TRENDnet TU2-ET100 Manuel utilisateur
TRENDnet User’s Guide Cover Page
© Copyright 2012 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide Table of Contents
i
Contents
Product Overview....................................................................................2
Package Contents......................................................................................................2
Features....................................................................................................................2
Product Hardware Features.......................................................................................3
Application Diagram..................................................................................................3
Installation on Windows..........................................................................4
Windows 7/Vista ......................................................................................................4
WindowsXP ..............................................................................................................5
Verifying the Driver Installation on Windows.............................................................6
TCP/IP Settings on Windows......................................................................................7
Installation on Mac................................................................................11
MacOS 10.4 ~ Mac OS 10.7.....................................................................................11
Verifying the Driver Installation on Mac...................................................................13
TCP/IP Settings on Mac............................................................................................14
© Copyright 2012 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TU2-ET100
2
Product Overview
TU2-ET100
Package Contents
The package includes:
TU2-ET100
Multi-Language Quick Installation Guide
CD-ROM (Driver & User’s Guide)
If any package contents aremissing or damaged, please contact the retail store,
online retailer, or reseller/distributor that the item was purchased.
Features
The TU2-ET100 is a high speedUSB network adapter that allows you toinstantly
connect toa 10/100Mbpsnetwork from a USBenabled desktop or Notebook PC.
Compliant with USB 2.0 and backwards compatible with the USB 1.0 and 1.1, you can
share files and printers and also gain access to broadband Internet to explore valuable
resources on the web.
Connect your laptop or PC at Fast Ethernet speeds
Quickly share data, music, movies and more
Compact design is ideal for on the go professionals.
© Copyright 2012 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TU2-ET100
3
Product Hardware Features
Product View
USB Port – Connect the USB port to your computer.
Ethernet Port –Connect one end of the network cable to Ethernet Port and the
other end to the Router
LED
LED Color Description
100Mbps Green On for 100Mbps
Off for 10Mbps or not connected
Link Amber LAN activity. Blinking when there is dataflow
between LAN and the host computer.
Application Diagram
© Copyright 2012 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TU2-ET100
4
Installation on Windows
Windows 7/ Vista
1. Insert the Driver CD-ROM into your CD-ROM Drive.
2. Click Run Autorun.exe (Windows 7 & Vista only)
3. Click Install Driver to install the driver.
4. Click Next.
© Copyright 2012 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TU2-ET100
5
5. Click Install.
6. Click Finish.
7. Remove the CD-ROMfrom yourcomputer’sCD-ROM drive.
8. Connect the adapter toan available USBport onyour computer
9. The adapter’s drivers will install automatically.
10. Connect a network cable from the TU2-ET100 to a switch, router or cable/DSL
modem.
Windows XP
1. Insert the Driver CD-ROM into your CD-ROM Drive.
2. Click Install Driver to install the driver.
3. Click Next.
© Copyright 2012 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TU2-ET100
6
4. Click Install.
5. Click Finish.
6. Remove the CD-ROMfrom yourcomputer’s CD-ROM drive.
7. Connect the adapter toan available USBport onyour computer
8. The adapter’s drivers will install automatically.
9. Connect a network cable from the TU2-ET100 to a switch, router or cable/DSL
modem.
Verifying the Driver Installation on Windows
To verify the driver installation on your Ethernet adapter, please launch
Device Manager through the steps below.
On Windows® 7/Vista: Right-click on the Computer icon on the desktop and
select Properties > Device Manager.
On Windows® XP: Right-click on the My Computer icon on the desktop and
select Properties > System > (Hardware) > Device Manager.
© Copyright 2012 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TU2-ET100
7
TCP/IP Settings on Windows
1. Click Start, Control Panel and, then click Network and Sharing Center, and then
clicking Change Adapter settings.
2. Right-click on the Local Area Connection of the adapter, and then click
Properties.
3. Under Networking tab, click Internet Protocol Version 4 (TCP/IPv4) for IPv4
setting or Internet Protocol Version 6 (TCP/IPv6) for IPv6 setting, and then click
Properties.
© Copyright 2012 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TU2-ET100
8
4. Setup the IPv4 IP address:
a. To obtain IP settings automatically, click Obtain an IP address
automatically, and then click OK.
b. To manual setup the IP address, select User the following IPv4 address,
then enterIP addresson the IP address,Subnet Mask, and Default
gateway boxes, and then specify the IP address on the Preferred DNS
server andAlternate DNS server boxes, and then click OK.
© Copyright 2012 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TU2-ET100
9
5. Setup IPv6 IP address settings:
Note: On Windows XP, it required to install IPv6 protocol in order to setup the
IPv6 IP . Please follow the How to Install IPv6 protocol on Windows XP on next
section for instruction.
a. To obtain IP settings automatically, click Obtain an IPv6 address
automatically and Obtain DNS server address automatically, and then
click OK.
b. To manual setup the IP address, select User the following IPv6 address,
then enterIP addresson the IPv6 address,Subnet prefix length, and
Default gateway boxes, and then specify the IP address on the Preferred
DNS server andAlternate DNS server boxes, and then click OK.
