TrekStor SurfTab breeze 7.0 Manuel utilisateur

SurfTab®breeze 7.0

USB

RESET

DC 5V

SurfTab breeze 7.0

microSD

DCB HGFE

INDEX

EN ……………………………………………………………………… 13

bQUICK GUIDE

Thank you for buying the TrekStor SurfTab breeze 7.0. Please read the

following instructions carefully so that you can become acquainted with

the functions of this product and its use.

Current product information can be found at the TrekStor Website

www.trekstor.de.

Package content

• TrekStor SurfTab breeze 7.0

• Micro-USB cable

• USB host cable

• Power supply (100-240V)

• Cleaning cloth

• Quick guide

1) Controls and connections of the SurfTab

A) Camera: Front side

B) Reset: Pressing this button (e. g. with an unfolded paperclip) performs

a reset. Note: A reset only resets the custom settings. Saved data will

remain on the device.

C) microSD/microSDHC card slot: To insert memory cards up to 32 GB.

D) Volume control: Briefly press the "+/-" button to raise or lower the volume.

E) Mains input

F) Micro-USB connector: To connect a computer via the micro USB cable.

G) Audio-out connector

H) Power button: A longer press turns the device on or off. A short press

deactivates/activates the standby mode of the display.

I) Loud speaker

EN 14

2) First set up

2.1) Charging the SurfTab

Before the first use, it is recommended to fully charge the SurfTab. Connect

the DC input connector with the SurfTab and connect the power supply to

an electrical outlet.

2.2) Getting started

A) After charging the SurfTab, hold down the power button for

2-3 seconds to switch on the device.

B) After switching on the device, the start screen appears. To set the user

interface to the desired language, please tap inside the applications

menu on "SettingS" and afterwards on "Language & input".

Tap now in the right column on the first field "Language"and

select your language.

2.3) Connecting the Internet

With the SurfTab you have the possibility to access the Internet via Wi-Fi.

If you want to establish a connection to a new network, please proceed

as follows:

A) Go via the applications menu to the settings and tap on "Wi-fi" under

"WireLeSS anD netWorkS". In case the Wi-Fi function is not activated yet,

first pull the on/off switch to "on".

B) On the right side all the wireless networks are displayed. Tap on your

preferred network and enter the password into the appropriate field.

C) The SurfTab then connects with the Internet. Via the browser symbol

you can now surf the Internet as usual.

iIf you have once established a connection to a Wi-Fi network, the SurfTab

automatically connects to it as soon as it is within reach.

iTo save power, it is advisable to turn off the wireless function, if you do not

need it.

3) Operation of the SurfTab

3.1) Switching on and off

To turn the SurfTab on, press the power button approx. 2-3 seconds.

The device turns then on. To turn the device off, press also for approx.

2-3 seconds the power button. Now the following message appears:

"WouLD you Like to Shut DoWn?". Tap on "ok" to shut down the SurfTab.

3.2) Activating/Deactivating the standby mode

If you do not want to use the SurfTablet for a while, press briefly the power

button to put the tablet in the standby mode. To exit the standby mode,

press again briefly the power button.

Once you have activated the screen again, the SurfTab first displays the

screen lock. Pull the lock icon to the right edge of the circle onto the open

lock, in order to unlock the tablet.

iThe SurfTab is locked automatically when it is not used for a certain

time. A change of the interval, from when the SurfTab is supposed to go

automatically into the standby mode, can be individually adjusted under

"sEttings" +"Display"+"slEEp".

3.3) Using the touch screen

Selecting items

Touch the screen once with your fingertip to open an element or select

an option.

Move items

Keep your finger on the item that you would like to move and drag it

to the desired position on the screen.

Scrolling

In order to roll a window or the screen up, down or sideways, simply slide

your finger up or down respective from left to the right and vice versa.

Enlarging

On the screen, pull simultaneously two fingers apart or tap twice on the

display to enlarge a website or a document.

