TradeQuip 1001T Manuel utilisateur

About the TradeQuip brand

The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop

environment by professional users. With proven and trusted “Made for the

Trade” reliability, 'TradeQuip' branded products offer the very best in performance for an

affordable price. All backed by a 1year trade guarantee across 1,000+ distributors Australia wide.

04/20 Product Code: 1001T

Made in China to TQB Brands Pty Ltd specifications.

Visit us at www.tqbbrands.com.au

Product Code: 1001T

ENGINE CRANE

Specifications

Safe Working Capacity: 1,200kg (AS1418.5 approved)

Adjustable Boom: 250kg, 500kg, 750kg & 1200kg

Lifting Ram Capacity: 8,000kg > Available as Spare

Part: Product Code: 2008

Stabiliser Arms Clearance: 195mm

Dimensions: (Arms Ext): 2300(H) x 960(W) x 550(D)mm

See pic for boom length, height and capacity

Nett Weight: 85kg

Carton 1 of 2 : 1440 x 300 x 160mm (Weight: 59kg)

Carton 2 of 2 : 850 x 580 x 90mm (Weight: 32kg)

04/20 Product Code: 1001T

Made in China to TQB Brands Pty Ltd specifications Page | 2

Visit us at www.tqbbrands.com.au

WARNING INFORMATION

IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE

WARNING

The instructions and warnings contained in this manual should be read and understood before using or operating this equipment.

Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough

understanding of how this equipment works. Failure to observe any of the instructions contained in the manual could result in

severe personal injury to the user or bystanders, or cause damage to the equipment and property. Keep this manual in a

convenient and safe place for future reference.

Whilst every effort has been made to ensure accuracy of information contained in this manual, the TQB Brands Pty Ltd policy of

continuous improvement determines the right to make modifications without prior warning.

CONTENT

WARNING INFORMATION................................................................................................................................................................... 2

CONTENT............................................................................................................................................................................................. 2

STANDARD OPERATING PROCEDURE ................................................................................................................................................. 3

ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE.................................................................................................................... 4

PARTS DIAGRAM & PARTS LIST........................................................................................................................................................... 8

TROUBLESHOOTING............................................................................................................................................................................ 9

WARRANTY ....................................................................................................................................................................................... 10

04/20 Product Code: 1001T

Made in China to TQB Brands Pty Ltd specifications Page | 3

Visit us at www.tqbbrands.com.au

STANDARD OPERATING PROCEDURE

DO NOT use this equipment unless you have been trained and assessed to a competent level in its sate use and operation,

and have been given permission to use this

PRE-OPERATIONAL SAFETY CHECKS

Before using the foldable engine crane ensure it is in sound condition, and good working order.

Replace or repair damaged parts. Use recommended parts only. Non authorised parts may be dangerous and will invalidate

the warranty. The nuts and bolts supplied with the crane are all high strength and should not be substituted for inferior types.

Always inspect the chain and hook prior to use.

Always lock the legs and jib in position before lifting a load.

Keep the stand clean for best and safest performance.

Locate the stand in an adequate working area for its function, keep area clean and tidy and free from unrelated materials,

and ensure there is adequate lighting.

Use on a firm, level surface capable of sustaining the foldable engine crane lift and the load.

Operators should maintain correct balance and footing. Ensure the floor is not slippery and wear non slip shoes.

Ensure all non-essential persons keep a safe distance whilst the crane is in use.

DO NOT exceed the safe working capacity 1200kg.

DO NOT operate the crane if damaged.

DO NOT use crane in damp or wet locations. DO NOT expose to rain.

DO NOT allow untrained persons to operate the crane.

DO NOT use the crane to lift or support people.

DO NOT stand beneath, in front of, or to the side of the load.

WARNING

This double pump long ram is designed for lifting purposes only.

Not for supporting loads.

Do not load beyond its rated capacity.

INTENDED USE

For regular professional use, to raise and/or lower passenger car engines and transmissions during service or repair work.

DO NOT tilt the unit

Wear the correct PPE

04/20 Product Code: 1001T

Made in China to TQB Brands Pty Ltd specifications Page | 4

Visit us at www.tqbbrands.com.au

ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE

1. FEATURES

This TradeQuip hydraulic engine crane has a 8 tonne long stroke lifting ram and double acting pump with a maximum safe

working load capacity of 1200kg. It is designed to quickly fold up to save space in the workshop. It is very simple to use with

a single acting hydraulic pump equipped and an automatic safety valve to control the lowering speed.

The jib extends to required lifting capacities of 300kg, 600kg, 900kg or 1200kg secured by a single locking pin. Mounted on 6

swivel castor wheels for excellent manoeuvrability around the workshop, the lifting range is 0-2300mm so an engine can be

lifted clear out of the engine bay with little effort. With great stability of its wide legs, this crane can also be used to lift

machines or other heavy items, making for an excellent piece of equipment for the workshop or warehouse.

2. ASSEMBLY

Ensure assembly is done on a flat, level surface to prevent misalignment.

Step 1:

Fasten the two larger rear castor wheels (9) on the Base

structure with Bolts (21), washers (30) and nuts 31). Face

bolts up when installing.

