SUMMARIZE
TR Series helical gearmotor is a new generation mechanic-electrical integrated product, which
designed basing on the modular system. It can be connected respectively with motors such as normal
motor, brake motor, explosion-proof motor, frequency conversion motor, servo motor, IEC motor and so
on. It can be mounted discretionary six orientation in solid space. This kind of product is widely used in
drive fields such as textile, foodstuff, beverage, chemical industry, automatic arm ladder, automatic
storage equipment, metallurgy, tobacco, environment-protection, logistics and so on.
1. Transmission ratio with fine stage covers a wide range;
2. Compact structure takes up small room;
3. low vibration; low noise; low energy dissipation;
4. Refined design; reliable and wearable; wide usage;
5. Modular, multistructure, can be combined in many forms to meet needs of all kinds of transmission
conditions.
TR Series helical gearmotor
of 1-stage, 2-stage or 3-stage
helical gears
unit and motor. The
helical
gear
which use the material of high quality alloy steel with the surface hardened takes shape through
processing of high-precision equipment. Except the TR..28 housing with aluminum alloy, all are cast iron
housing. housing is exactly processed to ensure the shape and position precision. And it reaches advanta-
geous performance such as: strong bearing capacity, long service-life; small volume; big ratio; light weight,
high efficiency, low noise.
TR Series helical gearmotor
has more than ten models. Combined with TRF series, the multi-stage
gear reduction can be achieved. Power 0.12-160KW; Ratio 1.3-27001;Torque 69-18000Nm. It can
connect (foot, flange) discretionary and use multi-mounting positions according to customers’ require-
ments.
SUMMARIZE
PERFORMANCE CHARACTERISTICS
