TRENDnet TV-IP751WC Manuel utilisateur

TV-IP751WC

rev: 08.28.2012

Wireless Cloud Camera

TV-IP751WC (v1.0R)

TRENDnet’s Wireless Cloud Camera, model TV-IP751WC, takes

the work out of viewing video over the internet. Previously to view

video remotely, users needed to perform many complicated and time

consuming steps: such as signing up for a third party dynamic IP

service and reconﬁ guring their router. The TRENDnet Cloud service

removes all of these complicated steps. Users simply open a web

browser and log into the TRENDnet Cloud with their unique password

to view and manage this camera. A free App for mobile devices brings

live video to smart phones and tablets.

ABOUT THE TV-IP751WC

Wireless n technology connects the camera to a wireless network and provides unsurpassed wireless coverage and improved streaming video quality. Add this camera to

your wireless network at the touch of a button with Wi-Fi Protected Setup (WPS). The TV-IP751WC offers 640 x 480 (VGA) video at up to 20 frames per second (fps),

one-way audio, motion detection recording, scheduled recordings, email alerts, date and time overlay, and four times digital zoom. A wall / ceiling mounting kit is included and

the camera’s off white housing blends into most environments.

PRODUCT OVERVIEW

• Easy remote camera viewing with free TRENDnet Cloud service

• High speed wireless n connection

• Program motion detection recording, email alerts and more

• One-way audio

• Wall / ceiling mounting kit

• Free mobile App

ABOUT SECURVIEW PRO MANAGEMENT SOFTWARE

Users can either control each TRENDnet camera individually or can use the free included enterprise class SecurView Pro software to manage up to 32 cameras. SecurView

Pro is compatible with Windows and Microsoft Server operating systems and supports all current TRENDnet cameras.

SecurView Pro provides users with extensive camera viewing options. Users can deﬁ ne a combination of weekly recording schedules and motion detection recording;

program motion detection areas of any shape; set date, time, and text overlays; and deﬁ ne mask overlays to conceal sensitive areas.

Zero loss architecture provides the ability to record a single video stream to multiple locations simultaneously. Manage recorded ﬁ les by time or by storage space. A

navigation timeline of stored video provides a quick visual reference of recorded content.

TV-IP751WC

rev: 08.28.2012

Wireless Cloud Camera

TV-IP751WC (v1.0R)

TRENDNET CLOUD SERVICE

• Free cloud service

• Automatically connects to a TRENDnet Cloud camera over the internet

• Cloud service eliminates the previous requirement to sign up for a Dynamic DNS service and reconﬁ gure your router and IP

camera

• Cloud camera requires internet connection

• Each camera accessed individually with unique web address (URL)

• Password protected cloud service

• Access to live video

• Full camera management with adequate network connection

• A single camera can be viewed remotely by multiple users concurrently

• The number of concurrent users is limited by ISP network bandwidth

• Remotely view multiple cameras on the same local area network (LAN)

• The number of viewable cameras is limited by ISP network bandwidth

• Cloud App for mobile devices (iOS®and Android®support)

FEATURES

• Wi-Fi compliant with IEEE 802.11n standard

• Backwards compatible with IEEE 802.11g and 802.11b devices

• One touch Wi-Fi Protected Setup (WPS) connection button

• 1 x 10/100 Mbps Ethernet port (for optional wired installation)

• Power and activity LED indicators (can be disabled)

• 1-way audio

• Reset button

• 4x digital zoom

• Dynamic DNS support

• Supports up to 640 x 480 pixel MJPEG resolution at up to 20 frames per second

• Compression rate: Very Low, Low, Medium (default), High, and Very High

• Image controls: brightness, contrast, saturation, light frequency, ﬂ ip image vertically, mirror image horizontally

• Deﬁ ne a recording schedule or motion detection recording

• Create motion detection ﬁ elds over the viewing area

• Supports TCP/IP networking, email, HTTP, and other internet protocols

• System controls:

• Deﬁ ne up to 64 user login accounts

• Set the date and time or synchronize with an NTP server

• Supports wireless encryption up to WPA2-PSK

• Quick Universal Plug and Play (UPnP) installation

• Mounting base and mounting hardware included

• 3-year limited warranty

TV-IP751WC

rev: 08.28.2012

Wireless Cloud Camera

TV-IP751WC (v1.0R)

SECURVIEW PRO CAMERA SOFTWARE FEATURES

• Manage up to 32 cameras*

• Compatible with Windows and Microsoft Server 2008

• Multiple language support

• Camera Viewing

• Preset viewing modes

• Program custom viewing modes

• Full screen view

• Drag and drop live feeds to a new location

• Program camera cycle viewing sequence

• Motion detection brings video forward

• Side, top, and bottom tool bars can be hidden

• Web based access from smart phones and tablets

• Recording options

• Program weekly recording schedules

• Motion detection recording

• Deﬁ ne motion detection areas of any shape

• Deﬁ ne motion detection sensitivity

• Event trigger recording

• Date and time overlay

• Mask overlay to conceal sensitive areas

• Save a single video stream to multiple locations simultaneously

• Deﬁ ne recording quotas by recording time or space allocation

• Disk clean feature condenses and optimizes old ﬁ les

• Real time recording stats to help manage ﬁ les

• Search and Playback

• Navigation timeline provides a quick visual reference to the recorded content

• Search continuous recordings by motion

• Search recordings by motion within a deﬁ ned ﬁ eld (a portion of the viewing area)

