Toshiba NB200 Series Manuel utilisateur

Chapter 1

Hardware Overview

1 Hardware Overview

NB200 Maintenance Manual 1-ii

Chapter 1 Contents

1.1 Features ..................................................................................................................1-1

1.2 2.5-inch HDD.........................................................................................................1-9

1.3 Power Supply .......................................................................................................1-10

1.4 Batteries................................................................................................................1-12

1.4.1 Main Battery.........................................................................................1-12

1.4.2 Battery Charging Control .....................................................................1-12

1.4.3 RTC Battery..........................................................................................1-13

1 Hardware Overview

NB200 Maintenance Manual 1-iii

Figures

Figure 1-1A ID Parts Description Placement Part A..........................................................1-5

Figure 1-2 S-ATA HDD.................................................................................................. 1-9

Tables

Table 1-1 HDD Specifications.......................................................................................1-9

Table 1-2 Quick/Normal Charging Time.....................................................................1-12

Error! Style not defined. Error! Style not defined. 1 Hardware Overview

NB200 Maintenance Manual 1-1

1.1 Features

The Toshiba NB200 is a small-size PC notebook equipped with an Intel®AtomTM Processor,

providing high-speed processing capabilities and advanced features. The computer employs a

lithium ion battery that allows it to be battery-operated for long periods of time. The display uses

10.1-inch WSVGA LCD panel. Many features can be Built To Order (BTO) to customize the

system for each user.

The computer has the following features:

Processor

The computer is equipped with an Intel®AtomTM Processor N270/280 that is XD bit

supported.

Memory (BTO)

The computer has one SODIMM slot which comes standard with 1GB/2GB, accepting BTO

for your memory requirements. It can incorporate up to 1 GB (XP) or 2 GB (Vista/Linux) of

main memory. It supports DDR2 at 533MHz.

Battery Pack (BTO)

The computer is powered by one rechargeable and removable lithium ion battery pack. The

capacity can be either 3-cell or 6-cell, depending on the model of the computer.

RTC Battery

The internal RTC battery backs up the Real Time Clock and calendar.

Hard Disk Drive (HDD)

The computer accommodates a 9.5 mm HDD with the following storage capacities:

120/160 GB, S-ATA (5,400rpm)

Additional HDD sizes may be introduced.

Solid State Drive (SSD)

The computer has a 9.5mm Toshiba SSD with the following capacities:

64 GB

Additional SSD sizes may be introduced.

1 Hardware Overview Error! Style not defined. Error! Style not defined.

NB200 Maintenance Manual 1-2

Display

The LCD display comes with the following:

10.1" WSVGA LCD, 1024 x 600 Resolution

Graphics

The computer uses Intel®945GSE for integrated graphics display.

Keyboard

The computer is equipped with a tile or flat keyboard. It comes with 85 or 86 keys

supported and with optional Windows and application keys (except for Linux models).

Pointing Device

The integrated Touch Pad and two control buttons in the palm rest allow control of the on-

screen pointer and support functions such as the scrolling of windows.

External Monitor Port

The analog VGA port provides support for VESA DDC2B compatible functions. A WDDM

driver is ready for Vista.

Universal Serial Bus (USB) Ports

The computer has three USB 2.0 ports. It is supported to daisy-chain a maximum of 127

USB devices. The serial data transfer rate is 480 Mbps or 12 Mbps and 1.5 Mbps. These

ports support PnP installation and hot plugging. USB Sleep and Charge function can be

supported by only one port of the left side. (mode 1-4)

Bridge Media Slot

This slot allows you to insert SD/SDHC, MiniSD/ MicroSD (through adapter) and MMC

memory cards. This model does not support CF cards, SmartMedia cards and Memory

Sticks.

Error! Style not defined. Error! Style not defined. 1 Hardware Overview

NB200 Maintenance Manual 1-3

Sound system

The integrated sound system is composed of one 1.0W Zylux / FG internal speaker, an

internal microphone and standard MIC-IN ports.

Internal Camera

A VGA webcam supports 0.3M pixels and comes with an LED indicator. The camera is not

a rotation type.

Internal Microphone

The computer has a built-in internal microphone equipped with echo-cancellation.

Headphones/Line-out Jack

This jack connects speakers or stereo headphones. When connected to speakers or

headphones, the internal speaker is automatically disabled.

