Portégé®R100 Series

Resource Guide

NOTE: Keep this guide in a convenient place to access important

information about your computer.

If you need assistance:

❖InTouch® Center

Calling within the United States (800) 457-7777

Calling from outside the United States (949) 859-4273

Please fill in for your reference and future use:

Model name______________________________________

Part number______________________________________

Serial number____________________________________

2Contents

RG 5.375 x 8.375 ver 2.3.2

Contents

Setting up your computer and getting started..................................... 4

Inserting PC Cards............................................................................ 11

Removing PC Cards.......................................................................... 11

Learning the basics........................................................................... 12

Moving the computer........................................................................ 13

Mobile computing............................................................................. 14

If something goes wrong.................................................................. 19

If you need further assistance........................................................... 23

Power cable connectors.................................................................... 24

Features and specifications............................................................... 25

Regulatory information ..................................................................... 29

Index ................................................................................................. 42

RG 5.375 x 8.375 ver 2.3.2

Welcome to the world of powerful and portable multimedia

computers! With your new Portégé R100 computer, your

access to information can accompany you wherever you go.

You will find that the Microsoft®Windows®XP operating

system is already installed on your computer. It offers

exciting features and easy Internet access.

This guide

This guide offers important information about your computer,

including solutions to the most common problems, and

features and specifications.

For more detailed information, descriptions of other features

and more extensive troubleshooting guidelines, see the

electronic user’s guide preinstalled on your system. It is also

available on the Web at pcsupport.toshiba.com.

Safety icons

This guide contains safety instructions that must be observed

in order to avoid potential hazards that could result in

personal injuries, damage to your equipment, or loss of data.

These safety cautions have been classified according to the

seriousness of the risk, and the icons highlight these

instructions as follows:

Danger indicates a hazardous situation, which will result in death,

serious personal injury, or substantial property damage if the safety

instruction is ignored.

Warning indicates a hazardous situation, which can result in death,

serious personal injury, or substantial property damage if the safety

instruction is ignored.

Caution indicates a hazardous situation, which will or can

cause minor personal injury or property damage if the safety

instruction is ignored.

Provides you with important but not hazard-related

information.

DANGER

4Setting up your computer and getting started

RG 5.375 x 8.375 ver 2.3.2

Other icons used

Additional icons highlight other helpful or educational

information:

TECHNICAL NOTE: This icon highlights technical information about

the computer.

HINT: This icon denotes helpful hints and tips.

DEFINITION: This icon indicates the definition of a term used in the

text.

Other documentation

Your computer comes with all or some of the following

documentation in addition to this resource guide:

❖An electronic version of the user’s guide. Look for the

user’s guide icon on your desktop or in the DOCS folder

on the C: drive.

❖Guides for other programs that may come preinstalled on

your computer or that are available for installation on

your Recovery CDs.

❖For accessory information, visit Toshiba's web site at

toshiba.com.

❖The Microsoft®Windows®operating system

documentation which explains the features of the

operating system.

Setting up your computer and getting started

Strain and stress injuries are becoming more common as

people spend more time using their computers. With a little

care and proper use of the equipment, you can work

comfortably throughout the day.

Setting up your computer and getting started

RG 5.375 x 8.375 ver 2.3.2

Using the computer keyboard incorrectly can result in discomfort

and possible injury. If your hands, wrists, and/or arms bother you

while typing, stop using the computer and rest. If the discomfort

persists, consult a physician.

For more information, consult books on ergonomics,

repetitive-strain injury, and repetitive-stress syndrome.

Placement of the computer

Proper placement of the computer and external devices is

important to avoid stress-related injuries. Consider the

following when placing your computer.

❖Place the computer on a flat surface at a comfortable

height and distance. You should be able to type without

twisting your torso or neck, and look at the screen

without slouching.

❖If you are using an external monitor, the top of the

display should be no higher than eye level.

❖If you use a paper holder, set it at about the same height

and distance as the screen.

