Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: S055-38I

38-inch Internal SCSI U2/160 SCSI-LVD/SE 5-Drive Ribbon Cable with Terminator (6xHD68 M)

Highlights

Cable includes active T-type LVD/SE terminator

UL-rated Amphenol brand cable

Connects up to 5 drives

Description

Introducing Tripp Lite's internal SCSI Ultra2/U160 5-drive LVD ribbon cable with an active U160 terminator. This 38 inch cable is used to connect up

to 5 SCSI devices to a SCSI host controller card. The cable is UL rated and is made with twist and flat "branded" ribbon. Because the cable is

backwards compatible, it will support SCSI 1,2 & 3 devices such as CD-ROMs and Hard Drives. All Tripp Lite SCSI products, regardless of the SCSI

generation, meet the latest SCSI specifications of ANSI (American National Standards Institute).

System Requirements

Wide SCSI controller card

Internal SCSI drives and devices with HD68 Pin interface

Package Includes

38-in. internal U2/160SCSI-LVDSE 6Conn 68Pin 5Drive with active terminator

Features

Ribbon cable connects up to 5 internal SCSI drives/devices to your internal SCSI controller

HD68 male connectors

Cable includes active terminator (T-type) LVD/SE terminator with local chip (ART IDC type)

UL rated twist and flat "branded" cable

SCSI U160 cables include active terminators which compensate for impedance mismatches

All Tripp Lite SCSI products, regardless of the SCSI generation, meet the latest specifications of ANSI

Tripp Lite offers a complete line of internal and external solutions for SCSI/RAID and fibre channel ranging from the very latest Ultra 320 to

legacy SCSI-1 and every combination in between

Specifications

OVERVIEW

Drives Supported 5

Intended Application Connecting Drives

Model Type SCSI Ultra160 Ribbon

INPUT

Cable Length (in.) 38

PHYSICAL

Color Gray

Style Ribbon & Internal Cables

CONNECTIONS

Connector A

INTERNAL HD68 (MALE)

Connector B

HD68 (MALE)

Number of Connectors 6

WARRANTY

Product Warranty Period

(Worldwide)

Lifetime limited warranty

Related Items

Optional Products

Product Type Related Model Description Qty.

SCSI Cables S055-38I 31-inch Internal SCSI U2/160 SCSI-LVD/SE 4-Drive Ribbon Cable with

Terminator

(5xHD68 M)

SCSI Cables S212-000 Internal SCSI Adapter

(HD68F/50F Socket IDC)

SCSI Cables S222-000 Internal SCSI Adapter SCA

(Ultra Micro 80F/HD68F)

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=2355.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