• Time lapse playback search

• Map cameras on an image such as a ﬂ oor plan

• Map cameras on Google Maps™

*Monitoring multiple cameras may require a high performance CPU

TV-IP751WC

rev: 08.28.2012

Wireless Cloud Camera

TV-IP751WC (v1.0R)

SPECIFICATIONS

CAMERA

General • Sensor: 1/5” CMOS Sensor

• Board Lens

• Focal Length: 4 mm

• F/No: 1.5

• Minimum illumination: 1 lux

• Focus Depth: 20 cm ~ inﬁ nity

• View:

• Horizontal: 38°

• Vertical: 28.7°

• Diagonal: 46.5°

• Digital Zoom: 4x

Audio • Built-in omni-directional microphone

• Sensitivity: -38 dB +/- 3 dB (5 meters max.)

• Frequency: 100~20000 Hz

• S/N: >60 dB

• Format: PCM

HARDWARE

Network • IEEE 802.3u 10/100 Mbps Fast Ethernet

LED • Power, Link / Act

WPS Button • Enable WPS connection

Reset Button • Reset to factory default

Power Consumption • Max 5 watts

Power • Input: 100~240 V, 50/60 Hz, 0.2A

• Output: 5V, 1.2A external power adapter

Dimension • 75 x 115 x 30 mm (2.95 x 4.5 x 1.2 in.)

Weight • 110 g (3.8 oz)

Temperature • Operating: 0°C ~ 40°C (32°F ~ 104°F)

• Storage: -15°C ~ 70°C (5°F ~ 158°F)

Humidity • Max 90% (non-condensing)

Certiﬁ cations • CE, FCC

REQUIREMENT

Management Interface • Internet Explorer 7.0 or higher

• Firefox 3.5 or higher

• Safari 4.0 or higher

• Google Chrome 19.0 or higher

To Run software • Windows 7 (32/64-bit), Vista (32/64-bit), XP (32/64-bit)

• Windows Server 2003, 2008

SecurView Pro Software • Channel: supports up to 32 cameras

• Record / Playback / Motion Detection / Audio

Network Protocols • IPv4, ARP, TCP, UDP, ICMP

• DHCP Client, NTP Client, DNS Client, DDNS Client, SMTP Client, FTP Client

• HTTP

• PPPoE

• UPnP

TV-IP751WC

rev: 08.28.2012

Wireless Cloud Camera

TV-IP751WC (v1.0R)

SPECIFICATIONS

WIRELESS

Standard • IEEE 802.11b, 802.11g and 802.11n

Frequency • 2.4 ~ 2.497 GHz ISM band

Modulation • DQPSK, DBPSK, DSSS and CCK

Antenna • Built-in 2 dBi antenna

Data Rate • 802.11b: up to 11 Mbps

• 802.11g: up to 54 Mbps

• 802.11n: up to 150 Mbps

Security • 64/128-bit WEP, WPA / WPA2-PSK

Output Power • 802.11b: 17 dBm (typical)

• 802.11g: 14.5 dBm (typical)

• 802.11n: 14.5 dBm (typical)

Receiving Sensitivity • 802.11b: -89 dBm at 11 Mbps

• 802.11g: -74 dBm at 54 Mbps

• 802.11n: -71 dBm at 150 Mbps

Channels • 1~11 (FCC), 1~13 (ETSI)

MANAGEMENT

Accounts • Up to 64 user accounts

Remote Login • Remote management supported

Backup / Restore • Save / retrieve conﬁ guration ﬁ les

Cloud Link • Display status and URL, enable / disable, refresh

SETTINGS

Image • Brightness, contrast, saturation, light frequency, ﬂ ip, mirror (horizontal / vertical)

Video Setting • Encoding: MJPEG

• Resolution and frame rate: VGA @ 20 fps, QVGA @ 30 fps, QQVGA @ 30 fps

• JPEG quality: Very Low, Low, Medium (default), High, Very High

Recording • Event based (motion detection) and scheduled

Snapshot • Trigger event: motion detection

• Action: send alert email and / or upload to FTP

• Real time snapshot

Port Settings • HTTP port: 80 (default)

Time • Synchronize with NTP server or PC, or set time / date manually

Wireless Cloud Camera

TV-IP751WC (v1.0R)

CONTACT INFORMATION

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web: www.trendnet.com

Email: [email protected]

1-888-326-6061

PACKAGE CONTENTS

TV-IP751WC

CD-ROM (Utility, software, & User’s Guide)

Multi-Language Quick Installation Guide

Network cable (1.5 m / 5 ft.)

Power adapter (5V DC, 1.2A)

Camera mounting kit
