TPM TPC-7000 Series Manuel utilisateur

TPM TPC-7000 User Manual

TurboPAC

TPC-7000 User Manual

Version: V1.0 2018OCT30

To properly use the product, read this manual thoroughly is necessary.

Part No.: 81-00TPC700-010

TPM TPC-7000 User Manual

Revision History

Date

Revision

Description

2018/10/30

1.0

Document creation.

TPM TPC-7000 User Manual

The product, including the product itself, the accessories, the software, the manual and the software

description in it, without the permission of TPM Inc. (“TPM”), is not allowed to be reproduced, transmitted,

transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except

the documentation kept by the purchaser for backup purposes.

The names of products and corporations appearing in this manual may or may not be registered trademarks,

and may or may not have copyrights of their respective companies. These names should be used only for

identification or explanation, and to the owners’ benefit, should not be infringed without any intention.

The product’s name and version number are both printed on the product itself. Released manual visions for

each product design are represented by the digit before and after the period of the manual vision number.

Manual updates are represented by the third digit in the manual vision number.

Trademark

◼MS-DOS and Windows 95/98/NT/2000/XP, Visual Studio, Visual C++, Visual BASIC are registered

trademarks of Microsoft.

◼BCB (Borland C++ Builder) is registered trademark of Borland.

◼Other product names mentioned herein are used for identification purposes only and may be trademarks

and/or registered trademarks of their respective companies.

TPM TPC-7000 User Manual

Electrical safely

◼To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before

relocating the system.

◼When adding or removing devices to or from the system, ensure that the power cables for the devices

are unplugged before the signal cables are connected. Disconnect all power cables from the existing

system before you add a device.

◼Before connecting or removing signal cables from motherboard, ensure that all power cables are

unplugged.

◼Seek professional assistance before using an adapter or extension card. These devices could interrupt

the grounding circuit.

◼Make sure that your power supply is set to the voltage available in your area.

◼If the power supply is broken, contact a qualified service technician or your retailer.

Operational safely

◼Please carefully read all the manuals that came with the package, before installing the new device.

◼Before use ensure all cables are correctly connected and the power cables are not damaged. If you

detect and damage, contact the dealer immediately.

◼To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots, sockets and

circuitry.

◼Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it may

become wet.

◼If you encounter technical problems with the product, contact a qualified service technician or the

dealer.

TPM                                                                           TPC-7000 User Manual



5
Contents
CONTENTS.................................................................................................................................................................................. 5
TPC-7000 INTRODUCTION....................................................................................................................................................... 7
1. FEATURES.................................................................................................................................................................................... 7
2. SPECIFICATIONS............................................................................................................................................................................ 8
3. OVERVIEW ................................................................................................................................................................................ 10
4. DIMENSION............................................................................................................................................................................... 12
HARDWARE CONFIGURATION............................................................................................................................................... 13
1. INSTALLATION / REPLACEMENT...................................................................................................................................................... 13
1.1. Memory Installation or Replacement................................................................................................................... 13
1.2. SSD/HDD Installation or Replacement ............................................................................................................... 14
1.3. Mini-PCIe Network Cards Installation or Replacement ...................................................................................... 16
1.4. Expansion Card Installation or Replacement ....................................................................................................... 17
1.5. Mounting Installation........................................................................................................................................... 18
1.6. DIN Rail Mounting Installation (Optional).......................................................................................................... 20
1.7. Pinout for COM Ports, DC-In & Power Button Connectors ................................................................................ 21
MOTIONNET INTRODUCTION ............................................................................................................................................... 23
1. WHAT IS MOTIONNET?............................................................................................................................................................... 23
2. MOTIONNET FUNCTIONS ............................................................................................................................................................. 23
3. ADVANTAGE OF MOTIONNET ........................................................................................................................................................ 24
4. MOTIONNET PRODUCT FAMILY ..................................................................................................................................................... 26
PROJECT ENCRYPTION .......................................................................................................................................................... 27
1. BENEFITS .................................................................................................................................................................................. 27
2. AES BRIEF INTRODUCTION........................................................................................................................................................... 27
3. FUNCTIONAL ARCHITECTURE......................................................................................................................................................... 27
BIOS SETUP........................................................................................................................................................................... 29
1. INTRODUCTION .......................................................................................................................................................................... 29
2. BIOS SETUP.............................................................................................................................................................................. 29
3. MAIN SETTINGS ......................................................................................................................................................................... 30
4. ADVANCED SETTINGS .................................................................................................................................................................. 31
5. CPU CONFIGURATION................................................................................................................................................................. 32
5.1. Power & Performance.......................................................................................................................................... 33
5.2. PCH-FW Configuration ....................................................................................................................................... 34
5.3. ACPI Settings....................................................................................................................................................... 35
5.4. iSmart Controller ................................................................................................................................................. 36
5.5. F81846 Super IO Configuration .......................................................................................................................... 37

