TrailFX DHS001B Manuel utilisateur

Page 1 of 4

TrailFX Drop Down Step

Part No. DHS001B / DHS002B

Fits: 2015-2019 Chevrolet, GMC / Colorado / Canyon Crew

Cab & Ext Cab

Product image

TO AVOID BEING SCRATCHED, PLEASE PROTECT THE SURFACE OF

THE TAILGATE VENT COVER CAREFULLY.

REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT.

PARTS LIST:

Item Qty Part Description Tools Needed

11Step Bar Driver Side 13 MM SOCKET & WRENCH

21Step Bar Passenger Side 14 MM SOCKET & WRENCH

33Mounting Bracket Driver Side 15 MM SOCKET & WRENCH

43Mounting Bracket Passenger Side RATCHET

512 M8 Bolt TORQUE WRENCH

612 M8 Lock Washer

712 M8 Flat Washer

812 M10 Flange Bolt

912 M10 Flange Nut

10 12 M8 Nut Clip

ALIGN THE STEP BARS AS DESIRED AND TIGHTEN ALL M10 FASTEN-

ERS TO 30 ft. - lbs., AND THE M8 FASTENERS TO 15 ft.-lbs.

READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION.

60 min Drilling Not

Required

Cutting Not Re-

quired

Mounting Kit Images

ITEM 4

ITEM 3

Page 2 of 4

5. Grab Driver Side Bar and install loosely to mount

brackets with (6) M10 Flange bolts and (6) Serrated

Flange Nuts. See Figure 3.

6. Repeat for passenger side.

7. Align and adjust the step bars as needed and fully

tighten all hardware.

8. See Figure 4 for reference.

1. Remove plastic plugs from rocker panel.

INSTALLATION PROCEDURE

FIGURE

Figure 1

Remove Plastic Plugs

2. Start at the front driver side of vehicle and grab (2) M8

Nut clips (2) M8 hex head bolts, (2) M8 flat washer, and

(2) M8 lock washer to driver mount bracket to rocker

panel. Assemble loosely. See Figure 1 and 2.

3. Repeat for center and rear locations.

4. Repeat for passenger side.

Page 3 of 4

COMPLETE INSTALLATION

FIGURE 9

DRIVER SIDE SHOWN FRONT

Item 3 Item 3 Item 3

Page 4 of 4

Keystone Automotive Operations Inc. (KAO) warrants this product to be free of defects in material and workmanship at the time of pur-

chase by the original retail consumer. KAO disclaims any other warranties, express or implied, including the warranty of fitness for a

particular purpose or an intended use. If the product is found to be defective, KAO may replace or repair the product at our option,

when the product is returned prepaid, with proof of purchase. Alteration to, improper installation, or misuse of this product voids the

warranty. KAO’s liability is limited to repair or replacement of products found to be defective, and specifically excludes liability for any

incidental or consequential loss or damage.

Check out these other TrailFX Products!!

PRODUCT CARE

FAQ’s

1. Mounting bracket are not getting Installed properly.

In some cases Illustration images shown in Installation manual may not be the exactly same as per actual vehicle images ,also if Driver / Passenger side

mounting brackets are very identical in the design, suggest referring Parts Identification guide to avoid fitment issue.

2. Products are thumping / rattling after installation.

Please ensure that all required mounting brackets / hardware’s are installed & tighten correctly. Suggest using white lithium / regular grease between the

metal to metal contact surfaces.

3. Missing / Excess Hardware.

Recheck hardware count as per the part list.

4. Product not installing properly.

Ensure make model year, cab length and bed size of your vehicle is listed in the application. All installation steps are followed correctly.

Learn more about running boards on our website.
