Trilogy Mentor XL Manuel utilisateur

Mentor XL

Master Reference Generator

User Guide

ISSUE 6.0

TRILOGY COMMUNICATIONS LIMITED

26 Focus Way

Andover

Hampshire

SP10 5NY

United Kingdom

Telephone. +44 (0) 1264 384000

Fax. +44 (0) 1264 334806

www.trilogycomms.com

Mentor XL

The Copyright of the information and drawings in this document is

the property of Trilogy Communications Limited of Andover,

Hampshire and is neither to be reproduced in whole or in part, nor

disclosed to a third party, without the prior written consent of

Trilogy Communications Limited.

The information in this document has been carefully compiled and

checked for accuracy. However, Trilogy Communications Limited

accepts no responsibility for inaccuracies which may occur and,

further, reserves the right to make changes to specification or

design without prior notice.

Comments or correspondence concerning this manual should be

addressed to the Publications Manager at the address given at the

front of this User Guide.

DOCUMENT NUMBER

36000600.docx

Issue 6.0

Issue

Date

Reason for Change

5.00

2 November 2011

V5.0.0.0 software

5.10

30 November 2012

V5.0.0.9, changes to GPS menus

5.20

14 May 2013

Introduced GPS option board 360-15-10

5.30

31 May 2013

Added extra detail for GPS

5.90

2 July 2015

Major re-format - draft

6.0

27 March 2016

New logos

Page 2 of 84 Trilogy Communications

Mentor XL

CONTENTS

1. APPLICATION...........................................................................................................................................6

1.1 INTRODUCTION.......................................................................................................................................... 6

1.2 VECTOR FOR MENTOR XL ............................................................................................................................ 6

1.3 AVAILABLE FEATURES AND OPTIONS .............................................................................................................. 7

1.4 TECHNICAL SUPPORT .................................................................................................................................. 8

1.5 WARRANTY............................................................................................................................................... 8

1.6 COMMON CONFIGURATIONS ........................................................................................................................ 8

2. INSTALLATION .........................................................................................................................................9

2.1 UNPACKING .............................................................................................................................................. 9

2.2 RACK MOUNTING ...................................................................................................................................... 9

2.3 EARTHING REQUIREMENTS........................................................................................................................... 9

2.4 MAINS CONNECTION AND FUSING............................................................................................................... 10

2.5 REAR PANEL CONNECTIONS ....................................................................................................................... 11

2.6 ANALOGUE AUDIO /REMOTE CONNECTOR PINOUT ........................................................................................ 12

2.7 AES ...................................................................................................................................................... 15

2.8 LTC....................................................................................................................................................... 15

2.9 ETHERNET............................................................................................................................................... 15

3. OPERATION ........................................................................................................................................... 16

3.1 FRONT PANEL.......................................................................................................................................... 16

3.2 POWER ON DISPLAY ................................................................................................................................. 17

3.3 FRONT PANEL CONTROLS........................................................................................................................... 17

3.4 BASIC OPERATIONAL TECHNIQUE ................................................................................................................ 17

3.5 SELECTING A FUNCTION............................................................................................................................. 18

3.6 CHANGING VALUES .................................................................................................................................. 18

3.7 MENU TIMEOUT ...................................................................................................................................... 19

3.8 FRONT PANEL LOCK.................................................................................................................................. 19

3.9 TOP LEVEL MENU .................................................................................................................................... 20

3.10 USING VECTOR ........................................................................................................................................ 22

3.11 UPDATING THE MENTOR XL....................................................................................................................... 22

4. DIGITAL VIDEO ...................................................................................................................................... 23

4.1 DIGITAL VIDEO –VIDEO STANDARD............................................................................................................. 24

4.2 DIGITAL VIDEO –TEST PATTERNS ................................................................................................................ 25

4.3 DIGITAL VIDEO –TIMING........................................................................................................................... 29

4.4 DIGITAL VIDEO –AES............................................................................................................................... 29

