Quick Reference Guide

SMMS-e / SHRM-e

TC-QRG-01

DISCLAIMER

Carrier Confidential and Proprietary Information– Not for Further Distribution

This Quick Reference is meant to be assist with

troubleshooting and is not a substitute for Toshiba

Carrier Engineering Manuals, Training Documents, white

papers or industry best practices.

Always follow prescribed safety practices and local codes

when installing or servicing Toshiba Carrier VRF

equipment.

For further guidance, contact your regional or national

Technical Support Manager.

Please Note:

TABLE OF CONTENTS

DN Codes

Error Codes

Service Functions

Board Replacement

Compressor Backup

Rotary Switches

Dip Switches

Thermistor Locations

Monitor Function Codes

Carrier Confidential and Proprietary Information– Not for Further Distribution

DN CODES

Carrier Confidential and Proprietary Information– Not for Further Distribution

How To Access The

RBC-AMS54E-UL

And Set The Proper DN Codes

Push the button to display the

menu screen.

Push and hold the button and

the button at the same time to

display the “Field Setting Menu”.

•Push and hold the buttons for 4 more

seconds.

Push the button and return.

DN CODE SELECTION

Carrier Confidential and Proprietary Information– Not for Further Distribution

Carry out the setting operation while the indoor unit is stopped.

(Turn off the air conditioning unit before starting the setting operation.)

DN CODE SELECTION

Push the button to select

“7. DN setting” on the “Field setting menu”

screen, then push the

button.

•The fan and louver of the indoor unit operate.

When the group control is used, the fan and

louver of the selected indoor unit operate.

•Move the cursor to select “Code(DN)” with the

button, then set

“Code(DN)” with the

button.

Carrier Confidential and Proprietary Information– Not for Further Distribution

DN CODE SELECTION

Move the cursor to select “Data” with the

button, then set “Data”

with the button.

Carrier Confidential and Proprietary Information– Not for Further Distribution

DN CODE SELECTION

Push the button to

finish the setting operation. appears

on the screen for a while, then the screen returns

to the “Field setting menu” screen.

•Pushing the button

displays the unit selection screen when the

group control is used. Push button

on the unit selection screen to finish the setting

operation. appears on the screen

for a while, then the screen returns to the

“Field setting menu” screen.

Carrier Confidential and Proprietary Information– Not for Further Distribution

DN Item Description At Shipment

01 Filter Display Delay Timer

0000: None 0001: 150H

According to Type

0002:2500H 0003: 5000H

0004:10000H

02 Dirty Filter State 0000: Standard 0000: Standard

0001:High Degree of Dirt

Central Control Address

(Shown as Group # on

Central Control)

0000: No.1 Unit to 0064: No.64 Unit 0099: Unfixed

0099: Unfixed

04 Specific Indoor Unit

Priority 0000:No

Priority 0001: Priority

0002:+2*C (3.6*F)

( Floor Type 0000: 0*C )

05 Fan Control Heating 0001: Default 0009: Fan Off Thermo Off 0001:

* Must have wired remote Change DN-32 to 0001 before use of DN-05

06 Heating SuctionTemp Shift

0000: No Shift 0001: +1*C (+1.8*F)

0002: +2*C (3.6*F)0002: + 2*C (+3.6F) to 0010: +10*C (+18*F)

( Up to +6 Recommended)

OC Preparing Indication

Selection 0000: Preparing indicated 0001: No Indication 0000: Preparing indicated

0D Existence of AUTO Mode

0000: Provided

0001: Not Provided

0001: Not Provided (Automatic selection from connected outdoor unit)

0E FS Box 0000: Only 1 indoor unit on FS 0001: More than 1 indoor unit 0000: Standard

0F Cooling Only 0000: Heat Pump 0000: Heat Pump

0001: Cooling Only (No Display of (AUTO) (HEAT) )

10 Unit Type

0001: 4-Way Air Discharge Cassette 0004: Standard Ducted

Depending on Model

0005: Slim Duct 0006: High Static Ducted

0007: Under Ceiling 0008: High Wall

0014: Compact 4 Way

11 Indoor Unit Capacity 0000: Unfixed 0001 to 0034 According to Capacity

See Page 50 SHRM Quick Reference

12 Line Address 0000: No.1 Unit to 0030: No. 30 Unit 0099: Unfixed

13 Indoor Unit Address 0001: No.1 Unit to 0064: No.64 Unit 0099: Unfixed

14 Group Address 0000: Individual 0001: Header in Group 0099: Unfixed

0002: Follower in Group

Louver Type

(Air direction adjustment)

0000: No louver 0001: Swing only

According to Type

0002: (1-Way Air discharge Cassette type, Under Ceiling type)

0003: (2-Way Air discharge Cassette type)

0004: (4-Way Air discharge Cassette type)

Temp Range C/H 0000: 0 degree to 0010: 10 degree 0003: 3 Degree

(Dead Band Heat

Cool/Cool Heat) (Cool / Heat are reversed with +/- (data value) / 2 against the set temperature)

Auto Switch Control Point ( Ts +/- 1.5 )

DN CODES

Carrier Confidential and Proprietary Information– Not for Further Distribution

DN Item Description At Shipment

Selection of

option/error input

(CN70)

0000: Filter Input 0001: Alarm Input (Air washer, etc.) 0002: None

0002: None

2b Thermo Output 0000: Indoor thermostat on 0000: Thermo on

SW (T10 3 ) 0001: ON receiving output of outdoor compressor

2E HA Terminal (CN61)

select

0000: Usual 0001: Leaving -ON prevention control 0000: Usual (HA terminal)

0002: Fire alarm input

31 Venting fan control 0000: Unavailable 0001: Available 0000: Unavailable

32 TA sensor location 0000: Body TA sensor 0001: Remote controller sensor 0000: Body TA sensor

33 Temperature unit select 0000: *C 0001: *F(at factory shipment) 0001: *F

36 Room temp on display 0000: set point 0001: shows room temp 0

40 Humidifier Control Drain pump control 0003: Humidifier on Drain Off 0003:

Self Clean Operation

Time

(4 way Cassette Only)

0000: None 0000: .5h to .012: 0h

0002: 1 hour

Set when compressor-ON time is 10 to 60 minutes

When ON time is 60 minutes or more,

the double of this operation time setting is set.

Selection of louver

horizontal discharge

position

(4-Way Air Discharge

Type Only)

0000: Smudging less setting

0000: Smudging-less

setting

0002: Cold draft preventing setting

C2 Current Demand X% to

outdoor unit 0050: 50% 0100: 100% 0075: 75%

Setting of self-clean

operation forced stop

(4-Way cassette type

only)

0000: No

0000: None

Clean operation is performed in case of stop by HA input

HA operation output OFF during clean operation in case of stop by remote controller

0001: YES

Clean operation is not performed in case of stop bt HA input

HA operation output ON during clean operation in case of stop by remote controller

Clean operation stop

function when [ON/OFF]

operation is prohibited.

(4-Way cassette type

only)

The air conditioner stops (including fire alarm such as remote monitor system) while

setup of [ON/OFF] operation prohibited (Central 1,2) is performed from central

controller side.

0000: Valid

0000: Valid (clean operation)

0001: Invalid (no clean operation)

CE Domestic/Overseas 0000: Domestic 0001: Overseas 0000:

DN CODES

Carrier Confidential and Proprietary Information– Not for Further Distribution
