Operator’s Manual

IMPORTANT: Read this manual carefully. It contains information about your

safety and the safety of others. Also become familiar with the controls and

their proper use before you operate the product.

FORM NO. 3321-838

Wheel Horse

265H

Lawn and Garden

Tractor

Model No. 72048 – 9900001 & Up

The Toro Company – 1998

Introduction

Thank you for purchasing a Toro product.

All of us at Toro want you to be completely satisfied

with your new product, so feel free to contact your

local Authorized Service Dealer for help with service,

genuine replacement parts, or other information you

may require.

Whenever you contact your Authorized Service

Dealer or the factory, always know the model and

serial numbers of your product. These numbers will

help the Service Dealer or Service Representative

provide exact information about your specific

product. You will find the model and serial number

plate located in a unique place on the product as

shown below.

1. Model and Serial Number Plate

For your convenience, write the product model and

serial numbers in the space below.

Model No:

Serial No.

Read this manual carefully to learn how to operate

and maintain your product correctly. Reading this

manual will help you and others avoid personal injury

and damage to the product. Although we design,

produce and market safe, state-of-the-art products,

you are responsible for using the product properly

and safely. You are also responsible for training

persons, who you allow to use the product, about safe

operation.

The warning system in this manual identifies

potential hazards and has special safety messages that

help you and others avoid personal injury, even death.

DANGER, WARNING and CAUTION are signal

words used to identify the level of hazard. However,

regardless of the hazard, be extremely careful.

DANGER signals an extreme hazard that will cause

serious injury or death if the recommended

precautions are not followed.

WARNING signals a hazard that may cause serious

injury or death if the recommended precautions are

not followed.

CAUTION signals a hazard that may cause minor or

moderate injury if the recommended precautions are

not followed.

Two other words are also used to highlight

information. “Important” calls attention to special

mechanical information and “Note” emphasizes

general information worthy of special attention.

The left and right side of the machine is determined

by sitting on the seat in the normal operator’s

position.

The engine exhaust from this product

contains chemicals known to the State of

California to cause cancer, birth defects,

or other reproductive harm.

IMPORTANT: The engine in this product is

not equipped with a spark arrester muffler.

It is a violation of California Public Resource

Code Section 4442 to use or operate this

engine on any forest–covered, brush–covered

or grass–covered land as defined in CPRC

4126. Other states or federal areas may have

similar laws.

Contents

Page

Safety 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Safe Operating Practices 2. . . . . . . . . . . . . .

Slope Chart 5. . . . . . . . . . . . . . . . . . . . . . . . .

Safety and Instruction Decals 7. . . . . . . . . .

Gasoline and Oil 8. . . . . . . . . . . . . . . . . . . . . . . .

Recommended Gasoline 8. . . . . . . . . . . . . .

Stabilizer/Conditioner 9. . . . . . . . . . . . . . . .

Filling the Fuel Tank 9. . . . . . . . . . . . . . . . .

Check Engine Oil Level 9. . . . . . . . . . . . . . .

Operation 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Think Safety First 10. . . . . . . . . . . . . . . . . . .

Controls 10. . . . . . . . . . . . . . . . . . . . . . . . . . .

Key Choice Switch 10. . . . . . . . . . . . . . . . . . .

Parking Brake 10. . . . . . . . . . . . . . . . . . . . . . .

Starting and Stopping the Engine 11. . . . . . .

Operating the Power Take Off (PTO) 12. . . .

The Safety Interlock System 13. . . . . . . . . . .

Operating–in–Reverse 13. . . . . . . . . . . . . . . .

Indicator Control Module 15. . . . . . . . . . . . .

Driving Forward or Backward 16. . . . . . . . . .

Stopping the Machine 16. . . . . . . . . . . . . . . .

Attachment Lift Lever 17. . . . . . . . . . . . . . . .

Adjusting Dial-A-Height 17. . . . . . . . . . . . . .

Positioning the Seat 18. . . . . . . . . . . . . . . . . .

Page

Headlights 18. . . . . . . . . . . . . . . . . . . . . . . . .

Positioning the Tilt Steering Wheel 18. . . . . .

Using the Cruise Control 19. . . . . . . . . . . . . .

Pushing the Machine by Hand 19. . . . . . . . . .

Maintenance 20. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Service Interval Chart 20. . . . . . . . . . . . . . . .

Air Cleaner 21. . . . . . . . . . . . . . . . . . . . . . . . .

Engine Oil 23. . . . . . . . . . . . . . . . . . . . . . . . .

