Satellite®A10/A15 Series

Resource Guide

Keep this guide in a convenient place to access important

information about your computer.

If you need assistance, contact the following:

InTouchCenter

Calling within the United States (800) 457-7777

Calling from outside the United States (949) 859-4273

Please fill in for your reference and future use:

Model name _______________________________________

Part number _______________________________________

Serial number ______________________________________

2Contents

RG 5.375 x 8.375 ver 2.3.4

Contents

Setting up your computer and getting started............................ 4

Installing additional memory (optional) ..................................... 7

Your computer’s TFT display.................................................... 10

Inserting PC Cards................................................................... 10

Removing PC Cards................................................................. 11

Learning the basics.................................................................. 11

Playing a CD or DVD ................................................................ 12

Moving the computer............................................................... 15

Mobile computing.................................................................... 15

If something goes wrong ......................................................... 19

If you need further assistance.................................................. 21

Power cable connectors........................................................... 23

Features and specifications...................................................... 23

Regulatory information ............................................................ 28

Index ........................................................................................48

RG 5.375 x 8.375 ver 2.3.4

Welcome to the world of powerful and portable multimedia computers!

With your new Toshiba notebook computer, your access to information can

accompany you wherever you go.

You will find that the Microsoft®Windows®XP operating system is already

installed on your computer. It offers exciting features and easy Internet

access.

This guide

This guide offers important information about your computer, including

solutions to the most common problems, and features and specifications.

For more detailed information, descriptions of other features and more

extensive troubleshooting guidelines, see the electronic user’s guide

preinstalled on your system. It is also available on the Web at

pcsupport.toshiba.com.

Safety icons

This guide contains safety instructions that must be observed in order to

avoid potential hazards that could result in personal injuries, damage to

your equipment, or loss of data. These safety cautions have been classified

according to the seriousness of the risk, and the icons highlight these

instructions as follows:

Danger indicates a hazardous situation, which will result in death, serious

personal injury, or substantial property damage if the safety instruction is

ignored.

Warning indicates a hazardous situation, which can result in death, serious

personal injury, or substantial property damage if the safety instruction is

ignored.

Caution indicates a hazardous situation, which will or can cause minor

personal injury or property damage if the safety instruction is ignored.

Provides you with important but not hazard-related information.

Other icons used

Additional icons highlight other helpful or educational information:

TECHNICAL NOTE: This icon highlights technical information about the

computer.

HINT: This icon denotes helpful hints and tips.

DANGE

4Setting up your computer and getting started

RG 5.375 x 8.375 ver 2.3.4

DEFINITION: This icon indicates the definition of a term used in the text.

Other documentation

Your computer comes with all or some of the following documentation in

addition to this resource guide:

❖Electronic user’s guide installed on your system.

❖Guides for other software that may come preinstalled.

❖Microsoft®Windows®XP operating system documentation.

❖For accessory information, visit Toshiba’s Web site at toshiba.com.

❖The Recovery Media containing the programs that are preinstalled at

the factory and any bundled software. Keep this media in a safe and

convenient place.

Setting up your computer and getting started

Strain and stress injuries are becoming more common as people spend

more time using their computers. With a little care and proper use of the

equipment, you can work comfortably throughout the day.

Using the computer keyboard incorrectly can result in discomfort and

possible injury. If your hands, wrists, and/or arms bother you while typing,

stop using the computer and rest. If the discomfort persists, consult a

physician.

For more information, consult books on ergonomics, repetitive-strain

injury, and repetitive-stress syndrome.

Placement of the computer

Proper placement of the computer and external devices is important to

avoid stress-related injuries. Consider the following when placing your

computer.

❖Place the computer on a flat surface at a comfortable height and

distance. You should be able to type without twisting your torso or

neck, and look at the screen without slouching.

❖If you are using an external monitor, the top of the display should be

no higher than eye level.

❖If you use a paper holder, set it at about the same height and distance

as the screen.

Seating and posture

When using your computer, maintain good posture with your body relaxed

and your weight distributed evenly. Proper seating is a primary factor in

reducing work strain.

Setting up your computer and getting started

RG 5.375 x 8.375 ver 2.3.4

Precautions

Your notebook computer is designed to provide optimum safety and ease of

use, and to withstand the rigors of travel. You should observe certain

precautions to further reduce the risk of personal injury or damage to the

computer.

Never apply heavy pressure to the computer or subject it to sharp impacts.

Excessive pressure or impact can damage computer components or

otherwise cause your computer to malfunction.

Some PC Cards become hot with prolonged use. Overheating of a PC Card

can result in errors or instability in its operation.

Be careful when you remove a PC Card that has been used for lengthy

periods of time.

Connecting to a power source

Your computer requires power to operate. Use the power cable and AC

adapter to connect the computer to a live electrical outlet, or to charge the

computer’s battery.

