Toshiba 2000 Manuel utilisateur

6F8C1147

  

     

Important Information

No patent liability is assumed by TOSHIBA Corporation with respect to use of information, illustrations,

circuits, equipment or examples of application in this publication.

TOSHIBA Corporation reserves the right to make changes and improvements to this publication and/or

related products at any time without notice. No obligation shall be incurred other than as noted in this

publication.

This publication is copyrighted and contains proprietary material. No part of this book may be reproduced,

stored in a retrieval system, or transmitted, in any form or by any means — electrical, mechanical,

photocopying, recording, or otherwise — without obtaining prior written permission from TOSHIBA

Corporation.

PROSEC, TOSLINE and TOSDIC are trademarks or registered trademarks of TOSHIBA Corporation.

IBM is a registered trademark of International Business Machines Corporation.

Microsoft, MS-DOS, Windows and Windows NT are registered trademarks of Microsoft Corporation in the

U.S.A. and other countries.

DeviceNet is a trademark of the Open DeviceNet Vender Association, Inc.

6F8C1147 i

Safety Precautions

This manual contains important information for the operator to operate this product safely and correctly

and avoid bodily injury and property damage.

Grasp the meanings of the following marks and their descriptions before reading this manual.

Hazard Classifications

WARNING Indicates a potentially hazardous situation which, if not avoided, could result in

serious injury or death.

CA CAUTION Indicates a potentially hazardous situation which, if not avoided, can result in

minor or moderate injury, or property damage. It can also be used to alert

against unsafe practices.

(Note) 1. Serious injury means loss of sight, injury, burns (high temperature, low temperature),

electrical shock, fracture, or intoxication which leaves aftereffects or requires hospitalization

or need to go the hospital for a long time.

2. Injury means hurt, burn, or electric shock which does not require hospitalization or going to

the hospital for a long time.

3. Property damage means extended breakdown of assets and materials.

Notation of Markings

Indicates a "may not" mark.

The concrete forbiddance is indicated with a pictograph or wording.

Indicate a mandatory action that you should never fail to do.

The concrete content is indicated inside or near the circle with a pictograph

or wording.

Indicates a caution.

The concrete content is indicated inside or near the triangle.

(Note) The descriptions of forbiddance, mandatory, and caution marks are subject to change,

depending on the labels on the main unit.

ii model 2000 PROFIBUS Module User’s Manual for S2T/S2E

Markings used on the model 2000 and in this Manual

Make sure warning markings are attached on the model 2000.

If any of them are missing or the wording is illegible, contact Toshiba’s Service Department

6F8C1147 iii

2. Precautions on Installation

WARNING

CAUTION

Operation without grounding may cause

accidental fire or shock.

Mandatory

Avoid the following locations when installing or

storaging this module.

• Locations where there is dust, salinity or ion

particles

• Locations where there are corrosive gases

(SO2, H2s) or flammable gases

• Locations where vibration or shock occurs

beyond the allowance

• Locations where there is condensation due

to sharp temperature variations

• Locations where the ambient temperature

exceeds the allowance range.

Please perform compulsive air-cooling in the

location where the ambient temperature

exceeds 45°C.

• Locations where the relative humidity

exceeds the allowance range

• Locations where this module is exposed to

direct sunlight

• Locations where strong electric radiation or

magnetic field is generated

Mandatory

Install this module at a place where

maintenance and inspection are easy to do.

Otherwise, recovery from failure may take

much more time, leading to a serious

accidents.

Mandatory

Improper the installation or wiring of the

system can cause not only insufficient

performance but also malfunction and failure

of this module.

Installation in an unspecified direction or

improper installation can cause fall-off, fire,

interference, or malfunction of this module.

Mandatory

Do not cover the hole of this module, and the

ventilator/air inlet of the system.

Otherwise, overheating, etc. can cause fire or

malfunction.

Forbidden

Avoid entering wire scraps or other foreign

debris into this module, and related

equipment. Otherwise, it can cause fire, failure

or malfunction.

Mandatory

iv model 2000 PROFIBUS Module User’s Manual for S2T/S2E

3. Precautions on Wiring

WARNING

CAUTION

Be sure to turn off power before wiring.

Otherwise, it can cause electric shock or

malfunction of this module.

Mandatory

It is assumed that the users have general

knowledge of industrial electrical control

systems.

Mandatory

6F8C1147 v

4. Precautions for Operation

WARNING

CAUTION

Configure emergency stop interlocking circuit

outside the model 2000. Otherwise, failure

and malfunction of the model 2000 can cause

human injury, machine damage or serious

accidents.

Mandatory

This module is dedicated to the model 2000.

Mount them on the bases of the model 2000.

Do not use them by themselves for other

purposes.

Otherwise, it can cause electrical shock or

injury or malfunction.

Forbidden

When you attempt to perform program

change, forced output, RUN/HALT controls,

etc during operation, carefully check for

safety.

Improper operation or negligence in checking

safety conditions can cause machine damage

or serious accidents.

Mandatory

Mount the modules on the base securely until

they click, and fix them on the base with

screws.

Insufficient installation can cause failure or

malfunction.

Mandatory

Set the operating switches of this module

according to this manual.

Improper setting can cause failure or

malufunction.

Mandatory

Sample programs and circuits described in

this manual are provided for explaining the

operations and applications of the S2.

You should test completely before using

them as a part of your application system.

Mandatory

vi model 2000 PROFIBUS Module User’s Manual for S2T/S2E

5. Safety Precautions on Maintenance and Inspection

WARNING

Configure the external circuit to turn on power

according to the following sequence.

Turn on the power of model 2000

→Turn on the power for the I/O module and

external load power supplies

Otherwise, it can cause machine damage,

malfunction or accidents.

Turn off power immediately if this module or

related equipment emitting smoke or odor.

Operation under such situation can cause fire

or electrical shock. Also unauhorized repairing

will cause fire or serious accidents. Do not

attempt to repair. Contact Toshiba for

repairing.

Mandatory Forbidden

Turn off power when removing any units,

modules, terminal blocks or wired cables after

installing.

Otherwise it can cause failure, malfunction or

electrical shock.

Do not disassemble or modify this module and

related equipment in hardware nor software.

Otherwise it can cause failure, malfunction,

electrical shock or injury.

ForbiddenMandatory

6F8C1147 vii

CAUTION

Be careful not to hit or fall off this module by

accident.

Excess shock can cause failure.

Forbidden

Place this modules removed from the unit on a

conductive mat or conductive bag (containing

a spare board, etc.) on an grounded desk.

Otherwise, static electricity can damage

components of the module.

Mandatory

Touch a grounded metal part to discharge the

static electricity on your body before touching

this module.

Otherwise, charged static electricity on your

body can cause malfunction or failure.

Mandatory

Use soft cloth to clean this module.

Use water-dipped and squeezed cloth to clean

it if dirty.

Leaving this module dirty can cause mistaking

or malfunction.

Mandatory

Do not apply benzene and thinner when

cleaning this module.

Otherwise, it can cause deformity or

descoloration the panel or case of this

module.

Forbidden

viii model 2000 PROFIBUS Module User’s Manual for S2T/S2E

6. Safety Precautions in Daily Operation

WARNING

CAUTION

Apply power of the specified ratings (voltage

fluctuation range, frequency, output rating,

etc.) described in this manual.

Otherwise, it can cause malfunction,

machine damage or fire due to overheat.

Mandatory

Turn off power immediately if the ambient

temperature or internal temperature exceeds

beyond normal range or if failure is occurred in

this module.

Contact Toshiba for repairing.

Operation under such situation can cause fire

or electrical shock.

Check the vent of this module periodically. If

vent is closed, it can cause raise of

temperature.

Mandatory

Do not touch any components, terminals,

connectors or printed circuit boards in the

module.

Otherwise, it can cause the IC or LSI or the

like to be broken by static electricity, resulting

in failure or malfunction.

Also, the edge of components can cause

injury.

Forbidden

Do not forcibly bend or pull or distort the

power cord and other cables. Otherwise, they

can be cut off or cause overheat.

Forbidden

Do not disassemble or modify this module and

related equipment.

Otherwise, it can cause malfunction or failure.

Forbidden

Do not enter wire scraps or other foreign

debris into this module and related

equipment.

Also, do not insert metal parts into them.

They can cause fire or accidents.

Forbidden
