FormNo.3397-489RevA

WiredControllerKit

ProForce®DebrisBlower

ModelNo.119-1100

InstallationInstructions

WARNING

CALIFORNIA

Proposition65Warning

ThisproductcontainsachemicalorchemicalsknowntotheStateofCaliforniato

causecancer,birthdefects,orreproductiveharm.

Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.

Safety

SafetyandInstructionalDecals

Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyareaofpotential

danger.Replaceanydecalthatisdamagedorlost.

119-1775

1.Rotatenozzleleft4.Continuous-variable

setting

2.Rotatenozzleright5.Fast

3.Slow

119-1776

1.Engine—Stop3.Engine—Start

2.Engine—Run

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.Toro.com.OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved*3397-489*A

DescriptionQty.Use

Wiredcontroller1Installthewiredcontroller—forDebrisBlowerswithserial

numbers290999999andearlier.

Wiredcontroller1

Wire-harnessadapter(usedonDebris

Blowerswithserialnumbers310000001to

311000001)

Installthewiredcontroller—forDebrisBlowerswithserial

numbers310000001to311000001.

Wiredcontroller1

Wire-harnessadapter(usedonDebris

Blowerswithserialnumbers312000001and

later)

Installthewiredcontroller—forDebrisBlowerswithserial

numbers31200000to31409999(ModelNo.44538,

44539,or44542).

Wiredcontroller1

Wire-harnessadapter(usedonDebris

Blowerswithserialnumbers315099999and

later)

Installthewiredcontroller—forDebrisBlowerswithserial

numbers31500000andlater(ModelNo.44552,44553,

or44554).

Important:Ensurethatyourefertothesetof

instructionsthatalignswiththeserialnumberofyour

DebrisBlower.Therearedifferentsetsofinstructions

dependingontheserialnumberofyourmachine.

InstallingtheWiredController

ForDebrisBlowerswithSerialNumbers

290999999andEarlier

1.Disconnectthebatterycablesfromthebattery.

Note:Disconnectthenegative-batterycablerst,and

thendisconnectthepositive-batterycable.

2.Disconnectthewire-harnessleadsfromthe

wireless-controlbase(Figure1).

Figure1

1.Wire-harnessleads2.Wireless-controlbase

3.Plugthewired-controller-harnessleadsintothe

wire-harnessleadspreviouslydisconnectedfromthe

wireless-controlbase(Figure2).

Figure2

1.Engine4.Wireless-controlbasewire

harness

2.Yellowwirefromthe

engine

5.Wireless-controlbase

3.Connectthese

wire-harnessleadstothe

wired-controllerharness.

6.Wiredcontroller

4.Plugtheremainingcontrollerwireintotheyellowwire

fromtheengine(Figure2).

5.Connectthepositive-batterycablerst,andthen

connectthenegative-batterycable.

InstallingtheWiredController

ForDebrisBlowerswithSerialNumbers

310000001to311000001

1.Disconnectthebatterycablesfromthebattery.

Note:Disconnectthenegative-batterycablerst,and

thendisconnectthepositive-batterycable.

2.Disconnectthewire-harnessleadsfromthe

wireless-controlbase(Figure1).

3.Plugtheappropriatewired-controllerharnessleadinto

theappropriatewire-harnessleadthatwaspreviously

disconnectedfromthewireless-controlbase(Figure

3andFigure4).

g018907

Figure3

1.Pinkwirefromtheadapter3.Wire-harnessleadtothe

wirecontroller

2.Wire-harnesslead

towireless-controller

harness

Figure4

1.Connectthiswire-harness

leadtothewired-controller

harness.

5.Wire-harnessadapter

2.Wireless-controlbasewire

harness

6.Wiredcontroller

3.Wireless-controlbase7.Yellowwirefromthe

wired-controllerharness

4.Connectthiswire-harness

leadtothewire-harness

adapter.

4.Plugtheappropriateleadfromtheharnessadapter

intotheremainingwireless-controlbasewire-harness

leadthatwaspreviouslydisconnectedfromthe

wireless-controlbase(Figure3).

5.Plugtheotherwired-controller-harnessleadintothe

appropriatewire-harness-adapterlead(Figure3and

Figure4).

6.Plugtheremainingcontrollerwireintothepinkwire

fromtheharnessadapter(Figure3andFigure4).

7.Connectthepositive-batterycablerst,andthen

connectthenegative-batterycable.

InstallingtheWiredController

ForDebrisBlowerswithSerialNumbers

31200000to315099999(ModelNo.

44538,44539,or44542)

1.Disconnectthebatterycablesfromthebattery.

Note:Disconnectthenegative-batterycablerst,and

thendisconnectthepositive-batterycable.

