SPS-5

Rate Computing Scale

Operation Manual

Revision 1.0

October 17, 1996

Contents subject to change without notice.

Transcell Technology, Inc.

975 Deerfield Parkway

Buffalo Grove, IL 60089

Tel (847) 419-9180

Fax (847) 419-1515

Web: www.transcell.net

ATTENTION:

To extend the life of your digital scale, do not drop items to be weighed onto the

platform or overload the scale beyond its rated capacity. Shock-loading and over-

loading may damage the load cell and void the warranty.

Table of Contents

Introduction..................................................................................................................................1

Getting Started.............................................................................................................................1

Basics of Operation.....................................................................................................................2

Rate Computing Operation..........................................................................................................3

Calibration....................................................................................................................................3

Specifications ..............................................................................................................................4

Updating Postal Rates.................................................................................................................5

Warranty and Service Information...............................................................................................6

Information in this document is subject to change without notice.

Introduction

The SPS-5 is a low-cost, easy to use, 5 lb rate

computing scale featuring the most commonly

used letter and small parcel rates offered by

the United States Postal Service.

Housed in an attractive and durable gray-

colored plastic enclosure, the scale looks great

on any desk at home or in the office.

The scale features a 6-key silicone rubber

keypad, which is usually found on more ex-

pensive scales, and displays its numerals on a

4-digit, easy-to-read LCD display. Six annun-

ciators let you know clearly what rate is cur-

rently displayed.

A large (6" x 8") plastic platter allows for easy

rate calculation of larger envelopes. An envi-

ronmentally friendly AC adapter is included at

no extra charge.

Getting Started

After unpacking the scale, a small amount of assembly is required:

;Locate the platter and affix to the scale in the holes provided. Be sure to align the end marked

“FRONT” with the front of the scale.

Please Do...

;Place the scale on a firm and stable floor or table.

;Plug the enclosed AC Adapter into the scale first, then into an AC outlet.

;Leave the scale on for at least 20 minutes before using. You will find the ON/OFF switch on the

back of the scale. You may leave the scale on at all times, if you wish.

;Press the ZERO key before operating the scale.

Please Do Not...

;Share an AC outlet with other noise producing products; i.e. anything with an electrical motor or

relay.

;Turn the scale ON with an object already on the platform.

;Operate the scale...

...in an area with changing ambient temperature.

...in direct sunlight.

...in an area with high humidity.

...in a dusty environment.

...in a windy area.

...in an area with vibration.

SPS-5 Operating Manual 1

Basics of Operation

MODEL SPS-5

SPS-5 Front Panel

KEY INDIC. FUNCTION

1ST Use this key to select the First Class / Priority Rate. The scale auto-

matically switches to Priority Mail for items weighing more than 11

ounces.

EXP Use this key to select the Express Mail Rate.

OZ Sets the scale in the correct zero position for accurate operation. Also

puts the scale back into ounce indication.

CAN Use this key to select the Airmail Letter rate to Canada. Please note

that this class of mail currently does not allow packages over 4 lb.

MEX Use this key to select the Airmail Letter rate to Mexico. Please note

that this class of mail currently does not allow packages over 4 lb.

INTL Use this key to select the Airmail Letter rate to countries other than

Canada and Mexico. Please note that this class of mail currently does

not allow packages over 4 lb.

Revision 10.96

Rate Computing Operation

How to obtain the proper rate for a letter or package:

1. Before weighing an item, make sure the scale shows a zero weight indication. If it does

not, remove all items from the platter and press the ZERO key.

2. Place the item on the center of the scale’s platter and allow the weight indication to stabi-

lize.

3. Select the desired class of mail by pressing the corresponding key.

MESSAGE MEANING / POSSIBLE SOLUTION

ππππππ A weight greater than 5 lb has been applied to the scale. Remove the weight from the plat-

ter. Try re-calibrating the scale if this doesn’t solve the problem. Otherwise, possible load

cell damage due to overloading.

“oVEr” The weight limit for the class of mail selected has been exceeded. This applies to the Air-

mail Letter rates which currently have a limit of 4 lb.

“Err 2” The scale’s calibration information has been lost. Re-calibrate scale.

Possible Scale Operation Error Messages

Calibration

Your SPS-5 scale is ready to use right out of the box. There is no need to calibrate the scale unless you

feel that the scale has become inaccurate. It is a good idea to check the calibration of your scale from

time to time with a precision test weight. Transcell recommends that you perform a new calibration on

your digital scale at least once a year. The SPS-5 must be calibrated with a 5 lb precision test weight.

