Tripp Lite P501-100 Manuel utilisateur

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: P501-100

100-ft. SVGA/VGA Easy Pull Gold Monitor Extension Cable with RGB Coax, (HD15 M/F)

Highlights

Two-piece design runs through conduit or other tight areas

Threaded circular DIN connector provides secure reattachment

75ohm mini-coax (RGB) and paired video wire construction delivers

outstanding signal quality

Superior-molded cables with foil and braid shielding for maximum EMI/RFI

protection

Description

Tripp Lite's 100 ft. SVGA/VGA Easy Pull Monitor Extension Cable w/ Connectors makes running long length video cables a snap. The pull-apart

design allows the cable to be run through conduit or other tight areas that a HD15 connector wouldn't fit through. Diameter of the circular DIN end is

only 7/8". Circular Easy Pull connector is threaded to ensure maximum security once the cable is reattached. The mini-coax (RGB) and paired video

wire construction delivers superior signal quality. Double shielding (foil and braid) provides maximum EMI/RFI protection. Both the high density

DB15 male and high density DB15 female connectors are molded and have integral strain relief to ensure they last a long time.

Applications

Suspended ceilings, walls, conduit or anywhere too small to fit a standard HD15 cable during installation.

Package Includes

100 ft. Male/Female Easy Pull SVGA/VGA Monitor Extension Cable w/ Connectors

Wallplate with HD15 cutout

Features

Two-piece design runs through conduit or other tight areas

Threaded circular DIN connector provides secure reattachment

Superior-molded cables with foil and braid shielding for maximum EMI/RFI protection

RGB 75-ohm coax construction for maximum video resolution

HD15 male to HD15 female molded connectors

Supports resolutions up to 1600 x 1200

Specifications

OVERVIEW

Intended Application Connecting Peripherals

Display Style Easy Pull

INPUT

Cable Length (ft.) 100

Cable Length (m) 30.48

PHYSICAL

Color Black

Style Video Cables

CONNECTIONS

Connector A

HD15 (MALE)

Connector B

HD15 (FEMALE)

CERTIFICATIONS

Certifications RoHS-Compliant

WARRANTY

Product Warranty Period

(Worldwide)

Lifetime limited warranty

Related Items

Optional Products

Product Type Related Model Description Qty.

Cable Adapters P160-000 Compact Gold HD15 Gender Changer

(HD15F/F)

Cables and Accessories P120-000 DVI Male to VGA Female Adapter

(Analog DVI-M to HD15F)

Switches P158-000 Compact Gold HD15 Gender Changer

(HD15M/M)

Video Cables & Adapters P501-050 50-ft. SVGA/VGA Easy-Pull Gold Monitor Extension Cable with RGB

Coax, (HD15 M/F)

Video Cables & Adapters P503-050 50-ft. Easy Pull All-in-One SVGA/VGA Monitor Cable with Connectors,

(HD15 M/M)

Video Cables & Adapters P503-100 100-ft. Easy Pull All-in-One SVGA/VGA Monitor Cable with RGB Coax,

(HD15 M/M)

Video Splitters B114-002-R VGA/SVGA 350MHz Video Splitter - 2 Port

(HD15 M/2xF)

Video Splitters B114-004-R VGA/SVGA 350MHz Video Splitter - 4 Port

(HD15 M/4xF)

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3767.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