2.Disconnectthewireharnessfromthewireless-control

base(Figure5).

g018879

Figure5

1.Wireless-controlbase2.Wireharness

3.Plugthewireless-control-baseleadintotheharness

adapterthatwaspreviouslydisconnectedfromthe

wirelesscontrolbase(Figure6andFigure7).

g018908

Figure6

1.Harness-adapter

leadtothewireless

control-base-harnesslead

3.Harness-adapter

leadtothe

wired-controller-harness

lead

2.Harness-adapter

leadtothe

wired-controller-harness

lead

Figure7

1.Wire-harnessadapter5.Pinkwirelocatedbythe

hourmeter

2.Connectthiswire-harness

leadtothewire-harness

adapter

6.Wiredcontroller

3.Wirelesscontrol-base-wire

harness

7.Yellowwirefromthe

wired-controllerharness

4.Wireless-controlbase

4.Plugtheharness-adapterleadintothe

wired-controller-harnesslead(Figure6and

Figure7).

5.Plugtheyellowwirefromwiredcontrollerharnessinto

thepinkwirelocatedbythehourmeter(Figure6and

Figure7).

6.Connectthepositivebatterycablerstandthen

connectthenegativebatterycable.

InstallingtheWiredController

ForDebrisBlowerswithSerialNumbers

315099999andlater(ModelNo.44552,

44553,or44554)

1.Disconnectthebatterycablesfromthebatteryand

removethebattery.

Note:Disconnectthenegative-batterycablerst,and

thendisconnectthepositive-batterycable.

2.Disconnectthewire-harnessleadsfromtheTEC

controller(Figure8).

Figure8

1.TECcontroller2.Wire-harnessleads

3.DisconnectthewireharnessfromtheRF2CAN

(Figure9).

Note:Ifyouintendtoinstallthewirelesscontrols

againinthefuture,theRF2CANandtheTEC

controllershouldberemoved.

Figure9

1.RF2CAN

4.Disconnectthewireharnessfromthekeyswitch.

5.Removethekeyswitch(Figure10).

Figure10

1.Keyswitch

6.Attachthecapstothewireharnesswherethekey

switchandRF2CANwereremoved(Figure11).

Figure11

1.RF2CANcap2.Key-switchcap

7.Routethewireharness,soitcomesoutbetweenthe

frontplateandthebattery(Figure12).

Note:Donotroutethewireharnessoutofthefront

opening.

Figure12

1.Routethewireharnesshere.

8.Plugthewireless-control-baseleadintotheharness

adapterthatwaspreviouslydisconnectedfromthe

wireless-controlbase(Figure13andFigure14).

Note:Ensurethatyouconnecttheleadsintothe

properconnectorcolorandinternalnotches.

Figure13

1.Harness-adapter

leadtothewireless

TEC-controller-harness

lead

3.Harness-adapter

leadtothe

wired-controller-harness

lead

2.Harness-adapter

leadtothe

wired-controller-harness

lead

4.Harness-adapter

leadtothewireless

TEC-controller-harness

lead

Figure14

1.Wire-harnessadapter5.Yellowwirelocatedbythe

hourmeter

2.Connectthiswire-harness

leadtothewire-harness

adapter.

6.Plasticcover

3.Wireless

TEC-controller-wire

harness

7.Wiredcontroller

4.WirelessTECcontoller8.Yellowwirefromthe

wired-controllerharness

9.Plugtheharness-adapterleadintothe

wired-controller-harnesslead(Figure13and

Figure14).

10.Plugtheyellowwirefromwired-controllerharnessinto

theyellowwirelocatedbythehourmeter(Figure13

andFigure14).

Note:Youwillneedtocuttheplasticcoveroffthe

yellow-wireconnectorontheharness.

11.Installthebattery.

12.Connectthepositive-batterycablerst,andthen

connectthenegative-batterycable.

Operation

Controls

UsingtheNozzle-DirectionButton

Pressthebuttontorotatethenozzletothedesireddirection

(Figure15).

g018877

Figure15

1.Nozzle-directionbutton3.Keyswitch

2.Throttle/engine-speed

knob

UsingtheThrottle/Engine-SpeedKnob

RotatetheknobtoFASTtoincreasetheenginespeed,orto

SLOWtodecreasetheenginespeed(Figure15).

UsingtheKeySwitch

Thekeyswitch(whichisusedtostartandstoptheengine),

has3positions:OFF,RUN,andSTART.

RotatethekeyclockwisetotheSTARTpositiontoengage

thestartermotor.Releasethekeywhentheenginestarts.

ThekeywillautomaticallymovetotheONposition.Toshut

theengineoff,rotatethekeycounterclockwisetotheOFF

position(Figure15).
