Toro 07921 Manuel utilisateur

FormNo.3421-992RevB

2-Personor4-PersonCanopyKit

Workman®GTXUtilityVehicle

ModelNo.07921—SerialNo.400000000andUp

ModelNo.07922—SerialNo.400000000andUp

InstallationInstructions

Installation

PreparingtheMachine

NoPartsRequired

Procedure

1.Parkthemachineonalevelsurface.

2.Engagetheparkingbrake.

3.Shutofftheengineandremovethekey.

4.Disconnectthebattery;refertoyourOperator’s

Manual.

5.Raisethecargobedtothedumppositionand

secureitwiththeproprod.

DrillingtheHolesforthe

MountingTubes

NoPartsRequired

Procedure

1.UsingthedimensionsshowninFigure1,drill1

hole(5/16inch)intotheoutsideoftheoorplate

onbothsidesofthemachine.

g259750

Figure1

2.UsingthedimensionsshowninFigure2,drill1

hole(5/16inch)intotheoutsideofthefootboard

ontheleftandrightsidesofthemachine.

g259751

Figure2

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.Toro.com.OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved*3421-992*B

InstallingtheFront

MountingTubes

Partsneededforthisprocedure:

2Frontmountingtube

2Flange-headbolt(5/16x3inches)

2Spacer(5/8x1inch)

4Flangenut(5/16inch)

2Carriagebolt(5/16x2inches)

Procedure

Looselyinstallthe2frontmountingtubesusing2

ange-headbolts(5/16x3inches),2spacers(5/8x1

inch),4angenuts(5/16inch),and2carriagebolts

(5/16x2inches)asshowninFigure3.

g268153

Figure3

Leftsideshown

1.Flangenut(5/16inch)4.Carriagebolt(5/16x2

inches)

2.Frontmountingtube5.Spacer(5/8x1inch)

3.Flange-headbolt(5/16x3

inches)

RemovingtheSidePanels

NoPartsRequired

ForGasolineMachines

Important:Beforeperformingthisprocedure,

checkyourmachinetoseeiftheholesfor

installationalreadyexist.Ifnot,proceedwiththis

procedure.

Note:Retainallthehardwarethatyouremoveinthis

procedure.

1.Removetheange-headboltsecuringthefuel

tanktothetanktray(Figure4).

g033946

Figure4

1.Fueltank4.Fuelline

2.Screw5.Venthose

3.Hold-down6.Flange-headbolt

2.Removethescrewssecuringthehold-down

(Figure4).

3.Disconnecttheventtubeandfuellinefromthe

tank(Figure4).

Note:Preparetocaptureandcleanupanyfuel

thatspillswhenyoudisconnectthefuellinefrom

thetank.

DANGER

Incertainconditions,fuelisextremely

ammableandhighlyexplosive.Are

orexplosionfromfuelcanburnyouand

othersandcandamageproperty.

•Drainthefuelfromthefueltankwhen

theengineiscold.Dothisoutdoors

andinanopenarea.Wipeupanyfuel

thatspills.

•Neversmokewhenhandlingfuel,

andstayawayfromanopenameor

whereasparkmayignitefuelfumes.

4.Removethefueltankfromthetray.

5.Removethe2ange-headboltssecuringthe

tanktraytotheframe(Figure5).

g033947

Figure5

1.Tanktray2.Flange-headbolt

6.Removethe4screwssecuringtheleftside

paneltothelowerseatassembly(Figure6).

g034000

Figure6

1.Leftsidepanel2.Screw

7.Removethenegative(–)cablefromthebattery

andthenthepositive(+)cable(Figure7).

g034125

Figure7

1.Nut3.Bolt

2.Positivecable(+)4.Negativecable(–)

8.Removethe2ange-headboltssecuringthe

batterytraytotheframe(Figure8).

g033999

Figure8

1.Flange-headbolt3.Rightsidepanel

2.Self-tappingscrew

9.Removethe4screwssecuringtherightside

paneltothelowerseatassembly(Figure8).

ForElectricMachines

Important:Beforeperformingthisprocedure,

checkyourmachinetoseeiftheholesfor

installationalreadyexist.Ifnot,proceedwiththis

procedure.

Note:Retainallthehardwarethatyouremoveinthis

procedure.

1.Removethe4self-tappingscrewssecuringthe

rightsidepaneltothemachine(Figure9).

g035126

Figure9

1.Rightsidepanel2.Self-tappingscrew

2.Removethe2boltssecuringthechargerbracket

tothebatterytray(Figure10).

g035124

Figure10

1.Leftsidepanel3.Bolt

2.Self-tappingscrew

3.Removethe4self-tappingscrewssecuringthe

leftsidepaneltothemachine(Figure10).

