Triotech TYPHOON Manuel utilisateur

Preliminary – January 2009

USER MANUAL

TYPHOON

Triotech Amusement Inc.

190 Des Industries Lavaltrie, Quebec (Canada)

J5T 3R2

Tel.: 450.586.5009

Toll free: 1-888-IN-LINE-4

Fax: 450.586.0299

e-mail: [email protected]

Dear valued customer,

Congratulations and thank you for purchasing TRIOTECH

AMUSEMENT’s Typhoon. You will not be disappointed with your

purchase. Your 2-seat theater is coin-operated and does not require

attendant. Featuring 4.1 Surround Sound and a 42” LCD screen this

dual-actuator motion platform is the most realistic simulation avail-

able in coin-op.

Sincerely,

TRIOTECH

CAUTION

Typhoon requires a dedicated 120V. 15 amp circuit or 220V. 7.5amp or the

machine may experience sporadic technical difficulties. Your Typhoon should

not share a breaker with other deluxe or motion based cabinets.

Determine Optimum Location

The game location must be free of: exposure to direct sunlight, high humidity, dust, salt mist,

high heat, or extreme cold. If installed in an unusually hot location, allow additional clearance

between ventilation slots in the game and any structure or object that would tend to restrict air

circulation.

TYPHOON Ships in one (1)

crate

Typhoon reception

Reception

Package approximate dimensions:

90” x 56” x 80”

LIST OF SUPPLIED ASSEMBLY PARTS

Reception

Item Description Photo/ Image Qty.

1Main cabinet

2Motion seat module

3Header assy

4Fan’s cover (right

&left)

5Hardware box

(inside of the coin

door; the access is

from the front of the

machine; a bag with

the necessaries keys is

attached to the coin

door's door)

Package Content

HARDWARE BOX MANIFEST

Reception

Bag

bin

No. IMAGE DESCRIPTION SIZE QTY. SPARE

1SD-100-0215 FLAT WASHER NEORENE #10 26

2SD-100-0187 PAN HEAD QUADREX

DRIVE #10-24 x 3/4" 26

3SD-100-0216 FLAT WASHER NEOPRENE #14 12

SD-100-0190

PAN HEAD QUADREX

DRIVE 1/4-20 x 3/4" 12

5SD-100-0328 LOCK WASHER 1/2" 6

6SD-100-0047 FLAT WASHER 1/2 “ 6

SD-100-0342

HEX.MACHINE SCREW 1/2 “-13 x 4” 6

NECESSARY TOOLS

TO COMPLETE ASSEMBLY

Installation

No. Tools Description /Image Application

1Forklift Capacity over 1000 lb

Appropriated long forks attached (~65”) Put the carrying package in the

place

2Socket 3/4"

Install the seat module (pg.14)

3Wrench 3/4”

Adjust the height of the cabinet

and seats (pg.9 and 14)

4Screwdriver

no.2 (square)

(Screw #10)

Phillips #2

Install the fan’s covers on to the

header(pg.10 )and the header to

the cabinet (pg. 11)

5Screwdriver

no.3 (square)

(Screw 1/4)

Phillips #3

Install the header on the cabinet

(pg.11)

SPACE REQUIREMENTS

Installation

For installation, the required space is ~ 15’ X 10’

When fully assembled, the required space will be ~ 7.5’ X 8’

Uncrating

Installation

1 - Start by removing the header assem-

bly from the seat.

2- Remove the header support

3- Remove the back legs holder

4-Pull the seat out of the cabinet about 6’’

or 15cm. Then pull the 3 cables out of the

hole one by one as shown in the picture

below.

5- Remove seat assembly from the crate.

6- Remove cabinet from the crate and

move in the desired final location.

- Locate the hardware box inside of the

coin door

- You will find a description of the hard-

ware on the bag.
