Food

Dehydrator

Safety and Instruction Manual

PLEASE READ CAREFULLY

T19001

T19001 Food Dehydrator

www.towerhousewares.co.uk

TECHNICAL DATA

Description: Food Dehydrator

Model: T19001

Rated Voltage: 220V-240V ~ 50/60Hz

Power Consumption: 250 Watts

DOCUMENTATION

We declare that this product conforms to the following product

legislation in accordance with the following directive(s):

2004/108/EC Electromagnetic Compatibility Directive.

2006/95/EC Low Voltage Directive.

2011/65/EU Restriction of Hazardous Substances Directive.

1935/2004/EC Materials & Articles in Contact With Food

(LFGB section 30 & 31).

RKW Quality Assurance, United Kingdom.

WARRANTY

This product is guaranteed for 12 months from the date of original

purchase. If any defect arises due to faulty materials of workmanship,

the faulty products must be returned to the place of purchase. Refund or

replacement is at the discretion of the retailer.

The Following Conditions Apply:

• The product must be returned to the retailer with proof of purchase.

• The product must be installed and used in accordance with the

instructions contained in this instruction guide.

• It must be used only for domestic purposes.

• It does not cover wear and tear, damage, misuse or consumable parts.

• RKW has limited liability for incidental or consequential loss or damage.

• This guarantee is valid in the UK and Eire Only.

An extended warranty is available for this appliance.

See back page for details.

Safety and Instruction Manual

Helpline: +44 (0) 844 984 0055

WARNING:

This appliance is double insulated.

Do Not connect any wire to the earth terminal.

IMPORTANT! WIRING SAFETY

(For UK Use Only) As the colours in the mains lead of this appliance

may not correspond with the coloured markings identifying the

terminals in your plug, please proceed as follows:

The wires in the mains lead are coloured in

accordance with the following code:

Blue [N] Neutral

Brown [L] Live

Plug Fitting Details (where applicable)

The wire coloured blue is the neutral and must

be connected to the terminal marked [N] or coloured black. The wire

coloured brown is the live wire and must be connected to the terminal

marked [L] or coloured red.

Always ensure that the cord grip is fastened correctly.

The plug must be ﬁtted with a fuse of the same rating already ﬁtted and

conforming to BS 1362 and be ASTA approved. If in doubt consult a

qualiﬁed electrician who will be pleased to do this for you.

Non-rewireable Mains Plug

If your appliance is supplied with a non-rewireable plug ﬁtted to the

mains lead and should the fuse need replacing, you must use an ASTA

approved one (conforming to BS 1362 of the same rating).

If in doubt, consult a qualiﬁed electrician who will be pleased to do this

for you.

If you need to remove the plug - disconnect it from the mains - and

then cut it off the mains lead and immediately dispose of it safely.

Never attempt to reuse the plug or insert it into a socket outlet as there

is a danger of an electric shock.

T19001 Food Dehydrator

www.towerhousewares.co.uk

PRODUCT SAFETY INFORMATION

• Check that the voltage of the main circuit corresponds with the rating

of the appliance before operating.

• Please ensure that the appliance is used on a stable, level, and heat

resistant surface.

• Do not immerse cords, plugs or any part of the appliance in water or

any other liquid.

• Do not leave the appliance unattended while it is operating.

• Close supervision is necessary when any appliance is used by or near

children or pets.

• This appliance can be used by children aged from 8 years and above

and persons with reduced physical, sensory or mental capabilities or

lack of experience and knowledge if they have been given supervision

or instruction concerning use of the appliance in a safe way and

understand the hazards involved.

• Children shall not play with the appliance.

• Cleaning and user maintenance shall not be made by children without

supervision.

• Switch off at the wall socket then remove the plug from the socket

when not in use or before cleaning.

• If the supply cord or appliance is damaged, stop using the appliance

immediately and seek advice from the manufacturer or its service

agent or a similarly qualiﬁed person.

• Do not let the cord hang over the edge of a table or counter or let it

come into contact with any hot surfaces.