Seating and posture

When using your computer, maintain good posture with your

body relaxed and your weight distributed evenly. Proper

seating is a primary factor in reducing work strain.

Precautions

Your notebook computer is designed to provide optimum

safety and ease of use, and to withstand the rigors of travel.

You should observe certain precautions to further reduce the

risk of personal injury or damage to the computer.

6Setting up your computer and getting started

RG 5.375 x 8.375 ver 2.3.2

Never apply heavy pressure to the computer or subject it to sharp

impacts. Excessive pressure or impact can damage computer

components or otherwise cause your computer to malfunction.

Some PC Cards become hot with prolonged use. Overheating of a

PC Card can result in errors or instability in its operation.

Be careful when you remove a PC Card that has been used for

lengthy periods of time.

Connecting the AC adapter

The AC adapter enables you to power the computer from an

AC outlet and to charge the computer’s batteries. The AC

power light on the computer glows when the device is

plugged in.

Use only the AC adapter supplied with your computer or an

equivalent adapter that is compatible. Use of any incompatible

adapter could damage your computer. Toshiba assumes no liability

for any damage caused by use of an incompatible adapter.

When you connect the AC adapter to the computer, always follow the

steps in the exact order as described in the User's Manual.

Connecting the power cable to a live electrical outlet should be the

last step otherwise the adapter DC output plug could hold an

electrical charge and cause an electrical shock or minor bodily injury

when touched. As a general safety precaution, avoid touching any

metal parts.

Power Cable and AC Adapter

Setting up your computer and getting started

RG 5.375 x 8.375 ver 2.3.2

Damaged power cables can cause fire or electric shock. Never

modify, forcibly bend, place heavy objects on top of, or apply heat to

the power cable.

If the power cable becomes damaged or the plug overheats, discon-

tinue use. There is a risk of electric shock.

Never remove the power plug from the outlet with wet hands. Doing

so may cause an electric shock.

Connecting a printer

You can connect a USB-compatible printer to your computer

through one of the USB ports. To confirm compatibility,

check its documentation.

To make the connection, you need a suitable USB cable,

which may come with your printer. Otherwise, you can

purchase one from a computer or electronics store.

To connect a printer:

1Connect the USB cable to the USB port.

2Connect the printer’s power cable to a wall outlet and

turn on the printer.

See your printer documentation for additional configuration

steps, or see “Setting up a printer” in the electronic user’s

guide.

Installing additional memory (optional)

Before you install or remove a memory module, turn off the computer

using the Start menu. If you install or remove a memory module

while the computer is in Standby or Hibernation mode, data will be

lost.

Your computer comes with enough memory to run most of

today’s popular applications. You may want to increase the

computer’s memory if you use complex software or process

large amounts of data.

Additional memory comes in 256 MB and 512 MB modules.

One memory slot is available.

One slot is available for adding a memory module.

DANGER

8Setting up your computer and getting started

RG 5.375 x 8.375 ver 2.3.2

If the computer is on, begin at step 1; otherwise, skip to step 3.

1If the computer is on, click Start, Turn off computer.

The Turn off computer window appears.

2Click Turn Off.

The operating system turns off the computer.

3Unplug and remove any cables connected to the

computer.

4Remove the battery (see "Changing the main battery" on

page 15).

5Close the display panel and turn the computer upside

down to locate the expansion memory slot cover to the

memory slot.

Base of the computer

6Using a standard Phillips no. 0 screwdriver, unscrew the

screw that secures the memory slot cover, then remove

the memory slot cover.

Removing the memory slot cover screws

7Place the screw and the cover in a safe place so that you

can retrieve them later.

Expansion

memory

slot cover

Setting up your computer and getting started

RG 5.375 x 8.375 ver 2.3.2

Static electricity can damage the memory module. Before you handle

the module, touch a grounded metal surface to discharge any static

electricity you may have built up.

To avoid damaging the memory module, be careful not to touch its

pin connector on the side you insert into the computer.

8Remove the new memory module from its antistatic

packaging.