EN 16

3.4) Elements on the home screen

A B C

D E F G H I

A) Google™ search

B) Microphone function for voice entry

C) Applications menu

D) Back to the previous screen

E) Back to the home screen

F) View recently used applications (to exit the display, wipe your finger

across the screen)

G) Volume control

H) Opens Submenu

I) Status display: The lower right corner is used to display different

messages (e. g. battery indicator, time or Wi-Fi connection,

available downloads)

3.5) Personalizing the start screen

The start screen has two more pages on the left and the right side, so that

all together five pages are available for an individual design. To display the

pages, pull the window with your finger from right to left or vice versa. You

can set up the start screen individually (as well as the four additional pages)

by adding or removing application shortcuts and widgets or changing the

desktop background.

To customize the start screen, tap first on the application menu on the right

top of the page. Then proceed as follows:

Applications

After you have tapped on the applications menu, a screen opens displaying

all currently available applications. Press longer time on an application,

which you would like to add to the start screen and then move it to the

desired position.

If you pull up the application to the edge of the screen, you can also place

the icon on the next screen.

Widgets

After you have tapped on the applications menu, a screen opens displaying

all currently available applications. Tap on the left top of the picture on

"WiDgetS" or pull the finger from right to left across the screen to display all

available widgets.

Now press longer time on the widget, which you would like to add to the

start screen and then move it to the desired position.

3.6) Removing applications from the start screen

A) To remove an application or a widget from the start screen, press as

long on the appropriate icon, until "reMove" or rather "X" appears on the

top of the screen.

B) Hold down the symbol and drag it on "reMove" or rather "X".

C) Once the symbol lights red, you can drop it and the application or

the widget is removed from the start screen.

iThis process only deletes the shortcuts on the start screen but not the

applications itself. An instruction how to fully delete an application from

your SurfTab, can be found under point 4.2.

EN 18

3.7) Changing the desktop background

A) Touch the start screen as long at any point until a window appears with

the message "Choose wallpaper from".

B) Now choose whether you want to use a background image from the

gallery, the wallpapers or the live wallpapers (moving pictures).

C) Click on the desired image and confirm your choice with "Set WaLLpaper".

iIf you select a background from the gallery, you also have the option to

select a specific area for your desired background motif.

3.8) The display keyboard

When you tap a text field in order to enter text (e. g. a web address), the

on-screen keyboard appears. Enter the text as usual via the keys. Besides that

use the keys "?123" or "~\{" to enter numbers and special characters. For the

entry of alternative letters (e. g. those with accents or umlauts), press and

hold a particular letter and the available characters appear.

iGo via "sEttings"+"languagE anD input" to the menu point "anDRoiD™ kEyboaRD"

in order to adjust further keyboard settings.

3.9) Using the camera

Tap on the applications menu and afterwards on the camera icon to activate

the function.

iTo press the shutter button, tap on the blue circle, which is below or right

of the picture; to zoom the picture in or out, drag the small circle from

the "-" to the "+" symbol and vice versa.

3.10) Creating an email account

To set up an email account, choose "eMaiL" via the applications menu

and then proceed as follows:

A) Tap on the upper edit box and enter a valid email address as well

as the corresponding password.

B) Tap on "next" to confirm your entry.

C) In the next steps you can adjust other account settings. Once you have

set up the account according to your wishes, the email application

ready for use.

3.11) Removing an email account

To remove the email account, choose "eMaiL" via the applications menu

and then proceed as follows:

A) Tap the top right on the three inter-related points (settings) and then

select on the left the field with the name of your account.

B) Now scroll inside the right windows to the very bottom and tap on

"reMove account".

C) Confirm your choice with OK and the account is deleted.

4) Using the App Center

Tap on the start screen or in the applications menu on the icon, through

which you can access the App Center. In addition to the applications and

widgets that are preloaded on the SurfTab already, you can find there

a variety of additional programs, applications and books used to extend

the functions of your SurfTabs.

If you use the App Center for the first time, you must read the terms of use

and accept these. Then you can browse the App Center by category or by

keywords in order to specifically look for an application.