• The use of accessory attachments is not recommended by the

appliance manufacturer, apart from those supplied with this product.

• Do not pull the plug out by the cord as this may damage the plug

and/or the cable.

• Do not use this product for anything other than its intended use.

• This appliance is for household use only.

• Do not carry the appliance by the power cord.

• Do not use the appliance outdoors.

• Never position the unit close to or on hot surfaces or open ﬂames.

• Do not spill liquid onto the base unit. If this happens switch off and

unplug from the mains, mop up the liquid and seek advice from a

qualiﬁed technician.

Safety and Instruction Manual

Helpline: +44 (0) 844 984 0055

• High temperatures are present during operation. Only touch the

handles on the unit.

• This appliance is Not intended for commercial use.

• Do not site the product under cupboards or near hanging fabric.

• This appliance can produce steam as part of the cooking process.

Avoid contact with steam escaping from the appliance.

• The appliance is not intended to be operated by means of an external

timer or separate remote control system.

• Extreme caution must be used when moving an appliance that

produces hot oil or other hot liquids from the cooking process.

• In the unlikely event the appliance develops a fault, stop using it

immediately and seek advice from the service department:

+44 (0) 844 984 0055

DISPOSAL OF THE UNIT

Appliances bearing the symbol shown here may not be disposed

of in domestic rubbish. You are required to dispose of old

electrical and electronic appliances like this separately.

Please visit www.recycle-more.co.uk or www.recyclenow.co.uk

for access to information about the recycling of electrical items.

Please visit www.weeeireland.ie for access to information about

the recycling of electrical items purchased in Ireland.

The WEEE directive, introduced in August 2006, states that

all electrical items must be recycled, rather than taken to landﬁll.

Please arrange to take this appliance to your local Civic Amenity

site for recycling, once it has reached the end of its life.

T19001 Food Dehydrator

www.towerhousewares.co.uk

WHAT’S IN THE BOX

Instruction Manual

Drying Rack

1. Lid

2. Dehydrating Trays x 5

3. Dehydrator Base Unit

4. Control Panel

BEFORE YOUR FIRST USE:

1. Remove your appliance from the packaging.

2. Before using the unit for the ﬁrst time, carefully clean the

unit and cover.

3. Do not use any aggressive detergents, brushes with metal or nylon

bristles or sharp objects such as knives or spatulas for cleaning

the appliance. Wipe with a sponge or cloth dampened in warm water.

4. Your appliance is now ready for normal use.

5. Dispose of the packaging in a responsible manner.

WARNING:

DO NOT immerse the unit in water.

Safety and Instruction Manual

Helpline: +44 (0) 844 984 0055

USING YOUR APPLIANCE:

Connecting the Unit

• Connect the appliance to the electrical supply. Make sure that the plug

is connected properly. The red power indicator light will illuminate.

Operating the Appliance

1. The LCD displays

then press /Time then into time setting，LCD

twinkling and displays

00hr

，press /Time button to set the working

time as you require, each press adds 1 hour. Press and hold to fast

forward，the Time setting range from 0-36 hours.，The appliance will

start to work 3 seconds after you have selected the time.

2. The working，Default temperature is 55oC. The LCD show

13hr

(remaining time) and

(working temperature).

3. You could adjust the temperature as you required while the

appliance is working. Press SET/oC into to temperature interface.

LCD display current temperature

press SET/oC button again

to set temperature as you require. Each press, increases the

temperature by 5o

4. Press and hold SET/oC to fast forward，the working temperature.

The setting range is 40oC - 70oC. The appliance will start to work

3 seconds after you have selected the temperature.

5. The LCD will return back working interface,

and

13hr

6. The appliance will go into standby mode once the timer reaches

7. To stop the appliance when it is in the middle of a cycle,

press the /Time

for 2 seconds, the appliance will enter standby

mode and display

T19001 Food Dehydrator

www.towerhousewares.co.uk

Selecting Food to Dehydrate:

1. Fruits

Most fruits can be prepared and stored, but their durations of

preparation are varied, and you may refer to the reference table for

details. When selecting the fruit, you should select the ripe ones

because they contain a large amount of natural sugar while the

unripe ones may taste bitter after they are baked.

