Tower Hobbies Sbach Manuel utilisateur

READ THROUGH THIS MANUAL

BEFORE STARTING CONSTRUCTION.

IT CONTAINS IMPORTANT

INSTRUCTIONS AND WARNINGS

CONCERNING THE ASSEMBLY

AND USE OF THIS MODEL.

WING LOADING

19 – 20 oz / ft2[58–62 g/dm2]

WEIGHT

4.0 – 4.3lbs [1814 –1928g]

Tower Hobbies®guarantees this kit to be free

from defects in both material and workmanship

at the date of purchase. This warranty does not

cover any component parts damaged by use or

modication. In no case shall Tower Hobbies’ liability

exceed the original cost of the purchased kit. Further, Tower

Hobbies reserves the right to change or modify this warranty

without notice.

In that Tower Hobbies has no control over the nal assembly or

material used for nal assembly, no liability shall be assumed nor accept-

ed for any damage resulting from the use by the user of the nal user-assem-

bled product. By the act of using the user-assembled product, the user accepts

all resulting liability.

If the buyer is not prepared to accept the liability associated with the use of this

product, the buyer is advised to return this kit immediately in new and unused condition

to the place of purchase.

To make a warranty claim, visit: towerhobbies/support

WARRANTY

TOWA2026

®A subsidiary of Hobbico, Inc.

®®

RADIO

4 – 5 channels, 4 servos

WING AREA

482.0in2[31.1dm2]

WINGSPAN

49.6 in [1260mm]

LENGTH

47.5 in [1207mm]

INSTRUCTION MANUAL

POWER

1.65" [42mm] diameter, 925W

RimFire .32 (42-50-800)

3300–4000 mAh 4S LiPo 75A ESC

(not included)

INTRODUCTION

Congratulations and thank you for purchasing the Tower

Hobbies Sbach EP. While the Sbach is primarily an aerobatic,

3D-type of plane, its contemporary and sleek lines make

it appealing to all kinds of pilots, both intermediate and

advanced. The Sbach can serve all as its light wing-loading

and large control surfaces make it an aerobatic machine,

while its long moments and large ying surfaces make it a

smooth-ying, everyday sport model, too.

For the latest technical updates or manual corrections, nd the

Sbach EP on the Tower Hobbies web site at www.towerhobbies.

com. If there is new technical information or changes to this

model a “tech notice” box will appear on the page.

ADDITIONAL ITEMS REQUIRED

Radio/Servos

A minimum 4-channel radio with four mini servos and 4 –

5-channel receiver are required to y the Sbach:

❍Futaba R617FS 7-channel FASST receiver (FUTL7627)

The Sbach is intended to be own with mini servos in the 20g

range such as Futaba S3150 or Futaba S3172SV mini servos.

❍(4) Futaba S3150 digital servos (FUTM0303)

(4) Futaba S3172SV mini servos (FUTM0125)

❍(4) 6" [150mm] servo extensions are required for the

ailerons (one on each servo and one in each channel

in the receiver).

❍(4) Tactic servo extensions for Futaba (TACM2090)

(4) Tactic servo extensions Universal (TACM2092)

Brushless Electric Motor

The electric setup for the Sbach is straightforward: a

Great Planes Electrifly Rimfire .32 on a 13 x 8 E or 14 x

7E prop with a 75A ESC powered by a 4S 3800mAh LiPo.

A Castle Creations Edge Lite 75 ESC* is illustrated in the

instruction manual.

❍RimFire .32 42-50-800 (GPMG4700)

❍APC 13 x 8 thin E prop (APCQ3080)

APC 14 x 7 thin E prop (APCQ4045)

❍Castle Creations Edge Lite 75 ESC (CSEM1200)

❍3300mAh – 4000mAh 4S LiPo:

FlightPower 4S 3300mAh 25C (FPWP2334)

FlightPower 4S 3600mAh 50C (FPWP5364)

FlightPower 4S 3800mAh 30C (FPWP3384)

* If setting the BEC voltage in the Castle Creations Edge Lite 75 ESC

higher than the factory default 5.0V, it is recommended to use a

separate BEC regulator such as the Castle Creations 10A BEC

regulator (CSEM0005) to power the radio system on-board the aircraft.

