Toshiba IK-WB02A - PoE Network Camera Manuel utilisateur

NETWORK CAMERA

Safety Precautions

IK-WB02A

For information on the latest products and peripheral

devices, refer to the following Web page.

■ http://www.netcam.toshiba.com

●The above URL is subject to change without prior notice.

If the URL changes, refer to the Toshiba website

(http://www.cctv.toshiba.com).

●The Operations Manual for this product is included on the

supplied mini CD-ROM.

●These Safety Precautions appy to firmware version

R 1.01

and later.

Model

*A lens is not supplied with the

network camera.

WB02-03

IK-WB02A Precautions E new 2004.11.24, 15:271

FCC(US) Information

Product Name : NETWORK CAMERA

Model Number(s) : IK-WB02A

FCC Notice “Declaration of Conformity Information”

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions :

(1) This device may not cause harmful interference, and

(2) this device must accept any interference received,

including interference that may cause undesired

operation.

Toshiba America Information System, Inc.

Security & Network Video Products

9740 Irvine Boulevard,

Irvine, California 92618-1697

(877)696-3822

This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to part 15

of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses

and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions,

may cause harmful interference to radio communications.

However, there is no guarantee that interference will not

Tested To Comply

With FCC Standards

FOR HOME OR OFFICE USE

IK-WB02A Precautions E new 2004.11.24, 15:272

occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception,

which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and

receiver.

- Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV

technician for help.

Warning : Changes or modifications made to this

equipment, not expressly approved by

Toshiba or parties authorized by Toshiba

could void the user's authority to operate the

equipment.

Canadian Information

Industry Canada

This Class B digital apparatus complies with Canadian

ICES-003.

Cet appareil numérique de la classe B est conforme à

la norme NMB-003 du Canada.

IK-WB02A Precautions E new 2004.11.24, 15:273

Thank you for purchasing the IK-WB02A Network

Camera.

Before you start using the camera, read these Safety

Precautions carefully to ensure correct usage. Once

you have finished reading these Safety Precautions,

keep it in a convenient place for future reference.

The design, specifications, software, and manual

contents are subject to change without prior notice.

Some pictures and illustrations contained herein may

slightly differ from the actual images.

Terms and Trademarks

●The term “OS” is used in the Operations Manual to

indicate operating systems compatible with this

product.

Windows 2000: Microsoft

Windows

2000 operating system

Windows XP: Microsoft

Windows

XP operating system

●The formal name of Windows®is Microsoft®

Windows®Operating System.

●Microsoft®and Windows®are trademarks or

registered trademarks of Microsoft®Corporation in

the United States and other countries.

●Adobe is a registered trademark and Acrobat

Reader is a trademark of Adobe Systems

Incorporated.

●Other product names appearing in these Safety

Precautions or the Operations Manual may be

trademarks or registered trademarks of their

respective holders.

Introduction

IK-WB02A Precautions E new 2004.11.24, 15:274

Accessories

Confirm that all of the following accessories have been

supplied with the network camera.

Mini CD-ROM

(x1)

*Includes the Operations

Manual and the software

Camera Finder.

Safety Precautions and Quick

Start Guide (this document) (x1)

The Quick Guide is at the back

of the Safety Precautions.

WARRANTY

(x1)

IK-WB02

IRIS connector

(x1)

EMI core

About the POWER

SELECT Switch

(x1)

(x3)

For details on how to use the

EMI core, refer to “How to use

EMI core” on the mini CD-ROM.

IK-WB02A Precautions E new 2004.11.24, 15:275

Introduction… ............................................................... 4

Table of Contents .......................................................... 6

IMPORTANT SAFEGUARDS ......................................... 7

NOTES ON USE AND INSTALLATION ........................ 11

Precautions for Use ..................................................... 12

Camera Installation Guide .......................................... 15

Table of Contents

For details on settings, operations, etc, refer to the

Operations Manual (PDF file) included on the mini

CD-ROM.

Acrobat Reader is required to view the PDF file. If you

do not have Acrobat Reader, download it from the Web

site of Adobe Systems Incorporated.

IK-WB02A Precautions E new 2004.11.24, 15:276

IMPORTANT SAFEGUARDS

1. Read Instructions

All the safety and operating instructions should be read

before the product is operated.

2. Retain Instructions

The safety instructions and instruction manual should be

retained for future reference.

3. Heed Warnings

All warnings on the product and in the instruction manual

should be adhered to.

4. Follow Instructions

All operating and use instructions should be followed.

5. Cleaning

Disconnect this video product from the power supply

before cleaning.

6. Attachments

Do not use attachments not recommended by the video

product manufacturer as they may cause hazards.

7. Water and Moisture

Do not use this video product near water-for example, near

a bath tub, wash bowl, kitchen sink, or laundry tub, in a

wet basement, or near a swimming pool and the like.

8. Accessories

Do not place this video product on an unstable cart, stand,

tripod, bracket or table. The video product may fall,

causing serious injury to a child or adult, and serious

damage to the product. Use only with stand, tripod,

bracket, or table recommended by the manufacturer, or

sold with the video product. Any mounting of the product

should follow the manufacturer's instructions, and should

use a mounting accessory recommended by the

manufacturer.

IK-WB02A Precautions E new 2004.11.24, 15:277

IMPORTANT SAFEGUARDS (Cont.)

