APSX1012SW.This inverter/charger supplies 1000 watts of continuous 230V AC power. Reliable large
transformerdesign and frequency control powers resistive loads like refrigerators,motors, pumps, compressors
and laser printers as well as electronic loads like TV’s, computers, power tool and battery chargers. The 3-stage
charging systemwill properly charge and maintain your vehicle's battery or separate batterybank. The charge
rate is selectable so you can use a variety of battery sizes ,as well as multiple batteries to fit your run time
requirements.
Features
Pure sine wave output
Continuous output inverter and high power battery charger
Quiet, high efficiency operation, high surge capacity and low idle current
Supply energy to various loads such as resistive load
Seamless transfer switching
Load sensing adjustable
Unlimited back up time with user supplied batteries
Specifications
OVERVIEW
Intended Application Emergency Backup Power
OUTPUT
Highlights
Clean Pure Sine Wave output
12V DC or 230V AC input; 230V,
50 Hz output (hardwired)
1000 watts continuous output,
2000 watts peak output
Selectable 4/40 amp wet/dry cell
battery charger
Quiet, high efficiency operation,
high surge capacity and low idle
current
Seamless transfer switching
Applications
Multipurpose inverter/charger with
seamless transfer switching. Uses
include conversion vans, fleet service
vehicles a stand alone power source
for off grid alternative energy with
transfer times of 8-12 milliseconds.
Package Includes
APSX1012SW inverter/charger
Instruction manual with warranty
information
1 / 3
Frequency compatibility 50 Hz
Output watts 1000
Continuous output capacity (watts) 1000
Peak output capacity (watts) 2000
Output nominal voltage 230V
Output voltage regulation Nominal 230v +/- 5% until LBW. Peak coltage 360v
Output frequency regulation 50/60 Hz (+/- 0.5 Hz)
Overload protection Includes 15A input breaker dedicated to the charging system and 15A output breaker for AC output loads
Outlet quantity / type Hardwire
INPUT
Nominal Input Voltage(s) Supported 230V AC
Recommended Electrical Service
DC INPUT: Requires 12VDC input source capable of delivering 240A for the required duration (when used at full
continuous capacity - DC requirements increase during OverPower and DoubleBoost operation). For automotive
applications, professional hardwire installation with 400A minimum battery system fusing is recommended.
Maximum input amps / watts
DC INPUT: Full continuous load - 240A at 12VDC. AC INPUT: 17 amps at 230VAC with full inverter and charger
load (8.7A max charger-only / combined input load to support charger and AC output is automatically controllable to
66%-33%-0% based on AC output loading using the charger limiting set points - see manual for setting instructions)
Input connection type DC INPUT: Set of 2 DC bolt-down terminals. AC INPUT: Hardwire via built in junction box with cover plate
Voltage compatibility (VAC) 230
Voltage compatibility (VDC) 12
BATTERY
Expandable battery runtime Runtime is expandable with any number of user supplied wet or gel type batteries
DC system voltage (VDC) 12
Battery charge Includes 4/40 amp DC charging system adjustable.
LEDS ALARMS & SWITCHES
Alarms Audible status indicators 10.5V (low battery)/21V start alarm
Switches The inverter provides a RJ-45 port for optional APSRMSW remote control. RJ45 port operates with standard RJ485
interface (APSRMSW sold separately)
Front panel LEDs Set of front panel LED's display inverter status, charger status, as well as battery voltage status
PHYSICAL
Unit Dimensions (HWD/in) 7.25 x 8.75 x 18
Unit Dimensions (HWD/cm) 18.41 x 22.22 x 45.72
Unit weight (lbs) 35.5
Unit weight (kg) 16
Cooling method Fan
2 / 3
Material of construction Powder coated Steel
Receptacle Color Grey
Form factors supported Mounting slots enable permanent placement of inverter on any horizontal surface (see manual for additional
mounting information)
ENVIRONMENTAL
Relative Humidity 0-95% non-condensing
SPECIAL FEATURES
Appearance gray color
Remote control capability Yes
WARRANTY
Product Warranty Period (U.S. &
Canada) 2-year limited warranty
Product Warranty Period
(International) 2-year limited warranty
Product Warranty Period (Mexico) 2-year limited warranty
Product Warranty Period (Puerto
Rico) 2-year limited warranty
Related Items
Optional Products
Model Number Description Qty.
APSRMSW Inverter Remote Control Module for Tripp Lite Pure Sine Wave Inverter/Chargers 1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at:
http://www.tripplite.com/sku/APSX1012SW.
© 2014 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice. Photos may differ slightly from final products.
3 / 3
