Toyan Engine FS-S100AT Guide de configuration
OWER'S INSTRUCTION MANUAL
FS-S100AT
Toyan
1
Thank you for Choosing our products,Model FS-S100AT is one kit with Precise Single Cylinder Four-stroke
model engine,. Before operating your engine, please read the "safety instructions and warnings" section on pages
3-4 of this booklet ,to strictly adhere to the advice contained therein
>Also,Please study the entire contents of this instruction manual,so as to familiarize yourself with engine
controls and other functions.
>Furthermore,Keep these instructions in a safe place so that you may readily refer to them whenever
Necessary
>It is suggested that any instructions supplied with radio control equipment,please check at the same time.
Toyan
2
CONTENTS
ABOUT YOUR TOYAN ENGINE----------------------------------------------------------------------------------------------3~4
BASIC STRUCTURE AND COMPONENTS---------------------------------------------------------------------------------5~6
INSTALLATION---------------------------------------------------------------------------------------------------------------------7
ATTENTION ABOUT STARTING--------------------------------------------------------------------------------------------8~10
OPERATION AND ADJUSTMENT----------------------------------------------------------------------------------------11~14
CARE AND MAINTENANCE-----------------------------------------------------------------------------------------------15~17
REPLACEMENT OF RUNNING PARTS----------------------------------------------------------------------------------------18
TROUBLESHOOTING METHOD FOR ENGINE FAILURE------------------------------------------------------------------19
ENGINE THREE VIEW DRAWINGS----------------------------------------------------------------------------------------- -20
MULTI-VIEW---------------------------------------------------------------------------------------------------------------------21
EXPLODED VIEWS--------------------------------------------------------------------------------------------------------------22
INSTALLATION INSTRUCTIONS FOR START MOTOR----------------------------------------------------------------- --23
OUR COMMITMENT--------------------------------------------------------------------------------------------------------- 24
Toyan
3
ABOUT YOUR TOYAN ENGINE
Remember that your engine is not a " toy ", but a highly efficient internal-combustion machine whose power is
capable of harming you, or others, if it is misused or abused.
As owner, you, alone, are responsible for the safe operation of your engine, so act with discretion and care at all
times.
As a professional user, please make sure the engine runs safely and carefully.
If at some future date, your Toyan engine is acquired by another person, we would respectfully request that these
instructions are also passed on to its new owner.
■The advice which follows for all production engines ,Incorrect operation or Ignore safety can lead to engine damage or
danger
Warning: These cover events which might involve serious (inextreme circumstances, even fatal ) injury.
●Model engine fuel is poisonous. Do not allow it to come into contact with the eyes or mouth. Always store it in a
clearly marked container and out of the reach of children.
●Model engine fuel is also highly flammable. Keep it away from an open flame, excessive heat, sources of sparks, or
anything else which might ignite it. Do not smoke or allow anyone else to smoke, near to it.
●Never operate your engine in an enclosed space. Model engines, like automobile engines, exhaust deadly
carbon-monoxide. Run your engine only in an open area.
Toyan
4
●Model engines generate considerable heat. Do not touch any part of your engine until it has cooled. Contact with the
muffler,cylinder head or exhaust header pipe, in particular, may result in a serious burn.
NOTES:
●This engine was designed for science experiments, model demonstrations, model car drives. Do not attempt to use
it for any other purpose.
●Mount the engine in your model securely, following the manufacturers' recommendations, using appropriate screws
and locknuts.
●Noise will happen when starts, please buy our matching muffler exhaust pipe or run away from the living
environment, because the noise of the operation may irritate others
●Safety glasses are strongly recommended
●Please note that the electric plug or battery wire should not touch the rotating parts. Also check whether the
connection of the throttle rocker arm is firm
●To be safe, keep all spectators (especially children) at least 3 meters away from engine when start the engine
●If you want to stop engin, shut off the throttle completely. In an emergency, clamp the fuel line in front of the carburetor
to cut off the fuel supply
●Do not attempt to remove the flywheel and start the synchronous pulley
●Do not extend the starting battery wire by more than 20cm. Otherwise, the starting current will be insufficient due to
the resistance voltage drop inside the battery line
●When starting the engine, please do not press the start button for a long time. The maximum starting time is 5 seconds.