LiPo Battery Charger

To charge a 4S 3800mAh LiPo at 1C, a charger capable of

about 65 Watts output power is required (4S x 4.2V/cell =

16.8V x 3.8A = 63 Watts). The Triton EQ2 (GPMM3156) is

more than enough charger with 100W output AC and 120W

output DC.

Adhesives, Hardware &

Other Accessories

Other than common hobby tools here is a list of the rest of

the items required:

❍6-minute epoxy (TOWR3806)

❍30-minute epoxy (TOWR3810)

TABLE OF CONTENTS

INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

ADDITIONAL ITEMS REQUIRED . . . . . . . . . . . . . . . . . . . 2

Radio/Servos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Brushless Electric Motor . . . . . . . . . . . . . . . . . . . . . . . 2

LiPo Battery Charger . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Adhesives, Hardware & Other Accessories . . . . . . . . . 3

KIT INSPECTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

KIT CONTENTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

PREPARATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

ASSEMBLE THE WING. . . . . . . . . . . . . . . . . . . . . . . . . . . 5

ASSEMBLE THE FUSELAGE . . . . . . . . . . . . . . . . . . . . . . 9

Install the Horizontal Stabilizer. . . . . . . . . . . . . . . . . . . 9

Glue in the Horizontal Stabilizer. . . . . . . . . . . . . . . . . 12

Hinge the Elevators and Rudder . . . . . . . . . . . . . . . . 12

Hook Up the Elevator and Rudder. . . . . . . . . . . . . . . 14

Mount the Motor and ESC. . . . . . . . . . . . . . . . . . . . . 15

Final Radio Installation. . . . . . . . . . . . . . . . . . . . . . . . 20

FINAL ASSEMBLY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Mount the Landing Gear . . . . . . . . . . . . . . . . . . . . . . 20

Mount the Cowl . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

PREPARE THE MODEL FOR FLIGHT . . . . . . . . . . . . . . 24

Set the Control Throws . . . . . . . . . . . . . . . . . . . . . . . 24

Check the C.G. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Balance the Model Laterally . . . . . . . . . . . . . . . . . . . 25

PREFLIGHT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Motor Safety Precautions . . . . . . . . . . . . . . . . . . . . . 25

Motor/Propeller Discussion . . . . . . . . . . . . . . . . . . . . . .

Battery Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Range Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

AMA SAFETY CODE (excerpts) . . . . . . . . . . . . . . . . . . . 27

General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Radio Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

FLYING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

❍Epoxy brushes (GPMR8060)

❍Mixing cups (GPMR8056)

❍Mixing sticks (GPMR8055)

❍Threadlocker thread locking cement (GPMR6060)

❍Thin CA (GPMR6001)

❍Medium CA (GPMR6007)

❍CA applicator tips (HCAR3780)

❍CA accelerator (GPMR6035)

❍Great Planes Standard Precision Prop Reamer

(GPMQ5006)

❍Optional: Z-bend pliers (HCAR2000) (see step 15 on

page 14)

❍Drills: 1/16" [1.6mm], 1/8" [3.2mm], 5/32" [4.0mm], #49

(.073")

A Robart

Super Stand

II (ROBP1402)

is also handy

for working

on your

Sbach.

A covering iron with a cover sock may be required for

tightening and re bonding covering to the model that may

have loosened between the time the plane was manufactured

and the time the model was removed from the box. The 21st

Century iron is preferred because of its long cord, contoured

shoe and precisely adjustable temperature range:

❍Coverite 21st Century Sealing Iron (COVR2700)

❍Coverite 21st Century Cover Sock (COVR2702)