Microphone/Line-in Jack

A 3.5mm mini microphone jack enables connection of a three-conductor microphone for

monaural input and also enables the connection of a stereo device for audio input.

LAN

The computer has built-in support for 10M/100M Ethernet LAN (10/100 megabits per

second, 10/100BASE-T). It employs a Realtek 8103EL for 10M/100Mbit LAN.

Wireless LAN (BTO)

Some computers in this series are equipped with a Wireless LAN (WLAN) card. This

WLAN module may come with the following types (depending on the model):

Atheros 802.11 bg (HB95 1x1)

3G (BTO)

The 3G module employs a PCI Express Mini Card. It enables computer users to have

mobile access to the internet or to a corporate network. The computer is equipped with

either a Ericsson F3507g model (which supports HSPA) or with a Qualcomm Gobi model

(which supports HSPA and EVDO).

1 Hardware Overview Error! Style not defined. Error! Style not defined.

NB200 Maintenance Manual 1-4

Bluetooth (BTO)

Some computers in this series offer Bluetooth wireless communication functionality which

eliminates the need for cables between electronic devices such as computers and printers.

When implemented, Bluetooth provides wireless communication in a small space. This

module is Version 2.1 + EDR (Antenna on Module type), basically Toshiba stack support it.

Error! Style not defined. Error! Style not defined. 1 Hardware Overview

Figure 1-1A shows the computer and its system unit configuration.

External monitor port

Thermal vent holes

USB ( USB Sleep and Charge function

is supported by this port only. )

Figure 1-1A ID Parts Description Placement Part A

NB200 Maintenance Manual 1-5

1 Hardware Overview Error! Style not defined. Error! Style not defined.

1 1

2 2

3 3

4 4

Title

Size Document Number R ev

Date: Sheet of

Security Classification

Compal Secret Data

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMP ETENT DI VISION OF R&D

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFO RMATION IT CONTAINS

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRON ICS, INC .

Issued Date

Deciphered Date

KAVAA LA-5121P M/B

1.A

Block Diagrams

242Monday, March 23, 2009

2009/03/20 2010/03/20

Compal Electronics, Inc.

File Name : LA-5121P

Touch Pad

page 22

Compal Confidential

)36..0(#D_H)13..3(#A_H

Int.KBD

page 28

400/533MHz

ALC272-GR

DMI x 2

Intel Diamondville SC

FSB

Clock Generator

SLG8SP556VTR

page 26

Fan Control

FCBGA8-437 Pins

200pin DDRII-SO-DIMM

Intel Calistoga GSE

SPI ROM

page 4

1.8V DDRII 400/533

page 4,5

page 28

HDA Codec

page 12

Memory BUS(DDRII)

BGA-652

page 28

page 6,7,8,9,10

Intel ICH7M

Thermal Sensor

page 11

page 15,16,17,18

page 29

ENE KB926 D3

LED Conn.

Model Name : KAVAA

page 13

page 21

SATA HDD&SSD

EMC1402

(22x22mm)

5V 1.5GHz(150MB/s)

SATA port 0

HD Audio

3.3V 24.576MHz/48Mhz

PCIe 1x [2,4]

LPC BUS

3.3V 33 MHz

USB

5V 480MHz

PCIeMini Card

RJ45

RTL8103EL 10/100M

page 24

PCIe 1x

PCIe port 3

page 28

Debug Port

RTS5159 2IN1

page 14

FCBGA998

USB

5V 480MHz

USB port 5

1.5V 2.5GHz(250MB/s)

USB port 0,2,7

USB Conn X3

Power Circuit DC/DC

page 30

RTC CKT.

page 16

page 31~37

DC/DC Interface CKT.

HP CONN

SPK CONN

MIC CONN

page 23

TPA6017

AMP.

MIC CONN

Int.

Touch Screen conn

BTOUSB port 4 ,5

page 20

PCIeMini Card

WiMax

PCIeMini Card

WLAN

USB port 4

PCIe port 2

page 19

USB port 1

page 21

Int. Camera

USB port 6

page 21

BT conn

CRT Conn.

(27x27mm)

(31x31mm)

Power/B

page 29

PCIeMini Card

GPS

page 27

GSENSOR

USB port 3

Card Reader

USB

5V 480MHz

page 19

page 25

page 20

page 23 page 23 page 23

page 23

USB port 5

LVDS

ONE CHANNEL

NB200 Maintenance Manual 1-6