5. ANALOGUE VIDEO ................................................................................................................................. 31

5.1 ANALOGUE VIDEO –ALL BLACK &BURST ..................................................................................................... 33

5.2 ANALOGUE VIDEO –YUV.......................................................................................................................... 34

5.3 ANALOGUE VIDEO –COMP /BB /BB ......................................................................................................... 35

5.4 ANALOGUE VIDEO –RGB.......................................................................................................................... 36

5.5 ANALOGUE VIDEO –YC /BB ..................................................................................................................... 37

5.6 AVAILABLE TEST PATTERNS ........................................................................................................................ 38

6. AUDIO ................................................................................................................................................... 39

6.1 AUDIO –MENU TREE ................................................................................................................................ 39

6.2 AUDIO:AES 1/AES 2. ............................................................................................................................ 40

6.3 AUDIO:ANALOGUE .................................................................................................................................. 40

7. LOCK MODE........................................................................................................................................... 41

7.1 GENLOCK -MODE .................................................................................................................................... 41

7.2 GENLOCK LOSS ........................................................................................................................................ 42

7.3 GENLOCK –FIELD LOCK............................................................................................................................. 42

7.4 GENLOCK –INPUT STANDARD .................................................................................................................... 42

Page 3 of 84 Trilogy Communications

Mentor XL

8. SETUP .................................................................................................................................................... 43

8.1 SETUP –TOP LEVEL .................................................................................................................................. 43

8.2 SETUP –MORE........................................................................................................................................ 45

9. STATUS.................................................................................................................................................. 47

10. OPTIONS AND FEATURES: INTRODUCTION........................................................................................ 49

10.1 HARDWARE OPTIONS................................................................................................................................ 50

10.2 SOFTWARE FEATURES ............................................................................................................................... 50

11. OPTIONAL FEATURE: 360-14-00 TIMECODE....................................................................................... 51

11.1 INTRODUCTION........................................................................................................................................ 51

11.2 TIMECODE OPTION -EXTENDED SETUP MENU............................................................................................... 52

11.3 VITC WITHIN ANALOGUE WAVEFORM .......................................................................................................... 56

11.4 VITC WITHIN SDI .................................................................................................................................... 58

12. OPTION: 360-15-12 GPS TIME REFERENCE......................................................................................... 60

12.1 INTRODUCTION........................................................................................................................................ 60

12.2 DISCLAIMER ............................................................................................................................................ 60

12.3 INSTALLATION.......................................................................................................................................... 60

12.4 GPS ANTENNA –INTERNAL RECEIVER .......................................................................................................... 62

12.5 EXTERNAL GPS RECEIVER /ANTENNA COMBINATION ..................................................................................... 64

12.6 CONNECTING A SINGLE EXTERNAL RECEIVER TO TWO MENTOR XL...................................................................... 65

12.7 ACQUISITION PROCESS .............................................................................................................................. 67

12.8 1PULSE PER SECOND (1 PPS) SIGNAL WAVEFORM ........................................................................................ 67

12.9 GPS MENU STRUCTURES .......................................................................................................................... 68

12.10 ABSOLUTE TIME REFERENCE (ATR)......................................................................................................... 70

13. OPTION: 360-16-01 TRI-LEVEL SYNC .................................................................................................. 71

13.1 INTRODUCTION........................................................................................................................................ 71

13.2 MENU STRUCTURE ................................................................................................................................... 71

13.3 AVAILABLE STANDARDS ............................................................................................................................. 72

14. OPTIONAL FEATURES: NTP AND SNMP.............................................................................................. 73

14.1 360-18-02 NTP (NETWORK TIME PROTOCOL)SUPPORT ............................................................................... 73

14.2 360-19-00 SNMP (SIMPLE NETWORK MANAGEMENT PROTOCOL)SUPPORT.................................................... 73

15. OPTION: 360-20-00 HD/3G-SDI MODULE........................................................................................... 74

15.1 360-20-00 MENU TREE........................................................................................................................... 74

