Installation and operation manual

Central Controller Unit

U-Match Inverter Systems

MultiSplit Inverter Systems

TCONTCCMHCM04A

April 2021

MS-SVX082A-EN

●This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction concerning use of the appliance by

a person responsible for their safety. Children should be supervised to ensure that

they do not play with the appliance.

●Use this equipment only for its intended purpose as described in this manual.

TCONTCCMHCM04A User Manual....................................................1

TCONTCCMHCM04A Wiring & Operating Instructions.....................................................2

Appearance.....................................................................................................................2

Specification....................................................................................................................3

Interface Features ..........................................................................................................3

Wiring Instructions..........................................................................................................4

Indoor Unit Dip Switch............................................................................................................6

TCONTCCMHCM04A Configuration File Replacement Instructions ...............................8

TCONTCCMHCM04A IP Modifying Instructions...............................................................11

Attached document..............................................................................................................14

1/ 14

TCONTCCMHCM04A Wiring & Operating Instructions

The core function of the protocol converter is to convert Modbus protocol

into BACnet protocol, implement Modbus device integration into BACnet

network. That is, the gateway acts as a Modbus Master (master station) and

supports connection of 4 Modbus Slaver devices. TCONTCCMHCM04A is a

standard BACnet network device in the BACnet network, and the user can

map the device data points in the MODBUS network one by one to the data

points in the BACnet network. The gateway provides the BACnet service

interface, and the third-party BACnet Client software integrates the Modbus

Slaver device into the system through the gateway.

Appearance

2/ 14

Specification

Function

Specification

Power supply AC and DC rated voltage 24V, working range 12V to 24V.

ROM

256M Flash

RAM

64M DDR2

Working

condition -20°C -- 70°C，5--90%RH (non-condensing)

Storage

Conditions

-40°C -- 85°C，5--95%RH (non-condensing)

Ethernet communication

Specification High-performance 100M/10M adaptive Industrial Network Card,

support AUTO

Protocol BACnet IP

RS-485 bus communication

Bus quantity

2 way RS485 bus communication

，Support 2 Modbus Slaver

per way

485

communication

parameters

9600 baud rate / 8 data bits /non parity /1 stop bit

Interface Features

Category Ports Function

Power supply V- +12/24V

V+ GND

3/ 14

Ethernet port Ethernet2 BACnet IP interface / Debug Interface

Modbus

interface 1

COM1

“A” of Modbus interface 1 (

Access gateway device

which address is 1,2

)

B “B” of Modbus interface 1(Access gateway device

which address is 1,2)

Modbus

interface 2

COM2

A “A” of Modbus interface 2(

Access gateway device

which address is 3,4

)

B “B” of Modbus interface 2(

Access gateway device

which address is 3,4)

RESET RESET Press the button 8 S continuously to

restart the

factory settings.

Wiring Instructions

TCONTCCMHCM04A default network portparameters are as follows：

IP address192.168.1.88

Subnet mask 255.255.255.0

Default gateway 192.168.1.1

TCONTCCMHCM04A should be used with gateway TCONTADPYCJA2A.

4/ 14

The specific connection diagram isas follows：

Connect to TCONTADPYCJA2A:

5/ 14

Indoor Unit Dip Switch

The address cannot be duplicated between the gateways connected to

the same TCONTCCMHCM04A. COM1 interface connect the gateway whose

address is 1&2; COM2 interface connect the gateway whose address is 3&4.

The indoor unit addresses under the same gateway cannot be duplicated,

and the address range is 1~32. The indoor units between different gateways

do not affect each other.

6/ 14

Indoor Unit Dip Switch

The address dip switch of the indoor unit is SW03, ON is 1, OFF is 0;

The address dip switch range is 1~32, dip switch setting as follows:

SW03

Address

…..

7/ 14

TCONTCCMHCM04A Configuration File Replacement

Instructions

1. The default IPof TCONTCCMHCM04A is 192.168.1.88 .

2. First, set the IP of the computer to the same network segment as

TCONTCCMHCM04A. Then “ping” the IP “192.168.1.88” to see if it can work;

if it works, then you can do the next setting.

3. If “192.168.1.88” cannot be pinged, press the RESET button for 8 seconds. After

HCM-04 restarts, ping 192.168.1.88. After pinging, you can start setting HCM-04.

4. File configuration

First double click to open “X2BACnet.exe” debugging software.

Click "File" on the menu bar to choose "Open… " or click on the toolbar to Open the

project.

8/ 14

In the dialog box, select the project file that you want to burn

Click "Gateway" on the menu bar to choose "Upload " or click on the toolbar to

upload the project.

In the pop up dialog box enter the gateway IP address, click the "Upload".