2. Vegetables

Vegetables selected should be fresh, tender, and free from

deterioration or spoilage.

3. Meat/poultry/seafood

The food should be fresh, however, the food that has just been taken

out of refrigerator must not be selected, otherwise a great deal of

water, when the food baked, may be produced and ﬂow into the

main machine. After the preparation of dried meat is completed, it

should be sealed and refrigerated.

Fruit

1. Before putting fruit into the tray, you should wash them clean and

remove water on their surface.

2. The bad or deteriorated part of the fruit should be removed.

3. Fine fruits like grapes may be put into the tray as a whole for baking.

4. For bigger fruits, you had better cut them into parts between

6-13mm

5. Light-coloured fruits like apples, pears, peaches, etc. will turn into

darker colour during baking storage. If you want to reduce the

change of colour, you may handle it in one of the following ways:

A) Using pineapple or lemon juice Soak the sliced apple, pineapple,

peach or other fruit into the lemon juice directly. Take it out after two

minutes. Wipe it with paper or cloth and then put it into the tray for

baking.

B) Using syrup for heating treatment. Put the sliced fruit into the

syrup. Boil it and then soak it in the syrup for 35 minutes (do not

stir). Remove the fruit and clean the fruit with fresh water. Wipe it

with paper or cloth and then put it into the tray for baking.

Safety and Instruction Manual

Helpline: +44 (0) 844 984 0055

Vegetables

1. Before putting the vegetable into the tray, you should wash the

vegetable clean and remove water on its surface.

2. Generally speaking, you had better cut the vegetable into slices

6mm thick. Other vegetables can be handled as following:

A) Soak the vegetable in boiling water for 1-2 minutes. Take out and

wash it with freezing water. Remove water on the vegetable and then

put it into the tray.

B) Boil some water and then put the vegetable on the steamer

or steaming for some time. Take it out and wash it with freezing

water. Remove water on the vegetable and then put it into the tray

(otherwise the excessive water will ﬂow into the main machine to

cause changer).

Meat /poultry/seafood

1. Remove the fat meat and then cut the rest of the meat into slices.

Which are about 3-6mm thick. You make cut squares on the sliced

meat loaves so that they become more tasty and refreshing after

they are dried.

2. If the meat slices are comparatively thick, they should be salted for

a long time so as to make them saturated with the ﬂavour, and the

thinner ones need shorter time of salting.

3. It will take around 6-8 hours for the food to be salted in refrigerator.

Food storage

1. You may store the food only after the tray has cooled down, The

food should be stored in clean dry and sealed containers, such as

glass tanks, food preservation bags to be used in refrigerator etc. If

you use a plastic bag to store the food, the air must be pumped out.

When you use other containers to store the food, you should try to

ﬁll the container as much as possible and compact it so as to reduce

the amount of air, thus preventing the food from getting damp.

2. Indicate the food name and date of storage.

3. Except for meat/poultry. Other food can be stored and put in a dry

and cool place. Food that will not be consumed immediately should

be put in refrigerator. If put in a sunlit or hot place, the food will

deteriorate easily.

4. Meat or chicken should be stored in refrigerator.

5. You had better check the food stored about once a month to prevent

the food from getting damp.