15.2 360-20-00 AVAILABLE VIDEO STANDARDS .................................................................................................. 75

15.3 360-20-00 AVAILABLE TEST PATTERNS ....................................................................................................... 75

16. COMMON CONFIGURATIONS............................................................................................................ 76

16.1 GPS LOCKED SPG AND TIMECODE GENERATOR. ............................................................................................ 76

16.2 GPS LOCKED NTP SERVER......................................................................................................................... 76

16.3 DAYLIGHT SAVING TIME ............................................................................................................................ 77

16.4 VITC AS A JAM!SOURCE ........................................................................................................................... 77

Page 4 of 84 Trilogy Communications

Mentor XL

17. SPECIFICATION .................................................................................................................................. 78

17.1 GENERAL................................................................................................................................................ 78

17.2 EMC ..................................................................................................................................................... 78

17.3 POWER .................................................................................................................................................. 78

17.4 INTERNAL REFERENCE OSCILLATOR STABILITY................................................................................................. 78

17.5 GENLOCK VIDEO INPUT PERFORMANCE ........................................................................................................ 79

17.6 GENLOCK OPERATIONAL CONTROL .............................................................................................................. 79

17.7 10 MHZ INPUT PERFORMANCE .................................................................................................................. 80

17.8 SD-SDI OUTPUTS .................................................................................................................................... 80

17.9 HD-SDI OUTPUTS ................................................................................................................................... 81

17.10 3G SDI OUTPUTS ................................................................................................................................ 81

17.11 ANALOGUE VIDEO OUTPUT PERFORMANCE .............................................................................................. 82

17.12 AES/EBU OUTPUTS ............................................................................................................................ 83

17.13 ANALOGUE AUDIO OUTPUT PERFORMANCE.............................................................................................. 83

17.14 CLOCK OUTPUT ................................................................................................................................... 83

17.15 GPI INPUTS AND OUTPUTS .................................................................................................................... 84

17.16 LTC TIMECODE ................................................................................................................................... 84

17.17 MISCELLANEOUS.................................................................................................................................. 84

Page 5 of 84 Trilogy Communications

Mentor XL

1. APPLICATION

1.1 INTRODUCTION

The Trilogy Mentor XL Synchronising Pulse Generator is one of the most flexible units available on

the market today. It is suitable for any digital or mixed format environment where a high quality

digital SPG is required. The part suffix xx denotes minor variations and updates which fall within the

scope of this document.

•5 analogue outputs

•3 SD-SDI black outputs with 4 channels of embedded AES silence and EDH

•2 AES-3 silence outputs

•10 MHz / 27 MHz/Word Clock output

•Each output individually timed

•Each output selectable to either 525 or 625 operation

•10 MHz reference input

•Looping Genlock input

All SDI and Analogue black/burst outputs offer full control over timing and are individually selectable

for 525 / 625 standard operation.

Mentor XL is fitted, as standard, with an oven-controlled reference oscillator allowing the unit to be

used either as station master, or as a slave.

The main black/burst generator provides 5 independently timed outputs, giving total timing freedom

with adjustment of ±4 fields (±2 fields 525) relative to the main timing plane in 0.5 ns steps.

Additional software features are available to add HD-SDI capability, test patterns (for Analogue

and/or digital outputs), audio test signals, full field test patterns, LTC, VITC, D-VITC, ATC, NTP and

SNMP. Optional hardware options are available to add a GPS module for high stability time and

oscillator referencing, an HD tri-level sync option module and SDI option modules providing

additional SD, HD and 3G SDI outputs.

In addition, an internal redundant power supply is available to increase MTBF, or to allow AC power

diversity in critical applications.

An Ethernet port is provided for the Vector management feature, to facilitate software upgrades and

time synchronisation by means of NTP (Network Time Protocol).

This Instruction Manual concentrates on the operational aspects of the unit and includes a full

technical specification.

1.2 VECTOR FOR MENTOR XL

A web browser based configuration tool is provided, offering:

•Online editing of Mentor XL configurations

•Partial or incremental updates without causing disruption (where possible)

•The ability to copy, backup and restore configuration data.

Please see Section 3.10 of this manual for information on getting started with Vector.

Page 6 of 84 Trilogy Communications

Mentor XL

1.3 AVAILABLE FEATURES AND OPTIONS

Three option card slots are available. The Mentor XL auto detects which type of option card is fitted

and presents the user with appropriate menu options.

A number of additional hardware options and software features are available for the Mentor XL.

At the time of writing in March 2015, these are:

Part Code

Description

Note

360-09-00

Optional redundant power supply

Hardware option

360-10-00

Video test signals

Software feature to add composite analogue and SDI

test signals.

360-11-00

Audio test tones

Software feature to add analogue and AES test tones

(including GLITS interrupted channel ident tone)

360-12-00

Full field test patterns

Software feature to generate FUBK test pattern,

selectable 4:3 & 16:9. Requires 360-10-00 video test

signals as pre-requisite.

360-13-00

HD video test patterns

Software feature to add HD-SDI test patterns. Requires

360-10-00 video test signals as pre-requisite.

360-14-00

Timecode feature

Software feature to provide two LTC outputs with VITC,

D-VITC and ATC.

360-15-12

GPS Time Reference

Hardware option: includes receiver module. Replaces

360-15-10 and 360-15-11.

360-15-02

Unbalanced AES Output card

Hardware option - activates the 2 x AES unbalanced

outputs. Requires 360-11-00 as pre-

requisite. Not

required if 360-15-01 fitted.

360-15-03

GPS Antenna and Universal mount

Bullet III Dome 5V antenna. Supplied with F - type

connector.

360-15-04

GPS Smart Antenna and Universal Mount

Trimble Accutime Smart Antenna, includes mating

connectors but excludes cable.

360-18-00

NTP Feature

Software feature – selectable as either server or client

mode via menus.

360-19-00

SNMP Support

Software feature to enable Simple Network

Management Protocol support.

360-20-00

HD/3G-SDI Expansion Module

Hardware option - provides 4 additional HD or 3G-SDI

outputs in any combination. Requires options 360-13-

00 (HD) as pre-requisite. See Note 1.

Notes:

1. Normally only a single 360-20-00 will be fitted to each Mentor XL.

Please see section 10 of this manual for more information on setup and configuration of options and

features. Additional hardware options and software features will be offered in the future: please

contact your supplier or Trilogy for more information.

Page 7 of 84 Trilogy Communications

Mentor XL

1.4 TECHNICAL SUPPORT

UK & International

Please contact Trilogy at the UK headquarters.

Trilogy Communications Ltd

26 Focus Way

Andover

Hampshire

SP10 5NY

United Kingdom

E-mail: broadcastsupport@trilogycomms.com

Tel: +44 (0)1264 384000

Trilogy USA Inc.

8201 Peters Road, Suite 1000

Fort Lauderdale, FL 33324

USA

Tel: (847) 461-1480

Toll Free Phone and Fax from US: 800-372-3198

In other regions please contact your local dealer. Current contact details may be found at

www.trilogycomms.com then follow links to the Broadcast division site.

1.5 WARRANTY

Conditions of the warranty may vary according to your terms of purchase. Please consult your sales

documentation or if in doubt, contact your original supplier or Trilogy, quoting date of purchase and

unit serial number.

1.6 COMMON CONFIGURATIONS

To cater for different system design philosophies and installations of varying complexity, we have

tried to make the Mentor XL as flexible as possible. Some common system modes and configurations

are described in section 16 on page 76.

Page 8 of 84 Trilogy Communications

Mentor XL

2. INSTALLATION

2.1 UNPACKING

Carefully unpack the unit from its transit material and check the unit for signs of damage. Check the

contents of the box against our despatch note and your original order to ensure that you have

received the correct parts.

In the event that the unit has been damaged or does not match your order, immediately contact

your supplier or Trilogy at the address given at the front of this guide.