Fasten the smaller two castor wheels (10) on the Base

structure with bolts (22), washers (24). Face bolts up when

installing.

Step 2:

Fasten the remaining larger two castor wheels (9) on the

front legs (4) with bolts (21), washers (30) and nuts (31).

Step 3:

Slide the legs (4) into the front of the base (1).

04/20 Product Code: 1001T

Made in China to TQB Brands Pty Ltd specifications Page | 5

Visit us at www.tqbbrands.com.au

Step 4

Fasten the guide plates (6) to the base frame (1) and front

legs (4) with bolts (14), washers (24), and nuts (23). Lift

one side of the base to align the hole on the frame to the

hole on each front leg (4), then insert the ring pins (5) into

the hole, and insert the cotter pin (7) into the hole of the

ring pin.

Step 5

Use two bolts (19), washers (26) and nuts (25) to connect the

bottom of the post (3) to the base frame (1).

Step 6

Use two bolts (14), washers (24) and nuts (23) to connect the lower

ends of the supports (6) to the inside of the base (1). Then use bolts

(16), washers (24) and nuts (23) to connect the top ends of the

supports to the post (3). Check to make sure the nuts are tightened.

Tighten all nuts.

04/20 Product Code: 1001T

Made in China to TQB Brands Pty Ltd specifications Page | 6

Visit us at www.tqbbrands.com.au

Step 7

Use bolts (15), washers (24) and nut (23) to attach the boom (2) to

the top of the post (3). Tighten nut (3) so that the boom (2) can

rotate freely, do not over-tighten as boom needs to be able to

rotate freely.

Step 8

Use bolts (17), washers (24) and nut (23) to fasten the lower end

of the long ram (11) to the post (3). Then bolt (18), washer (24)

and nut (23) to fasten the top of the long ram to the boom (2).

Step 9

Slide the boom extension (4) into boom (2) and use bolt (18), washer (24) and nut (23) to secure at the desired load

rating. Use bolt (20), washer (28) and nut (27) to attach the hook and chain (8) to the end of the boom extension.

The boom has four different load ratings; select desired rating before use.

04/20 Product Code: 1001T

Made in China to TQB Brands Pty Ltd specifications Page | 7

Visit us at www.tqbbrands.com.au

3. BEFORE USE

Prior to each use conduct a visual inspection by checking for abnormal conditions, such as cracked joints and damaged, loose,

or missing parts.

During transport it is possible that air has become trapped in the hydraulic system, causing poor lifting performance.

Purge any air from the system by fully opening the release valve (turn handle counter clock-wise as shown), then

while holding the boom down, operate pump handle rapidly several times.

Ensure all nuts and bolts are correctly fitted and tight.

4. OPERATION

TO RAISE:

Close the release valve by turning the handle clock-wise to a secure position. Do not over tighten.

TO LOWER:

Open the release valve by turning the handle counter clock-wise very slowly. The speed of lowering the load is

controlled by how much you turn the handle.

TO ADD OIL:

Only use high quality Hydraulic Oil. Do not use brake fluid, alcohol, glycerine, detergent motor oil. When adding oil

ensure dirt or foreign matter does not enter the system.

NOTE: ONLY USE GOOD QUALITY HYDRAULIC JACK OIL.

5. STORAGE

This foldable engine crane should always be stored under cover in a dry location and on a level surface with the jib in the fully

lowered position.

Note: Before raising the legs to the storage position ensure Bolt (6), and Nut (7) is inserted into the base support and tightened

to ensure the unit is stable and won't fall over.

6. MAINTENANCE

Replace or repair damaged parts. Use recommended TradeQuip genuine parts only. Non authorised parts may be

dangerous and will invalidate the warranty.

Check ram and plunger every 3 months for any signs of corrosion.

Clean as needed with a clean damp cloth.

7. SERVICE & REPAIR

Any Foldable engine crane found damaged in any way, or found to be worn or operates abnormally should be removed from

service until repaired by an authorised service agent. Owners and / or operators should be aware that repair of this product

may require specialised equipment and knowledge. Only authorised parts, labels and decals shall be used on this equipment.

Annual inspection of the hydraulic lift is recommended and can be made by an authorised repair facility to ensure that your

equipment is in optimum condition and that the equipment has the correct decals and safety labels specified by the

manufacturer.

04/20 Product Code: 1001T

Made in China to TQB Brands Pty Ltd specifications Page | 8

Visit us at www.tqbbrands.com.au

PARTS DIAGRAM & PARTS LIST

Part #

Description

QTY

Part #

Description

QTY

Base

Bolt M16x90

Boom

Bolt M16x80

Main Support Post

Bolt M14x100

Leg

Bolt M12x80

Lock Pin

Bolt M8x20

Support Strap

Bolt M8x12

Split "R" Pin

Nut M16

Chain & Hook Assembly

Flat Washer 016

3.5" Swivel Castor

Nut M14

3" Swivel Castor

Flat Washer 014

8 Ton Long Ram Jack

Nut M12

Handle

Flat Washer 012

Boom Extension

Lock Washer 012

Bolt M16x100

Nut M8

Bolt M16x120

Lock Washer08

Bolt M16x110

04/20 Product Code: 1001T

Made in China to TQB Brands Pty Ltd specifications Page | 9

Visit us at www.tqbbrands.com.au

TROUBLESHOOTING

TROUBLE

PROBABLE CAUSE

REMEDY

Will not hold load.