Spark Plug 25. . . . . . . . . . . . . . . . . . . . . . . . .

Greasing and Lubrication 26. . . . . . . . . . . . . .

Tire Pressure 26. . . . . . . . . . . . . . . . . . . . . . . .

Brake 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Fuel Tank 28. . . . . . . . . . . . . . . . . . . . . . . . . .

Fuel Filter 29. . . . . . . . . . . . . . . . . . . . . . . . . .

Front Wheel Toe-In 30. . . . . . . . . . . . . . . . . .

Transaxle Fluid 31. . . . . . . . . . . . . . . . . . . . . .

Fuse 31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Headlights 32. . . . . . . . . . . . . . . . . . . . . . . . .

Battery 33. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Wiring Diagram 36. . . . . . . . . . . . . . . . . . . . .

Cleaning and Storage 37. . . . . . . . . . . . . . . . .

Troubleshooting 38. . . . . . . . . . . . . . . . . . . . . . . . .

Warranty Back Cover. . . . . . . . . . . . . . . . . . . . . . . . . .

 !  % ! # ! !#    "

    $ "  "" &  

"   !! "  #"  !! !&!"!

"  % "&

 "!  % ! # %" &#  #" # "!

 % ! #      

"& "! &     " # " 

#"#  

Safety

This machine meets or exceeds the B71.1–1996

specifications of the American National Standards

Institute, in effect at the time of production.

However, improper use or maintenance by the

operator or owner can result in injury. To reduce

the potential for injury, comply with these safety

instructions and always pay attention to the safety

alert symbol, which means CAUTION,

WARNING, or DANGER—“personal safety

instruction.” Failure to comply with the

instruction may result in personal injury or death.

Safe Operating Practices

This product is capable of amputating hands and feet

and throwing objects. Always follow all safety

instructions to avoid serious injury or death.

POTENTIAL HAZARD

•Engine exhaust contains carbon monoxide,

which is an odorless, deadly poison.

WHAT CAN HAPPEN

•Carbon monoxide can kill you and is also

known to the State of California to cause

birth defects.

HOW TO AVOID THE HAZARD

•Do not run engine indoors or in an enclosed

area.

General Operation

1. Read, understand, and follow all instructions in

the operator’s manual and on the machine before

starting.

2. Allow only responsible adults who are familiar

with the instructions to operate the machine.

3. Clear the area of objects such as rocks, toys,

wire, etc., which could be picked up and thrown

by the blade.

4. Be sure the area is clear of other people before

mowing. Stop the machine if anyone enters the

area.

5. Never carry passengers.

6. Do not mow in reverse unless absolutely

necessary. Always look down and behind before

and while backing.

7. Be aware of the mower discharge direction and

do not point it at anyone. Do not operate the

mower without either the entire grass catcher or

the guard in place.

8. Slow down before turning. Sharp turns on any

terrain may cause loss of control.

9. Never leave a running machine unattended.

Always turn off blades, set parking brake, stop

engine, and remove the ignition and “Key

Choice” keys before dismounting.

10. Turn off blades when not mowing.

11. Keep hands, feet, hair and loose clothing away

from attachment discharge area, underside of

mower and any moving parts while engine is

running.

12. Stop the engine before removing the grass

catcher or unclogging the chute.

13. Mow only in daylight or good artificial light.

14. Do not operate the machine while under the

influence of alcohol or drugs.

15. Watch for traffic when operating near or crossing

roadways.

Safety

16. Use extra care when loading or unloading the

machine onto a trailer or truck.

17. Do not touch equipment or attachment parts

which may be hot from operation. Allow to cool

before attempting to maintain, adjust or service.

Slope Operation

Slopes are a major factor related to loss-of-control

and tip-over accidents, which can result in severe

injury or death. All slopes require extra caution. If

you cannot back up the slope or if you feel uneasy on

it, do not mow it.

•Mow up and down slopes greater than 5°, not

across.

•Mow downhill only on slopes above 10°, never

mow uphill. If a steep slope must be ascended,

back up the hill, and drive forward down the hill,

keeping the machine in gear.

•Remove obstacles such as rocks, tree limbs, etc.

from the mowing area. Watch for holes, ruts or

bumps, as uneven terrain could overturn the

machine. Tall grass can hide obstacles.

•Use slow speed. Choose a low gear so that you

will not have to stop or shift while on the slope.

•Follow the manufacturer’s recommendations for

wheel weight or counterweights to improve

stability.

•Use extra care with grass catchers or other

attachments. These can change the stability of

the machine.

•Keep all movement on slopes slow and gradual.

Do not make sudden changes in speed or

direction.

•Avoid starting or stopping on a slope. If tires

lose traction, disengage the blades and proceed

slowly straight down the slope.

DO NOT

•Do not operate machine on hillsides or slopes

exceeding 15°.

•Avoid turning on slopes. If you must turn, turn

slowly and gradually downhill, if possible.

•Do not mow near drop-offs, ditches, or

embankments. The machine could suddenly turn

over if a wheel goes over the edge of a cliff or

ditch, or if an edge caves in.

•Do not mow on wet grass. Reduced traction

could cause sliding.

•Do not try to stabilize the machine by putting

your foot on the ground.

•Do not use a grass catcher on steep slopes.

Heavy grass bags could cause loss of control or

overturn the machine.

Safety

Children

Tragic accidents can occur if the operator is not alert

to the presence of children. Children are often

attracted to the machine and the mowing activity.

Never assume that children will remain where you

last saw them. The following requirements must be

followed to prevent injury to children.

1. Keep children out of the mowing area and under

the watchful care of another responsible adult.

2. Be alert and turn the machine off if children

enter the area.

3. Before and while backing, look behind and down

for small children.

4. Never carry children. They may fall off and be

seriously injured or interfere with safe machine

operation.

5. Never allow children to operate the machine.

6. Use extra care when approaching blind corners,

shrubs, trees, the end of a fence or other objects

that may obscure vision.

Service

1. Stop the engine, disconnect spark plug wire(s)

and remove key before performing any service,

repairs, maintenance or adjustments.

2. Use extra care when handling gasoline and other

fuels. They are flammable and vapors are

explosive.

A. Use only an approved container.

B. Never remove the gas cap or add fuel when

the engine is running. Allow the engine to

cool before refueling. Do not smoke.

C. Never refuel the machine indoors.

D. Never store the machine or fuel container

inside where there is an open flame, such as

near a water heater or furnace.

3. Never run a machine inside a closed area.

4. Keep nuts and bolts tight, especially the blade

attachment bolts. Keep equipment in good

condition.

5. Never tamper with safety devices. Check safety

systems for proper operation before each use.

6. Keep the machine free of grass, leaves, or other

debris build-up. Clean up oil or fuel spillage.

Allow the machine to cool before storing.

7. Stop and inspect the equipment if you strike an

object. Repair, if necessary, before restarting.

8. Grass catcher components are subject to wear,

damage and deterioration, which could expose

moving parts or allow objects to be thrown.

Frequently check components and replace with

manufacturer’s recommended parts, when

necessary.

9. Mower blades are sharp and can cut. Wrap the

blade(s) or wear gloves, and use extra caution

when servicing them.

10. Use only genuine replacement parts to ensure

that original standards are maintained.

11. Check brake operation frequently. Adjust and

service as required.

12. Battery acid is poisonous and can cause burns.

Avoid contact with skin, eyes and clothing.

Protect your face, eyes and clothing when

working with a battery.

13. Battery gases can explode. Keep cigarettes,

sparks and flames away from battery.

Safety

Slope Chart

Read all safety instructions on pages 2–4.

Safety

Safety and Instruction Decals

Safety decals and instructions are easily visible to the operator and are located near

any area of potential danger. Replace any decal that is damaged or lost.

ON STEERING TOWER

(Part No. 93–0302)

ON DASH

LEFT SIDE

(Part No. 92–6720)

ON DASH

RIGHT SIDE

(Part No. 92–6721)

ON FRAME

RIGHT REAR

(Part No. 92–6726)

ON FRAME

CENTER REAR

(Part No. 92–6727)

ON LIFT LEVER

(Part No. 112168)

ON DIAL-A-HEIGHT KNOB

(Part No. 78–9740)

ON FRAME STEP

(Part No. 92–6725)

ON FRAME STEP

(Part No. 92–8946)

DASH INDICATOR PANEL

(Part No. 99-8036)

ON STEERING TOWER

(Part No. 83–6620)

ON SEAT BRACKET

(Part No. 99-2985) ON SEAT BRACKET

(Part No. 99-5339A)

Gasoline and Oil

Recommended Gasoline

Use UNLEADED Regular Gasoline suitable for

automotive use (85 pump octane minimum). Leaded

regular gasoline may be used if unleaded regular is

not available.

IMPORTANT: Never use methanol, gasoline

containing methanol, or gasohol containing

more than 10% ethanol because the fuel

system could be damaged. Do not mix oil with

gasoline.

POTENTIAL HAZARD

•In certain conditions gasoline is extremely

flammable and highly explosive.

WHAT CAN HAPPEN

•A fire or explosion from gasoline can burn

you, others, and cause property damage.

HOW TO AVOID THE HAZARD

•Use a funnel and fill the fuel tank outdoors,

in an open area, when the engine is cold.

Wipe up any gasoline that spills.

•Do not fill the fuel tank completely full.

Add gasoline to the fuel tank until the level

is 1/4” to 1/2” (6 mm to 13 mm) below the

bottom of the filler neck. This empty space

in the tank allows gasoline to expand.

•Never smoke when handling gasoline, and

stay away from an open flame or where

gasoline fumes may be ignited by a spark.

•Store gasoline in an approved container

and keep it out of the reach of children.

Never buy more than a 30-day supply of

gasoline.

POTENTIAL HAZARD

•In certain conditions gasoline is extremely

flammable and highly explosive.

WHAT CAN HAPPEN

•A fire or explosion from gasoline can burn

you, others, and cause property damage.

HOW TO AVOID THE HAZARD

•Always place gasoline containers on the

ground away from your vehicle before

filling.

•Do not fill gasoline containers inside a

vehicle or on a truck or trailer bed because

interior carpets or plastic truck bed liners

may insulate the container and slow the

loss of any static charge.

•When practical, remove gas–powered

equipment from the truck or trailer and

refuel the equipment with its wheels on the

ground.

•If this is not possible, then refuel such

equipment on a truck or trailer from a

portable container, rather than from a

gasoline dispenser nozzle.

•If a gasoline dispenser nozzle must be used,

keep the nozzle in contact with the rim of

the fuel tank or container opening at all

times until fueling is complete.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Toro Tondeuse à gazon

Toro

Toro 72027 Manuel utilisateur

Toro

Toro 04052 Greensmaster 1000 Manuel utilisateur

Toro

Toro 4573 Manuel utilisateur

Toro

Toro Groundsmaster 4000-D Manuel utilisateur

Toro

Toro 30799 Manuel utilisateur

Toro

Toro 26634 Manuel utilisateur

Toro

Toro Recycler 20379 Manuel utilisateur

Toro

Toro 414300000 Manuel utilisateur

Toro

Toro 74538 Manuel utilisateur

Toro

Toro Groundsmaster 4500-D Manuel utilisateur

Toro

Toro 2656 Manuel utilisateur

Toro

Toro Recycler 20012 Manuel utilisateur

Toro

Toro Recycler 20372 Manuel utilisateur

Toro

Toro STRIPE 21620 Manuel utilisateur

Toro

Toro Recycler 20372 Manuel utilisateur

Toro

Toro 13AX61RH848 Manuel utilisateur

Toro

Toro 74408TE Manuel utilisateur

Toro

Toro wheel horse 8-25 Manuel utilisateur

Toro

Toro TimeCutter 4225 Instructions d'installation et d'utilisation

Toro

Toro TurfMaster 22207 Manuel utilisateur

Toro

Toro 74161 Manuel utilisateur

Toro

Toro TimeMaster 21199HD Manuel utilisateur

Toro

Toro TimeCutter 74726 Manuel utilisateur

Toro

Toro LX427 Manuel utilisateur

Manuels Tondeuse à gazon populaires d'autres marques

RHINO

RHINO 1958 Manuel utilisateur

Wolf Garten

Wolf Garten Compact plus 40 B Manuel utilisateur

Cub Cadet

Cub Cadet LTX 1045 Manuel utilisateur

Craftsman

Craftsman 917.378461 Manuel utilisateur

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manuel utilisateur

Challenge

Challenge CH18V2 Instructions de fonctionnement

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manuel utilisateur

DEWEZE

DEWEZE ATM-725 Manuel d'utilisation

Weed Eater

Weed Eater 180083 Manuel utilisateur

Husqvarna

Husqvarna Poulan Pro PP185A42 Manuel utilisateur

Better Outdoor Products

Better Outdoor Products Quick Series Manuel utilisateur

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manuel d'utilisation

MTD

MTD 795, 792, 791, 790 Manuel utilisateur

Dennis

Dennis FT 610 Manuel utilisateur

AIRFORCE

AIRFORCE F-15 Gen 3 Manuel utilisateur

MTD

MTD 126-220-000 Manuel utilisateur

Stihl

Stihl RMA 443 PV Manuel utilisateur

Yard-Man

Yard-Man 3700-0 Manuel utilisateur