KIT INSPECTION

Before starting to build, take an inventory of this kit to make

sure it is complete, and inspect the parts to make sure they

are of acceptable quality. If any parts are missing or are not of

acceptable quality, or if you need assistance with assembly,

contact Product Support. When reporting defective or

missing parts, use the part names exactly as they are written

in the Kit Contents list. Visit: towerhobbies/support

PARTS LIST

Order No. Description

Wing

Fuselage

Tail Surfaces

Cowl

Hatch

Landing Gear

Wheel Pants

Spinner

Decals

Wing Tube

TOWA5030

TOWA5031

TOWA5032

TOWA5033

TOWA5034

TOWA5035

TOWA5036

TOWA5037

TOWA5038

TOWA5039

KIT CONTENTS

1. Cowl

2. Fuselage

3. Left Wing Half

4. Right Wing Half

5. Horizontal Stabilizer

6. Rudder

7. Wheel Pants

8. Main Wheels

9. Tailwheel Assembly

10. Wing Joiner

11. Pushrods

12. Main Landing Gear

13. Spinner

14. Nylon Parts

15. Hardware

16. Elevator Joiner &

Rudder Torque Rod

17. Hardware

12 13 14

CANOPY REMOVAL/INSTALLATION

The canopy hatch is held in place with tabs in the back and

springs over dowels in the front. To remove the canopy, push

forward to disengage the tabs, then lift the rear up and pull

the canopy back and out to disengage the dowels. (If you feel

too much pressure is required to push the canopy forward,

the tabs could be shortened slightly to shorten the “throw”

that the canopy has to be pushed.)

PREPARATION

Between the time the covering was applied to your model

and the time it arrives in your hands it is normal for the

covering to loosen and wrinkle – especially if it has been a

long time and/or the air is dry at your location (causing the

structure to contract and the covering to loosen). But this is

easy to x using the proper tools and techniques.

The best way to renew the covering job is with a covering

iron with a protective cover sock not only to tighten the

covering, but also to thoroughly bond the covering to the

wood underneath. The preferred tool is a 21st Century cover

iron with a cover sock set to about 300°F [150°C]. This

translates to about 280°F [140°C] measured on the surface

of the cover sock.

Begin with the wings. You may also do the fuselage and tail

surfaces now, or wait until they are needed for assembly later.

❏1. Over unsupported covering, glide the iron across, but

where the lm is over structure apply pressure to bond the

covering down. Adjust the heat setting as necessary so the

covering tightens, shrinks and bonds to the wood, but not

so hot as to cause seams to pull apart.

❏2. Where possible, support the structure underneath with

your free hand to prevent the sheeting from bending inward.

❏3. OPTIONAL: When you get to the ailerons, elevators

and rudder, puncture three or four pinholes through the

covering on the bottom of those surfaces between each

of the braces or “ribs.” This will allow heated, expanding

air to escape so the covering will tighten. These pinholes

may appear obtrusive at rst, but when the covering is

heated the pinholes virtually disappear. Heat the side of the

covering without the pinholes rst.

❏4. Stack a few paper towels on top of each other and cut

them into small squares. These small paper towel squares

come in handy for dabbing up excess CA or wiping up

epoxy when dampened with denatured alcohol.

❏5. NOTE: All machine-thread screws that thread into

metal (hex nuts, blind nuts, wheel collars, etc.) should

be lightly wetted with threadlocker.

❏6. NOTE: The procedure for preparing the holes in

wood for all wood screws is as follows:

A. Drill the hole with the drill specied in the step.

B. Install, then remove the screw to form “threads” in

the hole.

C. Add a drop or two of thin CA to harden the hole.

D. Allow the CA to harden, then install the screw(s)

with the hardware that is being mounted/installed/

attached (servos, control horns, etc.).

ASSEMBLE THE WING

Hook up the Ailerons

Refer to this image while hooking up the aileron.

S3171SV

S3171SV #49 [.073"]

Drill

5/8" [16mm]

90°

❏1.

Connect the aileron servo to your radio so you can power

the servo. Position the servo arm so it will be perpendicular

to the servo, then cut off the unused arms. Drill out the holes

in the arm with a #49 (.073") drill.

Horn all the way to

leading edge of aileron.

90° Pushrod Connector

1/16"

[1.6mm]

❏2. Hook up the aileron with the hardware shown; note

that the aileron horn is mounted all the way to the forward

edge of the aileron. Using care not to drill through the top

of the aileron, drill 1/16" [1.6mm] holes for the servo and

horn mounting screws. Don’t forget to temporarily remove

the screws and harden the holes with thin CA. Connect

the pushrod to a hole about 5/8" [16mm] out on the servo

arm and the middle hole in the aileron horn. This geometry

should provide the correct 3D throw with the transmitter

servo end points dialed to about 110%.

