Reset to Factory Default and Master Cards Programming
To reset tofactory default, power off, press the Exit Button (or connect “OPEN”
and “GND” to be short circuit), hold it and power on, there will be two beeps,
and the LED light turns into orange, release the exit button (or disconnect
“OPEN” and “GND”), then read any two cards on the external reader, the LED
will turn into red, means reset to factory default successfully. Of the two cards
reading, the 1 one is Master Add Card, the 2 one is the Master Delete Card.
Remarks:
The Master Cards are not included in the standard packing. Thetype of the
Master Card is according tothe external reader. For example: the external
reader is 125KHzHID Reader, then the Master Card must be 125KHz HID cards.
If no Master Cards added, must press the Exit Button for at least 10 seconds
before release.
Reset to factory default, the user's information is still retained.
PROGRAMMING
Programming will vary depending on access configuration. Follow the
instructions according to your access configuration.
Notes:
Remote Control: Please use the Infrared Remote Controlto program the
Pulse Mini. The “IR” on the Pulse Mini is the infrared receiving window,
please direct the Remote Controlto it.
User ID number: Assign a user ID to the access card in order to track it.
The commonuser ID number can be any number from 0~999.
IMPORTANT: User IDs do not have to be proceeded with anyleading zeros.
Recording of User ID is crucial. Modifications tothe user require the User
ID be available.
PIN: Can be any 4~6 digits except 8888 which is reserved.
Enter and Exit Program mode
Programming Step Keystroke Combination
1. Enter Program Mode (Master Code) #
(Factory default is 123456
2. Exit Program Mode *
