INSTALLATION INSTRUCTIONS
The integral mounting-feet system incorporated into your Mask
speaker allows for a quick installation by following these easy steps.
1. Remove the grill and set aside in a clean dust-free environment.
2. Attach the speaker cable (observing the proper polarity with your
amplier; + to +, - to -). Make sure the left channel of the amplier
channel is connected to the left speaker channel and the right
amplier channel to the right speaker channel.
3. Make sure the mounting feet are turned inward to clear the
opening and insert the speaker into the ceiling or wall. Position the
speaker into the hole.
Note: The ange of the speaker is designed to ex and conform to
any small imperfections in the wall surface. Tighten the 6 screws on
the front of the bafe only enough to make the ange become snug
against the ceiling or wall. As you tighten the screws, the feet will
automatically ip into an outward position, thereby clamping the
drywall between the feet and the ange.
Caution: Over-tightening may warp the bafe, crack the wall, cause
the ange to distort, and make the grill difcult to install.
4. Secure the grill into place.
Note: The speaker ange incorporates high strength magnets to
secure the grill into place. Simply line the grill with the speaker ange.
PAINTING INSTRUCTIONS
If you plan on paint your grills, we recommend that it be done prior
to installation. The scrim cloth backing must be removed prior to
painting the grills. The surface should be cleaned with a light solvent
to remove any dust or residue. Totem Acoustic recommends a light
spray-painting using 5 parts thinning agent to 1-part paint. Do not
paint the grills while they are attached to the speaker.
Totem Acoustic offers a variety of accessories to make your
installation of the speakers and other Totem Acoustic products easy,
economical and professional. For more information, contact your
Totem Authorized Dealer or visit www.totemacoustic.com.
In our attempt to constantly improve, our products features and
specications are subject to change without notice.
Mounting Feet
Flange
The grills can be painted. However, great care
should be taken not to clog the holes, as this will
greatly reduce the sound quality of the speakers.