3. Prepare the other wing with the aileron servo the

same way.

❏4. Use 6 or 30-minute epoxy to glue the nylon alignment

pins into both wings with approximately 1/4" [6mm]

protruding from the wing.

❏5. Test-t, but do not glue the berglass wing tabs into

the ends of the wings.

❏6. Fit the wings to the fuselage with the wing tube. Make

sure the tabs insert into the fuselage and the holes in the

tabs align with the holes in the brackets for the tab screws

in the fuselage. Make any adjustments necessary.

7. Remove the wings and tabs. Use 30-minute epoxy to glue

the tabs into the ends of the wing and wipe away excess

epoxy. Before the epoxy hardens, reinstall the wings back

onto the fuselage and position the tabs so the slotted holes

will be centered over the holes in the brackets. Momentarily

remove the wings to be sure there is no excess epoxy

around the tabs that would inadvertently stick the wing to

the fuselage. Reinstall the wings and immediately proceed

to the next step.

❏8. Before the epoxy has hardened, fasten the tabs

with an M3 x 10 SHCS (socket-head cap screw) and M3

lock washers and at washers. Push the wings snugly to

the fuselage and allow the epoxy to fully harden before

removing the wings.

ASSEMBLE THE FUSELAGE

Installl the Horizontal Stabilizer

❏1. If you haven’t yet done so, tighten the covering over

the fuselage and the tail surfaces. Be certain to seal the

bottom fuselage covering to the front of the former so the

covering cannot pull away.

❏2. Test-t the elevators to the stabilizer with the hinges

and the joiner wire—you may insert T-pins through the

middle of any hinges that don’t remain centered.

❏3. View the elevators from whatever perspective

necessary to see that they are aligned with each other. If

necessary, remove the joiner and lightly “tweak” with pliers

to align the elevators.

❏4. Temporarily mount the elevator servo, then remove

it (it’s easier to drill the holes for the elevator servo now,

before the stab has been glued in).

❏5. Mount the wings to the fuselage. Slide the horizontal

stabilizer into position. View the model from the rear to see

if the stab is parallel with the wing.

❏6. If necessary, remove the stab and carefully sand the

stab saddle where necessary to align the stab with the wing.

❏7. Now that the stab is level with the wing, center the

stab laterally by using a ruler to equalize the distance from

both ends of the stab to the fuselage.

❏8. Once centered, stick T-pins into the trailing edge of

the stab on both sides of the fuselage to lock the trailing

edge into place.

❏9. Tie a loop around one end of an approximately 48"

[1200mm] non-elastic line. Fold a piece of masking tape

over the other end of the line. Mark a line on the tape.

❏10. Insert a pin into the middle of the fuselage crutch

across the top of the former as shown. Loop the line over

the pin.

❏11. Hold the line with the tape to one corner of the stab.

Swing the line over to the corner on the other end of the

stab. Adjust the stab and slide the tape along the line until

the stab is centered and equalized.

❏12. Once you’re satised with stab alignment, use a

ne-point felt-tip pen to mark the outline of the fuselage all

the way around both sides of the horizontal stabilizer. Even

though the ink and most of the covering on top of the stab

are black, you’ll still be able to see the line indicating where

the covering will be cut and removed in the next step.

❏13. Cut the covering 1/32" [1mm] inside the lines you

marked around the stab. A hobby knife may be used if

the blade is brand new and sharp so little pressure will be

required for cutting, but extreme care must be used to cut

only through the covering and not into the sheeting

otherwise, the stab will be weakened. The best way is with

a soldering iron with a cutting-type of tip. A heat setting of

about 500F [260C] seems to work well.

❏14. Wipe away any residual ink with a paper towel square

dampened with denatured alcohol, then peel the covering

from the stab.

Glue in the Horizontal Stabilizer

❏1. Gather your small paper towel squares and denatured

alcohol for epoxy clean up. Small balsa sticks chopped

up from 1/16" [1.5mm] balsa sheet are also handy for

“squeegeeing” away most of the epoxy before using the

paper towel squares.

❏2. Don’t forget to place the elevator joiner wire into the

fuselage. It can be held out of the way with a rubber band

as shown in following images.