Dirt on valve seals.

1. Lower lifting boom. Close the

release valve and remove the oil

filler plug.

2. Place one foot on the leg and pull up

the lifting boom to its full height by

hand.

3. Open the release valve to lower the

lifting boom.

4. Worn seals.

Will not lift load.

Will not lift load to its full height.

Pump feels unsteady under load.

Pump will not lower completely.

Air block.

1. Purge air from the hydraulic system

by opening the release valve and

remove the oil filler plug

2. Pump handle a couple of full strokes

and close the release valve.

Pump will not lift to its full height.

Pump feels unsteady under load.

The reservoir could be overfilled.

Low hydraulic oil level.

1. Check the oil level. Remove the filler

plug. Top up oil to correct level.

Will not lower completely.

The pump cup seal could be worn out.

1. Replace cup seal.

Will not lower completely.

Air block.

Unit requires lubrication.

1. Release air from hydraulic pump by

removing filler plug.

2. Oil external moving parts.

04/20 Product Code: 1001T

Made in China to TQB Brands Pty Ltd specifications Page | 10

Visit us at www.tqbbrands.com.au

WARRANTY

TradeQuip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective

materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the

guarantee period is ninety days from the date of purchase.

Should the machine develop any fault, please return the complete tool to your nearest authorised warranty repair agent or contact

TQB Brands Pty Ltd Warranty team –warranty@tqbbrands.com.au.

If upon inspection it is found that the fault occurring is due to defective materials or workmanship, repairs will be carried out free

of charge. This guarantee does not apply to normal wear and tear, nor does it cover any damage caused by misuse, careless or

unsafe handling, alterations, accident, or repairs attempted or made by any personnel other than the authorised TQB Brands Pty

Ltd repair agent.

This guarantee applies in lieu of any other guarantee expressed or implied and variations of its terms are not authorised.

Your TQB Brands Pty Ltd guarantee is not effective unless you can produce upon request a dated receipt or invoice to verify your

proof of purchase within the 12 month period.

Consumer Guarantee

Our goods come with a guarantee that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement

or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have

the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

All images and illustrations shown are for reference purposes only. All information, specifications and illustrations in this manual are based on

the latest information available at the time of publication and are subject to change without notice. The information in this manual is periodically

revised to ensure the latest information is included. Download the latest version of this manual and other related technical documentation from

www.tqbbrands.com.au.

Table des matières

Autres manuels TradeQuip Système de levage

TradeQuip

TradeQuip 2056T Manuel utilisateur

TradeQuip

TradeQuip 2052 Manuel utilisateur

TradeQuip

TradeQuip 2002T Manuel utilisateur

TradeQuip

TradeQuip 2059T Manuel utilisateur

TradeQuip

TradeQuip 2103T Manuel utilisateur

TradeQuip

TradeQuip 1055T Manuel utilisateur

TradeQuip

TradeQuip 6007T Manuel utilisateur

TradeQuip

TradeQuip 2057T Manuel utilisateur

TradeQuip

TradeQuip 2053T Manuel utilisateur

TradeQuip

TradeQuip 2081T Manuel utilisateur

TradeQuip

TradeQuip 2102T Manuel utilisateur

TradeQuip

TradeQuip 2101T Manuel utilisateur

TradeQuip

TradeQuip 1030 Manuel utilisateur

Manuels Système de levage populaires d'autres marques

morse

morse 82H-124 Manuel utilisateur

Braun

Braun NL955 Series Manuel utilisateur

haacon

haacon 1889.10 Manuel utilisateur

Protekt

Protekt AT 252 Manuel utilisateur

R. Beck Maschinenbau

R. Beck Maschinenbau HS 600 Manuel utilisateur

Nova Technology International, LLC

Nova Technology International, LLC NAS Series Manuel utilisateur

Genie

Genie Z-60/34 Manuel utilisateur

Screen Technics

Screen Technics INTERFIT Vertical Up Lift Manuel utilisateur

Mortuary Lift

Mortuary Lift ULTIMATE 1000 Manuel utilisateur

Custom Equipment

Custom Equipment Hy-Brid 3 Series Manuel de programmation

Custom Equipment

Custom Equipment Hy-Brid Lifts 2 Series Manuel de programmation

Hy-Brid Lifts

Hy-Brid Lifts HB-P3.6 Manuel de programmation

BERG

BERG BeNomic EasyLeaf Manuel utilisateur

Powermate

Powermate LiftGate LG-3 Manuel utilisateur

Snorkel

Snorkel TM12 Series Manuel utilisateur

Terberg

Terberg OMNIDEKA Manuel utilisateur

Harmar Mobility

Harmar Mobility AL625 Mode d'emploi

Rotary

Rotary SPO16 Manuel utilisateur