Use only the AC adapter supplied with your computer or an equivalent

adapter that is compatible. Use of any incompatible adapter could damage

your computer. Toshiba assumes no liability for any damage caused by use

of an incompatible adapter.

When you connect the AC adapter to the computer, always follow the steps in

the exact order as described in the User's Manual. Connecting the power

cable to a live electrical outlet should be the last step otherwise the adapter

DC output plug could hold an electrical charge and cause an electrical shock

or minor bodily injury when touched. As a general safety precaution, avoid

touching any metal parts.

Hold the power cable by its plug when you connect/disconnect it. Do NOT

pull the cable itself. Doing so may damage the power cable and result in a

short circuit or electric shock.

AC adapter

Power cable AC power indicator

AC adapter

DANGE

6Setting up your computer and getting started

RG 5.375 x 8.375 ver 2.3.4

The power cord on this product contains lead, a chemical known to

the State of California to cause birth defects or other reproductive

harm. Wash hands after handling.

To connect AC power to the computer:

1Connect the power cable to the AC adapter.

2Plug the AC adapter into the DC-IN port.

3Connect the power cable to a live electrical outlet.

If the electrical outlet is live, the system indicator panel’s AC power light

( ) glows green.

Damaged power cables can cause fire or electric shock. Never modify,

forcibly bend, place heavy objects on top of, or apply heat to the power

cable.

If the power cable becomes damaged or the plug overheats, discontinue use.

There is a risk of electric shock.

Never remove the power plug from the outlet with wet hands. Doing so may

cause an electric shock.

Connecting a printer

You can connect a USB-compatible printer to your computer through one

of the USB ports. You can also connect a parallel printer through the

parallel port.

To confirm a printer’s compatibility, check its documentation.

Connecting a USB printer

To achieve the connection, you need a suitable USB cable, which may

come with your printer. Otherwise, you can purchase one from a computer

or electronics store.

Follow the manufacturer’s instructions for connecting a USB printer to your

computer.

Connecting a parallel printer

To achieve the connection, you need a suitable cable, which may come with

your parallel printer. Otherwise, you can purchase one from a computer or

electronics store.

If you connect a parallel printer, do so before you turn on the computer.

Follow the manufacturer’s instructions for connecting a parallel printer to

your computer.

DANGE

Installing additional memory (optional)

RG 5.375 x 8.375 ver 2.3.4

Installing additional memory (optional)

Before you install or remove a memory module, turn off the computer using

the Start menu. If you install or remove a memory module while the

computer is in Standby or Hibernation mode, data will be lost.

A memory module must be installed in slot A. Do not try to operate the com-

puter with a memory module in slot B only.

If you install a memory module that is incompatible with the computer, a

beep will sound when you turn on the computer. If the module is installed in

slot A, there will be a long beep followed by a short beep. If the module is in

slot B, there will be a long beep followed by two short beeps. In this case,

turn off the computer and remove the incompatible module.

Your computer comes with enough memory to run most of today’s popular

applications. You may want to increase the computer’s memory if you use

complex software or process large amounts of data.

Additional memory comes in various capacities (visit Toshiba’s Web site at

toshiba.com for more information). There are two memory slots. Your

system may have both slots occupied.

If you use the computer for a long time, the memory modules will become

hot. If this happens, let the modules cool to room temperature before you

replace them.

You need a standard Phillips no. 1 screwdriver to install a memory module.

To avoid damaging the computer’s screws, use a standard Phillips no. 1

screwdriver that is in good condition.

If you are adding memory after you have started to use the computer, begin

at step 1, otherwise skip to step 2.

1Turn off the computer via the Start menu.

See “Turn Off or Shut down command” in your electronic user’s

guide.

The operating system turns off the computer.

2Unplug and remove any cables connected to the computer.

3Close the display panel and turn the computer upside down to locate

the memory slot cover.

8Installing additional memory (optional)

RG 5.375 x 8.375 ver 2.3.4

Base of your Satellite computer

4Using a standard Phillips no. 1 screwdriver, unscrew the screw that

secures the memory slot cover, then remove the memory slot cover.

Removing the memory slot cover

5Put the screw and the cover in a safe place so that you can retrieve

them later.

The following figure shows the inside of the memory compartment.

Viewing the inside of the memory compartment

Memory

slot cover

Installing additional memory (optional)

RG 5.375 x 8.375 ver 2.3.4

6Remove the memory module from its antistatic packaging.

Static electricity can damage the memory module. Before you handle the

module, touch a grounded metal surface to discharge any static electricity

you may have built up.

To avoid damaging the memory module, be careful not to touch its gold

connector bar (on the side you insert into the computer).

7Holding the memory module by its edges so that the gold connector

bar faces the slot, fit the module into the socket.

8Gently put the memory module connector down at an angle and press

down until the clips snap into place.

Do not force the module into position. The memory module should be

level when secured in place.

Inserting the memory module

Avoid touching the connectors on the memory module or on the computer.