4.1) Downloading and using applications

A) After you have selected an application, tap on "DoWnLoaD" to install

the application.

B) Once the application has been downloaded and installed, it is located

in the applications menu. Operate the applications either from there

or add them to your start screen (see also section 3.5).

iCertain applications need to be purchased before they can be downloaded.

For the selection of the correct payment method, please follow the

instructions of the App Center.

4.2) Uninstalling applications

If you like to uninstall an application, go via "SettingS" to "appS" and select the

application that you would like to delete. Tap now in the following window

on "uninStaLL" and confirm your choice once again with ok".

Autres manuels pour SurfTab breeze 7.0

Table des matières

Autres manuels TrekStor Comprimé

TrekStor

TrekStor SurfTab twin 10.1 Manuel utilisateur

TrekStor

TrekStor SurfTab breeze 7.0 Manuel utilisateur

TrekStor

TrekStor SurfTab xiron 7.0 3G Manuel utilisateur

TrekStor

TrekStor SurfTab xintron i 10.1. Manuel utilisateur

TrekStor

TrekStor SurfTab xiron Manuel utilisateur

TrekStor

TrekStor SurfTab breeze 10.1 quad Manuel utilisateur

TrekStor

TrekStor SURFTAB THEATRE L15 Manuel utilisateur

TrekStor

TrekStor SurfTab ventos 7.0 Manuel utilisateur

TrekStor

TrekStor surftab breeze 9.6 quad Manuel utilisateur

TrekStor

TrekStor SurfTab breeze 7.0 quad Manuel utilisateur

TrekStor

TrekStor SurfTab ventos 7.0 Manuel utilisateur

TrekStor

TrekStor SurfTab ventos 8.0 Manuel utilisateur

TrekStor

TrekStor SurfTab twin 10.1 Manuel utilisateur

TrekStor

TrekStor SurfTab ventos 7.0 HD Manuel utilisateur

TrekStor

TrekStor SurfTab breeze 7.0 quad Manuel utilisateur

TrekStor

TrekStor PrimeTab S11B Manuel utilisateur

TrekStor

TrekStor SurfTab xiron 10.1. Manuel utilisateur

TrekStor

TrekStor SurfTab ventos 9.7 Manuel utilisateur

TrekStor

TrekStor SurfTab duo W3 Manuel utilisateur

TrekStor

TrekStor SurfTab breeze 10.1 quad Manuel utilisateur

TrekStor

TrekStor SurfTab twin 11.6 Manuel utilisateur

TrekStor

TrekStor SurfTab theatre 13.3 Manuel utilisateur

TrekStor

TrekStor SurfTab breeze 7.0 quad 3G Manuel utilisateur

TrekStor

TrekStor surftab breeze 9.6 quad 3g Manuel utilisateur

Manuels Comprimé populaires d'autres marques

Laser

Laser MID-1060 Guide de l'utilisateur

MUNBYN

MUNBYN IRT09J Guide de démarrage rapide

Motorola

Motorola MC3090R - Win CE 5.0 Professional 520 MHz Manuel utilisateur

Dell

Dell Latitude ST Manuel du propriétaire

Lenovo

Lenovo IdeaTab S6000L Manuel du propriétaire

Venturer

Venturer WT9L11 Manuel utilisateur

EDUGEAR

EDUGEAR UnoBook Manuel utilisateur

Philips

Philips PI3210G/58 Manuel utilisateur

ADLINK Technology

ADLINK Technology IMT-BT Manuel utilisateur

TwinMOS

TwinMOS TwinTAB-T102D1 Manuel utilisateur

Archos

Archos 9.7 xenon Manuel utilisateur

Getac

Getac E100 Manuel utilisateur

HANNspree

HANNspree HANNspad SN70T3 Manuel utilisateur

Philips

Philips PI3105W2/55 Manuel utilisateur

LG LG-V935 Manuel utilisateur

Zeki

Zeki TBDB763B Manuel utilisateur

Ricoh

Ricoh eQuill Manuel utilisateur

DT Research

DT Research DT365CT Instructions de montage