TPM TPC-7000 User Manual

5.5.6. Serial Port 1 Configuration .................................................................................................................................. 38

5.5.7. Serial Port 2 Configuration .................................................................................................................................. 39

5.5.8. Serial Port 3 Configuration .................................................................................................................................. 40

5.5.9. Serial Port 4 Configuration .................................................................................................................................. 41

5.5.10. F81846 Hardware Monitor................................................................................................................................. 42

5.5.11. CSM Configuration............................................................................................................................................ 44

5.5.12. USB Configuration ............................................................................................................................................ 45

5.6. CHIPSET SETTINGS ...................................................................................................................................................................... 47

5.6.1. PCH-IO Configuration......................................................................................................................................... 48

5.6.2. SATA and RST Configuration.............................................................................................................................. 49

5.6.3. Security Settings .................................................................................................................................................. 50

5.6.4. Boot Settings........................................................................................................................................................ 51

5.7. SAVE & EXIT SETTINGS ................................................................................................................................................................ 52

TPM TPC-7000 User Manual

1. TPC-7000 Introduction

The TPC-7000 series is applicable to smart industrial automation or controller, such as motion control and

digital input and output control. It is a compact and fanless design with an Intel® 7th / 6th Gen. Core™ i7 /

i5 / i3 desktop processor.

With fanless thermal, compact size, small footprint, and wide operating temperatures 0 ~ 60°C. TPC-7000

provides high performance, high versatility, and easy to install in field cabinets, and ultra-reliable operating

in the most demanding of industrial environment.

Motionnet is a super high-speed serial communication system, digital-serial control interface for

communication between host algorithm and axis-controllers, I/O devices and other function devices. Hence,

The SmartPAC series is an idea system for industrial automation, machine automation and motion control

markets.

1.1. Features

◼Robust and Flexible Fanless Embedded System

◼Support Intel ® Core ® i7/i5/i3 Desktop Processor

◼Support DDR4-2133 SO-DIMM, Max. 32GB

◼Support storage with SSD/HDD

◼Support RAID 0/1

◼Support DVI-I and DisplayPort

◼Support Mini PCIe, PCIe x8 and PCIe x1

◼Support Mini PCIe, PCI and PCIe x1 (Option)

TPM TPC-7000 User Manual

◼Intel ® I211-AT and Intel ® I219-LM Gigabit Ethernet port

◼1 x RS-232 and 1 x RS-232/422/485

1.2. Specifications

Product Name

TPC-7000A

TPC-7000B

System

CPU

Intel® 7th / 6th Gen. Core™ i7 / i5 / i3 Desktop Processor

Intel® Core™ i7-6700TE Processor 8M Cache, up to 3.40 GHz

Intel® Core™ i5-6500TE Processor 6M Cache, up to 3.30 GHz

Intel® Core™ i3-6100TE Processor 4M Cache, 2.70 GHz

Intel® Core™ i7-7700T Processor 8M Cache, up to 3.80 GHz

Intel® Core™ i5-7500T Processor 6M Cache, up to 3.30 GHz

Intel® Core™ i3-7101TE Processor 3M Cache, 3.40 GHz

TDP = 35W

Operating

System

For Intel® 7th Gen. Core™:

•Windows10 Iot (64-bit)

For Intel® 6th Gen. Core™:

•Windows10 Iot (64-bit)

•Windows Embedded Standard 7

(32-bit & 64-bit)

For Intel® 7th Gen. Core™:

•Windows10 Iot (64-bit)

For Intel® 6th Gen. Core™:

•Windows10 Iot (64-bit)

•Windows Embedded Standard 7

(32-bit & 64-bit)

Expansion

TPC-7000AC

TPC-7000AM

TPC-7000BC

TPC-7000BM

•1 x PCIe (x8)

•1 x PCI

•1 x PCIe (x8)

•1 x PCIe (x4)

2 x COM ports:

RS-232 only

1 x Motionnet:

MPE-L111

Inside

2 x COM ports:

RS-232 only

1 x Motionnet:

MPE-L111

Inside

Chipset

Intel® Q170

Memory

1 x DDR4-2133 SO-DIMM 8GB, expandable to 32 GB (Non-ECC)

Storage

2.5” 120GB SSD (the first one is external and installed by default, the

second one is internal for option.)

Super I/O

Fintek F81846AD-I

Audio Codec

Realtek ALC662

Network

•Intel® I219LM GbE PHY

•Intel® I211AT GbE

TPM TPC-7000 User Manual

Power Supply

DC-In 24V (3-pin terminal block)

BIOS

AMI BIOS

Chassis

Aluminum & steel, silver

Mounting

•Desktop mount / Wall mount (wall mount kit included)

•DIN rail mount (optional)

Dimensions (W

x H x D)

275 x 113 x 140 mm

(10.83” x 4.45” x 5.51”)

Weight

2.7 kg (5.95 lb)

Certificate

CE / LVD / FCC Class B

Remote Power

Button

2-pin terminal block for the external / remote power button

DC Input

24V DC-in through a 3-pin terminal block

LAN

2 x RJ45 GbE LAN

USB

•4 x USB 3.0

•2 x USB 2.0

Serial

2 x COM ports:

•COM1: RS-232/422/485, selectable from BIOS

•COM2: RS-232 only

Digital I/O

4-In & 4-Out (Optional)

Display

•1 x DVI-I

•1 x DisplayPort

Audio Jack

1 x Line-Out

SATA

2 x SATA III connector

Temperature

•Operating:

0 ~ 60 °C (32 ~ 140 °F) with airflow

0 ~ 50 °C (32 ~ 122 °F) without airflow

•Storage: 0~ 80 °C (32 ~ 176 °F)

Relative

Humidity

5 ~ 90% at 45 °C (non-condensing)

Vibration

Protection

Shinewave tests:

•Operating: 0.25 Grms / 5 ~ 500 Hz

•Non-operating: 1 Grms / 5 ~ 500Hz

Shock

Protection

•Operating: 20 g / 11 ms

•Non-operating: 40 g / 11 ms

TPM TPC-7000 User Manual

1.3. Overview

Oblique View

Rear View

No.

Name

No.

Name

LED Indicator

(from top to bottom: S1*, E1*,

SSD/HDD, Power)

COM Ports

(COM1 RS-232/422/485,

COM2 RS-232)

Power Button

DC-In Power Connector (3 pins)

Terminal Block for Remote Power

Button (2 pins)

USB 2.0 Ports

Audio Jack for Line-Out

Reserved for Motionnet or RS-232 Port

GbE LAN Ports

1st SSD/HDD Drive Bay

DVI-I Port

Expansion Card Cable Organizer

USB 3.0 Ports

Wall Mount Kit

DisplayPort

Antenna Holes

Be cautious of the hot surface when using the device.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels TPM Contrôleurs

TPM

TPM EasyPAC Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