Grease or dust on the connectors may cause memory access problems.

9Replace the memory slot cover.

10 Replace the screw and tighten it.

11 Turn the computer over and reconnect any cables you removed.

12 Turn on the computer.

To verify that the computer correctly recognizes the memory, click

Start, Control Panel and click Performance and Maintenance.

Click System to view the recognized memory.

13 If the computer does not recognize the memory, shut down the

computer, remove the memory slot cover, and make sure the memory

module is seated properly, as described in step 8.

10 Your computer’s TFT display

RG 5.375 x 8.375 ver 2.3.4

Removing a memory module

If you use the computer for a long time, the memory modules will become

hot. If this happens, let the modules cool to room temperature before you

replace them.

1Follow steps 1 through 5 in “Installing additional memory (optional)”

on page 7.

2Gently push the memory clips outward until the memory module pops

up.

Removing the memory module

3Gently pull the memory module diagonally to remove it from the slot.

4Complete the procedure by following steps 9 through 13 in “Installing

additional memory (optional)” on page 7.

Your computer’s TFT display

Small bright dots may appear on your TFT display when you turn on your

computer. Your display contains an extremely large number of thin-film

transistors (TFT) and is manufactured using high-precision technology.

Any small bright dots that may appear on your display are an intrinsic

characteristic of the TFT manufacturing technology.

Inserting PC Cards

Use caution when lifting or turning your computer. Failure to do so may

result in damage to components, such as cables, attached to your computer,

or to the computer itself.

Before you insert a PC Card, refer to the documentation that comes with

the card to see if you need to do anything before you insert it.

To insert a PC Card:

1Turn off the computer.

You may also hot swap a PC Card (see “Hot swapping” on page 11).

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Toshiba Ordinateur portable

Toshiba

Toshiba Satellite 2250XCDS Manuel utilisateur

Toshiba

Toshiba L25-S1192 Manuel utilisateur

Toshiba

Toshiba Portege 610CT Guide de l'utilisateur

Toshiba

Toshiba L675D-S7013 Manuel utilisateur

Toshiba

Toshiba TECRA S5 Manuel utilisateur

Toshiba

Toshiba Satellite Pro A60 Series Manuel utilisateur

Toshiba

Toshiba PORTEGE X20W-D Manuel utilisateur

Toshiba

Toshiba Satellite P200 Series Manuel utilisateur

Toshiba

Toshiba Satellite 1555CDS Manuel utilisateur

Toshiba

Toshiba L670-BT2N25 Manuel utilisateur

Toshiba

Toshiba Satellite Pro S300L Manuel utilisateur

Toshiba

Toshiba T-Series T2200sx Manuel utilisateur

Toshiba

Toshiba T135D-S1325 Manuel utilisateur

Toshiba

Toshiba P770-ST5GX2 Manuel utilisateur

Toshiba

Toshiba L645-S4055 Manuel utilisateur

Toshiba

Toshiba Portege Z20-B Series Manuel utilisateur

Toshiba

Toshiba U205-S5022 Manuel utilisateur

Toshiba

Toshiba A205-S7458 - Satellite - Core 2 Duo 1.5 GHz Manuel du propriétaire

Toshiba

Toshiba A135-S4477 - Satellite - Core 2 Duo 1.6 GHz Manuel utilisateur

Toshiba

Toshiba Portege R835-P50 Manuel utilisateur

Toshiba

Toshiba Satellite 5100 Series Manuel de la liste des pièces

Toshiba

Toshiba Satellite C655 Manuel utilisateur

Toshiba

Toshiba A135-S4417 Manuel utilisateur

Toshiba

Toshiba Satellite L745-S4355 Manuel utilisateur

Manuels Ordinateur portable populaires d'autres marques

HP ze2401xt - Pavilion Notebook PC Manuel utilisateur

Velocity

Velocity NoteMagix M10 Manuel utilisateur

Dell

Dell Alienware 17 R2 Manuel utilisateur

HP ENVY 17 Manuel

Winbook

Winbook LM Manuel utilisateur

Dell

Dell Inspiron 1464 Manuel utilisateur

Dell

Dell Inspiron 15R 5537 Manuel utilisateur

HP PROBOOK 4520S Manuel

Dell

Dell Latitude ATG D620 Manuel utilisateur

Sony

Sony VAIO PCG-FX270 Manuel utilisateur

Dell

Dell Latitude 7310 Manuel utilisateur

Dell

Dell Precision GU806 Manuel utilisateur

Sony

Sony VAIO PCG-R505JLK Manuel utilisateur

Lenovo

Lenovo THINKPAD X32 Manuel utilisateur

HP Compaq tc4200 Guide de démarrage rapide

Lenovo

Lenovo ThinkPad X201 Tablet Manuel

Lenovo

Lenovo THINKPAD X31 Manuel

Sony

Sony VGN-T240P VAIO Manuel utilisateur