To calibrate the scale:

1. Remove all items from the platter and turn the scale OFF. Press and hold the 1ST/PRI

key while turning the scale back ON.

2. The scale shows “CAL” briefly then “ZERO”.

3. Press the ZERO key. The scale then shows “ADD”.

4. Place the 5 lb test weight on the platter and wait for scale to show “SAVE”.

5. Press the INT’L key to save the 5 lb calibration value.

6. Once the 5 lb calibration value has been saved, the scale shows an “End” message.

7. You must now turn the scale OFF and then turn it back ON without pressing any keys.

Your SPS-5 is now calibrated and ready for use.

SPS-5 Operating Manual 3

Calibration - Continued

MESSAGE MEANING / POSSIBLE SOLUTION

Shows “Err”

Continuously The scale is unstable. Make sure you are not violating one of the Do Not’s in the “Getting

Started” section. Otherwise, the scale may require service.

Shows “Add”

Continuously The scale is not detecting weight internally. Possible damage to the load cell. Scale re-

quires service.

Possible Calibration Error Messages

Specifications

CAPACITY:

80 oz (5 lb) x 0.1 oz

CONSTRUCTION:

Housing: Gray ABS

Sub-Platform: Metal

Platter: Gray ABS

Feet: Non-skid Hard Rubber

DISPLAY:

4 Character, 7-Segment LCD

6 Annunciators

KEYPAD:

6-key Silicone Rubber Type

OVER CAPACITY ANNUNCIATION:

102% of Full Scale Capacity

POWER SOURCE:

AC Adapter, 9 VDC, 100 mA, incl.

WEIGHT:

Net Weight: 4.0 lb (1.8 kg)

Shipping Weight: 5.6 lb (2.5 kg)

PHYSICAL DIMENSIONS:

7.9in [200mm]

8.5in [215mm]

2.6in [65mm]

5.7in [145mm]

8.5in [215mm]

Revision 10.96

Updating Postal Rates

When the Post Office changes its rates, it is necessary to obtain a new, updated Rate Cartridge from

your dealer or reseller containing all the necessary rate information. The SPS-5 was designed in such a

way as to make this an easy, painless process. You will need a small Phillips head screwdriver to com-

plete the process. Please follow the directions listed below and you will have no problems.

To install your new Rate Cartridge:

1. Turn the scale OFF and unplug the AC adapter from the back of the scale.

2. Remove the top platform and set it aside.

3. Gently turn the scale completely over so that the bottom of the scale is facing you. Refer to the

drawing below.

4. Locate the Rate Cartridge Cover (a thin metal plate) located towards the front of the scale, held in

place by two (2) Phillips head screws.

5. Remove the two screws and the cover and set them aside so that they are not lost. Please do not

remove any other screws from the bottom of the scale!

6. The cavity inside will contain a small circuit board which is piggybacked onto another larger circuit

board. This smaller circuit board is the Rate Cartridge. Use your fingers to remove the old Rate Car-

tridge.

7. Take a look at the new Rate Cartridge. On one side of the circuit board, there is an IC and a five pin

socket. Install the new Rate Cartridge by lining up the five pins inside the scale with the five open-

ings of the socket on the Rate Cartridge.

8. Once all five pins are lined up with the socket, press the Cartridge gently down until it is completely

seated in place. There is no way to install the cartridge backwards. However, it is possible to overlap

one or more of the five pins. Please be sure to line up all five pins!

9. Replace the Rate Chip Cover and mounting screws, return scale to its upright position, and replace

the platter.

10.Once you re-connect the adapter, your scale is ready for use with its new, updated rates.

Front of Scale

RATE COMPARTMENT

RATE CARTRIDGE

SPS-5 Bottom View

SPS-5 Operating Manual 5

Warranty and Service Information

Seller warrants that the SPS-5 Rate Computing Scale will conform to written specifications,

drawings, and other descriptions made by the manufacturer, including any modifications

thereof. The Seller warrants the goods against faulty workmanship and defective materials. If

any goods fail to conform to these warranties, Seller will, as its sole and exclusive liability

hereunder, repair or replace such goods if they are returned within the following warranty

period:

Twelve (12) months from date of shipment from manufacturer.

These warranties are made upon the express condition that:

1) Transcell Technology, Inc. is given prompt written notice upon discovery by Buyer of such

non-conformity, with a detailed explanation of the alleged deficiencies;

2) Such goods are returned to the Seller at the expense of the Buyer;

3) Examination of such goods by Seller discloses that the nonconformity actually exists and was

not caused by accident, misuse, neglect, alteration, improper installation improper or un-

authorized repair, or improper testing, and

4) Such goods have not been modified, altered, or changed by any person other than the Seller

or its duly authorized repair agents.