T19001 Food Dehydrator

www.towerhousewares.co.uk

Reference table of food baking temperature

Fruit drying time reference table

Fruit Processing

requirements Drying time Hr Effect

Apple

Peeled, pith

and cut into

6mm thick

sheet

5~15 Becomes soft, curved

Banana Peeled，cut into

3mm sheet 10~36 Brittle

Plum

After one

minute into

boiled water

then half open

blisters

5~25 Becomes soft, curved

Grapes 1~2 into boiled

water 10~36 Become soft

Lemon Cut into 6mm

thick sheet 5~25 Brittle

Mango Peeled cut

into 6mm thick

sheet 15~24 Becomes soft, curved

Orange Cut into 6mm

sheet 5~15 Becomes soft, curved

Kiwi Peeled cut

into 6mm thick

sheet 10~25 Becomes soft, curved

Pear

Peeled, pith

and cut into

6mm thick

sheet

8~24 Becomes soft, curved

Pineapple Peeled cut

into 6mm thick

sheet 10~21 Becomes soft, curved

Type of food Green leafy

Vegetables Bread Vegetable Fruit Peanut

Drying

temperature

oC45~50 55~70 55~60 55~65 40

Table des matières

Autres manuels Tower Hobbies Appareils de cuisine

Tower Hobbies

Tower Hobbies T19028 Manuel de l'opérateur

Tower Hobbies

Tower Hobbies T27013RG Manuel de l'opérateur

Tower Hobbies

Tower Hobbies T21001 Manuel de l'opérateur

Tower Hobbies

Tower Hobbies T80440 Manuel de l'opérateur

Tower Hobbies

Tower Hobbies T27021 Manuel utilisateur

Tower Hobbies

Tower Hobbies T21001 Manuel de l'opérateur

Tower Hobbies

Tower Hobbies T12056 Manuel utilisateur

Tower Hobbies

Tower Hobbies T27002 Manuel de l'opérateur

Tower Hobbies

Tower Hobbies T19003 Manuel de l'opérateur

Tower Hobbies

Tower Hobbies T27006 Manuel de l'opérateur

Tower Hobbies

Tower Hobbies T13004 Manuel de l'opérateur

Tower Hobbies

Tower Hobbies T80410 Manuel de l'opérateur

Tower Hobbies

Tower Hobbies T27020 Manuel de l'opérateur

Tower Hobbies

Tower Hobbies Kitchen Master T80433 Manuel de l'opérateur

Tower Hobbies

Tower Hobbies T12033RG Manuel de l'opérateur

Tower Hobbies

Tower Hobbies Presto PT27028WHT Manuel de l'opérateur

Tower Hobbies

Tower Hobbies T14016 Manuel de l'opérateur

Tower Hobbies

Tower Hobbies Presto PT27027WHT Manuel de l'opérateur

Tower Hobbies

Tower Hobbies T27020D Manuel de l'opérateur

Tower Hobbies

Tower Hobbies T1606 Manuel de l'opérateur

Tower Hobbies

Tower Hobbies T12009 Manuel de l'opérateur

Tower Hobbies

Tower Hobbies T27013 Manuel de l'opérateur

Tower Hobbies

Tower Hobbies T16017JTF Manuel de l'opérateur

Tower Hobbies

Tower Hobbies Cavaletto T10044PNK Manuel de l'opérateur

Manuels Appareils de cuisine populaires d'autres marques

Tayama

Tayama TYG-35AF Manuel utilisateur

AEG

AEG 43172V-MN Manuel utilisateur

REBER

REBER Professional 40 Guide de l'utilisateur

North American

North American BB12482G / TR-F-04-B-NCT-1 Manuel utilisateur

Presto

Presto fountain popper Manuel utilisateur

Westmark

Westmark 1035 2260 Manuel utilisateur

Zanussi

Zanussi ZCG64396XA Manuel utilisateur

HOFFEN

HOFFEN SM-9302M Manuel utilisateur

Philips

Philips HD3133 Manuel utilisateur

Ronco

Ronco Beef Jerky Manuel utilisateur

Hendi

Hendi 470411 Manuel utilisateur

Livoo

Livoo MEN386 Manuel utilisateur

Vogue

Vogue D446 Manuel utilisateur

croydon

croydon WR-10313-700 Manuel utilisateur

ADE

ADE AUTOMATIC-L Manuel utilisateur

Chefman

Chefman RJ43-SQ Series Manuel utilisateur

Vacmaster

Vacmaster VP680 Manuel utilisateur

Jetmaster

Jetmaster 900HG Manuel utilisateur