9Insert the memory module in the slot and gently press it

down into place.

The clips on either side of the module will click to secure

the module.

Inserting the memory module

10 Seat the memory slot cover and secure it with the screw.

11 When you turn the computer on, it should automatically

recognize the total memory capacity. Use System

Properties to verify that the added memory is recognized.

If it is not recognized, check the module’s connection.

Do not touch the connectors on the memory module or on the

computer. Debris on the connectors may cause memory access

problems.

Press only the area above the connector. Do not press on the

electronic components.

Removing a memory module

To remove the memory module:

1Turn the computer off and remove all cables connected to

the computer.

10 Setting up your computer and getting started

RG 5.375 x 8.375 ver 2.3.2

Do not try to remove a memory module with the computer in Standby

or Hibernation mode. You can damage the computer and the memory

module.

2Turn the computer upside down and remove the main

battery module.

3Using a standard Phillips no. 0 screwdriver, unscrew the

screw that secures the memory slot cover, then remove

the memory slot cover.

4Place the screw and the cover in a safe place so that you

can retrieve them later.

5Pull the clips away from the memory module.

The memory module pops partially out of the slot.

6Carefully remove the module from the slot

Do not touch the connectors on the memory module or on the

computer. Debris on the connectors may cause memory access

problems.

7Seat the cover and secure it with the screw.

Checking total memory

When you add or remove memory, you can check that the

computer has recognized the change. To do this:

1ClickStart, then click Control Panel

2ClickPerformance and Maintenance.

3ClickSystem.

4TheGeneral tab view automatically appears and shows total

memory.

If the computer does not recognize the memory configuration, turn

off the computer, remove the memory slot cover, and make sure

the memory module is seated properly, as described in step 9 of

"Installing additional memory (optional)" on page 7.

Autres manuels pour Portege R100

Table des matières

Autres manuels Toshiba Ordinateur de bureau

Toshiba

Toshiba dynaEdge DE-100 Series Manuel utilisateur

Toshiba

Toshiba Canvio Home Manuel utilisateur

Toshiba

Toshiba Equium 8000S Manuel utilisateur

Toshiba

Toshiba HX-10 Manuel utilisateur

Toshiba

Toshiba TECRA C50-C Series Manuel utilisateur

Toshiba

Toshiba Equium 7300S SERIES Manuel utilisateur

Toshiba

Toshiba 7130 Mise à jour du firmware

Toshiba

Toshiba Satellite M500D Manuel utilisateur

Toshiba

Toshiba Tecra A3 Manuel utilisateur

Toshiba

Toshiba Equium 7100M Manuel utilisateur

Toshiba

Toshiba T-Series T3100e Manuel utilisateur

Toshiba

Toshiba Satellite A70 Manuel utilisateur

Toshiba

Toshiba GX1C000JZF10 Manuel utilisateur

Toshiba

Toshiba A20-S259 - Satellite - Pentium 4 2.66 GHz Manuel utilisateur

Toshiba

Toshiba DX730-ST6N01 Manuel utilisateur

Toshiba

Toshiba EQUIUM M40 Manuel utilisateur

Toshiba

Toshiba Satellite L300 Series Manuel utilisateur

Toshiba

Toshiba Portege A600 Manuel utilisateur

Toshiba

Toshiba Equium 7000S Manuel utilisateur

Toshiba

Toshiba Infinia 7230 Manuel utilisateur

Toshiba

Toshiba SATELLITE M40 Series Manuel utilisateur

Toshiba

Toshiba Portege 2000 Manuel utilisateur

Toshiba

Toshiba QOSMIO G20 Series Manuel utilisateur

Toshiba

Toshiba Infinia 7202 Manuel utilisateur

Manuels Ordinateur de bureau populaires d'autres marques

HP m9060n - Pavilion - Elite Fiche technique

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

HP Presario SV7000 - Desktop PC Manuel utilisateur

HP ProDesk 400 G5 Manuel

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur
