Trident NS13 Manuel utilisateur

Sweeping machine

Use and Maintenance manual

Original istruction - DOC. 10074794- Ver. AA - 10-2017

SYMBOLS USED IN THE MANUAL .................................................................................... 4

SYMBOLS USED ON THE MACHINE AND BATTERY CHARGER .................................... 4

PURPOSE AND CONTENT OF THE MANUAL................................................................... 5

STORING THE USE AND MAINTENANCE MANUAL......................................................... 5

ON DELIVERY OF THE APPLIANCE .................................................................................. 5

INTRODUCTORY COMMENT ............................................................................................. 5

TECHNICAL DESCRIPTION................................................................................................ 5

INTENDED USE................................................................................................................... 5

SAFETY................................................................................................................................ 5

SERIAL NUMBER PLATE .................................................................................................... 5

SPARE PARTS..................................................................................................................... 6

TECHNICAL DATA ............................................................................................................... 6

GENERAL SAFETY REGULATIONS ................................................................................... 7

HANDLING THE PACKED APPLIANCE .............................................................................11

HOW TO UNPACK THE APPLIANCE.................................................................................11

HOW TO TRANSPORT THE APPLIANCE .........................................................................11

BATTERY TYPE ..................................................................................................................11

BATTERY MAINTENANCE AND DISPOSAL......................................................................11

RECHARGING THE BATTERY.......................................................................................... 12

PREPARING TO WORK..................................................................................................... 13

WORK ................................................................................................................................ 13

AT THE END OF THE WORK ............................................................................................ 13

MAINTENANCE ................................................................................................................. 14

DISPOSAL.......................................................................................................................... 14

TROUBLESHOOTING ....................................................................................................... 15

EC DECLARATION OF CONFORMITY ............................................................................. 15

CONTENTS

Protective gloves symbol:

Always wear protective gloves, to avoid the risk of serious injury to your hands.

Warning symbol:

Carefully read the sections marked with this symbol and observe the indications, for the safety of the operator and the

appliance.

Covered place symbol:

the operations preceded by this symbol must always be carried out in a dry, covered area.

“OPEN” symbol:

used on the rear of the appliance, to indicate the position of the debris hopper uncoupling button.

“Power” symbol:

used in the battery charger base, to indicate the green LED. This LED shows when the electric circuit is operating.

“Charging” symbol:

used in the battery charger base, to indicate the red LED. This LED shows when the battery is recharging.

Open book symbol with an “i”:

Indicates the need to consult the instruction manual.

Main switch symbol:

located on the central rear part of the appliance, to indicate the main switch.

Recycling symbol:

carefully read the sections marked with this symbol for recycling the appliance.

Tool symbol:

indicates the need to use tools not included in the supply.

Lifting point symbol:

located on the front and rear of the appliance, to indicate the lifting points.

Explosion risk symbol:

indicates that the battery may explode in certain conditions, if not handled in accordance with the directives indicated in

the manufacturer's manual.

SYMBOLS USED IN THE MANUAL

SYMBOLS USED ON THE MACHINE AND BATTERY CHARGER

The descriptions contained in this document are not binding. The company therefore reserves the right to make any modications at any time

to elements, details, or accessory supply, as considered necessary for reasons of improvement or manufacturing/commercial requirements.

The reproduction, even partial, of the text and drawings contained in this document is prohibited by law.

The company reserves the right to make any technical and/or supply modications. The images are shown as a reference only, and

are not binding as to the actual design and/or equipment.

Open book symbol:

Tells the operator to read the manual before using the appliance.

Battery symbol:

used on the left side of the appliance, to indicate the position of the battery.

Disposal symbol:

carefully read the sections marked with this symbol for disposing of the appliance.

PURPOSE AND CONTENT OF THE MANUAL

STORING THE USE AND MAINTENANCE MANUAL

ON DELIVERY OF THE APPLIANCE

INTRODUCTORY COMMENT

TECHNICAL DESCRIPTION

INTENDED USE

SAFETY

SERIAL NUMBER PLATE

The aim of this manual is to provide customers with all the information

needed to use the appliance in the safest, most appropriate and

most autonomous way. It includes information concerning technical

aspects, safety, operation, appliance downtime, maintenance, spare

parts and scrapping. Operators and qualied technicians must read

The Use and Maintenance Manual must be stored in its special

pouch close to the appliance, protected from liquids and anything

When the machine is delivered to the customer, an immediate

check must be performed to ensure all the material mentioned in

the shipping documents has been received, in addition to verifying

that the equipment has not been damaged during transportation. If

Any type of equipment can only work properly and e󰀨ectively if used

correctly and kept in full working order by performing the maintenance

operations described in the attached documentation. You should

therefore read this instruction manual carefully, consulting it again

if issues arise while using the machine. If necessary, remember that

NS13 is an electric battery-powered brush designed for cleaning dry

surfaces in both outdoor and indoor environments. The appliance

has: a central brush for collecting the dirt, two side brushes for

This electric brush was designed and built to be used by a qualied

operator to clean smooth, compact ooring in the commercial,

residential and industrial sectors, in proven safety conditions.

The appliance is only suitable for use in indoor - or at least covered

- areas. The appliance is not suitable for use in the rain, or under

jets of water.

Operator cooperation is paramount for accident prevention. No

accident prevention programme can be e󰀨ective without the full

co-operation of the operator who is directly responsible for machine

operation. The majority of occupational accidents that happen both

in the workplace or whilst moving are caused by failure to respect

The serial number plate is located on the lower part of the appliance,

indicating its general characteristics (in particular, the serial number).

The serial number is a very important piece of information and should

always be provided together with any request for assistance or when

purchasing spare parts.

the instructions in this manual carefully before carrying out any

operation on the appliance. If in doubt about the correct interpretation

of instructions, contact your nearest Customer Service Centre to

obtain the necessary clarications.

else that could compromise its legibility.

this is the case, the carrier must ascertain the extent of the damage

at once, informing our customer service o󰀩ce. It is only by prompt

action of this type that the missing material can be obtained, and

compensation for damage successfully claimed.

our assistance service (organised in collaboration with our dealers)

is always available for advice or direct intervention.

cleaning in corners, and a debris hopper for holding the dirt. Do not

use the appliance for purposes other than the one indicated above.

WARNING: it is forbidden to use the appliance for picking up

dangerous dusts or inammable liquids in places with an

explosive atmosphere.

the most basic safety rules. An attentive, careful operator is most

e󰀨ective guarantee against accidents and is fundamental in order to

implement any prevention programme.

SPARE PARTS

TECHNICAL DATA U/M NS13

Working width in 14,75

Working capacity, up to yr2/h 1770

Central brush (number / diameter) N.bre /Øin 1 / 2,75

Side brush (number / diameter) N.bre /Øin 2 / 2,8

Central brush rpm rpm 2115

Side brush rpm rpm 940

Brush motor V/W 10.8 / 70

Total power W 70

Maximum gradient % 2

Debris hopper volume gal 0,53

Appliance length in 12,2

Appliance height in 5,4

Height of the fully extended handlebar (idle position) in 43,3

Appliance width in 14,5

Rated battery voltage V 10.8

Battery autonomy min 45

Battery weight lb 0,4

Unladen appliance weight lb 5,3

Appliance weight in running order lb 6,2

POS. CODE QTY DESCRIPTION

1 224069 1 Command handle

2 224072 1 Dummy battery

3 224071 1 Debris hopper

4 224073 1 Power supply battery

5 224074 1 Battery charger base

6 224464 1 Brushes

The regulations below must be carefully followed in order to avoid

harm to the operator and damage to the appliance.

CAUTION:

• Carefully read the warnings contained in this booklet and take

care of it for further consultations.

• Since the packaging elements (plastic bags, staples, etc.) are

a source of danger they should not be left within the reach of

children, disabled persons, etc.

• This appliance should only be used for the purpose for which

it was constructed, namely: cleaning inert surfaces and

collecting non-ammable and non-explosive solid substances.

Any other use is considered incorrect and hence dangerous.

• When the appliance is operating do not bring it close to

delicate organs like ears, mouth, eyes, etc.

• The appliance can be used by children over 8 years of age

and by people with limited physical,sensorial or mental, or by

people who have no experience or the required knowledge,

as long as they are supervised or after they have been given

instruction regarding using the appliance safely and they

understand the dangers involved in using it.

• Children should not play with the appliance.

• Children should not clean or carry out maintenance operations

without the supervision of an adult.

• Carefully read the labels on the appliance. Do not cover them

for any reason and replace them immediately if they become

damaged.

• The appliance must be only used by authorised, trained

personnel.

• Do not use the appliance on surfaces with an inclination

greater than the one shown on the serial number plate. The

appliance is not suitable for cleaning rough or uneven oors.

GENERAL SAFETY REGULATIONS

Do not use the appliance on slopes.

• Make sure the power cable of the battery charger base is not

damaged in any way (crushed, torn, etc.). Protect the cable from

heat, oil and sharp edges. Regularly check the power cable for

any damage such as the formation of cracks, or ageing. If you

notice any damage, the cable must be replaced before using

the machine (contact a specialised technician immediately).

• Do not cut o󰀨 the plug on the battery charger base with the

intention of replacing it with another plug as this may cause a

dangerous situation.

• In the event of danger, immediately remove the battery from

the appliance.

• Before carrying out maintenance work, switch o󰀨 the appliance

using the main switch and remove the supply battery from its

housing.

• When using the appliance, pay attention to other people and

especially to children.

• Only use the accessories supplied with the appliance or

those specied in the instruction manual, the use of other

accessories can compromise the safety of the appliance.

• When the appliance is not being used, the battery should not

be left connected to the appliance.

• Do not immerse the appliance in water. Do not use solvents or

other derivatives to clean it.

• The manufacturer cannot be held liable for any damage

to persons, animal or objects deriving from improper and

unreasonable use, and in any event not complying with the

instructions mentioned above.

• For scrapping, follow the regulations in force in the country.

• Before connecting the battery charger base to the socket,

make sure the electrical information on the plate corresponds

to that of the mains supply. The battery charger base must

only be powered with a voltage equal to that shown on the

serial number plate.

WARNING:

• The appliance must not be used or kept outdoors, in damp

conditions or directly exposed to rain.

• The appliance must be stored in an enclosed area with a

temperature between -13°F and 131°F.

• Conditions of use: room temperature between 32°F and

104°F, with relative humidity between 30 and 95%.

• The socket for the battery power cable must have an earth

connection in compliance with the regulatory standards.

• The appliance does not cause harmful vibrations.

• Never pick up gases, explosive/inammable liquids or powders,

nor acids and solvents! These include gasoline, paint thinners

and fuel oil (which, when mixed with the vacuum air, can form

explosive vapours or mixtures), and also non-diluted acids

and solvents, acetones, aluminium and magnesium powders.

These substances may also corrode the materials used to

construct the appliance.

• If the appliance is to be used in dangerous areas (for example,

gas stations), ensure that all relevant safety regulations are

observed. The appliance must never be used in environments

with a potentially explosive atmosphere.

• Do not place any liquid containers on the appliance.

• In the event of a re, use a powder extinguisher. Do not use

water.

• Adapt the speed to the adhesion conditions.

• Avoid working with the brushes when the machine is standing

still, so as not to damage the oor.

• Do not knock against shelving or sca󰀨olding, where there

is a danger of falling objects. The operator must always be

equipped with the appropriate safety devices (gloves, shoes,

helmet, goggles, etc.).

• If the appliance does not work properly, check this is not caused

by failure to carry out routine maintenance. Otherwise, ask for

intervention of the authorised technical assistance centre.

• If you need to replace any components, request the ORIGINAL

spare parts from an Authorised dealer and/or Retailer.

• Restore all electrical connections after any maintenance

interventions.

• Have the appliance checked by an authorised technical

assistance centre every year.

• When disposing of consumable materials, observe the laws

and regulations in force. When, after years of valuable work,

your appliance needs to be nally decommissioned, dispose

of the materials contained within it appropriately, bearing in

mind that the appliance is made of fully recyclable materials.

Table des matières

Autres manuels Trident Ventilateur

Trident

Trident FD15 Manuel utilisateur

Manuels Ventilateur populaires d'autres marques

Weed Eater

Weed Eater VS2000BV Manuel utilisateur

KRAUSMANN

KRAUSMANN U37020-00 Manuel utilisateur

Bosch

Bosch ALB 36 LI Manuel utilisateur

Cub Cadet

Cub Cadet HB425 Manuel utilisateur

GreenWorks Pro

GreenWorks Pro BLB482 Manuel utilisateur

ARIETE

ARIETE 2768 Manuel utilisateur

NuTone

NuTone 331H Manuel utilisateur

GÜDE

GÜDE GLB 200 18 Li-Ion Manuel utilisateur

I.VA.CO.

I.VA.CO. SC Series Mode d'emploi

DeWalt

DeWalt DCE100 Manuel utilisateur

Becker

Becker SV 7.330 Manuel utilisateur

Metabo

Metabo AG 18 Pro Manuel utilisateur

Desa

Desa GA3650TB Manuel utilisateur

Echo

Echo Power Blower PB-230LN Manuel utilisateur

Echo

Echo PB-413H Manuel utilisateur

Black & Decker

Black & Decker BV3100 Manuel utilisateur

Ryobi

Ryobi RY08570 Manuel utilisateur

Haaga

Haaga 355 Manuel utilisateur