5) Transcell Technology, Inc. will have a reasonable time to repair or replace such goods.

THESE WARRANTIES EXCLUDE ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, ORAL

OR WRITTEN, INCLUDING WITHOUT LIMITATION WARRANTIES OF MERCHANTABILITY

OR FITNESS FOR A PARTICULAR PURPOSE. SELLER WILL NOT IN ANY EVENT BE LIABLE

FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.

IN ACCEPTING THIS WARRANTY, THE PURCHASER OR BUYER AGREES TO WAIVE ANY

AND ALL OTHER CLAIMS FOR RIGHT TO WARRANTY FROM TRANSCELL TECHNOLOGY,

INC. SHOULD THE SELLER BE OTHER THAN TRANSCELL TECHNOLOGY, INC., THE

BUYER AGREES TO LOOK ONLY TO THE SELLER FOR WARRANTY CLAIM OR CLAIMS.

No terms, conditions, understanding, or agreements purporting to modify the terms of this war-

ranty shall have any legal effect unless made in writing and signed by a corporate officer of the

Seller.

Transcell Technology, Inc •975 Deerfield Pkwy •Buffalo Grove, IL 60089 •USA

TEL (847) 419-9180 •FAX (847) 419-1515

Revision 10.96

Table des matières

Autres manuels Transcell Technology Échelle

Transcell Technology

Transcell Technology SPC-150 Manuel utilisateur

Transcell Technology

Transcell Technology Neptune-6500 Series Manuel utilisateur

Transcell Technology

Transcell Technology WB-5040-SWP Manuel utilisateur

Transcell Technology

Transcell Technology TC-100 Series Manuel utilisateur

Transcell Technology

Transcell Technology PC 150 Manuel utilisateur

Transcell Technology

Transcell Technology SPS-30 Manuel utilisateur

Transcell Technology

Transcell Technology SPS-30 Plus Manuel utilisateur

Transcell Technology

Transcell Technology TC-2010 Series Manuel de la liste des pièces

Transcell Technology

Transcell Technology SRP-300 Manuel utilisateur

Transcell Technology

Transcell Technology TC-200-6 Manuel utilisateur

Transcell Technology

Transcell Technology PC 150 Manuel de la liste des pièces

Transcell Technology

Transcell Technology CS Series Manuel utilisateur

Transcell Technology

Transcell Technology EL 3000 Manuel utilisateur

Transcell Technology

Transcell Technology SPS-70 Manuel utilisateur

Transcell Technology

Transcell Technology DCSG series Manuel technique

Transcell Technology

Transcell Technology TC-2005 Series Manuel de la liste des pièces

Transcell Technology

Transcell Technology WEIGHBLOK Instruction manuelle

Transcell Technology

Transcell Technology NEPTUNE-5500 Series Manuel utilisateur

Transcell Technology

Transcell Technology TI-500E SS Manuel utilisateur

Transcell Technology

Transcell Technology ESW SERIES Manuel utilisateur

Transcell Technology

Transcell Technology TC-100 Series Guide de l'utilisateur

Transcell Technology

Transcell Technology TC-2010 Series Manuel de la liste des pièces

Transcell Technology

Transcell Technology PC35 Manuel utilisateur

Transcell Technology

Transcell Technology tcs3t series Manuel utilisateur

Manuels Échelle populaires d'autres marques

AWS

AWS ZEO-50 Manuel utilisateur

Gima

Gima Glass Body Fat Analyzer Manuel de la liste des pièces

Seca

Seca 374 Manuel utilisateur

TEC

TEC TEC SL59 SERIES Manuel utilisateur

Axis

Axis B/E Series Manuel utilisateur

Alecto

Alecto ACW-40 Manuel utilisateur

Rice Lake

Rice Lake MSI-4260 IS Manuel utilisateur

IKA

IKA RCT basic safety control Manuel utilisateur

ADE

ADE M20011 Manuel utilisateur

Duronic

Duronic KS3000 Manuel utilisateur

Digi

Digi SM-720 Manuel utilisateur

Cardinal

Cardinal CS Series Manuel utilisateur

Korona

Korona Kastella Manuel utilisateur

A&D

A&D FC-50Ki Manuel utilisateur

BDA

BDA CAMARGUE Manuel utilisateur

Tanita

Tanita HD-357 Manuel utilisateur

Leifheit

Leifheit 03173 Manuel utilisateur

Lumme

Lumme LU-1340 Manuel utilisateur