2.2 RACK MOUNTING

The 1U rack frame has integral 19" mounting ears for direct mounting in a standard 19" rack.

Carefully place the unit in your rack and firmly attach it to the rack using 4 bolts.

IMPORTANT: This unit has air intakes on one side of the unit and fan assisted exhaust vents on the

other side of the unit. Ensure that these have an unobstructed air flow, otherwise the unit will

overheat. Pay particular attention to ensure that any rack wiring or cable trays do not obstruct the

vent. 60mm of clear space should be allowed between the vents and any potential obstruction.

2.3 EARTHING REQUIREMENTS

The unit is provided with a single 4mm earthing stud on the rear panel. Incoming mains earth from

the IEC connector is internally bonded to both the chassis and technical 0V to meet safety

requirements and performance specifications. The stud allows the addition of an earth strap, if

required, in rack installations.

Page 9 of 84 Trilogy Communications

Mentor XL

2.4 MAINS CONNECTION AND FUSING

Important

Power Supply Cord Used as Disconnect Means

CAUTION: THE POWER SUPPLY CORD IS USED AS THE MAIN DISCONNECT DEVICE. ENSURE THAT

THE SOCKET-OUTLET IS LOCATED / INSTALLED NEAR THE EQUIPMENT AND IS EASILY ACCESSIBLE.

ATTENTION: LE CORDON D’ALIMENTATION EST UTILISÉ COMME INTERRUPTEUR GÉNÉRAL. LA

PRISE DE COURANT DOIT ÊTRE SITUÉE OU INSTALLÉE À PROXIMITÉ DE L’ÉQUIPMENT ET ÊTRE

FACILE D’ACCÉS.

The power supplies within the unit are a switched mode design and will cope automatically with a

wide input voltage range (see specification, section 17.3)

The standard Mentor XL is fitted with a single mains power supply unit (PSU), with an option to fit a

second PSU. Each PSU has its own, dedicated, IEC mains plug on the rear of the Mentor XL. These

should be wired according to the instructions provided with a mating mains socket using suitable

cable. See above for earthing requirements.

Mains cable conductors are to be three-core (two-wire with ground), wire gauge 18 AWG (cross

sectional area 0.75mm²) Jacket to be type SJT.

Covers are only to be removed by trained personnel. Shock hazard exists with covers removed;

therefore disconnect mains supply before removal. Interconnection between circuit boards and

panels are all safety extra low voltage (SELV) as defined by IEC/EN/CSA/UL 60950-1-200X. The

equipment signal connections must only be connected to SELV circuits to prevent hazards from

improper connection.

Page 10 of 84 Trilogy Communications

Table des matières

Manuels Onduleur populaires d'autres marques

Fourgroup

Fourgroup Easy Manuel utilisateur

Velleman

Velleman PI300M Manuel utilisateur

Sungrow

Sungrow SG350HX-US Manuel utilisateur

WilTec

WilTec 61897 Manuel utilisateur

SMA

SMA SUNNY BOY STORAGE 2.5 Manuel utilisateur

Simplicity

Simplicity LANDLORD 316 Manuel utilisateur

Santak

Santak SMAX 3000 Manuel utilisateur

ATON

ATON RA.Store-3 Manuel utilisateur

ZIEHL-ABEGG

ZIEHL-ABEGG FXET4AMQ Manuel utilisateur

Tektronix

Tektronix CFG250 Manuel utilisateur

Champion

Champion 200989 Manuel utilisateur

Vanner

Vanner 20-500 Series Manuel utilisateur

GE GEP Manuel utilisateur

Astrel Group

Astrel Group Power Reducer Guide rapide

MULTIQUIP

MULTIQUIP GDP-5H Mode d’emploi

GoWISE

GoWISE PS1007 Manuel utilisateur

Promate

Promate PM13500D ES Manuel utilisateur

Mastervolt

Mastervolt WHISPER 3.5M3000 RPM Manuel utilisateur