If it does not start, please stop for 15 seconds and press the button to start again, so as not to burn the starting motor
and ignition circuit due to the long starting.
Toyan
5
BASIC STRUCTURE AND COMPONENTS
Engine Hood Idle screw
Cylinder head Throttle rocker arm
Carburetor
Fuel inlet Needle Valve
Start motor Muffler
Engine main body Pressurization mouth
Start belt Flywheel nut
Flywheel
Crankcase
Start gear
Toyan
6
BASIC STRUCTURE AND COMPONENTS
正時同步皮帶 Timing belt
Guide pulley
Fan blade
Exhaust pipe Cooling fan wheel
Synchronous Pulley
Camshaft
Crankcase bottom case Fuel outlet
Toyan
7
INSTALLATION
Make sure the surface of engine mounting is flush and in the same flat. Improper installation may lead to
deformation of crankcase, bearing, etc. Unstable operation and performance degradation will happen. The 3.0mm
hexagon socket screws are recommended when fixed engine. If the existing hole in the engine bracket is not perfectly
aligned with the engine mounting hole, do not install with force. If installed on other engine platforms, please purchase
adjustment pads to fit between the engine bracket and the engine
Please use the right stable engine bracket Do not use weak or defective engine supports
If the width of engine bracket needs to be adjusted,please purchase TOYAN special adjustment pad
Toyan
8
ATTENTION ABOUT STARTING
For the sake of safety, it is strongly recommended not to disassemble the engine and start the mechanism. If any
starting problems, please contact your local dealer or TOYAN technician to solve them. If return to the factory for testing,
TOYAN will provide you with high-quality after-sales service. If any problem caused by unauthorized disassembly, you will bear
the corresponding responsibilities and expenses
1 .Sparking plug
The Item of FS-S100AT requires a special sparking plug(including already) . , spark plug needs to be done through
the special CDI ignition control, when hall detects display the piston running to the TDC, spark plug will be ignited,
fuel will be ignition,then generate will acting.Therefore, you can control the engine speed by adjusting the damper to
achieve the best effect you want.
Check the relative position of the magnet before starting (as shown below)：
The marking point of the timing pulley is facing
Under the circumstances (see 11P),
Loosen the two screws on the flywheel,
Turn the collar to make the magnet position
To the arrow (45 degree direction),
Tighten two more screws
Toyan
9
2.Fuel
Please use quality guaranteed methanol model engine fuel. Self - dispensing or counterfeit fuel will greatly reduce
the performance and life span of the engine. Since it is a four-stroke engine, in order to ensure the normal
operation of the engine, we require the only 25% nitro methane fuel can be used. If high nitro fuel is used, the
ignition time and cylinder pressure of the engine will be greatly affected, and the normal and stable operation
cannot be maintained.when the nitro content of the fule increases or the fuel brand changes,it is recommended
to use the fuel-rick needle adjustment to run the engine to make sure the best settings for the new fuel can be
rechecked
Remind!
If the engine is running at very high speeds and on high nitro fuel,The life of the spark plug does not last
long,pls use Toyan special sparking plug if needed. Please note that engine fuel is toxic. Keep it out of contact
with eyes or mouth and always store it in a clearly marked container and place, and keep out of reach of
children. It is highly flammable. Keep away from open fires, overheating or any source of ignition
3.Fuel tank:
It is recommended to use a 100cc tank. The tank should be installed on the same flat as the engine. The gap
between the fuel inlet & outlet of the fuel tank and carburetor should be kept within 1 cm (the carburetor must
be higher than the fuel inlet & outlet of the fuel tank). If the gap is too high, the carburetor's working efficiency
will be reduced and the engine will be started adversely. To ensure clean fuel supply, pls use standard 5mm
silicone tubing and properly install oil filters. Since the engine itself relies on negative pressure to absorb oil, it is
recommended the muffling exhaust pipe can be used to pressurize the fuel tank.
