Total Control MRX-2 Manuel utilisateur
Owner’s Manual
MRX-2
Network Base Station
M X-2 Owner’s Manual ©2014 Universal emote Control, Inc.
The information in this manual is copyright protected. No part of
this manual may be copied or reproduced in any form without prior
written consent from Universal emote Control, Inc.
UNIVE SAL EMOTE CONT OL, INC. SHALL NOT BE LIABLE FO
OPE ATIONAL, TECHNICAL O EDITO IAL E O S/OMISSIONS
MADE IN THIS MANUAL.
The information in this manual may be subject to change without
prior notice.
Total Control is a registered trademark of Universal emote Control,
Inc.
Complete Control is a registered trademark of Universal emote Control,
Inc.
U C - Control the Experience is a registered trademark of Universal
emote Control, Inc.
All other brand or product names are trademarks or registered
trademarks of their respective companies or organizations.
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
Page 1
Introduction
The MRX-2 Network Base Station allows for control of your
components by sending infrared and serial commands to your system.
This base station can be used with either a Total Control or a
Complete Control system.
When used in a Total Control System:
Expand zones throughout the home or commercial space by
installing multiple MRX-2’s.
Control equipment such as shades and TV lifts using the base
stations sensors, relays and RS-232 ports.
Control URC RF Lighting using the optional RFTX-1 transmitter.
When used in a Complete Control System:
The MRX-2 is required to use the CC Control App for iOS devices,
like the iPad and iPhone.
Extend control to other rooms by installing multiple MRX-2’s
throughout the home or commercial space.
The MRX-2 offers traditional R only control from compatible
URC MX series remotes via an optional RFX-250.
MRX-2 ETWORK BASE STATIO
Page 2
Features and Benefits
When used in a Total Control System:
Expand Control: Add an MRX-2 to a Total Control system to
expand control to other rooms/areas in the home or office.
Components located out of reach from the MRX Advanced
Network System Controller may be controlled via R, RS-232 or
Relays by using an MRX-2 to expand the scope of a Total
Control system.
Lighting Control: By connecting an optional RFTX-1 RF
Transmitter, take control of your URC lighting (within range).
Control a specific light, a whole room or even the entire home
from any remote control or iOS device.
When used in a Complete Control System:
Enables iOS Control: The addition of an MRX-2 base station to
a control system, allows for control via URC’s CC Control iOS
app for iPads, iPhones and iPod touch. Each iDevice requires
programming by a qualified custom install professional.
Note: equires the purchase of CC Control Setup code (one
code per system).
o Aiming: Using a base station results in flawless control of
your components without having to aim the remote! The signal
travels to the base station via RF or Wi-Fi and is then converted
back to infrared before being sent to the device being
controlled; perfect for hidden components.
Note: An optional FX-250 Antenna is required for use with
U C remote controls.
MRX-2 ETWORK BASE STATIO
Page 3
MRX-2 ETWORK BASE STATIO
Parts Guide
The MRX-2 Network Base Station includes:
1 - MRX-2 Network Base Station
1 - 12V-1000mA Power Supply
6 - Visible Emitters with 10 foot plug
in cables including 1 pink sleeved
emitter for the RFTX-1 port
1 - Two Meter 3.5mm Stereo to
3.5mm Stereo (for daisy chaining
multiple MRX-2 with one RFX-250)
1 - Adjustment Tool
1 - Mounting Plate for wall mounting
the MRX-2
Front and Rear Panel Descriptions
Front
The front panel consists of 4 indicator lights which will illuminate
when in use.
Power:
lluminates when the power supply is connected to an outlet.
Status: Flashes blue when an RF or Network signal is received.
Sensor: lluminates to indicate when the sensor is activated.
Ethernet: lluminates when connected to an active network.
Reset: Press the Reset button located under the MRX-2 to restart the
unit.
Power Status Sensor Ethernet Reset: Bottom
MRX-2 ETWORK BASE STATIO
Page 4
Rear
The rear panel ports are:
Power: Uses the included 12V/1Amp power supply.
LA : Plug an ethernet cable (RJ45) to the LAN(Local Area network).
Relay O, C, COM: Configurable switch closure control.
RS-232 Ports: Two RS232 ports provide direct control.
Sensor: Connect with one of URC’s or compatible third party,
sensors.
IR I :
Allows MRX-2 control from a base station such as a MRF-260.
Note:I outing is lost from commands received from this input.
IR Outputs: Connect emitters for R control of connected devices.
RFTX Port: Dual port #6 for the RFTX-1 connecting cable or
included sleeved R emitter.
RF I : Connects to an optional single RFX-250 (Only for MX series
products.)
RF Out: Used for daisy chaining MRX-2s for RF Operation (Refer to
the RFX-250 manual.)
RF ID: 15 unique RF D's provide RF control and routing to multiple
MRX-2’s in the same home.
Note: DO NOT USE F ID #0, as it is the interference "sniffer", used
to detect F interference in the area.
Page 5
Ethernet
Power
Relay: O,
C, COM
RS-232 Ports
Sensor
IR I
IR Outputs: #1-6
RFTX Port: #6
RF I RF Out
RF ID
MRX-2 ETWORK BASE STATIO
Page 6
MRX-2 ETWORK BASE STATIO
etwork Installation
The MRX-2 can be installed in either a Total Control or a Complete
Control System. Connect the Ethernet cable (RJ45) to the rear of the
MRX-2 and the other end to the active network.
Total Control Install
Complete Control Install
Page 7
MRX-2 ETWORK BASE STATIO
Specifications
etwork: One 10/100 Ethernet port
Relay: One relay configurable to be NO, NC or Momentary
Sensor: One sensor supports Video or Voltage sensing via URC
sensors.
RS-232: Two RS-232 ports support TX, RX and GND two way
communication via URC cables.
IR: Six adjustable R ports enable the included URC emitters to
control R devices Note: 6th R Output requires the included
sleeved emitter (identified by a pink connector), since it can
optionally be used to connect an RFTX-1
Weight: 8.4 oz.
Size: 248 x 120mm x28mm
Power: 12V External Power Supply