CAUTION: Have everything ready and on-hand for gluing

in the stab. Work quickly and efciently because some

30-minute epoxies may harden faster than others and

time ies when trying to work with precision—you don’t

want the epoxy hardening up before you have the stab

accurately aligned. ❏3. Mix up approximately 1/4 oz. of 30-minute epoxy.

Apply epoxy all the way around the stab saddle on both

sides of the fuselage and to the top and bottom of the stab.

❏4. Slide the stab into position. Wipe away excess epoxy

with the balsa sticks and paper towel squares dampened

with denatured alcohol. Double-check alignment, place any

weight on the stab if required for alignment and allow the

epoxy to harden before proceeding.

Table des matières

Autres manuels Tower Hobbies Jouet

Tower Hobbies

Tower Hobbies Tower Trainer 40 Ready-to-Fly Manuel utilisateur

Tower Hobbies

Tower Hobbies Razor 3D Manuel utilisateur

Tower Hobbies

Tower Hobbies FUN 51 Manuel utilisateur

Tower Hobbies

Tower Hobbies Power Vee Manuel utilisateur

Tower Hobbies

Tower Hobbies CrazE Wing EP ARF Manuel utilisateur

Tower Hobbies

Tower Hobbies Tower Kaos 40 MKII Manuel utilisateur

Tower Hobbies

Tower Hobbies NO GRAVITY Manuel utilisateur

Tower Hobbies

Tower Hobbies TOWA2200 Manuel utilisateur

Tower Hobbies

Tower Hobbies TOWER TRAINER 60 MKII Manuel utilisateur

Tower Hobbies

Tower Hobbies UPROAR Manuel utilisateur

Tower Hobbies

Tower Hobbies P-51 MUSTANG MKII EP Rx-R Manuel utilisateur

Tower Hobbies

Tower Hobbies P-51D Mustang Manuel utilisateur

Tower Hobbies

Tower Hobbies Laser 200 Flatty Manuel utilisateur

Tower Hobbies

Tower Hobbies Millennium Master Rx-R Manuel utilisateur

Tower Hobbies

Tower Hobbies Slow Ride Manuel utilisateur

Tower Hobbies

Tower Hobbies Mini Uproar Manuel utilisateur

Tower Hobbies

Tower Hobbies RYAN STA Manuel utilisateur

Tower Hobbies

Tower Hobbies Turbo Vee 2 Instructions d'installation et d'utilisation

Tower Hobbies

Tower Hobbies Uproar V2 .46 EP ARF Manuel utilisateur

Tower Hobbies

Tower Hobbies F40 Corsair Manuel utilisateur

Tower Hobbies

Tower Hobbies F6F Hellcat Manuel utilisateur

Tower Hobbies

Tower Hobbies Tower Trainer 40 ARF Manuel utilisateur

Tower Hobbies

Tower Hobbies KAOSARF .60/EP Manuel utilisateur

Tower Hobbies

Tower Hobbies VISTA GRANDE EP Manuel utilisateur

Manuels Jouet populaires d'autres marques

marklin

marklin 37321 Manuel utilisateur

Canon

Canon PAPER CRAFT Manuel utilisateur

GREAT PLANES

GREAT PLANES Pitts M-12S Manuel utilisateur

NOCH

NOCH 14261 Manuel utilisateur

Hausler

Hausler 450 SE V2 Manuel utilisateur

Dynaflite

Dynaflite Daydream Manuel utilisateur

MiniacRC

MiniacRC MIGHTY MINI P40 WARHAWK Manuel

Kenner

Kenner Batman 63651 Manuel utilisateur

LEGO

LEGO 8527 Manuel utilisateur

iKarus

iKarus ECO 8 Manuel utilisateur

Multiplex

Multiplex EasyStar II Mode d’emploi

Walkera

Walkera 38 Mode d’emploi

Hasbro

Hasbro TRANSFORMERS BUMBLEBEE Manuel utilisateur

MD MXION SWD Manuel utilisateur

Mattel

Mattel Disney Pixar Cars Cozy Cone Spiral Rampway Manuel utilisateur

marklin

marklin 39671 Manuel utilisateur

Meccano

Meccano 15103 Manuel utilisateur

LEGO

LEGO TECHNIC 8735 Manuel utilisateur
