Toro 04266 Manuel utilisateur
FormNo.3427-206RevA
Out-FrontBrushKit
Greensmaster®800/1000/Flex™18/21/Flex™1800/2100/eFlex®
1800/2100Mower
ModelNo.04266
InstallationInstructions
Installation
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
DescriptionQty.Use
Leftbrushbracket1
Rightbrushbracket1
Flangeheadbolt(3/8x1inch)2
Bolt(M10x30mm)2
Leveladjustmentscrew2
Jamnut(5/16inch)2
Locknut(5/16inch)2
Brushspring2
Brushrod2
Bolt(M6x40mm)4
Spacer4
Locknut(M6)4
Mountthebrushbrackets(GreensmasterFlexmodels
only)
Leftbrushbracket1
Rightbrushbracket1
Bolts(fullythreaded,5/16x1-1/2inches)4
Locknut(5/16inch)4
Leveladjustmentscrew2
Jamnut(5/16inch)2
Locknut(5/16inch)2
Brushspring2
Brushrod2
Bolt(M6x40mm)4
Spacer4
Locknut(M6)4
Mountthebrushbrackets(Greensmaster800/1000/2000
modelsonly)
Brush1
Brushtab2
Bolt(M8x60mm)4
Washer4
Locknut(M8)4
Flange-headbolt(M6x20mm)4
Flangenut(M6)4
Mountthebrush.
©2018—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3427-206*A
Mountingthe
BrushBrackets
GreensmasterFlexModelsonly
1.Positionthemachineonalevelsurface,engage
theparkingbrake,removethekey(ifequipped),
disconnectthebattery,andshutoffthemachine.
2.Removetheboltandwashersecuringtheleft
endofthefrontframetothetabontopofthe
cuttingunit(Figure1).
g018505
Figure1
1.Bolt3.Frontframe
2.Washer
3.Mounttheleftbrushbrackettothefrontframe
andtabasfollows:
•OnFlex1800/2100models,securethe
brushbrackettothefrontframeandtabwith
aangeheadbolt(3/8x1inch)asshownin
Figure2.
•OnFlex18/21models,securethebrush
brackettothefrontframeandtabwithanew
bolt(M10x30mm)andthewasherthatwas
previouslyremoved(Figure2).
g018486
Figure2
1.Boltandwasher(Flex
18/21models)
4.Jamnut(5/16inch)
2.Flangeheadbolt(Flex
1800/2100models)
5.Brushbracket
3.Leveladjustmentscrew6.Locknut(5/16inch)
Note:Thebracketistobepositionedsothe
holeinthebottomistothefront.Thebracket
shouldtovertheendofthefrontframeandtab.
4.Looselymounttheleveladjustmentscrewtothe
brushbracketwithajamnut(5/16inch)anda
locknut(5/16inch)asshowninFigure2.
5.Mountabrushspringandbrushrodtothebrush
bracketwith(2)bolts(M6x40mm),spacers
andlocknuts(M6)asshowninFigure3.
Note:Ensurethatthebrushspringismounted
withthebumptotheoutside.Thebrushrod
shouldbecenteredinthebrushspringwhenitis
rotatedupward,intothestorageposition.
2
g017161
Figure3
1.Locknut(M6)4.Brushspring
2.Brushrod5.Bolt(M6x40mm)
3.Spacer
6.Repeatthisprocedureontheoppositesideof
themachine.
Note:Therewillbeleftoverlocknuts.
Mountingthe
BrushBrackets
Greensmaster800/1000/2000Models
only
1.Positionthemachineonalevelsurface,engage
theparkingbrake,removethekey(ifequipped)
andshutoffthemachine.
2.Removethe2boltsandwasherssecuringthe
grassbasketmountingrodtotheleftsideplate
(Figure4).Discardtheboltsbutretainthe
washers.
g017162
Figure4
1.Bolt3.Grassbasketmounting
rod
2.Washer
3.Securethegrassbasketmountingrodtotheleft
sideplatewith2new,fullythreadedbolts(5/16
x1-1/2inches)andthe2washersthatwere
previouslyremoved(Figure5).
4.Inserttheleftbrushbracketontotheboltand
secureitwith2locknuts(5/16inch)asshown
inFigure5.
g018504
Figure5
1.Leveladjustmentscrew3.Brushbracket
2.Jamnut4.Locknut(5/16inch)
Note:Thebracketistobepositionedsothat
theholeinthebottomistothefront.
3
5.Looselymounttheleveladjustmentscrewtothe
brushbracketwithajamnut(5/16inch)anda
locknut(5/16inch)asshowninFigure5.
6.Mountabrushspringandbrushrodtothebrush
bracketwith2bolts(M6x40mm),spacers,and
locknuts(M6)asshowninFigure6.
Note:Ensurethatthebrushspringismounted
withthebumptotheoutside.Thebrushrod
shouldbecenteredinthebrushspringwhenitis
rotatedupward,intothestorageposition.
g017164
Figure6
1.Locknut4.Brushspring
2.Brushrod5.Bolt
3.Spacer
7.Repeatthisprocedureontheoppositesideof
themachine.
MountingtheBrush
1.Ifthebrushisgoingtobeusedonan18inch
cuttingunit,measureandcut1-1/2inchesoff
eachendofthebrush.
2.Mountabrushtabtoeachendofthebrushwith
2bolts(M8x60mm),washers,andlocknuts
(M8).PositionthetabsasshowninFigure
7.Usetheouterholesforinstallationona21
inchcuttingunitandtheinnerholesfor18inch
cuttingunit.
Note:Thebrushbristlesarecutatanangle.
Mountthebrushsothelongerbristlesare
closesttothemachinewhenmowing.
3.Secureabrushrodmountingbrackettoeach
brushtabwith2angeheadbolts(M6x20mm)
andangenuts(M6)(Figure7).
g017165
Figure7
1.Brushweight(optional)6.Flangeheadbolt(M6x20
mm)
2.Flangenut(M6)7.Brush
3.Bolt(M8x60mm)8.Washer
4.Brushtab9.Locknut(M8)
5.Brushrodmounting
bracket
4.Adjusttheoperatingheightofthebrushand
levelitbylooseningthejamnuts,rotatingthe
adjustmentscrewstothedesiredpositionand
tighteningthejamnuts.
Note:Theendsofthebrushbristlesshouldbe
atonthegroundduringthemowingoperation.
Ifthebrushhopsduringoperation,rotatethe
brushsothatonlythefrontbristlestouchthe
surfaceandtherearbristlesarelessthan1/2
inchabovethesurface.
5.Rotatethebrushupwardandsecuretherods
intothebrushspringswhenthebrushisnot
required.
4
