TP-Link TL-WN322G Manuel utilisateur

TL-WN322G

54M Wireless USB Adapter

2.4GHz 802.11b/g Rev：1.0.1

Specifications are subject to change without notice. is a registered trademark of

TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or

registered trademarks of their respective holders.

No part of the specifications may be reproduced in any form or by any means or used to make any

derivative such as translation, transformation, or adaptation without permission from TP-LINK

http://www.tp-link.com

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to pro-vide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not in-stalled and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

•Consult the dealer or an experienced radio/ TV technician for help.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

1) This device may not cause harmful interference.

2) This device must accept any interference received, including interference that may

cause undesired operation.

Any changes or modifications not expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.

FCC RF Radiation Exposure Statement

This device has been tested for compliance with FCC RF Exposure (SAR) limits in the typical

laptop computer configuration and this device can be used in desktop or laptop computers with

side mounted PCMCIA slots. This device cannot be used with handheld PDAs (personal digital

assistants). This device and its antenna must not be co-located or operated in conjunction with

any other antenna or transmitter.

CE Mark Warning

This is a class B product. In a domestic environment, this product may cause radio interference, in

which case the user may be required to take adequate measures.

III

National Restrictions

2400.0-2483.5 MHz

Country Restriction Reason/remark

Bulgaria General authorization required for outdoor use and

public service

France

Outdoor use limited to 10

mW e.i.r.p. within the band

2454-2483.5 MHz

Military Radiolocation use. Refarming of the 2.4 GHz

band has been ongoing in recent years to allow current

relaxed regulation. Full implementation planned 2012

Italy If used outside of own premises, general authorization is

required

Luxembourg None General authorization required for network and service

supply(not for spectrum)

Norway Implemented This subsection does not apply for the geographical area

within a radius of 20 km from the centre of Ny-Ålesund

Russian Federation Only for indoor applications

Package contents

The following contents should be found in your box:

¾One TL-WN322G 54M Wireless USB Adapter

¾One USB extension cable

¾One TL-WN322G 54M Wireless USB Adapter Resource CD, including:

•Drivers and Utility

•User Guide

•Other Helpful Information

)Note:

If any of the listed contents are damaged or missing, please contact the retailer from

whom you purchased the product for assistance.

CONTENTS

Chapter 1 Introduction................................................................................................1

1.1 Main Features..............................................................................................1

1.2 LED Status...................................................................................................1

1.3 System Requirements..................................................................................1

1.4 Network Configuration..................................................................................2

Chapter 2 Installation Guide.......................................................................................3

2.1 Before You Begin.........................................................................................3

2.2 Installation for Windows 2000 ......................................................................3

2.3 Installation for Windows Vista ......................................................................6

Chapter 3 Uninstall Guide.........................................................................................10

3.1 Uninstall the utility software through Control Panel....................................10

3.2 Uninstall the utility software through Programs..........................................12

3.3 Uninstall the driver software from your PC.................................................14

Chapter 4 Software Configuration ...........................................................................16

4.1 Station Mode Configuration........................................................................16

4.1.1 Current Network Information...............................................................16

4.1.2 More Setting........................................................................................16

4.2 Wireless network mode configuration ........................................................26

Chapter 5 Examples for application.........................................................................28

5.1 Example one: Configuration of WEP Encryption........................................28

5.2 Example two: Configuration of PSP Mode.................................................30

Chapter 6 Configuration for windows Vista ............................................................34

Appendix A: Glossary...................................................................................................37

Appendix B: Specifications..........................................................................................39

TL-WN322G 54M Wireless USB Adapter User Guide

Chapter 1 Introduction

The TL-WN322G 54M Wireless USB Adapter is a USB 2.0 pen-size wireless adapter

supporting IEEE 802.11b/g 2.4GHz radio operation. It provides high-speed wireless

connection with data rate up to 54Mbps. Additionally , wireless roaming allows the user to

move among different AP without losing the current connection. The adapter provides

excellent security features including：TKIP, AES, WPA, and up to 256 bit WEP encryption

security make the network almost impenetrable.

Featuring high performance transmission rates, simple installation and adaptability, as well

as strong security the TL-WN322G 54M Wireless USB Adapter is the perfect solution for

small office and home needs.

1.1 Main Features

¾Complies with IEEE 802.11b and IEEE 802.11g Standards.

¾Provided 64/128/256 bit WEP Encryption.

¾Supports WPA, WPA2, IEEE 802.1X, TKIP, AES.

¾Supports 54/48/36/24/18/12/9/6Mbps or 11/5.5/2/1Mbps wireless LAN data transfer

rates.

¾USB 2.0 interface and compatible with USB 1.1.

¾High Speed Data Rate Up to 54Mbps.

¾Supports Windows 98, ME, 2000, XP, 2003, 64bit XP, Vista.

¾Simulated AP Mode, And Supports PSP connection.

1.2 LED Status

The TL-WN322G 54M Wireless USB Adapter has a LED indicator and a built-in antenna

for wireless connectivity.

LED Indicator:

¾Ad-hoc Mode: Solid Green, whether the wireless device is connected or not.

¾Infrastructure Mode: Solid green while connected, and blinking during activity

1.3 System Requirements

The following are the minimum system requirements in order to use the TL-WN322G 54M

Wireless USB Adapter.

- -

TL-WN322G 54M Wireless USB Adapter User Guide

¾PC/AT compatible computer with a USB interface.

¾Windows 98/ME/2000/XP/2003/64bit XP/ Vista operating system.

(Windows 98/ME don’t support USB 2.0, the performance could influenced)

1.4 Network Configuration

To better understand how the wireless LAN products work together to create a wireless

network, it might be helpful to depict a few of the possible wireless LAN PC card network

configurations. The wireless LAN products can be configured as:

Ad-hoc (peer-to-peer) Mode

This is the simplest network configuration with several computers equipped with the PC

Cards that form a wireless network whenever they are within range of one another. In

ad-hoc mode, each client is peer-to- peer, would only have access to the resources of the

other client and does not require an access point. This is the easiest and least expensive

way for the SOHO to set up a wireless network.

The image below depicts a network in ad-hoc mode.

Figure 1-1 Ad-hoc mode.

Infrastructure Mode

The infrastructure mode requires the use of an access point (AP). In this mode, all wireless

communication between two computers has to be via the AP. It doesn’t matter if the AP is

stand-alone or wired to an Ethernet network. If used in stand-alone, the AP can extend the

range of independent wireless LANs by acting as a repeater, which effectively doubles the

distance between wireless stations.

The image below depicts a network in infrastructure mode.

- -

TL-WN322G 54M Wireless USB Adapter User Guide

Figure 1-2 Infrastructure mode.

Chapter 2 Installation Guide

2.1 Before You Begin

Before installing the new drivers of your TL-WN322G 54M Wireless USB Adapter, you

need to disable all of the Wireless LAN drivers that you have installed.

During the installation, Windows 98/ME/2000/XP/2003/64bit XP/ Vista may need to copy

systems files from its installation CD. Therefore, you may need a copy of the Windows

installation CD at hand before installing the drivers.

2.2 Installation for Windows 2000

Follow the steps below in order to install the TL-WN322G 54M Wireless USB Adapter

drivers:

1. Insert the Resource CD into your CD-ROM drive, Click the Start button and choose

Run. In the field that appears, enter F:\XXX\Win98_Me_2K_XP_X64\Setup.exe (if "F"

is the letter of your CD-ROM drive; XXX represents the setup program path, which is

labeled on the Resource CD).

Once the setup begins you will see the Install Shield Wizard, as the image depicts below.

- -