9. Ventilation

This video product should never be placed near or over a

radiator or heat register. This video product should not be

placed in a built-in installation such as a bookcase or rack

unless proper ventilation is provided or the manufacturer's

instructions have been adhered to.

10. Power Sources

This video product should be operated only from the type

of power source indicated on the marking label. If you are

not sure of the type of power supply to your location,

consult your product dealer.

11. Power-Cord Protection

Power-Supply cords should be routed so that they are not

likely to be walked on or pinched by items placed upon or

against them, paying particular attention to cords at plugs,

screws and the point where they exit from the product.

12. Lightning

For added protection for this video product during a

lightning storm, or when it is left unattended and unused

for long periods of time, unplug it from the wall outlet and

disconnect the power supply and cable system. This will

prevent damage to the video product due to lightning and

power-line surges.

13. Overloading

Do not overload power supply and extension cords as

this can result in a risk of fire or electric shock.

14. Object and Liquid Entry

Never push objects of any kind into this video product

through openings as they may touch dangerous voltage

points or short-out parts that could result in a fire or

electrical shock. Never spill liquid of any kind on the video

product.

IK-WB02A Precautions E new 2004.11.24, 15:278

15. Servicing

Do not attempt to service this video product yourself as

opening or removing covers may expose you to dangerous

voltage or other hazards. Refer all servicing to qualified

service personnel.

16. Damage Requiring service

Disconnect this video product from the power supply and

refer servicing to qualified service personnel under the

following conditions.

a. When the power-supply cord or plug is damaged.

b. If liquid has been spilled, or objects have fallen into the

video product.

c. If the video product has been exposed to rain or water.

d. If the video product does not operate normally by

following the operating instructions in the instruction

manual. Adjust only those controls that are covered by

the instruction manual as an improper adjustment of

other controls may result in damage and will often

require extensive work by a qualified technician to

restore the video product to its normal operation.

e. If the video product has been dropped or the cabinet

has been damaged.

f. When the video product exhibits a distinct change in

performance-this indicates a need for service.

17. Replacement Parts

When replacement parts are required, be sure the service

technician has used replacement parts specified by the

manufacturer with the same characteristics as the original

part. Unauthorized substitutions may result in fire, electric

shock or other hazards.

18. Safety Check

Upon completion of any service or repairs to this video

product, ask the service technician to perform safety

checks to determine that the video product is in proper

operating condition.

IK-WB02A Precautions E new 2004.11.24, 15:279

IMPORTANT SAFEGUARDS (Cont.)

The CAUTION label, shown on the above part, is attached

on the bottom of camera.

The lightning flash with arrowhead symbol,

within an equilateral triangle, is intended to alert

the user to the presence of uninsulated

"dangerous voltage" within the product's

enclosure that may be of sufficient magnitude

to constitute a risk of electric shock to persons.

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the appliance.

WARNING:

TO REDUCE THE RISK OF FIRE OR

ELECTRIC SHOCK, DO NOT

EXPOSE THIS APPLIANCE TO RAIN

OR MOISTURE.

CAUTION

CONNECT 24V AC UL LISTED

CLASS 2 POWER SUPPLY.

FIELD INSTALLATION MARKING:

WORDED : “THIS INSTALLATION SHOULD BE MADE BY A QUALIFIED SERVICE

PERSON AND SHOULD CONFORM TO ALL LOCAL CODES.”

Note: The camera is designed for indoor use.

IK-WB02A Precautions E new 2004.11.24, 15:2710

Autres manuels pour IK-WB02A - PoE Network Camera

Table des matières

Autres manuels Toshiba Caméra de sécurité

Toshiba

Toshiba 27A43 Manuel utilisateur

Toshiba

Toshiba IK-64DNA Manuel utilisateur

Toshiba

Toshiba Teli CSGV90BC3 Manuel utilisateur

Toshiba

Toshiba IK-WR04A Manuel utilisateur

Toshiba

Toshiba IK-WD12A Manuel utilisateur

Toshiba

Toshiba IK-6550A - Analog Camera, 540 TV Lines Manuel utilisateur

Toshiba

Toshiba CCD Monochrome Camera IK-539A Manuel utilisateur

Toshiba

Toshiba IK-WD04A Mode d’emploi

Toshiba

Toshiba IK-WB16A Manuel utilisateur

Toshiba

Toshiba IK-6420A Manuel utilisateur

Toshiba

Toshiba IK-1000 - Starlight Color Video Camera CCTV Manuel utilisateur

Toshiba

Toshiba IK-WB70A - IP/Network Camera, PoE Manuel utilisateur

Toshiba

Toshiba IK-53V Manuel utilisateur

Toshiba

Toshiba IK-TF5 Manuel utilisateur

Toshiba

Toshiba IK-WB15A - IP Network Camera Manuel utilisateur

Toshiba

Toshiba IK-TF5P2 Manuel utilisateur

Toshiba

Toshiba IK-WD14A Manuel utilisateur

Toshiba

Toshiba IK-WB21A - IP Network PTZ Camera Manuel utilisateur

Toshiba

Toshiba IK-WF51A Manuel utilisateur

Toshiba

Toshiba CS3910BH Manuel utilisateur

Toshiba

Toshiba IK-DP01A Manuel utilisateur

Toshiba

Toshiba ik-tf7p2 Manuel utilisateur

Toshiba

Toshiba IK-TF5C Manuel utilisateur

Toshiba

Toshiba IK-WF51R Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