DrillingtheSupportBracket

NoPartsRequired

Procedure

DrillthesupportbracketusingthemeasurementsshowninFigure11.

Whenyoudrillthehighestupperhole,ensurethatyoudrillallthewaythroughtheouterbracket,frametube,

andrewall.

CAUTION

Usecautionwhendrillingtheholesintotherightsideoftheframeonanelectricmachine.

Ifyoudrilltoofar,youcoulddamagethebatteriesorothercomponents.

g260925

Figure11

InstallingtheSidePanels

NoPartsRequired

ForGasolineMachines

1.Securetherightsidepanelusingthepreviously

removed4screws(Figure8).

2.Securethebatterytraytotheframeusingthe

previouslyremoved2ange-headbolts(Figure

8).

3.Securethebatterycablesusingthepreviously

removed2boltsand2nutsandconnectthe

batteryterminals(Figure7).

4.Securetheleftsidepanelusingthepreviously

removed4screws(Figure6).

5.Securethetanktraytotheframeusingthe

previouslyremoved2ange-headbolts(Figure

5).

6.Placethefueltankinthetanktray.

7.Connectthefuellineandventtubetothefuel

tank(Figure4).

8.Securethehold-downusingthepreviously

removedscrews(Figure4).

9.Securethefueltanktothetanktrayusingthe

previouslyremovedange-headbolt(Figure4).

10.Fillthefueltank;refertotheOperator’sManual.

ForElectricMachines

1.Securetheleftsidepanelusingthepreviously

removed4self-tappingscrews(Figure10).

2.Securethechargerbrackettothebatterytray

usingthepreviouslyremoved2bolts(Figure10).

3.Securetherightsidepanelusingthepreviously

removed4self-tappingscrews(Figure9).

InstallingtheRear

MountingTubesand

Tube-MountingBracket

Partsneededforthisprocedure:

2Rearmountingtube

1Tube-mountingbracket

2Flange-headbolt(5/16x3inches)

2Flangenut(5/16inch)

2Flange-headbolt(3/8x1-3/4inches)

2Flange-headbolt(3/8x3-1/2inches)

4Locknut(3/8inch)

1Trimseal

Procedure

1.Looselyinstallthe2rearmountingtubesusing

2ange-headbolts(3/8x3-1/2inches),2

ange-headbolts(3/8x1-3/4inches),and4

locknuts(3/8inch)asshowninFigure12.

g261071

Figure12

Leftsideshown

1.Rearmountingtube3.Flange-headbolt(3/8x

1-3/4inches)

2.Locknut(3/8inch)4.Flange-headbolt(3/8x

3-1/2inches)

2.Securethetube-mountingbrackettotherear

mountingtubesusing2ange-headbolts(5/16

x3inches)and2angenuts(5/16inch)as

showninFigure13.

3.Installthetrimsealontothetube-mounting

bracket(Figure13).

g259788

Figure13

1.Trimseal3.Flange-headbolt(5/16x3

inches)

2.Flangenut(5/16inch)4.Tube-mountingbracket

4.Tightenthefastenersinstalledinstep1.

Torquethe5/16-inchfastenersto20to25N∙m

(175to225in-lb).

Torquethe3/8-inchfastenersto37to45N∙m

(27to33ft-lb).

InstallingtheLongCanopySupportBrackets

Fora4-PersonCanopyOnly

Partsneededforthisprocedure:

2Longcanopysupportbracket

8Hex-washerheadbolt(5/16x3/4inch)

2Trimseal

Procedure

1.Securethe2longcanopysupportbracketstothefrontandrearmountingtubesusing8hex-washer

headbolts(5/16x3/4inch)asshowninFigure14.

2.Installthe2trimsealsontothe2longcanopysupportbrackets(Figure14).

g261122

Figure14

InstallingtheCanopy

Partsneededforthisprocedure:

1Canopy

4Flange-headbolt(1/4x1-3/4inches)

4Sealingwasher

4Locknut(1/4inch)

Procedure

Important:Ifyouareinstallingamirrorkit,installitbeforeinstallingthecanopy.

Securethecanopytothefrontandrearmountingtubesusing4ange-headbolts(1/4x1-3/4inches),4sealing

washers,and4locknuts(1/4inch)asshowninFigure15.

g259844

Figure15

2-personcanopyshown

1.Sealingwasher3.Canopy

2.Locknut(1/4inch)4.Flange-headbolt(1/4x1-3/4inches)

InstallingtheCanopySupportBracket

Partsneededforthisprocedure:

1Canopysupportbracket

2Flange-headbolt(1/4x2-1/4inches)

2Locknut(1/4inch)

2Sealingwasher

1Trimseal

2Spacer(1/4inch)

Procedure

1.Installthetrimsealontothetube-mountingbracket(Figure16).

g259845
