Toyota Navigation and Multimedia System Manuel utilisateur
249
3
Interior features
3-2. Using the audio system
Audio system types
Entune Audio
Title Page
Using the radio P. 272
Using the CD player P. 274
Playing back MP3 and WMA discs P. 274
Operating an iPod P. 281
Operating a USB memory P. 287
Optimal use of the audio system P. 271
Using the AUX port P. 293
250
3-2. Using the audio system
Entune Audio Plus
Owners of this system should refer to the “Navigation and Multime-
dia System Owner's Manual”.
Entune Premium Audio with Navigation
Owners of this system should refer to the “Navigation and Multime-
dia System Owner's Manual”.
251
3-2. Using the audio system
3
Interior features
Audio system
Audio system operation buttons
Operations such as listening to audio, using the hands-free phone
and changing audio settings are started by using the following but-
tons.
“AUDIO” button
Display the “Select Audio Source”
screen or audio top screen. (→P. 268)
button
Press this button to access the
Bluetooth® hands-free system.
(→P. 312)
“CAR” button
Press this button to access the energy
monitor/consumption screen. (→P. 41)
“SETUP” button
Press this button to customize the
function settings. (→P. 261)
252
3-2. Using the audio system
Operating the touch screen
By touching the screen with your finger, you can control the audio
system, etc.
■Drag*
Touch the screen with your finger, and move the screen to the
desired position.
●Scrolling the lists
■Flick*
Touch the screen with your finger and quickly move the screen by
flicking your finger.
●Scrolling the main screen page
*:The above operations may not be performed on all screens.
■When using the touch screen
●If the screen is cold, the display may be dark, or the system may seem to
be operating slightly slower than normal.
●The screen may seem dark and hard to see when viewed through sun-
glasses. Change your angle of viewing, adjust the display on the “Display
Settings” screen (→P. 265) or remove your sunglasses.
●Flick operations may not be performed smoothly in high altitudes.
253
3-2. Using the audio system
3
Interior features
NOTICE
■To avoid damaging the touch screen
●To prevent damaging the screen, lightly touch the screen buttons with your
finger.
●Do not use objects other than your finger to touch the screen.
●Wipe off fingerprints using a glass cleaning cloth. Do not use chemical
cleaners to clean the screen, as they may damage the touch screen.
254
3-2. Using the audio system
Steering wheel audio switches
Operating the audio system using the steering wheel switches
Volume switch
• Increases/decreases vol-
ume
• Press and hold: Continu-
ously increases/decreases
volume
Back switch
• Returns to the previous
screen
Cursor switch
• Selects (radio stations/radio
presets/tracks/files/songs)
• Moves cursor
• Press and hold: Seek up/
down (radio stations)
• Fast up/down (tracks/files)
Enter switch
• Displays the preset/list
screen
• Selects items
Some audio features can be controlled using the switches on the
steering wheel.
Operation may differ depending on the type of audio system or navi-
gation system. For details, refer to the manual provided with the
audio system or navigation system.
255
3-2. Using the audio system
3
Interior features
“MODE/HOLD” switch
• Changes audio source
• Press and hold this switch
to mute or pause the current
operation
To cancel the mute or
pause, press and hold
CAUTION
■To reduce the risk of an accident
Exercise care when operating the audio switches on the steering wheel.
256
3-2. Using the audio system
USB/AUX port
Connecting using the USB/AUX port
■iPod
Push the lid.
Open the cover and connect an
iPod using an iPod cable.
Turn on the power of the iPod if it
is not turned on.
■USB memory
Push the lid.
Open the cover and connect the USB memory device.
Turn on the power of the USB memory device if it is not turned on.
■Portable audio player
Push the lid.
Open the cover and connect the portable audio player.
Turn on the power of the portable audio player if it is not turned on.
Connect an iPod, USB memory device or portable audio player to the
USB/AUX port as indicated below. Select “iPod”, “USB” or “AUX” on
the audio source selection screen and the device can be operated
via audio system.
STEP
1
STEP
2
STEP
1
STEP
2
STEP
1
STEP
2
257
3-2. Using the audio system
3
Interior features
CAUTION
■While driving
Do not connect a device or operate the device controls.
258
3-2. Using the audio system
Basic audio operations
Operating the audio system
Basic audio operations and functions common to each mode are
explained in this section.
Press the “∧” or “∨” button
to seek up or down for a
radio station, or to access a
desired track or file.
Press this knob to turn the audio sys-
tem on and off, and turn it to adjust
the volume.
Press this button to eject a disc Press to pause
or resume play-
ing music.
Insert a disc
into the disc slot
: Select to pause music.
: Select to resume playing
music.
Turn this knob to select radio
station bands, tracks and files.
Also the knob can be used to
select items in the list display.
